飞机主起落架移动荷载作用下道基动力响应分析

凌道盛; 王云龙; 赵云; 黄博; 周燕国

doi:10.11779/CJGE201801005

飞机主起落架移动荷载作用下道基动力响应分析 English Version

凌道盛^1,2,
王云龙^1,2,
赵云^1,2,
黄博^1,2, ,,
周燕国^1,2

1.软弱土与环境土工教育部重点实验室（浙江大学）,浙江杭州 310058
2.浙江大学岩土工程研究所,浙江杭州 310058

基金项目: 国家重点基础研究发展计划（“ 973 计划”）项目（2014CB047005）

详细信息

作者简介:
凌道盛(1968-),男,教授,博士生导师,主要从事交通岩土工程、计算土力学等方面的教学和科研。E-mail：dsling@zju.edu.cn。

通讯作者:
黄博，E-mail：cehuangbo@zju.edu.cn

中图分类号: TU435
计量
- 文章访问数: 449
- HTML全文浏览量: 5
- PDF下载量: 412
出版历程
- 收稿日期: 2016-11-07
- 发布日期: 2018-01-24

Dynamic response of subgrade under moving loads of main landing gears

1.MOE Key Laboratory of Soft Soils and Geoenvironmental Engineering, Zhejiang University, Hangzhou 310058, China
2.Institute of Geotechnical Engineering, Zhejiang University, Hangzhou 310058, China

摘要

摘要: 飞机起降过程中主起落架移动荷载引起的跑道道基土体循环动应力是导致跑道沉降和差异沉降的主要原因。采用移动荷载作用下跑道动力响应半解析有限单元法,基于叠加原理分析了B747-400和A380-800客机主起落架轮组移动荷载作用下道基土体动应力响应规律。分析结果表明：在B747-400和A380-800客机主起落架移动荷载作用下,道基浅层土体竖向正应力沿横向呈倒锅底型分布,荷载影响深度可达13 m;主起落架机轮分布对浅层道基土体竖向正应力影响较大,对深层土体影响不大;飞机移动速度对浅层道基土体竖向正应力分布影响较小,但对深层土体影响较明显,当飞机滑行速度达到60~80 m/s时,荷载影响深度达静力分析时的1.5~1.7倍;采用柔性道面板时,浅层土体竖向正应力较刚性道面结构时增加约50%,荷载影响深度增加约10%。
- 主起落架 /
- 移动荷载 /
- 跑道道基 /
- 动力响应 /
- 荷载影响深度
Abstract: The cyclic dynamic stress of runway subgrade soil induced by the moving loads of the main landing gears in the process of taking off and landing is the main cause of the settlement and differential settlement of runway. Based on the superposition principle, the dynamic responses of the subgrade soil under the moving loads of the main landing gears B747-400 and A380-800 are analyzed by using the semi-analytical finite element method. The results show that under the the moving loads of main landing gears of B747-400 and A380-800, the vertical normal stress of subgrade of shallow soil is inverted as the pot type distribution, and the load influence depth can be up to 13 m. The distribution of the main loading gears has a greater influence on the vertical normal stress of shallow subgrade soil than the deep subgrade soil. The moving speed of aircrafts has an obvious effect on the distribution of the vertical normal stress of deep subgrade soil. Under the taking-off speed of 60 ~ 80 m/s, the load influence depth is 1.5 ~ 1.7 times than that of the static analysis. Compared with that of the rigid pavement, the vertical normal stress of shallow soil increases by about 50% and the load influence depth increases by about 10% for flexible panel.
- main landing gear /
- moving load /
- runway subgrade soil /
- dynamic response /
- load influence depth

HTML全文

参考文献(19)

[1]	张献民, 薛华鑫, 董倩, 等. 飞机跑道荷载响应深度变化规律[J]. 北京航空航天大学学报, 2014, 40(4): 427-432. (ZHANG Xian-min, XUE Hua-xin, DONG Qian, et al.Influencing depth under aircraft loads of runway[J]. Journal of Beijing University of Aeronautics and Astronautics, 2014, 40(4): 427-432. (in Chinese))
[2]	张献民, 董倩, 吕耀志. 飞机主起落架构型对道面力学响应的影响[J]. 西南交通大学学报, 2014,49(4): 675-681. (ZHANG Xian-min, DONG Qian, LÜ Yao-zhi.Mechanical responses of pavement under aircrafts with different main landing gears[J]. Journal of Southwest Jiaotong University, 2014, 49(4): 675-681. (in Chinese))
[3]	张献民, 刘小兰, 董倩. 大型飞机A380-800在既有跑道起降的适应性研究[J]. 北京航空航天大学学报, 2016, 42(9): 1812-1818. (ZHANG Xian-min, LIU Xiao-lan, DONG Qian.Study on the landing adaptability of A380-800 aircraft load based on the existingpavement[J]. Journal of Beijing University of Aeronautics and Astronautics, 2016, 42(9): 1812-1818. (in Chinese))
[4]	凌建明, 刘文, 赵鸿铎. 大型军用飞机多轮荷载作用下水泥混凝土道面的结构响应[J]. 土木工程学报, 2007, 40(4): 60-65. (LING Jian-ming, LIU Wen, ZHAO Hong-duo.Mechanical responses of rigid airport pavement to multiple-gear military aircraft loadings[J]. China Civil Engineering Journal, 2007, 40(4): 60-65. (in Chinese))
[5]	呙润华, 凌建明. 飞机荷载作用下道面地基附加应力特征[J]. 同济大学学报, 2001,29(3): 288-293. (GUO Run-hua, LING Jian-ming.Additional stresses of pavement subgrade resulted from aircraft loads[J]. Journal of Tongji University, 2001, 29(3): 288-293. (in Chinese))
[6]	蔡迎春, 郑元勋, 刘忠玉, 等. 飞机荷载作用下粉砂土路基动力响应研究[J]. 岩土力学, 2012, 33(9): 2863-2868. (CAI Ying-chun, ZHENG Yuan-xun, LIU Zhong-yu, et al.Study of dynamic response of silty sand subgrade loaded by airplane[J]. Rock and Soil Mechanics, 2012, 33(9): 2863-2868. (in Chinese))
[7]	MARSHALL K G, THOMPSON R.Assessing damage to airport pavement structuredue to complex gear loads[J]. Journal of Transportation Engineering, 2006, 132(11): 888-897.
[8]	凌道盛, 张凡, 赵云, 等. 飞机荷载作用下非均匀道基动力响应分析[J]. 土木工程学报, 2017(2): 97-109. (LING Dao-sheng, ZHANG Fan, ZHAO Yun, et al.Dynamic response in inhomogeneous subgrade subjected to moving aircraft load[J]. China Civil Engineering Journal, 2017(2): 97-109. (in Chinese))
[9]	HUANG Y H.Finite element analysis of slabs on elastic solid[J]. Journal of Transportation Engineering, 1974, 100(2): 403-416.
[10]	HAMMONS M I.Advanced pavement design:finite element modeling for rigid pavement joints report II: model development[R]. Washington DC: Federal Aviation Administration, US Department of Transportaion, 1998.
[11]	郑飞, 翁兴中. 飞机荷载下水泥混凝土道面板应力计算方法[J]. 交通运输工程学报, 2010, 10(4): 8-15. (ZHENG Fei, WENG Xing-zhong.Calculating methods of stress for cement concrete pavementslab under plane loads[J]. Journal of Traffic and Transportation Engineering, 2010, 10(4): 8-15. (in Chinese))
[12]	姚炳卿. 考虑接缝传荷能力的机场刚性道面板的有限元分析方法[J]. 土木工程学报, 1993, 26(3): 22-31. (YAO Bing-qing.Analysis of airport rigid pavement slab considering load transfer capacity of joint by finite element[J]. China Civil Engineering Journal, 1993, 26(3): 22-31. (in Chinese))
[13]	陈新法, 干钢. 飞机跑道动土压试验研究[J]. 工程力学, 1997, 14(增刊): 540-545. (CHEN Xin-fa, GAN Gang.Experimental study on earth pressure of aircraft runway[J]. Engineering Mechanics, 1997, 14(S0): 540-545. (in Chinese))
[14]	蔡袁强, 刘新峰, 郭林, 等. 飞机荷载作用下超载预压软土地基的长期沉降[J]. 浙江大学学报(工学版), 2013, 47(7): 1157-1163. (CAI Yuan-qiang, LIU Xin-feng, GUO Lin, et al.Long-term settlement of surcharge preloading foundation in soft clay area induced by aircraft loads[J]. Journal of Zhejiang University (Engineering Science), 2013, 47(7): 1157-1163. (in Chinese))
[15]	王广德, 韩黎明, 柴震林, 等. 飞机动荷载作用下场道地基沉降[J]. 地下空间与工程学报, 2013, 9(4): 939-945. (WANG Guang-de, HAN Li-ming, CHAI Zhen-lin, et al.The runway subgrade settlement induced by moving aircraft loading[J]. Chinese Journal of Underground Space and Engineering, 2013, 9(4): 939-945. (in Chinese))
[16]	边学成, 陈云敏. 列车移动荷载作用下分层地基响应特性[J]. 岩石力学与工程学报, 2007, 26(1): 182-189. (BIAN Xue-cheng, CHEN Yun-min.Characteristics of layered ground responses under train moving loads[J]. Chinese Journal of Rock Mechanics and Engineering, 2007, 26(1): 182-189. (in Chinese))
[17]	MH/T5004—2010民用机场水泥混凝土道面设计规范[S]. 2010. (MHT 5004—2010 Specifications for airport cement concrete pavement design[S]. 2010. (in Chinese))
[18]	赵成刚, 白冰. 土力学原理[M]. 北京: 清华大学出版社, 北京交通大学出版社, 2009. (ZHAO Cheng-gang, BAI Bing.Principles of soil mechanics[M]. Beijing: Tsinghua University Press, Beijing Jiaotong University Press, 2009. (in Chinese))
[19]	MH 5010—1999民用机场沥青混凝土道面设计规范[S]. 2000. (MHT 5010—2010 Specifications for asphalt concrete pavement design for civil airport[S]. 2000. (in Chinese))
