二层水平介质中震源的精确定位

张向东; 王帅; 赵彪; 贾宏宇

doi:10.11779/CJGE201406008

二层水平介质中震源的精确定位 English Version

1. 辽宁工程技术大学土木与交通学院,辽宁阜新 123000; 2. 中冶沈勘工程技术有限公司,辽宁沈阳 110016; 3. 阜新工大爆破工程有限责任公司,辽宁阜新 123000

基金项目: 国家自然科学基金委员会-神华集团有限公司煤炭联合基金项目（51174268）

详细信息

作者简介:
张向东(1962- ),男,教授,博士生导师,主要从事岩土工程等方面的教学和科研工作。E-mail: jwd101@126.com。

中图分类号: TU435；P315.3
计量
- 文章访问数: 0293
- HTML全文浏览量: 0
- PDF下载量: 0226
出版历程
- 收稿日期: 2013-12-08
- 发布日期: 2014-06-19

Precise positioning in double-layer horizontal media

1. College of Civil Engineering and Transportation, Liaoning Technical University, Fuxin 123000, China; 2. Shen Kan Engineering & Technology Corporation, MCC, Shenyang 110016, China; 3. Fuxin Gong Da Blasting Co., Ltd., Fuxin 123000, China

摘要

摘要: 现有震源定位模型均基于均匀介质,为进一步提高震源定位精度,提出了二层水平介质中震源定位方法。采用惠更斯原理推导折射定律过程中的等时线概念,结合工程中广泛采用的折射点近似确定方法,得到将震源深度与水平坐标分离的走时方程。采用特定的台站分布方案,将走时方程简化为线性方程组。采用合理假设并取几何平均数的方法修正震源深度的计算结果。二层模型在多种定位条件下的计算精度均明显高于经典线性定位方法。对各种定位条件下二层模型的计算结果分析表明,在波速比和台站间距取不同值时,存在定位效果最优的取值范围,且二层模型尤其适用于埋深较大的深震源定位。台站与震源水平、竖直距离比较大时,定位精度变差,建议在地（矿）震易发区布置台站。另外,当震源与台站距分界面距离比过大或过小时较经典线性方法不具优势,建议与经典线性定位法结合使用。二层模型的进一步优化和向多层模型推广,将进一步完善地（矿）震震源精确定位方案。
- 震源定位 /
- 二层介质 /
- 惠更斯原理 /
- 台站分布方案 /
- 深部开采
Abstract: The existing source positioning models for earthquakes and rock bursts are based on homogeneous media. In order to improve source positioning accuracy, a source positioning method in double-layer horizontal media is proposed. Using the isochron concept in the process of deriving the law of refraction based on the Huygens principle and the approximate determination method of refraction point which is widely used in engineering, we get a travel time equation by which the depth and horizontal coordinates are obtained. Based on the specific distribution solution of monitoring stations, the travel time equation is simplified into linear equations. Reasonable assumptions and geometric means are adopted to revise the calculated results of source depth. The positioning accuracy of double-layer media model is significantly higher than that of classical linear positioning method under a variety of conditions. The analysis of the calculated results of double-layer media model under various positioning conditions shows that: (1) when the wave velocity ratio and station spacing are different, there is an optimal value range for source positioning; (2) the double-layer media model is especially suitable for deep source positioning with large buried depth; (3) when the ratio of horizontal to vertical distance between station and source is larger, the positioning accuracy is worse. It is suggested to build stations on the areas where earthquakes are easily prone to happen; (4) there is no advantage when the ratio of distances from interface of the source and stations is too large or small, so it is suggested to use the classic linear positioning method. Further optimization of double-layer media model and promotion to multi-layer media one will improve the precise positoning.
- positioning location /
- double-layered medium /
- Huygens principle /
- distribution solution of station /
- deep mining

HTML全文

参考文献(13)

[1]	朱权洁, 姜福兴, 尹永明, 等. 基于小波分形特征与模式识别的矿山微震波形识别研究[J]. 岩土工程学报, 2012, 34(11): 2036-2042. (ZHU Quan-jie, JIANG Fu-xing, YIN Yong-ming, et al. Classification of mine microseismic events based on wavelet-fractal method and pattern recognition[J]. Chinese Journal of Geotechnical Engineering, 2012, 34(11): 2036-2042. (in Chinese))
[2]	苗小虎, 姜福兴, 王存文, 等. 微地震监测揭示的矿震诱发冲击地压机理研究[J]. 岩土工程学报, 2011, 33(6): 971-976. (MIAO Xiao-hu, JIANG Fu-xing, WANG Cun-wen, et al. Mechanism of microseism-inducdrock burst revealed by microseismic monitoring[J]. Chinese Journal of Geotechnical Engineering, 2011, 33(6): 971-976. (in Chinese))
[3]	彭府华, 李庶林, 程建勇, 等. 中尺度复杂岩体应力波传播特性的微震试验研究[J]. 岩土工程学报, 2014, 36(2): 312-319. (PENG Fu-hua, LI Shu-lin, CHENG Jian-yong, et al. Experimental study on characteristics of stress wave propagation in the mesoscale and complex rock mass by microseismic monitoring[J]. Chinese Journal of Geotechnical Engineering, 2014, 36(2): 312-319. (in Chinese))
[4]	潘一山, 赵扬锋, 官福海, 等. 矿震监测定位系统的研究及应用[J]. 岩石力学与工程学报, 2007, 26(5): 1002-1011. (PAN Yi-shan, ZHAO Yang-feng, GUAN Fu-hai, et al. Study on rockburst monitoring and orientation system and its application[J]. Chinese Journal of Rock Mechanics and Engineering, 2007, 26(5): 1002-1011. (in Chinese))
[5]	林峰, 李庶林, 薛云亮, 等. 基于不同初值的微震源定位方法[J]. 岩石力学与工程学报, 2010, 29(5): 996-1002. (LIN Feng, LI Shu-lin, XUE Yun-liang, et al. Microseismic sources location methods based on different initial values[J]. Chinese Journal of Rock Mechanics and Engineering, 2010, 29(5): 996-1002. (in Chinese))
[6]	张伯军. 弹性动力学简明教程[M]. 2版. 北京: 科学出版社, 2011: 170-174. (ZHANG Bo-jun. A concise course of elastic dynamics[M]. 2nd ed. Beijing: Science Press, 2011: 170-174. (in Chinese))
[7]	黄琼, 陈洁, 孟升卫, 等. 一种快速超宽带穿墙雷达成像算法[J]. 电子与信息学报, 2009, 31(8): 2001-2005. (HUANG Qiong, CHEN Jie, MENG Sheng-wei, et al. A fast imaging algorithm for UWB Through-Wall radar[J]. Journal of Electronics & Information Technology, 2009, 31(8): 2001-2005. (in Chinese))
[8]	金添, 周智敏, 常文革. 基于两层均匀媒质的GPEN SAR地下目标成像方法及其性能分析[J]. 信号处理, 2006, 22(2): 238-243. (JIN Tian, ZHOU Zhi-min, CHANG Wen-ge. GPEN SAR underground targets imaging formation in two-layer homogeneous media environment and its performance analysis[J]. Signal Processing, 2006, 22(2): 238-243. (in Chinese))
[9]	张明新, 王光力, 吴仁彪. 探地雷达成像中多层介质分界面折射点确定[J]. 中国民航学院学报, 2002, 20(6): 20-24. (ZHANG Ming-xin, WANG Guang-li, WU Ren-biao. Determination of refraction points between the interfaces of multiple media in GPR[J]. Journal of Civil Aviation University of China, 2002, 20(6): 20-24. (in Chinese))
[10]	田玥, 陈晓非. 水平层状介质中的快速两点间射线追踪方法[J]. 地震学报, 2005, 27(2): 147-154. (TIAN Yue, CHEN Xiao-fei. A rapid and accurate two-point ray tracing method in horizontally layered velocity model[J]. ACTA Seismologica Sinica, 2005, 27(2): 147-154. (in Chinese))
[11]	赵近芳. 大学物理学(上)[M]. 2版. 北京: 北京邮电大学出版社, 2006: 183-184. (ZHAO Jin-fang. University physics (Vol 1)[M]. 2nd ed. Beijing: Beijing University of Posts and Telecommunications Press, 2006: 183-184. (in Chinese))
[12]	韩志勇, 陈佳. 一种有效确定多层介质分界面折射点位置的方法[J]. 河北师范大学学报（自然科学版）, 2010, 34(1): 50-53, 56. (HAN Zhi-yong, CHEN Jia. An efficient method of refraction points determination between the interfaces of Multi-media[J]. Journal of Hebei Normal University (Natural Science Edition), 2010, 34(1): 50-53, 56. (in Chinese))
[13]	刘金丽, 高见. 联合采用Inglada算法和Geiger算法确定地震精确位置[J]. 防灾科技学院学报, 2012, 14(2): 54-59. (LIU Jin-li, GAO Jian. Hypocenter Location by Using Combined Method of Inglada and Geiger Algorithms[J]. J. of Institute of Disaster Prevention, 2012, 14(2): 54-59. (in Chinese))
