基于修正纵向等效连续化模型的隧道变形受力研究

李翔宇; 刘国彬; 杨潇; 韩春龙

doi:10.11779/CJGE201404010

基于修正纵向等效连续化模型的隧道变形受力研究 English Version

李翔宇^{1, 2},
刘国彬³,
杨潇³,
韩春龙⁴

1. 中国建筑科学研究院地基基础研究所,北京 100013;
2. 建筑安全与环境国家重点实验室,北京 100013;
3. 同济大学地下建筑与工程系,上海 200092;
4. 上海电力设计院有限公司,上海 200025

详细信息

作者简介:
李翔宇(1984- ),男,河南鄢陵人,博士,工程师,从事地基基础和地下结构工程的研究。E-mail: leexiangyu@126.com。

中图分类号: U45
计量
- 文章访问数: 0291
- HTML全文浏览量: 0
- PDF下载量: 0407
出版历程
- 收稿日期: 2013-07-09
- 发布日期: 2014-04-21

Deformation and stress of tunnel structures based on modified longitudinal equivalent continuous model

1. Institute of Foundation Engineering, China Academy of Building Research, Beijing 100013, China;
2. State Key Laboratory of Building Safety and Built Environment, Beijing 100013, China;
3. Department of Geotechnical Engineering, Tongji University, Shanghai 200092, China;
4. Shanghai Electric Power Design Institute Co., Ltd., Shanghai 200025, China

摘要

摘要: 及时掌握隧道结构变形受力情况对于保证地铁运营安全意义重大。通过增加考虑横向刚度、环缝作用范围和螺栓预应力的影响,建立了新型的盾构隧道修正纵向等效连续化模型,据此提出了弹、塑性状态下隧道纵向等效抗弯刚度、极限弯矩以及最大环缝张开量的计算方程；以上海地铁二号线为工程背景,分析了横向刚度和环缝作用范围对隧道等效抗弯刚度的影响规律；之后建立了5类隧道结构临界状态下隧道纵向曲率半径、接缝张开值、管片应力、螺栓拉力的求解公式,并求得了对应的界限指标,所得指标值可作为隧道健康状态诊断的依据。
- 纵向等效连续化模型 /
- 横向刚度 /
- 环缝作用范围 /
- 螺栓预紧力 /
- 界限指标
Abstract: It is of great importance for guaranteeing the metro operation safety to promptly grasp the condition of deformation and stress of tunnel structures. A new modified longitudinal equivalent continuous model for shield tunnels is established based on the conventional one by taking into consideration the lateral rigidity, influence scope of annular gap and bolt pre-stress. Subsequently the equations for solving the equivalent longitudinal bending stiffness, the ultimate moment of tunnel and the maximal amount of joint opening under elastic and plastic states are derived respectively using to the modified model. Based on the engineering practice of Shanghai metro line 2, the influence laws of lateral rigidity and influence scope of annular gap on the equivalent longitudinal bending stiffness are analyzed. Finally, the formulae for longitudinal curvature radius, joint opening, segment stress and bolt tension are proposed according to five critical conditions of tunnel structures, and the corresponding critical indexes which can be used to diagnose the tunnel health are obtained.
- longitudinal equivalent continuous model /
- lateral rigidity /
- influence scope of annular gap /
- bolt pre-stress /
- critical index

HTML全文

参考文献(12)

[1]	志波由纪夫, 川島一彦, 大日方尚己. 応答変位法によるシ―ルドトソネルの地震时断面力の算定法[C]// 土木学会論文集. 1989: 385-394. (YUKIS Shiba, KAZUHIKO Kawashima, NAOMI Obinata. Calculation of internal force of structure during earthquake using response displacement method[C]// Proceedings of the Civil Academy. 1989: 385-394. (in Japanese))
[2]	林永国. 地铁隧道纵向变形结构性能研究[D]. 上海: 同济大学, 2001. (LIN Yong-guo. Longitudinal deformation structural performance study of metro tunnel[D]. Shanghai: Tongji University, 2001. (in Chinese))
[3]	臧小龙. 软土盾构隧道纵向结构变形研究[D]. 上海: 同济大学, 2003. (ZANG Xiao-long. Research on longitudinal structure deformation of shield tunnel in soft soil[D]. Shanghai: Tongji University, 2003. (in Chinese))
[4]	廖少明. 圆形隧道纵向剪切传递效应研究[D]. 上海: 同济大学, 2002. (LIAO Shao-ming. Longitudinal shear transfer effects study of shield tunnel[D]. Shanghai: Tongji University, 2002. (in Chinese))
[5]	徐凌. 软土盾构隧道纵向沉降研究[D]. 上海: 同济大学,2005. (XU Ling. Research on longitudinal settlement behavior of shield tunnels[D]. Shanghai: Tongji University, 2005. (in Chinese))
[6]	鲁志鹏. 基于静态量测数据的盾构法地铁隧道建设和运营安全评价研究[D]. 上海: 同济大学, 2008. (LU Zhi-peng. The safety evaluation research of metro shield tunnel during construction and operation based on static measured data[D]. Shanghai: Tongji University, 2008. (in Chinese))
[7]	周宁, 袁勇. 越江盾构隧道纵向变形曲率与管环渗漏的关系[J]. 同济大学学报（自然科学版）, 2009, 37(11): 1446-1451, 1501. (ZHOU Ning, YUAN Yong. Correlation of cross-river shield tunnel between longitudinal deformation curvature and segment leakage[J]. Journal of Tongji University (Natural Science), 2009, 37(11): 1446-1451, 1501. (in Chinese))
[8]	张文杰, 徐旭, 李向红, 等. 广义的盾构隧道纵向等效连续化模型研究[J]. 岩石力学与工程学报, 2009, 28(增刊2): 3938-3944. (ZHANG Wen-jie, XU Xu, LI Xiang-hong, et al. Research on generalized longitudinal equivalent contituous model of shield tunnels[J]. Chinese Journal of Rock Mechanics and Engineering, 2009, 28(S2): 3938-3944. (in Chinese))
[9]	叶飞, 何川, 朱合华, 等. 考虑横向性能的盾构隧道纵向等效刚度分析[J]. 岩土工程学报, 2011, 33(12): 1870-1876. (YE Fei, HE Chuang, ZHU He-hua, et al. Longitudinal equivalent rigidity analysis of shield tunnel considering transverse characteristics[J]. Chinese Journal of Geotechnical Engineering, 2011, 33(12): 1870-1876. (in Chinese))
[10]	黄宏伟, 徐凌, 严佳梁, 等. 盾构隧道横向刚度有效率研究[J]. 岩土工程学报, 2006, 28(1): 11-18. (HUANG Hong-wei, XU Ling, YAN Jia-liang, et al. Study on transverse effective rigidity ratio of shield tunnels[J]. Chinese Journal of Geotechnical Engineering, 2006, 28(1): 11-18. (in Chinese))
[11]	田敬学, 张庆贺. 盾构法隧道的纵向刚度计算方法[J]. 中国市政工程, 2001(3): 35-37. (TIAN Jing-xue, ZHANG Qing-he. Calculation of longitudinal rigidity of shield tunnels[J]. China Municipal Engineering, 2001(3): 35-37. (in Chinese))
[12]	CHEN Bao, WEN Zhu-yin. Elasto-plastic analysis for the effect of longitudinal uneven settlement[C]// Reclaiming the Underground Space-Proceedings of the ITA World Tunnelling Congress 2003. Rotterdam: Balkema, 2003.
