静、动水压力条件下海底隧道地震反应特性分析

刘勇, 陈国兴, 孔梦云

刘勇, 陈国兴, 孔梦云. 静、动水压力条件下海底隧道地震反应特性分析[J]. 岩土工程学报, 2013, 35(zk2): 357-362.
引用本文: 刘勇, 陈国兴, 孔梦云. 静、动水压力条件下海底隧道地震反应特性分析[J]. 岩土工程学报, 2013, 35(zk2): 357-362.
shu
LIU Yong, CHEN Guo-xing, KONG Meng-yun. Seismic response of undersea tunnels to hydrodynamic and hydrostatic pressures[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(zk2): 357-362.
Citation: LIU Yong, CHEN Guo-xing, KONG Meng-yun. Seismic response of undersea tunnels to hydrodynamic and hydrostatic pressures[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(zk2): 357-362.
shu

静、动水压力条件下海底隧道地震反应特性分析  English Version

  • 1. 南京工业大学岩土工程研究所,江苏 南京 210009; 2. 南京工业大学城市地下空间研究中心,江苏 南京 210009

基金项目: 国家重点基础研究发展计划（973计划）（2011CB013605）
详细信息
    作者简介:

    刘 勇(1987- )，男，江苏盐城人，硕士研究生，主要从事海底隧道抗震研究。E-mail: liuy37@126.com。

  • 中图分类号: TU43

Seismic response of undersea tunnels to hydrodynamic and hydrostatic pressures

  • 1. Institute of Geotechnical Engineering, Nanjing University of Technology, Nanjing 210009, China; 2. Research Center of Urban Underground Space, Nanjing University of Technology, Nanjing 210009, China

摘要

    摘要
  • 摘要: 建立了基于ABAQUS软件的海水-土-隧道结构体系有限元模型,采用Airy微小振幅波动理论,对静、动水压条件下不同埋深海底隧道地震反应特性进行了比较。结果表明：动水压力作用下隧道结构的水平向加速度及相对水平位移分别比静水压力作用下的相应值大1.1～1.4倍和1.8～2.3倍；随着隧道埋深增加,隧道结构的应力、水平位移逐渐减小,动水压力影响系数KD有减小的趋势,也即达到一定埋深时,动水压力对隧道结构的地震反应没有影响；隧道拱肩和拱腰处的应力反应明显大于其他部位,拱肩和拱腰处为隧道结构的最危险部位。
    Abstract: Based on the theory of Airy minute amplitude of vibration, A finite element model for sea-soil-tunnel system is established on the basis of the software of ABAQUS. The seismic responses of under sea tunnels to of effects analysis hydrodynamic and hydrostatic pressures under different buried depths are compared. The results show that, the horizontal acceleration and relative horizontal displacement is 1.1~1.4 and 1.8~2.3 times respectively under hydrodynamic pressure than hydrostatic pressure. With the increasing buried depth, the stress and displacement as well as the corresponding impact factor of hydrodynamic pressure KD decrease, that is, the hydrodynamic pressure has no effect on seismic response when it reaches certain depths.The stress in spandrel and haunch is significantly larger than that in the other parts so that the spandrel and haunch are the most dangerous parts of the tunnel.
    • HTML全文
    • 参考文献(13)
  • [1] ZHANG X, LI S C, DING X L. Seismic response of QINGDAO sub-sea tunnel considering transversely isotropic[J]. Boundaries of Rock Mechanic, 2008.
    [2] SHUNZO Okamoto. Introduction to earthquake engineering[M]. Tokyo: University of Tokyo Press, 1984: 867-871.
    [3] 刘继国, 郭小红, 程 勇. 高地震烈度下超大直径海底盾构隧道地震响应分析[J]. 现代隧道技术, 2011, 48(3):53-58. (LIU Ji-guo, GUO Xiao-hong, CHENG Yong. Seismic response analysis on super large-diameter undersea shied tunnel under high seismic intensity[J]. Morden Tunnelling Technology, 2011, 48(3): 53-58. (in Chinese))
    [4] 陈向红, 张鸿儒. 暗挖海底隧道地震动水压力响应分析[J]. 北京交通大学学报, 2012, 36(1): 36-40. (CHEN Xiang-hong, ZHANG Hong-ru. Analysis of effect of hydrodynamic pressure on undersea tunnels constructed by excavation method[J]. Journal of Beijing Jiaotong University, 2012, 36(1): 36-40. (in Chinese) )
    [5] 朱镜清. 地震作用下海水与海床土的耦合运动[J]. 地震工程与工程振动, 1988, 8(2): 37-43. (ZHU Jing-qing. Coupled motion between sea water and sea bed-soil under earthquake action[J]. Earthquake Eengineering and Eengineering, 1988, 8(2): 37-43. (in Chinese) )
    [6] 朱镜清, 周 建. 海底地震动估计的一个流体力学基础[J]. 地震工程与工程振动, 1991, 11(3): 87-93. (ZHU Jing-qing, ZHOU Jian. A fluid mechanics basis for estimating undersea ground motion[J]. Earthquake Eengineering and Eengineering, 1991, 11(3): 87-93. (in Chinese))
    [7] 朱镜清, 周 建. 海底隧道体系地震反应分析方法[J]. 地震工程与工程振动, 1992, 12(2): 90-98. (ZHU Jing-qing, ZHOU Jian. A seismic analysis method of undersea tunnels[J]. Earthquake Eengineering and Eengineering, 1992, 12(2): 90-98. (in Chinese))
    [8] 席仁强, 陈国兴, 王志华. 覆水场地地震反应分析[J]. 防灾减灾工程学报, 2009, 29(6): 610-617. (XI Ren-qiang, CHEN Guo-xing, WANG Zhi-hua. Seismic response of underwater site[J]. Journal of Disaster Prevention and Mitigation Engineering, 2009, 29(6): 610-617. (in Chinese))
    [9] 陶建华. 水波的数值模拟[M]. 天津: 天津大学出版社, 2005. (TAO Jian-hua. Numerical simulation of water waves[M]. Tianjing: Tianjing University Press, 2005. (in Chinese))
    [10] 陈国兴. 岩土地震工程学[M]. 北京: 科学出版社, 2007. (CHEN Guo-xing. Geotechnical earthquake enigneering[M]. Beijing: Science Press, 2007. (in Chinese))
    [11] LEE J, FENVES G L. A plastic-damage concrete model for earthquake analysis of dams[J]. Earthquake Engineering and Structural Dynamics, 1998, 27(9): 937-956.
    [12] 陈 磊, 陈国兴. 近断层强地震动下双层竖向重叠地铁隧道的地震反应[J]. 防灾减灾工程学报, 2008(4): 399-408. (CHEN Lei, CHEN Guo-xing. Seismic response of two-layer overlapping metro tunnel under near-fault strong ground motion[J]. Journal of Disaster Prevention and Mitigation Engineering, 2008(4): 399-408. (in Chinese) )
    [13] 吕 明, GROV E, NILSEN B, 等. 挪威海底隧道经验[J].岩石力学与工程学报, 2005, 24(23): 4219-4225. (LÜ Ming, GROV E, NILSEN B, et al. Norweglan experience in subsea tunnelling[J]. Chinese Journal of Rock Mechanics and Engineering, 2005, 24(23): 4219-4225. (in Chinese))
