邻近桥桩地铁车站施工数值模拟及敏感性分析

姜谙男; 塔拉; 李鹏

邻近桥桩地铁车站施工数值模拟及敏感性分析 English Version

大连海事大学道桥所,辽宁大连 116026

详细信息

作者简介:
姜谙男（1971- ），男，山东烟台人，博士，教授，主要从事地下工程及岩土工程的科研与教学工作。E-mail: jiangannan@163.com。

中图分类号: TU473
计量
- 文章访问数: 0221
- HTML全文浏览量: 0
- PDF下载量: 0344
出版历程
- 收稿日期: 2013-06-14
- 发布日期: 2013-11-24

Numerical simulation and sensitivity analysis for construction of metro station near bridge pile

Highway and Bridge Engineering Institute, Dalian Maritime University, Dalian 116026, China

摘要

摘要: 在城市中修建地铁隧道的过程中,开挖扰动对既有建筑和桥桩的影响问题特别值得关注。大连地铁2号线香工街车站采用明挖法施工,高架桥桥桩外边缘距离车站主体结构外墙净距仅2.55m,车站开挖对高架桥影响极大。采用数值模拟的方法研究隧道施工对近接高架桥的影响,模拟获得了各开挖时步的地层位移、最大主应力、围护桩位移和桥桩位移。在数值模拟基础上,采用正交设计方法,根据极差分析原理,分析E₂,μ₂,E₃,μ₃,c₃和φ₃6个因素对于地表沉降、桥墩沉降、桩体倾斜、支撑轴力及桥墩倾斜的影响,获得敏感性的排序。分析结果对于该工程的施工的反馈分析和方案评价具有积极的意义。
- 地铁车站 /
- 明挖 /
- 近接施工 /
- 三维数值模拟 /
- 敏感性
Abstract: In the construction process of metro tunnel, to special attention should be paid the problem of excavation disturbance affecting the adjacent piles of buildings and bridges. Xianggong Station of Dalian metro line No. 2 adopts the open excavation method. There is only a distance of 2.55 m between the trestle bridge pile and the external wall of main metro structure. How the tunnel excavation and supporting affect the trestle bridge is studied by means of numerical simulation. The displacements of ground strata, the maximum stresses and the displacements of skirt pipes and bridge piles are obtained. Based on the numerical simulation, by adopting the orthogonal method and the extreme difference method, the influences of six factors of E₂, μ₂, E₃, μ₃, c₃ and φ₃ on the settlements of ground surface and bridge pier, leanings of skirt pipes and bridge piles and supporting force are analyzed, and the sensitivity sequence of the factors is obtained. The analysis results have active meaning for the feedback analysis and construction scheme appraisement.
- metro station /
- open excavation /
- approaching construction /
- 3-D numerical simulation /
- sensitivity

HTML全文

参考文献(7)

[1]	NEW B M, O’REILLY M P. Tunneling induced ground movements: predicting the magnitude and effects[C]// James D Geddes eds, Proc.4th Int, Con. On Ground Movements and Structures. London: Pentech Press, 1992: 671-679.
[2]	刘建航, 侯学渊. 盾构隧道[M]. 北京: 中国铁道出版社, 1991: 329-394. (LIU Jian-hang, HOU Xue-yuan. Shield tunnel[M]. Beijing: Railway Press of China, 1991. (in Chinese))
[3]	阳军生, 刘宝琛. 城市隧道施工引起的地表移动及变形[M]. 北京: 中国铁道出版社, 2002. (YANG Jun-sheng, LIU Bao-chen. The ground surface movement and deformation[M]. Beijing: Railway Press of China, 2002. (in Chinese))
[4]	房师军, 付拥军, 姚爱军. 某地铁工程深基坑排桩围护结构变形规律分析[J]. 岩土工程学报, 2011, 33(增刊1): 216-219. (FANG Shi-jun, FU Yong-jun, YAO Ai-jun, Deformation of row pile retaining structures for deep foundation pit of subway[J]. Chinese Journal of Geotechnical Engineering, 2011, 33(S1): 216-219. (in Chinese))
[5]	李强, 王明年, 李德才, 等. 地铁车站暗挖隧道施工对既有桩基的影响[J]. 岩石力学与工程学报, 2006, 25(1): 184-190. (LI Qiang, WANG Ming-nian, LI De-cai, et al. Effects of subsurface construction of metro station tunnel on existing pile foundation[J]. Chinese Journal of Rock Mechanics and Engineering, 2006, 25(1): 184-190. (in Chinese))
[6]	史继尧, 刘招伟, 余永强. PBA施工对地表沉降影响的数值模拟[J]. 低温建筑技术, 2010, 2: 62-64. (SHI Ji-yao, LIU Zhao-wei, YU Yong-qing. The Numerical Simulation of the Effects of PBA Construction on Ground Surface Settlement[J],Low Temperature Architecture Technology, 2010, 2: 62-64. (in Chinese))
[7]	刘文卿. 试验设计[M]. 北京: 清华大学出版社, 2005, 2. (LIU Wen-qing. experimental design[M]. Beijing: Tsinghua University Press, 2005, 2. (in Chinese))
