Numerical analysis of effect of large-scale unloading on underlying shield tunnels
-
摘要: 杭州铁路东站西广场项目基坑是杭州地区第一个在已建地铁盾构隧道顶部进行大面积开挖卸荷的工程。以西广场项目基坑工程为背景,建立三维数值分析模型,对基坑施工全过程进行动态模拟,研究了分层分块开挖、底板加筋垫层、土体加固等施工措施控制隧道隆起的有效性,并将计算结果与实测结果进行对比分析,得出以下结论：顶部大面积卸荷引起隧道的变形以隆起为主,合理的设计施工能够将隧道变形控制在要求范围；分层分块开挖的同时尽快浇筑底板垫层可取得较好效果；加固土体在地基位移场中起屏障作用,可有效降低隧道隆起。Abstract: The foundation pit of West Square of Hangzhou East Railway Station is the first project that large-scale unloading is conducted on the top of shield subway tunnels. A 3D FEM model is used to simulate the whole excavation course of the foundation pit, and the effect of various adopted construction measures on underlying shield subway tunnel is studied. The construction measures include step excavation, reinforced cushion and reinforcement of soils surrounding the tunnel. Some conclusions are drawn through the comparison between the calculated and the monitoring results: (1) the heave occupieds a dominant position in the tunnel deformation caused by top excavation, and proper design and construction can lead to an desired tunnel deformation; (2) better results will be got by combining excavation by layers and by blocks with building reinforced cushion simultaneously; (3) the reinforcement around tunnels acts as a protective screen of tunnels in ground displacement field, so the tunnel heave decreases substantially .
-
Keywords:
- unloading /
- shield tunnel /
- heave /
- numerical simulation /
- reinforcement
-
[1] 高广运, 高 盟, 杨成斌, 等. 基坑施工对运营地铁隧道的变形影响及控制研究[J]. 岩土工程学报, 2010, 32(3): 453-459. (GAO Guang-yun, GAO Meng, YANG Cheng-bin, et al. Influence of deep excavation on deformation of operating metro tunnels and countermeasures[J]. Chinese Journal of Geotechnical Engineering, 2010, 32(3): 453-459. (in Chinese)) [2] 彭 敏. 基坑开挖引起下卧运营隧道变形的研究[J]. 中国市政工程, 2010(10): 72-74. (PENG Min. Research on operation tunnel deformation by foundation pit excavation[J]. China Municipal Engineering, 2010(10): 72-74. (in Chinese)) [3] 程 斌, 刘国彬. 基坑工程施工对邻近建筑物及隧道的相互影响[J]. 工程力学, 2000(A03): 486-491. (CHENG Bin, LIU Guo-bin. The effection to the adjacent building and tunnel due to excavation[J]. Engineering Mechanics, 2000(A03): 486-491. (in Chinese)) [4] 中国土木工程学会土力学及岩土工程分会. 深基坑支护技术指南[M]. 北京: 中国建筑工业出版社, 2012. (Chinese Institution of Soil Mechanics and Geotechnical Engineering. Guide to deep excavation support[M]. Beijing: China Architecture & Building Press, 2012. (in Chinese))
