循环荷载作用下软土中吸力锚承载力拟静力有限元分析

王建华, 李书兆

王建华, 李书兆. 循环荷载作用下软土中吸力锚承载力拟静力有限元分析[J]. 岩土工程学报, 2013, 35(8): 1403-1412.
引用本文: 王建华, 李书兆. 循环荷载作用下软土中吸力锚承载力拟静力有限元分析[J]. 岩土工程学报, 2013, 35(8): 1403-1412.
shu
WANG Jian-hua, LI Shu-zhao. Pseudo static finite element analysis of bearing capacity of suction anchor subjected to cyclic loads in soft clay[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(8): 1403-1412.
Citation: WANG Jian-hua, LI Shu-zhao. Pseudo static finite element analysis of bearing capacity of suction anchor subjected to cyclic loads in soft clay[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(8): 1403-1412.
shu

循环荷载作用下软土中吸力锚承载力拟静力有限元分析  English Version

  • 1. 天津大学水利工程仿真与安全国家重点实验室，天津 300072; 2. 天津大学岩土工程研究所，天津 300072

基金项目: 国家自然科学基金项目（51179120）
详细信息
    作者简介:

    王建华(1955- )，男，博士，教授，博士生导师，主要从事岩土地震工程与海洋岩土工程研究。E-mail: tdwjh@eyou.com。

  • 中图分类号: TU411

Pseudo static finite element analysis of bearing capacity of suction anchor subjected to cyclic loads in soft clay

  • 1. State Key Laboratory of Hydraulic Engineering Simulation and Safety of Tianjin University, Tianjin 300072, China; 2. Geotechnical Engineering Institute of Tianjin University, Tianjin 300072, China

摘要

    摘要
  • 摘要: 建议了一种利用软土不排水循环强度，评价静荷载与循环荷载共同作用下软土中吸力锚承载力的拟静力弹塑性有限元方法。该方法首先依据软土的不排水静强度，通过弹塑性有限元计算，确定平均系泊荷载作用下土体单元的八面体平均剪应力，再据此确定与一定循环破坏次数对应的土单元循环强度；然后，按土单元循环强度再次通过弹塑性有限元计算，确定锚系泊点沿系泊方向的荷载位移曲线；最终由荷载位移曲线、按位移破坏标准确定锚的循环承载力。这一方法的特点是考虑了平均系泊荷载对软土循环强度、进而对静荷载与循环荷载共同作用下锚承载力的影响。为说明这一方法的可行性，进行了不同锚径、不同长径比、不同平均荷载、不同摩擦系数、不同加载方向、不同破坏模式条件下的软土中吸力锚循环承载力模型试验。利用拟静力有限元方法对模型试验结果进行了预测，预测结果比试验结果偏小，平均偏小不超过10%。模型试验结果还表明，软土中锚的归一化循环承载力随循环破坏次数的变化只取决于归一化平均荷载，可以忽略加载方向、锚的直径、锚外壁摩擦系数对归一化循环承载力变化关系的影响。若归一化平均荷载为0.5，当循环破坏次数为1000时，对于竖向破坏的锚，循环承载力大约为静承载力的75%；对于水平破坏的锚，循环承载力大约为静承载力的80%，这与已有的离心模型试验结果基本一致。
    Abstract: A pseudo-static elasto-plastic finite element method is proposed to evaluate the bearing capacity of suction anchors subjected to a combination of average and cyclic loads in soft clay using the undrained cyclic strength. The octahedral shear stress of soil elements associated with the average mooring load is first determined by elasto-plastic finite element calculations using the undrained static strength of soft clay for the method. The undrained cyclic strength of soil elements associated with the specified number of cycles to failure is further determined based on the octahedral shear stress. The load-displacement curve at the mooring point along the loading direction is then determined by the elasto-plastic finite element calculations using the undrained cyclic strength. The cyclic bearing capacity of anchors is finally determined based on the curve and the displacement criterion to failure. The effects of the average mooring load on the undrained cyclic strength and the bearing capacity of suction anchors subjected to a combination of average and cyclic loads are considered. In order to show the validity of the method, model tests on cyclic bearing capacity of suction anchors with different diameters, aspect ratios, average loads, frictional factors, loading directions and failure modes are conducted. The test results are predicted using the pseudo-static elasto-plastic finite element method. The predicted results are less than the test ones. The average difference is not over 10%. Variations of the normalized cyclic bearing capacity with the number of cycles to failure only depend on the normalized average loads. The effects of load directions, anchor diameters and frictional factors of outer wall on the normalized cyclic bearing capacity can be neglected. If the normalized average load is 0.5 and the number of cycles to failure is 1000, the cyclic bearing capacities are about 75% and 80% of the static bearing capacity respectively for the vertical failure and the lateral failure, which are in
    • HTML全文
    • 参考文献(1)
  • [1] ANDERSEN K H, MURFF J D, RANDOLPH M F,et al. Suction anchors for deepwater applications[C]// Frontiers in Offshore Geotechnics. Perth, 2005: 3-30.
    ANDERSEN K H. Bearing capacity under cyclic loading-offshore, along the coast, and on land[J]. Canada Geotechnical Journal, 2009, 46(3): 513-535.
    PREVOST J H. Offshore gravity structures: analysis[J]. Journal of Geotechnical Engineering, ASCE, 1981, 107(2): 143-165.
    周 健. 饱和软黏土循环变形的弹塑性研究[J]. (岩土工程学报), 2000, 22(4): 499-502.(ZHOU Jian. Elastoplastic study on cyclic strain of saturated soil[J]. Chinese Journal of Geotechnical Engineering, 2000, 22(4): 499-502. (in Chinese)).
    ANDERSEN K H, LAURITZSEN R. Bearing capacity for foundation with cyclic loads[J]. Journal of Geotechnical Engineering, ASCE, 1988, 114(5): 540-555.
    ANDERSEN K H, JOSTAD H P. Foundation design of skirted foundations and anchors in clay[C]// Offshore Technology Conference. Houston, 1999: 10824.
    ANDERSEN K H, DYVIK R, SCHRDER K,et al. Field tests of anchors in clay II: predictions and interpretation[J]. Journal of Geotechnical Engineering, ASCE, 1993, 119(10): 1532-1549.
    ANDERSEN K H, DYVIK R, LAURITZSEN R,et al. Model tests of offshore platforms II interpretation[J]. Journal of Geotechnical Engineering, ASCE, 1989, 115(11): 1550-1568.
    DET NORSKE VERITAS. Geotechnical design and installation of suction anchors in clay[M]. H?vik: DNV Recommended Practice RP-E303, 2005.
    WANG Jian-hua, YANG Yang, LIU Jing-lei. Model tests and analysis method on cyclic bearing capacity of suction caissons with the taut mooring system in soft clays[C]// 21st Int Offshore and Polar Engrg Conf. USA Maui, 2011: 478-484.
    WANG Jian-hua, LI Chi, KATHRYN Moran. Cyclic undrained behavior of soft clays and cyclic bearing capacity of a single bucket foundation[C]// 15th Int Offshore and Polar Engrg Conf. Seoul, 2005: 392-399.
    WANG Jian-hua, YANG Hai-ming. Model tests and numerical simulation on bearing capacity of bucket foundations in soft clay under vertical static and cyclic loads[C]// 17th Int Offshore and Polar Engrg Conf. Protuga, 2007: 1547-1552.
    王建华, 杨海明. 软土中桶形基础水平循环承载力模型试验[J]. (岩土力学), 2008, 29(10): 2606-2612.(WANG Jian-hua, YANG Hai-ming. Model tests on horizontal cyclic bearing capacity of bucket foundations in soft clays[J]. Rock and Soil Mechanics, 2008, 29(10): 2606-2612. (in Chinese))
    范庆来, 栾茂田, 杨 庆, 等. 考虑循环软化效应的软基上深埋大圆筒结构承载力分析[J]. (大连理工大学学报), 2006, 469(5): 702-706.(FAN Qing-lai, LUAN Mao-tian, YANG Qing, et. al. Analyses of bearing capacity for deeply-buried large-diameter cylindrical structureonsoft clay considering cyclic-softening effect[J]. Journal of Dalian University of Technology, 2006, 469(5): 702-706. (in Chinese))
    栾茂田, 武 科, 范庆来, 等. 复合加载下桶形基础循环承载性能数值分析[J]. (海洋工程), 2007, 25(3): 88-94.(LUAN Mao-tian, WU Ke, FAN Qing-lai,et al. Numerical analysis of cyclic bearing capacity of bucket foundation under combined loading mode[J]. The Ocean engineering, 2007, 25(3): 88-94. (in Chinese))
    ANDRESEN L, JOSTAD H P. ANDERSEN K H, et al. Finite element analyses in offshore foundation design[C]// The 12th International Conference of International Association for Computer Methods and Advances in Geomechanics. Goa, 2008: 3247-3262.
    ANDERSEN K H, KLEVEN A, HEIEN D. Cyclic soil data for design of gravity structures[J]. Journal of Geotechnical Engineering, ASCE, 1988, 114(5): 517-539.
    American Petroleum Institute. Geotechnical and foundation design consideritions[S]. United States, 2011.
    李 驰, 王建华. 饱和软黏土动力特性循环扭剪实验研究[J]. (岩土力学), 2008, 29(2): 460-464.(LI Chi, WANG Jian-hua. Cyclic torsional shear experimental studies on dynamic characters for saturated soft clay[J]. Rock and Soil Mechanics, 2008, 29(2): 460-464. (in Chinese)).
    王建华, 曲延大. 循环应力作用下饱和软黏土的不固结不排水强度与破坏准则[J]. (水利学报), 2011, 42(6): 672-677.(WANG Jian-hua, QU Yan-da. Unconsolidated and undrained strength and failure criterion of the soft clay under cyclic stresses[J]. Journal of Hydraulic Engineering, 2011, 42(6): 672-677. (in Chinese)).
    刘晶磊. 循环荷载作用下软黏土中张紧式吸力锚承载力研究[D]. 天津: 天津大学, 2012.(LIU Jing-lei. Study on bearing capacity of suction anchors with taut mooring systems in soft clay under cyclic loading[D]. Tianjin: Tianjin University, 2012. (in Chinese))
    王建华, 刘晶磊, 周杨锐. 静荷载与循环荷载作用下张紧式吸力锚承载特性的模型试验[J]. (岩土工程学报), 2012, 34(6): 997-1004.(WANG Jian-hua, LIU Jing-lei, ZHOU Yang-rui. Model tests on bearing capacities of suction anchors with taut mooring systems under combined static and cyclic loads[J]. Chinese Journal of Geotechnical Engineering, 2012, 34(6): 997-1004. (in Chinese))
    EI-SHERBINY R M. Performance of suction caisson anchors in normally consolidated clay[D]. Austin: The University of Texas at Austin, 2005.
    WANG Jian-hua, LIU Jing-lei, YANG Yang. Model tests on failure modes and bearing capacities of suction anchors with taut mooring system[C]// 22th Int Offshore and Polar Engrg Conf. Rhodes, 2012(2): 1547-1552.
    王建华, 刘晶磊, 陈文强. 加载方向对张紧式吸力锚极限承载力的影响分析[J]. (岩土工程学报), 2012, 34(3): 385-391.(WANG Jian-hua, LIU Jing-lei, CHEN Wen-qiang. Effects of loading direction on ultimate bearing capacity of suction anchors with taut mooring system[J]. Chinese Journal of Geotechnical Engineering, 2012, 34(3): 385-391. (in Chinese))
    CHEN W, RANDOLPH M F. Uplift capacity of suction caissons under sustained and cyclic loading in soft clay[J]. ASCE, Journal of Geotechnical and Geoenvironmental Engineering, 2007, 133(11): 1352-1363.
