基于极限平衡法的箱筒型基础防波堤稳定性分析

肖忠, 王元战, 及春宁

肖忠, 王元战, 及春宁. 基于极限平衡法的箱筒型基础防波堤稳定性分析[J]. 岩土工程学报, 2013, 35(5): 828-833.
引用本文: 肖忠, 王元战, 及春宁. 基于极限平衡法的箱筒型基础防波堤稳定性分析[J]. 岩土工程学报, 2013, 35(5): 828-833.
shu
XIAO Zhong, WANG Yuan-zhan, JI Chun-ning. Stability analysis of bucket foundation breakwaters based on limit equilibrium method[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(5): 828-833.
Citation: XIAO Zhong, WANG Yuan-zhan, JI Chun-ning. Stability analysis of bucket foundation breakwaters based on limit equilibrium method[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(5): 828-833.
shu

基于极限平衡法的箱筒型基础防波堤稳定性分析  English Version

  • 天津大学水利工程仿真与安全国家重点实验室和天津市港口与海洋工程重点实验室，天津 300072

基金项目: 国家自然科学基金项目（51109157）；国家自然科学基金创新研究群体科学基金项目（51021004）；天津市应用基础与前沿技术研究计划项目（12JCQNJC04900）；高等学校博士学科点专项科研基金项目（20110032120049）；大连理工大学海岸和近海工程国家重点实验室开放基金项目(LP1106)；天津大学自主创新基金项目（60302037，60302011）
详细信息
    作者简介:

    肖 忠(1983- )，男，博士，讲师，主要从事港口海岸及近海工程结构设计理论和方法、岩土力学及土与结构相互作用研究。E-mail: tjuzhongxiao@tju.edu.cn。

  • 中图分类号: TU47

Stability analysis of bucket foundation breakwaters based on limit equilibrium method

  • State Key Laboratory of Hydraulic Engineering Simulation and Safety and Tianjin Key Laboratory of Port and Ocean Engineering, Tianjin University, Tianjin 300072, China

摘要

    摘要
  • 摘要: 箱筒型基础防波堤是一种适用于软土地基和深水波浪条件的新型港口与海岸工程结构，依靠沉入地基中的筒型基础维持结构稳定。根据箱筒型基础防波堤极限状态下的结构运动模式，考虑箱筒型基础防波堤的三维空间几何特性、受力特点、极限状态转动点的位置等因素，建立了箱筒型基础防波堤稳定性计算的极限平衡法，通过与有限元结果对比，相互验证了正确性，与有限元法相比，极限平衡法计算速度快，效率高，更方便工程应用。结合天津港防波堤延伸工程，对箱筒型基础防波堤的稳定性进行了分析。结果表明，基础筒高8～10 m时，天津港延伸工程中的箱筒型基础防波堤的抗滑、抗倾和竖向承载力均具有较高的安全度。
    Abstract: The bucket foundation breakwater is a new type of port and coastal engineering structure suitable for soft foundations and deep water waves, the stability of which is sustained by the bucket foundation penetrated in soils. According to the motion mode of the bucket foundation breakwater in the limit state, a limit equilibrium method is established in consideration of its three-dimensional geometry, force characteristics and rotation point position. Compared with the finite element method, the limit equilibrium method is consistent in the calculated results. But the limit equilibrium method has faster calculation speed and higher efficiency. So it is more convenient in engineering application. According to the project of extending breakwaters in Tianjin Port, the stability of the bucket foundation breakwater is analyzed. The results show that when the height of the bucket is 8 to 10 m, the anti-sliding, anti-overturning and vertical bearing capacities of the bucket foundation breakwater in the project all have high degree of safety.
    • HTML全文
    • 参考文献(10)
  • [1] 彭增亮). 箱筒型基础结构气浮拖航的稳性计算[J]. (中国港湾建设), 2007(1):15-19. (PENG Zeng-liang.
    Calculation of stability of caisson-cylindrical foundation structures pneumatically floated during towage[J]. China Harbour Engineering, 2007(1): 15-19.( (in Chinese))
    [2] 肖 忠,(王元战),(及春宁),等. 筒型基础防波堤稳定性有限元数值分析[J]. (土木工程学报), 2009,42(7):119-125. (XIAO Zhong, WANG Yuan-zhan, JI Chun-ning, et al. Finite element analysis for stability of bucket foundation breakwater[J]. China Civil Engineering Journal,2009,42(7): 119-125. (in Chinese)
    [3] 王元战),肖 忠,(李元音),等 筒型基础防波堤土压力性状的有限元分析[J]. 岩土工程学报,2009, 31(4): 622-627. (WANG Yuan-zhan, XIAO Zhong, Li Yuan-yin, et al. Finite element analysis for earth pressure on bucket foundation of breakwater[J]. Chinese Journal of Geotechnical Engineering,2009,31(4): 622-627. (in Chinese)
    [4] 王元战),肖 忠,(迟丽华),等. 筒型基础防波堤稳定性简化计算方法[J]. (岩土力学), 2009,30(5):1367-1372. (WANG Yuan-zhan, XIAO Zhong, CHI Li-hua, et al. A simplified calculation method for stability of bucket foundation breakwater[J]. Rock and Soil Mechanics,2009,30(5): 1367-1372. (in Chinese)
    [5] XIAO Zhong,WANG Yuan-zhan,ZHANG Zhi-kai,et alA simplified method for vertical bearing capacity of bucket foundation breakwater under wave load[C]// The 2nd International Conference on Mechanic Automation and Control Engineering, Inner Mongolia, IEEE press, 2011: 2839-2842.
    [6] 吴凤亮),李 伟. 箱筒型基础防波堤结构的沉降量分析[J]. (国防交通工程与技术), 2006(4):39-42. (WU Feng-liang, LI Wei. Settlement analysis of the breakwater structure with box- type suction foundation[J]. Traffic Engineering and Technology for National Defence, 2006(4): 39-42. (in Chinese)
    [7] 喻志发),(李立新),(朱耀庭). 从实测数据判断箱筒型结构在风浪作用下的稳定性[J]. (中国港湾建设), 2010(4):21-24. (YU Zhi-fa, LI Li-xin, ZHU Yao-ting.
    Judging stability of caisson-cylindrical structure under the action of big waves from the measured data[J]. China Harbour Engineering, 2010(4): 21-24.( (in Chinese))
    [8] 蒋敏敏),(蔡正银),(徐光明),等. 软土地基上箱筒型基础防波堤静力离心模型试验研究[J]. (岩石力学与工程学报), 2010,29(增刊2):3865-3870. (JIANG Min-min, CAI Zheng-yin, XU Guang-ming, et al. Judging stability of caisson- cylindrical structure under the action of big waves from the measured data[J]. Chinese Journal of Rock Mechanics and Engineering,2010,29(S2): 3865-3870. (in Chinese)
    [9] American Petroleum Institute. Recommended practice for planning, designing and constructing fixed offshore platforms[S]. Washington D C: API Publishing Services, 2000.
    [10] 侯晋芳). 软粘土土坡稳定性研究[D]. 天津: 天津大学, 2007.(HOU Jin-fang.
    Study on stability of soft clay slope[D]. Tianjin: Tianjin University, 2007.( (in Chinese))
