Finite element analysis of one-dimensional consolidation of undrained symmetry plane under continuous drainage boundary
-
摘要: 连续排水边界可以修正边界透水与不透水这两种极端理想化的边界问题.在Terzaghi一维固结理论的基础上,结合连续排水边界给出了连续排水边界下不排水对称面一维固结的解析解答.基于ABAQUS有限元软件开发了一维连续排水边界条件的子程序,对不排水对称面位置变化的影响因素包括边界透水性能,排水时间和渗透系数进行研究,得到了不排水对称面的变化规律.最后将该数值分析方法引入饱和软黏土中不同深度设置排水砂层进行比较,结果表明在不排水对称面位置处设置排水砂层时土体的固结速度是最快的.连续排水边界的引入有利于确定不排水对称面的位置,所得的结论和文中的有限元分析过程对促进固结理论的发展具有重要的实际价值和意义.Abstract: The continuous drainage boundary can correct the pervious and impervious boundaries which are extremely idealized. Based on the Terzaghis one-dimensional consolidation theory and the continuous drainage boundary; an analytical solution of one-dimensional consolidation of undrained symmetry plane under continuous drainage boundary is given. One-dimensional subroutine of continuous drainage boundary is written based on the finite element analysis of ABAQUS. The influence factors of undrained symmetry plane is studied; including boundary permeability; drainage time and permeability coefficient. The variation of the undrained symmetry plane is obtained. Finally; the location of setting sand layers at different depths in saturated soft clay is compared by the method of finite element analysis. The results show that the rate of consolidation is the fastest when the sand layer is set at the location of undrained symmetry plane. The continuous drainage boundary can help to determine the location of undrained symmetry plane. The results and the process of finite element analysis are of practical and important value and significance for the development of soil consolidation theory.
-
[1] TERZAGHI K. Erdbaumechanik and bodenphysikalischer grundlage[M]. Lpz Deuticke, 1925. [2] REDULIC L. Porenziffer and porenwasserdruck in tonen[M]. Bauingenieur, 1936: [3] BIOT M A. General theory of three-dimensional consolidation[J]. Journal of Applied Physics, 1941(12): 155-167 [4] BIOT M A. Consolidation settlement under a rectangular load distribution[J]. Journal of Applied Physics, 1941(12): 426- 430.426- 430 [5] NAMEE M C, GIBSON R E. Plan strain and axially symmetric problems of the consolidation of a semi-infinite clay stratum[J]. Journal of Mechanical Applied Mathematics, 1960, 1(2): 124-135 [6] GIBSON R E, SCHIFFMAN R L, PU S L. Plan strain and axially symmetric consolidation of a clay layer on a smooth impervious base[J]. Journal of Mechanical Applied Mathematics, 1970, 23(4): 256-264 [7] 黄文熙. 水坠坝的固结理论及其应用[J]. 水利学报, 1982(9): 13-23
HUANG Wen-xi. Application of consolidation theory to earth dams built by sluicing-siltation method[J]. Journal of Hydraulic Engineering, 1982(9): 13-23. (in Chinese))[8] 梅国雄, 夏 君, 梅 岭. 基于不对称连续排水边界的太沙基一维固结方程及其解答[J]. 岩土工程学报, 2011, 33(1): 28-31. (MEI Guo-xiong, XIA Jun, MEI Ling. Terzaghis one-dimensional consolidation equation and its solution based on asymmetric continuous drainage boundary[J]. Chinese Journal of Geotechnical Engineering, 2011, 33(1) [9] 郑 昱, 梅国雄, 梅 岭. 广义连续排水边界在一维固结问题中的应用[J]. 南京工业大学学报, 2010, 32(6): 55-58
ZHENG Yu, MEI Guo-xiong, MEI Ling. Generalized continuous drainage boundary applied in one dimensional consolidation theory[J]. Journal of Nanjing University of Technology, 2010, 32(6): 55-58. (in Chinese))[10] 黄文熙. 土的工程性质[M]. 北京: 水利电力出版, 1983 141-145. (HUANG Wen-xi. Engineering properties of soil[M]. Beijing: WaterResources and Electric Power Press, 1983 [11] 薛守义. 高等土力学[M]. 北京: 中国建材工业出版社, 2007: 193. (XUE Shou-yi. Advancd soil mechanics[M]. Beijing: ChinaBuilding Material Industry Publishing House, 2007 [12] 蔡 烽, 何利军, 周小鹏, 等. 连续排水边界下成层地基一维固结问题的有限元分析[J]. 中南大学学报, 2012, 12(6): 55-63
CAI Feng, HE Li-jun, Zhou Xiao-peng,,et al. Finite element analysis of one-dimensional consolidation problem with continuous drainage boundaries in layered ground[J]. Journal of Central south University, 2012, 12(6): 55-63. (in Chinese))[13] 罗 勇, 龚晓南, 连 峰. 成层地基固结性状中不同定义平均固结度研究分析[J]. 科技通报, 2006, 22(6): 813-816
LUO Yong, GONG Xiao-nan, LIAN Feng. Comparable analysis of different definitions of average degree of consolidation of layered soils[J]. Bulletin of Science and Technologys, 2006, 22(6): 813-816. (in Chinese)) -
