基于波速孔压静力触探试验计算软土中静压桩的 单桩极限承载力

曹 权; 施建勇; 雷国辉; 艾英钵

基于波速孔压静力触探试验计算软土中静压桩的单桩极限承载力 English Version

曹权^1,2,3,
施建勇^1,2,
雷国辉^1,2,
艾英钵^1,2

1. 河海大学岩土工程科学研究所，江苏南京 210098 ； 2. 岩土力学与堤坝工程教育部重点实验室，江苏南京 210098 ； 3. 深圳市市政设计研究院有限公司，广东深圳 518029

基金项目: 国家自然科学基金项目(50878075)

详细信息

作者简介:
曹权( 1970 – ) ，男，安徽安庆人，博士，高级工程师，主要从事土的原位测试研究。

中图分类号: TU470
计量
- 文章访问数: 1825
- HTML全文浏览量: 2
- PDF下载量: 653
出版历程
- 收稿日期: 2010-12-07
- 发布日期: 2012-01-19

Calculation of ultimate bearing capacity of jacked-in piles in soft soil based on seismic piezocone penetration tests

1. Geotechnical Engineering Institute, Hohai University, Nanjing 210098, China; 2. Key Laboratory of Ministry of Education for Geomechanics and Embankment Engineering, Hohai University, Nanjing 210098, China; 3. Shenzhen Municipal Design and Research Institute Co., Ltd., Shenzhen 518029, China )

摘要

摘要: 根据静力触探探头和静压桩贯入软土时的特点，采用柱孔扩张理论来模拟圆锥锥身和桩身贯入过程中应力场的变化，采用球孔扩张理论分析锥尖和桩端的挤土受力情况，推导出该条件下柱孔扩张和球孔扩张的极限扩孔压力理论解，在此基础上，对静力触探探头和静压桩进行受力对比分析，推导出利用波速孔压静力触探试验成果估算静压桩极限承载力的理论表达式。理论计算值与现场试验桩的静载荷试验结果较为吻合，说明该理论解具有一定的实用价值。
- 波速孔压静力触探试验 /
- 静压桩 /
- 饱和软黏土 /
- 小孔扩张理论 /
- 单桩极限承载力
Abstract: According to the characteristics of installation of seismic piezocone penetration testSCPTu) penetrometers and jacked-in piles, the penetration process is simulated by means of the cavity expansion theory. Based on this evaluation, the analytical solutions of the limit pressure of spherical and cylindrical cavities are presented. According to the analytical solutions and comparison of forces between SCPTu penetrometers and the piles, an analytical relationship between the data measured from SCPTu and the ultimate bearing capacity of a single pile is established. Compared with the axial load tests on a single pile in the field, the value of the new analytical solution which is used to predict the ultimate bearing capacity of jacked-in piles by utilizing the SCPTu data is verified.
- seismic piezocone penetration test /
- jacked-in pile /
- saturated soft clay /
- cavity expansion theory /
- ultimate bearing capacity of a single pile

HTML全文

参考文献(19)

[1]	BUSTAMANTE M, GIANESELLI L. Pile bearing capacity prediction by means of static penetrometer[C]// Proceedings, European Symposium on Penetration Testing, Vol.2, Amsterdam, The Netherlands, 1982: 493 – 500.
[2]	CUDMANI R, OSINOV V A. The cavity expansion problem for the interpretation of cone penetration and pressuremeter tests[J]. Canadian Geotechnical Journal, 2001, 386): 622 – 638.
[3]	WHITE D J. Field measurements of CPT and pile base resistance in sand[R]. Cambridge: University of Cambridge, 2003.
[4]	GUI M W, BOLTON M D. Geometry and scale effects in CPT and pile design [C]// Proc 1st Int Conf Site Characterization, Atlanta, 1998: 1063 – 1068.
[5]	ROY M, TREMBLAY M, TAVENAS F, et al. Development of pore pressures in quasi-static penetration tests in sensitive clay[J]. Canadian Geotechnical Journal, 1982, 191): 124 – 138.
[6]	叶观宝 , 汤竞 , 徐超 , 等 . 利用孔压静力触探试验估算沉桩过程中产生的超孔隙水压力 [J]. 工程力学 , 2005, 22 增刊 ): 194 – 198.YE Guan-bao, TANG Jing, XU Chao, et al. Estimation of excess porewater pressure during pile instalition by piezocone test[J]. Engineering Mechanics, 2005, 22S0): 194 – 198.in Chinese))
[7]	ESLAMI A, FELLENIUS B H. Pile capacity by direct CPT and CPTu methods applied to 102 case histories [J]. Canadian Geotechnical Journal, 1997, 346): 886 – 904.
[8]	TAKESUE K, SASAKI H, MATSUMOTO T. Correlation between ultimate pile skin friction and CPT data[C]// Geotechnical Site Characterization proceedings ISC’98, Atlanta, 1998: 1177 – 1182.
[9]	曹权 . 基于孔压静力触探试验（ SCPTu ）研究软土中静压桩的承载力性状 [D]. 南京 : 河海大学 , 2010.CAO Quan. Research on characteristics of bearing capacity of jacked-in pile in soft soil based on seismic piezocone penetration tests(SCPTu) [D]. Nanjing: Hohai University, 2010.in Chinese))
[10]	BISHOP R F, HILL R, MOTT N F. The theory of indentation and hardness tests[C]// Proc Phys Soc, 1945: 147 – 159.
[11]	GIBSON R E, Discussion of G. Wilson, the bearing capacity of screw piles and screwcrete cylinders[J]. Journal of the Institution of Civil Engineers, 1950, 34 : 382.
[12]	LADANYI B, EDEN W J. Use of the deep penetration test in sensitive clays[C]// Proc 7th International Conference on Soil Mechanics and Foundation Engineering, Mexico, 1969: 225 – 230.
[13]	KONRAD J M, LAW K T. Undrained shear strength from piezocone test[J]. Canadian Geotechnical Journal, 1987, 246): 392 – 405.
[14]	POTYONDY J G. Skin friction between various soils and construction materials[J]. Géotechnique, 1961, 114): 339 – 353.
[15]	BOZOZUK M, KEENAN G H, PHEENEY P E. Analysis of load tests on instrumented steel test piles in compressible silty soil[C]// Behavior of deep foundations, American Society for Testing and Materials, Special Technical Publication 670, 1979: 153 – 180.
[16]	ROY M, TREMBLAY M, TAVENAS F, et al. Development of pore pressures in quasistatic penetration tests in sensitive clay[J]. Canadian Geotechnical Journal, 1982, 193): 124 – 138.
[17]	MAY R E. A study of the piezocone penetrometer in normally consolidated clay[D]. Oxford: Oxford University, 1987.
[18]	RANDOLPH M F. Science and empiricism in pile foundation design[J]. Géotechnique, 2003, 5310): 847 – 875.
[19]	JGJ 94 — 2008 建筑桩基技术规范 [S]. 2008.JGJ 94 — 2008 Technical code for building pile foundations[S]. 2008.in Chinese))
