    干湿循环过程中膨胀土的胀缩变形特征

    唐朝生, 施斌

    唐朝生, 施斌. 干湿循环过程中膨胀土的胀缩变形特征[J]. 岩土工程学报, 2011, 33(9): 1376-1384.
    引用本文: 唐朝生, 施斌. 干湿循环过程中膨胀土的胀缩变形特征[J]. 岩土工程学报, 2011, 33(9): 1376-1384.
    shu
    TANG Chao-sheng, SHI Bin. Swelling and shrinkage behaviour of expansive soil during wetting-drying cycles[J]. Chinese Journal of Geotechnical Engineering, 2011, 33(9): 1376-1384.
    Citation: TANG Chao-sheng, SHI Bin. Swelling and shrinkage behaviour of expansive soil during wetting-drying cycles[J]. Chinese Journal of Geotechnical Engineering, 2011, 33(9): 1376-1384.
    shu

    干湿循环过程中膨胀土的胀缩变形特征  English Version

    • 南京大学地球科学与工程学院，江苏 南京 210093

    基金项目: 国家自然科学基金项目（41072211）；高等学校博士学科点专项科研基金项目（新教师基金课题）(20090091120037)；国家自然科学基金重点项目（40730739）
    详细信息
      作者简介:

      唐朝生 (1980 – ) ，男，湖南衡阳人，博士 ，副教授，主要从事环境岩土工程和工程地质方面的教学和研究工作。

    • 中图分类号: TU443

    Swelling and shrinkage behaviour of expansive soil during wetting-drying cycles

    • (School of Earth Sciences and Engineering, Nanjing University, Nanjing 210093, China)

    摘要

      摘要
    • 摘要: 为了了解干湿循环过程中膨胀土的胀缩变形特征，分别开展了两组干湿循环试验。在控制吸力干湿循环试验中，吸力控制范围为 0.4 ～ 262 MPa ，采用了两种吸力控制方法，分别为渗析法（吸力＜ 4 MPa ）和蒸汽平衡法（吸力＞ 4 MPa ），当每一级吸力达到平衡时，测量试样对应的含水率和体积；在常规干湿循环试验中， 采取了两种干缩路径，分别为全干燥和部分干燥，并测量试样在每次干湿循环过程中的轴向变形及循环结束后的含水率。结果表明： 在脱湿和吸湿过程中，试样孔隙比随吸力变化可分 3 个典型阶段：大幅变化阶段（ 0.4 ～ 9 MPa ）、过渡阶段（ 9 ～ 82 MPa ）和平缓阶段（ 82 ～ 262 MPa ）； 当吸力大于 113 MPa 时，试样的胀缩变形基本可逆，而当吸力小于 113 MPa 时，试样的胀缩变形 表现出明显的不可逆性，且不可逆程度随吸力的减小而增加。试样在常规干湿循环过程中的胀缩变形随循环次数的增加逐渐趋于稳定；胀缩特征受干缩路径的影响非常明显，全干缩路径中测得的膨胀率高于部分干缩路径，膨胀速率随干湿循环次数的增加而增加；试样在干湿循环过程中的膨胀率大小在一定程度上取决于吸湿能力。
      Abstract: Two groups of laboratory cyclic wetting-drying tests are conducted on expansive soil to study the swelling and shrinkage behaviour. In suction-controlled wetting-drying tests, two suction control methods are used: the osmotic method for low suction range (0.4 ～ 4 MPa) and the vapor equilibrium technique for high suction range (4 ～ 262 MPa). At each suction level, water content and volume of soil specimen are determined after equilibrium is reached. In conventional wetting-drying tests, soil specimen is allowed to swell , and either shrinks fully or partially to the initial height in each cycle. Simultaneously, axial deformation is measured. After each cycle, the water content of specimen is also assessed. The results show that the void ratio of specimen varies with the suction in three typical stages in both drying and wetting paths, i.e., sharp variation stage (0.4 ～ 9 MPa), transition stage (9 ～ 82 MPa) and peace stage (82 ～ 262 MPa). The reversibility in the swelling and shrinkage deformation is found when the suction is higher than 113 MPa, but significant hysteresis is observed as the suction is lower than 113 MPa and the hysteresis extent increases with decreasing suction. In conventional wetting-drying tests, it is observed that the swelling and shrinkage behaviour gradually reaches equilibrium with increasing cycles and is significantly influenced by shrinkage pattern. The measured swelling potential of specimen subjected to full shrinkage cycle is higher than that of specimen subjected to partial shrinkage cycle. Swelling velocity increase with the increase of the wetting-drying cycle is noted when the specimen fully shrinks. Generally speaking, the swelling ability of specimen in wetting-drying cycle significantly depends on water absorption capability.
      • HTML全文
      • 参考文献(29)
    • [1] 刘祖德 , 孔官瑞 . 平面应变条件下膨胀土卸荷变形试验研究 [J]. 岩土工程学报 , 1993, 15 (2): 68 – 73. (LIU Zu-de, KONG Guan-rui. Study on unloading deformation of expansive soil under plane strain condition[J]. Chinese Journal of Geotechnical Engineering, 1993, 15 (2): 68 – 73. (in Chinese))
      [2] 卢再华 , 陈正汉 , 蒲毅彬 . 膨胀土干湿循环胀缩裂隙演化的 CT 试验研究 [J]. 岩土力学 , 2002, 23 (4): 417 – 422. (LU Zai-hua, CHEN Zheng-han, PU Yi-bin. A CT study on the crack evolution of expansive soil during drying and wetting cycles[J]. Rock and Soil Mechanics, 2002, 23 (4): 417 – 422. (in Chinese))
      [3] ALBRECHT B A, BENSON C H. Effect of desiccation on compacted natural clay [J] . Journal of Geotechnical and Geoenvironmental Engineering, 2001, 127 (1): 67 – 75.
      [4] 杨和平 , 张 锐 , 郑健龙 . 有荷条件下膨胀土的干湿循环胀缩变形及强度变化规律 [J]. 岩土工程学报 , 2006, 28 (11): 1936 – 1941. (YANG He-ping, ZHANG Rui, ZHENG Jian-Long. Variation of deformation and strength of expansive soil during cyclic wetting and drying under loading condition[J]. Chinese Journal of Geotechnical Engineering, 2006, 28 (11): 1936 – 1941. (in Chinese))
      [5] OSIPOV V I, BIK N N. RUMJANTSEVA N A. Cyclic swelling of clays[J]. Appl Clay Sci, 1987, 2 (7): 363 – 374.
      [6] DAY R W. Swell-shrink behavior of compacted clay[J]. ASCE, J Geotech Eng Div, 1994, 120 (3): 618 – 623.
      [7] 刘松玉 , 季 鹏 , 方 磊 . 击实膨胀土的循环膨胀特性研究 [J]. 岩土工程学报 , 1999, 21 (1): 9 – 13. (LIU Song-yu, JI Peng, FANG Lei. Approach to cyclic swelling behavior of compacted expansive clays[J]. Chinese Journal of Geotechnical Engineering, 1999, 21 (1): 9 – 13. (in Chinese))
      [8] BASMA A A, AL-HOMOUD A S, MALKAWI A I H, AL-BASHABSHEH M A. Swelling-shrinkage behavior of natural expansive clays[J]. Applied Clay Science, 1996, 11 : 211 – 227.
      [9] DIF A E, BLUMEL W F. Expansive soils under cyclic drying and wetting[J]. Geotechnical Testing Journal, 1991, 14 : 96 – 102.
      [10] ALONSO E E, ROMERO E, HOFFMANN C, et al. Expansive bentonite/sand mixtures in cyclic controlled suction drying and wetting[J]. Engineering Geology, 2005, 81 : 213 – 226.
      [11] ALONSO E E. Modelling expansive soil behaviour[C]// Proceedings of 2nd International Conference On Unsaturated Soils. Beijing, 1998, 2 : 37 – 70.
      [12] LEONG E C, HE L, RAHARDJO H. Factors affecting the filter paper method for total and matric suction measurements[J]. Geotechnical Testing Journal, 2002, 25 (3): 1 – 11.
      [13] LAGERWERFF J V, OGATA G, EAGLE H E. Control of osmotic pressure of culture solutions with polyethylene glycol [J]. Science, 1961, 133 : 1486 – 1487.
      [14] KASSIF G, BEN SHALOM A. Experimental relationship between swell pressure and suction[J]. Géotechnique , 1971, 21 (3): 245 – 255.
      [15] DELAGE P, SILVA S D, LAURE G P R D. Un nouvel appareil triaxial pour les sols nonsatures[C]// Proceedings of the 9th European Conference on soil mechanics and foundation Engineering. Dublin, 1987, 1 : 25 – 28.
      [16] TARANTINO A. MONGIOVI L. A study of the efficiency of semipermeable membranes in controlling soil matrix suction using the osmotic technique[C]// Unsaturated Soils for Asia, 303-308, Toll and Leong eds, Balkema, 2000.
      [17] CUISINIER O. MASROURI F. Hydromechanical behaviour of a compacted swelling soil over a wide suction range[J]. Engineering Geology, 2005, 81 : 204 – 212.
      [18] MONROY R, RIDLEY A, DINEEN K, ZDRAKOVIC L. The suitability of osmotic technique for the long term testing of partly saturated soils[J]. Geotechnical Testing Journal, 2007, 30 (3): 220 – 226.
      [19] 叶为民 , 唐益群 , 崔玉军 . 室内吸力量测与上海软土土水特征 [J]. 岩土工程学报 , 2005, 27 (3): 347 – 349. (YE Wei-ming, TANG Yi-qun, CUI Yu-jun. Measurement of soil suction in laboratory and soil-water characteristics of Shanghai soft soil[J]. Chinese Journal of Geotechnical Engineering, 2005, 27 (3): 347 – 349. (in Chinese))
      [20] DELAGE P, CUI Y J. An evaluation of the osmotic method of controlling suction[J]. Geomechanics and Geoengineering, 2008, 3 (1): 1 – 11.
      [21] PERON H, HUECKEL T, LALOUI L. An improved volume measurement for determining soil water retention curve [J] . Geotechnical Testing Journal, 2007, 30 (1): 1 – 7.
      [22] DELAGE P, HOWAT M, CUI Y J. The relationship between suction and swelling properties in a heavily compacted unsaturated clay[J]. Engineering Geology, 1998, 50 (1-2): 34 – 48.
      [23] TANG A M, CUI Y J. Controlling suction by the vapour equilibrium technique at different temperatures and its application in determining the water retention properties of MX80 clay [J] . Canadian Geotechnical Journal, 2005, 42 (1): 287 – 296.
      [24] 栾茂田 , 汪东林 , 杨 庆 , 等 . 非饱和重塑土的干燥收缩试验研究 [J]. 岩土工程学报 , 2008, 30 (1): 118 – 122. (LUAN Mao-tian, WANG Dong-lin, YANG Qing, et al. Experimental study on drying shrinkage of unsaturated compacted soils[J]. Chinese Journal of Geotechnical Engineering Journal, 2008, 30 (1): 118 – 122. (in Chinese))
      [25] CUI Y J, MANTHO A T, CUI K, AUDIGUIER M. Water retention properties and volume change behaviour of natural Romainville clay[C]// Proc of the 3rd International Conference on Unstaturated Soils UNSAT2006. 2006: 873 – 882.
      [26] CUI Y J, LOISEAU C, DELAGE P. Microstructure changes of a confined swelling soil due to suction controlled hydration[C]// Proc of the 3rd International Conference on Unstaturated Soils UNSAT2002. Recife, 2002, 2 : 593 – 589.
      [27] CORNELIS W M, CORLUY J, MEDINA H, et al. Measuring and modeling the soil shrinkage characteristic curve[J]. Geoderma, 2006, 137 : 179 – 191.
      [28] VILLAR M V, LLORET A. Influence of dry density and water content on the swelling of a compacted bentonite[J]. Applied Clay Science, 2008, 39 : 38 – 49.
      [29] ZEMENU G, MARTINE A, ROGER C. Analysis of the behaviour of a natural expansive soil under cyclic drying and wetting[J]. Bull Eng Geol Environ, 2009, 68 : 421 – 436.
