隧道岩溶溃水延滞性特征分析及其安全风险规避

刘新荣, 张旭东, 黄明

刘新荣, 张旭东, 黄明. 隧道岩溶溃水延滞性特征分析及其安全风险规避[J]. 岩土工程学报, 2011, 33(9): 1326-1332.
引用本文: 刘新荣, 张旭东, 黄明. 隧道岩溶溃水延滞性特征分析及其安全风险规避[J]. 岩土工程学报, 2011, 33(9): 1326-1332.
shu
LIU Xin-rong, ZHANG Xu-dong, HUANG Ming. Delay characteristics and risk mitigation of karst water burst flood of tunnels[J]. Chinese Journal of Geotechnical Engineering, 2011, 33(9): 1326-1332.
Citation: LIU Xin-rong, ZHANG Xu-dong, HUANG Ming. Delay characteristics and risk mitigation of karst water burst flood of tunnels[J]. Chinese Journal of Geotechnical Engineering, 2011, 33(9): 1326-1332.
shu

隧道岩溶溃水延滞性特征分析及其安全风险规避  English Version

  • 1. 重庆大学土木工程学院，重庆 400045 ； 2. 福州大学土木工程学院，福建 福州 350108

基金项目: 国家自然科学基金李晓红创新群体项目 （ 50621403 ）；福州大学校人才基金项目（ 022356 ）
详细信息
    作者简介:

    刘新荣 (1969 – ) ，男，浙江开化人，博士，教授，主要从事岩土工程、地下空间与工程等领域的教学与科研工作。

  • 中图分类号: U45

Delay characteristics and risk mitigation of karst water burst flood of tunnels

  • (1. College of Civil Engineering, Chongqing University, Chongqing 400045, China; 2. College of Civil Engineering, Fuzhou University, Fuzhou 350108, China)

摘要

    摘要
  • 摘要: 通过对宜万铁路马鹿箐隧道多达 19 次的突涌水数据统计和现象分析，总结提出了“岩溶溃水”的概念，通过对各个施工阶段溃水特征分析表明岩溶溃水还具有延滞性特征。通过对溃水发生的时程分析，得到溶腔溃水延滞性形成的机理为溶隙、脉管及填充物由于压力差从渗流扩大呈汇流，袭夺周围脉管和溶隙的地下水，溶腔地下水潜蚀充填物封堵，最后集中释放；分析得到溃水延滞性的主要影响因素为溶腔内蓄积的水量和达到瞬间疏通的临界水压条件，以及溶腔内水流通道的淤塞条件；研究表明，对大气补给的响应，溃水延滞时间有不断缩短的规律，据此可判断隧道溃水可能性将不断减小；结合降雨量、涌水量和水位观测成果，基于降雨入渗法和统计分析法预测得到的溶腔涌水量结果，提出了抢险和泄水期间的安全作业控制指标。
    Abstract: Based on field tests on 19 groups of data and phenomenon analysis of inrush or bursting waste from karst cavity of Maluqing tunnel of Yichang-Wanxian Railway, a conceptual model of karst water burst flood (KWBF) is proposed by means of statistical analysis and phenomenological induction. Through analyzing its characteristics during different construction stages, it is shown that KWBF has the delay characteristics. The time history analysis of the karst water burst flood shows that because of pressure dispersion between inside and outside of the cavity, seepage enlargement is evolved into conflux so as to deprive groundwater from aquifer aqueduct and fracture, and the water together with mud suddenly releases from karst into the tunnel. The key factor for the delay characteristic of KWBF is water amount and silt or filling degree of conflux aqueduct. The delay time of KWBF on supply air continuously reduces the response time, according to which the possibility of KWBF is reduced. Forecasting of KWBF is conducted by use of the rainfall seeping theory and statistical analysis method. The basic data are obtained from field quantity observation such as rainfall and hydrograph measurement. The control index of safe operation during the rescue and discharge period is proposed.
    • HTML全文
    • 参考文献(15)
  • [1] 任旭华 , 陈祥荣 , 单治钢 . 富水区深埋长隧洞工程中的主要水问题及对策 [J]. 岩石力学与工程学报 , 2004, 23 (11): 1924 – 1929. (REN Xu-hua, CHEN Xiang-rong, SHAN Zhi-gang. Water problems and corresponding countermeasures in projects of deep-lying long tunnels located in water-enriched regions[J]. Chinese Journal of Rock Mechanics and Engineering, 2004, 23 (11): 1924 – 1929. (in Chinese))
    [2] WILLIAM B White. Conceptual models for karstic aquifers[J]. Speleogenesis and Environment of Karst Aquifers, 2003, 1 (1): 11 – 16.
    [3] LAURENT Eisenloht, MAHMOUD Bouzelboudjen, LASZLO Kiraly. Numerical versus statistical modeling of natureal response of a karst hydrogeological system[J]. J Hydrology, 1997(202): 244 – 262.
    [4] 林传年 , 李利平 , 韩行瑞 . 复杂岩溶地区隧道涌水预测方法研究 [J]. 岩石力学与工程学报 , 2008, 27 (7): 1469 – 1476. (LIN Chuan-nian, LI Li-ping, HAN Xing-rui. Research on forecast method of tunnel water inrush in complex karst areas[J]. Chinese Journal of Rock Mechanics and Engineering, 2008, 27 (7): 1469 – 1476. (in Chinese))
    [5] 蒙 彦 , 雷明堂 . 岩溶区隧道涌水研究现状及建议 [J]. 中国岩溶 , 2003, 22 (4): 287 – 292. (MENG Yan, LEI Ming-tang. The advance and suggestion for the study on discharge rate in karst tunnel gushing[J]. Carsologica Sinica, 2003, 22 (4): 287 – 292. (in Chinese))
    [6] 徐国峰 , 杨建峰 , 陈侃福 . 台缙高速公路苍岭隧道水文地质勘察与涌水量预测 [J]. 岩石力学与工程学报 , 2005, 24 ( 增刊 2): 5531 – 5542. (XU Guo-feng, YANG Jian-feng, CHEN Kan-fu. Surveying of hydrogeology condition and forecasting of water inflow in Cangling tunnel Taizhou—Jinyun highway[J]. Chinese Journal of Rock Mechanics and Engineering, 2005, 24 (S2): 5531 – 5542. (in Chinese)).
    [7] 李兴高 , 刘维宁 , 张昀青 . 隧道渗涌水量的随机模型预测 [J]. 中国安全科学学报 , 2002, 12 (4): 60 – 64. (LI Xing-gao, LIU Wei-ning, ZHANG Yun-qing. Predicting the amount of water inflow in tunnel by stationary random model[J]. China Safety Science Journal, 2002, 12 (4): 60 – 64. (in Chinese))
    [8] 叶志华 , 韩行瑞 , 张高朝 , 等 . 隧道岩溶涌水专家评判系统在朱家岩隧道涌水预报中的应用 [J]. 中国岩溶 , 2006, 25 (2): 139 – 145. (YE Zhi-hua, HAN Xing-rui, ZHANG Gao-chao, et al. Application of expert’s judging system to predicting karst water bursting in Zhujiayan tunnel[J]. Carsologica Sinica, 2006, 25 (2): 139 – 145. (in Chinese))
    [9] 王建秀 , 杨立中 , 何 静 . 深埋隧道涌水量数值计算中的试算流量法 [J]. 岩石力学与工程学报 , 2002, 21 (12): 1776 – 1780. (WANG Jian-xiu, YANG Li-zhong, HE Jing. Trial method for simulating tunnel discharge[J]. Chinese Journal of Rock Mechanics and Engineering, 2002, 21 (12): 1776 – 1780. (in Chinese))
    [10] 李苍松 , 何发亮 , 陈成宗 . 渝怀线武隆隧道岩溶涌水量计算新方法 [J]. 中国铁道科学 , 2005, 26 (5): 41 – 46. (LI Cang-song, HE Fa-liang, CHEN Cheng-zong. New calculation method of water inflow quantity in Wulong tunnel on Chongqing-Huaihua Railway[J]. China Railway Science, 2005, 26 (5): 41 – 46. (in Chinese))
    [11] 刘招伟 . 圆梁山隧道岩溶突水机理及其防治对策 [D]. 北京 : 中国地质大学 , 2004. (LIU Zhao-wei. Karst waterburst mechanism and prevention countermeasures in Yuanliangshan tunnel[D]. Beijing: China University of Geosciences, 2004. (in Chinese))
    [12] 邹成杰 . 水利水电岩溶工程地质 [M]. 北京 : 水利水电出版社 , 1994. (ZOU Cheng-jie. Karst geology engineering in hydropower project[M]. Beijing: Water Resources and Hydropower Press, 1994 (in Chinese))
    [13] ZHANG L L, FRANKLIN A. Prediction of water flowinto rock tunnels:an analytical solution assuming an hydraulic conductivity gradient[J]. Int J Rock Mech Min Sci Geomech Abstr, 1993, 30 (1): 37 – 46.
    [14] 金新锋 , 夏日元 , 梁 彬 . 宜万铁路马鹿箐隧道岩溶突水来源分析 [J]. 水文地质工程地质 , 2007, 2: 71 – 75. (JIN Xin-feng, XIA Ri-yuan, LIANG Bin. Analysis of bursting water source of Maluqing tunnel[J]. Yichang-Wanzhou Railway, 2007, 2: 71 – 75. (in Chinese))
    [15] 铁道第四勘察设计院 . 宜万铁路宜昌至万州段新建工程施工图 —— 马鹿箐隧道设计图 [R]. 武汉 : 2004. ( Fourth Survey and Design Institute of Railway. New construction drawings of Yichang-Wanzhou section in Yichang-Wanzhou Railway ——design drawings of Maluqing tunnel[R]. Wuhan: 2004. (in Chinese))
