柔性聚合物砂浆物理力学与密封性能研究

    Study on physical-mechanical and sealing performance of flexible polymer mortar

    • 摘要: 密封技术是压缩空气储能(compressed air energy storage, CAES)人工硐室储气库建设的关键技术之一,其密封材料的选择至关重要。为了验证聚氨酯类聚合物砂浆(polyurethane polymer mortar,PPM)作为CAES人工硐室储气库密封材料的可行性,对PPM进行了气体渗透性试验和力学试验,分析其气密性能和强度与变形性能,并利用FLAC3D软件分析了PPM密封层结构的受力特性与气体泄漏率。结果表明:PPM具有极佳的气密性能,其本质渗透率量级可达到10-20~10-22 m2,可满足CAES密封层的密封要求。PPM的拉伸性能优异,弹性模量低,变形能力强,与混凝土之间具有自黏能力。当PPM本质渗透率为10-19 m2时,储气库渗漏量为0.215%,满足1 d内空气质量允许泄漏率的要求。由于PPM的弹性模量低,使得PPM密封层的计算环向应力均表现为压应力;最大环向拉应变仅有1.15%~1.20%,远小于其极限拉伸应变,可有效防治密封层产生拉伸破坏。由此可见,PPM在气渗和力学指标上均可满足CAES密封材料的性能要求。



      Abstract: Sealing technology is crucial in developing compressed air energy storage (CAES) man-made cavern power plants, and the selection of sealing materials is paramount. To verify the feasibility of polyurethane polymer mortar (PPM) as a sealing material for CAES man-made cavern, experiments on gas permeability and mechanical properties are conducted on PPM. Additionally, numerical simulations using FLAC3D are performed to analyze the PPM sealing layer's structural stress characteristics and leakage rate. The results indicate that PPM has excellent gas-tightness performance, with gas permeability on the order of 10-20~10-22 m2, which satisfies the sealing requirements of the CAES sealing layer. PPM has excellent tensile properties, low elastic modulus, high deformation capacity, and self-bonding ability with concrete. When the PPM intrinsic permeability is 10-19 m2, the leakage rate of man-made cavern is 0.215%, which meets the permissible air quality leakage rate requirement within one day. Due to the low elastic modulus of PPM, the calculated hoop stresses of the PPM sealing layer are all compressive stresses, and the maximum hoop tensile strain is only 1.15%~1.20%, which is much smaller than its ultimate tensile strain, thus avoiding tensile failure of the sealing layer. Therefore, PPM can meet the requirements of CAES sealing material in terms of gas permeability and mechanical indices.



    /
