土工膜防渗水库渗漏的数值模拟方法研究

    Numerical simulation methods for leakage in reservoirs with geomembrane seepage control

    • 摘要: 渗漏是水库运维安全的关键性影响因素,而关于土工膜缺陷渗漏的研究水平尚处于试验阶段,未见有报道土工膜防渗水库缺陷渗漏数值模拟方法方面的研究成果。首先,阐述土工膜缺陷渗漏的研究难点,并根据土工膜缺陷渗流特征,提出将缺陷土工膜及其接触层作为防渗层(简称缺陷土工膜防渗层)的反分析模拟方法;然后,基于1360 d的西夏水库渗漏监测数据,建立水库三维土工膜缺陷渗流模型,对西夏水库的10个运行过程反演缺陷土工膜防渗层等效渗透系数。结果验证表明,研究方法合理,并且揭示了随着西夏水库向动态高库水位运行,缺陷土工膜防渗层的等效渗透系数有降低、升高及稳定3个阶段,符合土工膜下粗粒土的渗透变形规律,与土工膜下监测点的渗压及渗压降的3个阶段对应。研究成果为土工膜防渗水库安全运营评价提供技术支撑。



      Abstract: Leakage significantly impacts the operational and maintenance safety of reservoirs. The existing researches on the leakage due to defective geomembranes remain at experimental stage, with limited exploration of numerical simulation methods specifically focused on impermeable reservoirs with defective geomembranes. Many challenges associated with geomembrane defective seepage were elaborated upon. Based on the characteristics of seepage through defective geomembranes, an inverse simulation method was proposed, which uses the defective geomembrane and its contact layer as the seepage control layer, termed the impermeable layer with defective geomembranes. Based on the monitoring data of leakage in the Xixia Reservoir over a period of 1360 days, a three-dimensional seepage model of the impermeable reservoir with defective geomembranes was developed. The equivalent permeability coefficients of impermeable layer with defective geomembranes were back-calcualted and validated using data from ten operational periods of the Xixia Reservoir. The validation showed that the research method was reasonable and revealed that with the operation of the reservoir to the dynamic high reservoir level, the equivalent permeability coefficient of the impermeable layer with the defective geomembrane consists of three phases of decreasing, increasing and stabilizing, which was in line with the law of infiltration and deformation of coarse-grained soil under the geomembrane and corresponded to the three phases of the seepage pressure and the seepage pressure drop in the monitoring points under the geomembrane. Research resulted provide technical support for the evaluation of safe operation of geomembrane impermeable reservoirs.



    /
