Thermal infrared precursor information of crack propagation for rock bridges
-
摘要: 由于岩质边坡内部锁固段岩桥应力聚集较高,含节理的岩质边坡易发生突发性失稳。对含不同岩桥长度花岗岩试件开展单轴试验,采用红外热像仪全程监测,研究岩质边坡破裂前的热红外热像和温度变化特征,并借助声发射和高速摄像机分析裂纹开展源、裂纹扩展趋势、声发射特征及演变机制。研究表明：岩桥试件破裂前存在两种热红外前兆,未来破裂处热像异常前兆和热红外平均温度-时间曲线异常;热红外前兆出现时间提前于声发射前兆,随着岩桥长度的增加,热红外前兆提前性变得更为突出;下部预制节理裂隙尖端处的热像变化可以预测未来裂纹扩展方向,定位表面裂纹开展源头;利用断裂力学应变能密度因子理论,揭示了单轴应力状态下岩桥长度对起裂扩展的影响机制。热红外前兆相较于其他前兆形式更提前可靠,采用红外热像仪监测岩桥试件破裂前的变化特征,研究结果为节理岩质边坡的防治提供理论依据。Abstract: Due to the high stress accumulation in the rock bridge of its locked section, the rock slope with joints is prone to sudden instability. The uniaxial tests are carried out on the granite specimens with different rock bridge lengths. By full use of infrared camera monitoring, the thermal infrared images and temperature variation characteristics before rock burst are studied, and the acoustic emission and high-speed cameras are used to analyze the crack propagation sources, crack propagation trend, acoustic emission characteristics and evolution mechanism. It is discovered from the experimental study that there are two types of thermal infrared precursors before fracture of the rock bridge specimens, anomalous thermal image precursor and thermal infrared ones, and with the increase in the length of the rock bridges, the thermal infrared precursors become more prominent. The variation in thermal images at the tip of the lower prefabricated joints can be used to predict future crack propagation directions and to locate the origin of surface cracks. Using the strain energy density factor theory of fracture mechanics, the influence mechanism of rock bridge lengths on initiation crack propagation under uniaxial stress is revealed. The thermal infrared precursors are more reliable than other precursors by using the infrared thermal imager to monitor the variation characteristics of rock bridge specimens before fracture. The research results may provide a theoretical basis for the prevention and control of jointed rock slopes.
-
Keywords:
- rock bridge /
- TIR precursor /
- acoustic emission /
- crack propagation /
- strain energy density
-
[1] 杜坤. 真三轴卸载下深部岩体破裂特性及诱发型岩爆机理研究[D]. 长沙: 中南大学, 2013.
(DU Kun.Study on the failure characteristics of deep rock and the mechanism of strainburst under true triaxial unloading condition[D]. Changsha: Central South University, 2013. (in Chinese))[2] 刘善军, 吴立新, 王川婴, 等. 遥感-岩石力学(VIII) ——论岩石破裂的热红外前兆[J]. 岩石力学与工程学报, 2004, 23(10): 1621-1627.
(LIU Shan-jun, WU Li-xin, WANG Chuan-ying, et al.Remote sensing-rock mechanics (VIII)——TIR omens of rock fracturing[J]. Chinese Journal of Rock Mechanics and Engineering, 2004, 23(10): 1621-1627. (in Chinese))[3] 崔承禹, 邓明德, 耿乃光. 在不同压力下岩石光谱辐射特性研究[J]. 科学通报, 1993, 38(6): 538-541.
(CUI Cheng-yu, DENG Ming-de, GENG Nai-guang.Study on spectral radiation characteristics of rock under different pressures[J]. Chinese Science Bulletin, 1993, 38(6): 538-541. (in Chinese))[4] 吴立新, 刘善军, 吴育华, 等. 遥感-岩石力学(II) ——断层双剪黏滑的热红外辐射规律及其构造地震前兆意义[J]. 岩石力学与工程学报, 2004, 23(2): 192-198.
(WU Li-xin, LIU Shan-jun, WU Yu-hua, et al.Remote sensing-rock mechanics (II) ——Laws of thermalinfrared radiation from viscosity-sliding of bi-shearedfaults and its meanings for tectonic earthquake omens[J]. Chinese Journal of Rock Mechanics and Engineering, 2004, 23(2): 192-198. (in Chinese))[5] 吴立新, 刘善军, 许向红, 等. 遥感-岩石力学(III)——交汇断层黏滑的热红外辐射与声发射规律及其构造地震前兆意义[J]. 岩石力学与工程学报, 2004, 23(3): 401-407.
(WU Li-xin, LIU Shan-jun, XU Xiang-hong, et al.Remote sensing-rock mechanics (III) ——Laws of thermalinfrared radiation and acoustic emission from friction sliding intersected faults and its meanings for tectonic earthquake omens[J]. Chinese Journal of Rock Mechanics and Engineering, 2004, 23(3): 401-407. (in Chinese))[6] 钟美娇, 张元生, 张璇. 祁连山地震带中强地震前热红外异常研究[J]. 地震工程学报, 2015, 37(4): 1073-1076.
(ZHONG Mei-jiao, ZHANG Yuan-sheng, ZHANG Xuan.Analysis of thermal infrared anomaly in Gansu Jingta Ms4.7 Earthquake on March 21,2016[J]. China Earthquake Engineering Journal, 2015, 37(4): 1073-1076. (in Chinese))[7] 谷中元, 周科平. 单轴循环加载下花岗岩力学特征及红外分析[J]. 中国安全生产科学技术, 2018, 14(8): 146-151.
(GU Zhong-yuan, ZHOU Ke-ping.Mechanical properties and infrared analysis of granite under uniaxial cyclic loading[J]. Journal of Sagely Science and Technology, 2018, 14(8): 146-151. (in Chinese))[8] 周子龙, 熊成, 蔡鑫, 等. 单轴载荷下不同含水率砂岩力学和红外辐射特征[J]. 中南大学学报(自然科学版), 2018, 49(5): 1189-1196.
(ZHOU Zi-long, XIONG Cheng, CAI Xin, et al.Mechanical and infrared radiation properties of sandstone with different water contents under uniaxial compression[J]. Journal of Central South University (Science and Technology), 2018, 49(5): 1189-1196. (in Chinese))[9] 陈智强, 张永兴, 周检英. 开挖诱发隧道围岩变形的红外热像试验研究[J]. 岩土工程学报, 2012, 34(7): 1271-1277.
(CHENG Zhi-qiang, ZHANG Yong-xing, ZHOU Jian-ying.Experimental study on infrared photographs of deformation and failure of surrounding rock of tunnels procession induced by excavation[J]. Chinese Journal of Geotechnical Engineering, 2012, 34(7): 1271-1277. (in Chinese))[10] THOMSON W. On the dynamical theory of heat[J]. Trans R Soc Edinburgh, 1853, 20: 83-261. [11] PALANISWAMY K, KNAUSS W G.Propagation of a crack under general, in-plane tension[J]. International Journal of Fracture Mechanics, 1972, 8(1): 114-117. [12] BARONE S, PATTERSON E A.The development of simultaneousthermo-and photo-elasticity for principal stress analyses[J]. Strain, 1999, 35(2): 57-65. [13] 陈国庆, 刘顶, 徐鹏, 等. 节理岩桥真三轴开挖卸荷试验研究[J]. 岩石力学与工程学报, 2018, 37(增刊): 1-14.
(CHEN Guo-qing, LIU Ding, XU Peng, et al.Unloading failure of joint rock bridge by true-triaxial test[J]. Chinese Journal of Rock Mechanics and Engineering, 2018, 37(S0): 1-14. (in Chinese))[14] 李世愚, 和泰名, 尹祥础, 等. 岩石断裂力学导论[M]. 合肥: 中国科学技术大学出版社, 2010.
(LI Shi-yu, HE Tai-ming, YIN Xiang-chu, et al.Introduction to rock fracture mechanics[M]. Hefei: University of Science and Technology of China Press, 2010. (in Chinese)) -
