基于3D-ILC含不同角度内裂纹圆盘断裂特性研究

王海军, 张九丹, 任然, 汤雷, 郁舒阳, 钟凌伟, 张珂

王海军, 张九丹, 任然, 汤雷, 郁舒阳, 钟凌伟, 张珂. 基于3D-ILC含不同角度内裂纹圆盘断裂特性研究[J]. 岩土工程学报, 2019, 41(9): 1636-1644. DOI: 10.11779/CJGE201909007
引用本文: 王海军, 张九丹, 任然, 汤雷, 郁舒阳, 钟凌伟, 张珂. 基于3D-ILC含不同角度内裂纹圆盘断裂特性研究[J]. 岩土工程学报, 2019, 41(9): 1636-1644. DOI: 10.11779/CJGE201909007
WANG Hai-jun, ZHANG Jiu-dan, REN Ran, TANG Lei, YU Shu-yang, ZHONG Ling-wei, ZHANG Ke. Fracture characteristics of Brazilian disc with fully internal cracks based on 3D-ILC[J]. Chinese Journal of Geotechnical Engineering, 2019, 41(9): 1636-1644. DOI: 10.11779/CJGE201909007
Citation: WANG Hai-jun, ZHANG Jiu-dan, REN Ran, TANG Lei, YU Shu-yang, ZHONG Ling-wei, ZHANG Ke. Fracture characteristics of Brazilian disc with fully internal cracks based on 3D-ILC[J]. Chinese Journal of Geotechnical Engineering, 2019, 41(9): 1636-1644. DOI: 10.11779/CJGE201909007

基于3D-ILC含不同角度内裂纹圆盘断裂特性研究  English Version

基金项目: 国家重点研发计划项目(2016YFC0401801); 国家自然科学基金项目(51409170,51739008); 江苏省自然科学基金项目(BK20171130); 中央级公益性科研院所基本科研业务费重点项目(Y419005)
详细信息
    作者简介:

    王海军(1985— ),男,博士,主要从事断裂力学及岩石力学相关科研工作。E-mail:hjwang@nhri.cn。

    通讯作者:

    汤雷,E-mail:leitang@nhri.cn

Fracture characteristics of Brazilian disc with fully internal cracks based on 3D-ILC

  • 摘要: 巴西圆盘试验是力学领域的一个经典试验,含裂纹的圆盘试验多集中于二维或表面裂纹,但含内裂纹的I-II-III型断裂研究一直较为落后。基于3D-ILC技术,在对巴西圆盘试样表面无任何影响的情况下,凭空生成任意参数的内裂纹,开展含不同角度内裂纹的及完整巴西圆盘试样试验,对裂纹扩展过程、应力双折射规律、裂纹起裂及破坏荷载进行分析,并与已有文献进行对比,开展三维内裂纹I-II-III型断裂数值模拟,分析KI,KII,KIII分布规律及实现裂纹扩展全过程模拟,规律与试验相符。结果表明:①3D-ILC在断裂力学试验中的优势得到证明,为断裂力学中的内裂纹及I-II-III型断裂问题的研究奠定了基础。②与完整试样匀称连续的应力云纹分布相比,含内裂纹试样应力云纹集中于内裂纹尖端,呈花瓣状,色差对比显著。③30°内裂纹被括弧状破坏面切断;60°内裂纹上下尖端出现I-II型翼裂纹扩展,侧面出现III型裂纹叠加;90°内裂纹试样,沿内裂纹面扩展破坏,为纯I型破坏。④与完整试样破坏荷载相比,含30°,60°,90°内裂纹试样破坏荷载分别下降10.7%,60.6%,89.2%;30°,60°,90°内裂纹起裂与破坏荷载比分别为100%,11.7%,15.6%。⑤数值模拟与物理试验特征一致。结论与成果对断裂力学领域的三维内裂纹、I-II-III型断裂问题的研究提供了试验与理论基础。
    Abstract: The fully internal crack is created in the Brazilian disc based on the 3D-ILC method, without any effect on the surface. The uniaxial compression experiments are performed on the Brazilian discs with internal cracks at different angles. The experimental results are compared with the existing literatures. The propagation of the fully internal crack, the distribution of the stress-induced birefringence, the initiation of the crack and the failure stress and the fracture surface characteristics are investigated. Then the numerical simulations are carried out. The results show that: (1) The validity of the 3D-ILC is proved in the fracture mechanics researches. (2) The stress birefringence of the cracked specimen is discontinuous at the internal crack. (3) Compared to the intact specimens, the internal cracks greatly reduce the strength of the Brazilian disc, with decrease of 10.7%, 60.6% and 89.2% for the specimens with 30°, 60° and 90°. The stresses of crack initiation are 100%, 11.7% and 15.6% of the failure stress for the specimens with 30°, 60° and 90°. (4) The internal crack is penetrated by the primary crack for the Brazilian disc with crack of 30°. The mode I-II 3D wing cracks occur at the crack tip, while the mode III cracks occur at the sides of discs with internal crack of 60°. The primary crack is mode I crack for the disc with internal crack of 90°. (5) Numerical simulations are carried out on the Brazilian discs. The results may provide experimental support for the corresponding theoretical researches.
  • [1] GRIFFITH A A.The phenomena of rupture and flow in solids[J]. Philtransrsoca, 1921, 221(2): 163-198.
    [2] 李夕兵, 罗琳, 黎崇金. 考虑岩石交界面方向效应的巴西劈裂试验研究[J]. 工程科学学报, 2017, 39(9): 1295-1304.
    (LI Xi-bing, LUO Lin, LI Chong-jin.Experimental study of Brazilian splitting considering the directional effect of rock interface[J]. Journal of Engineering Science, 2017, 39(9): 1295-1304. (in Chinese))
    [3] HONDROS G.The evaluation of Poisson's ratio and modulus of materials of a low tensile resistence by the Brazilian (indirect tensile) test with particular reference to concrete[J]. Aust J Appl Sc, 1959, 112(6): 68-71.
    [4] FOWELL R J.Suggested method for determining mode I fracture toughness using Cracked Chevron Notched Brazilian Disc (CCNBD) specimens[J]. International Journal of Rock Mechanics & Mining Sciences & Geomechanics Abstracts, 2007, 32(7): 57-64.
    [5] TANG Tianxi, BAŽANT ZDENEK P, YANG Sungchul, et al. Variable-notch one-size test method for fracture energy and process zone length[J]. Engineering Fracture Mechanics, 1996, 55(3): 383-404.
    [6] 张盛, 王启智. 用5种圆盘试样的劈裂试验确定岩石断裂韧度[J]. 岩土力学, 2009, 30(1): 12-18.
    (ZHANG Sheng, WANG Qi-zhi.Fracture toughness of rock was determined by splitting test of 5 kinds of disc specimens[J]. Rock and Soil Mechanics, 2009, 30(1): 12-18. (in Chinese))
    [7] 陈枫, 孙宗颀, 徐纪成. 单轴压缩下中心裂纹巴西试样的权函数分析[J]. 岩石力学与工程学报, 2000, 19(5): 599-603.
    (CHEN Feng, SUN Zong-qi, XU Ji-cheng.Weight function analysis of Brazilian specimens with central crack under uniaxial compression[J]. Journal of Rock Mechanics and Engineering, 2000, 19(5): 599-603. (in Chinese))
    [8] 李念斌, 董世明, 华文. 裂纹面接触对中心裂纹圆盘应力强度因子影响分析[J]. 岩土力学, 2017, 38(8): 2395-2401.
    (LI Nian-bin, DONG Shi-ming, HUA Wen.Analysis of the effect of crack surface contact on the stress intensity factor of the central crack disc[J]. Rock and Soil Mechanics, 2017, 38(8): 2395-2401. (in Chinese))
    [9] 崔智丽, 宫能平, 经来旺. 岩石非理想裂纹圆盘试样动态断裂韧性测试的有限元分析及试验研究[J]. 岩土力学, 2015, 36(3).(CUI Zhi-li, GONG Neng-ping, JING Lai-wang. Finite element analysis and experimental study on dynamic fracture toughness test of non-ideal cracked disk specimen of rock[J]. Rock and Soil Mechanics, 2015, 36(3). (in Chinese))
    [10] 戴峰, 魏明东, 徐奴文. 人字形切槽巴西圆盘Ⅰ型渐进断裂数值模拟研究[J]. 岩石力学与工程学报, 2015(增刊2): 3906-3914.
    (DAI Feng, WEI Ming-dong, XU Nu-wen.Numerical simulation of type I progressive fracture of Brazilian disk with herringbone groove[J]. Journal of Rock Mechanics and Engineering, 2015(S2): 3906-3914. (in Chinese))
    [11] 许媛, 戴峰, 徐奴文. 人字形切槽巴西圆盘岩石试样复合型断裂渐进过程数值模拟研究[J]. 岩土工程学报, 2015, 37(12): 2189-2197.
    (XU Yuan, DAI Feng, XU Nu-wen.Numerical simulation of mixed-mode fracture evolution of Brazilian disc rock specimen with herringbone groove[J]. Journal of Geotechnical Engineering, 2015, 37(12): 2189-2197. (in Chinese))
    [12] 李术才, 杨磊, 李明田. 三维内置裂隙倾角对类岩石材料拉伸力学性能和断裂特征的影响[J]. 岩石力学与工程学报, 2009, 28(2): 281-289.
    (LI Shu-cai, YANG Lei, LI Ming-tian, et al.Effect of three-dimensional built-in fracture dip angle on tensile mechanical properties and fracture characteristics of rock-like materials[J]. Journal of Rock Mechanics and Engineering, 2009, 28(2): 281-289. (in Chinese))
    [13] 付金伟, 朱维申, 雒祥宇. 含三维内置断裂面新型材料断裂体破裂过程研究[J]. 中南大学学报(自然科学版), 2014(9): 3257-3263.
    (FU Jin-wei, ZHU Wei-shen, LUO Xiang-yu.Study on fracture process of a new material fracture body with 3-D built-in fracture plane[J]. Journal of Central South University (Natural Science Edition), 2014(9): 3257-3263. (in Chinese))
    [14] 李世愚. 岩石断裂力学导论[M]. 北京: 中国科学技术大学出版社, 2010.
    (LI Shi-yu.Introduction to rock fracture mechanics[M]. Beijing: China University of Science and Technology Press, 2010. (in Chinese))
    [15] 李廷春, 吕海波, 王辉. 单轴压缩载荷作用下双裂隙扩展的CT扫描试验[J]. 岩土力学, 2010, 31(1): 9-14.
    (LI Ting-chun, LÜ Hai-bo, WANG Hui.CT scanning test of double crack propagation under uniaxial compression[J]. Rock and Soil Mechanics, 2010, 31(1): 9-14. (in Chinese))
    [16] 王萍. 基于核磁共振的脆硬性泥页岩水化损伤演化研究[J]. 岩土力学, 2015, 36(3): 687-693.
    (WANG Ping.Study on hydration damage evolution of brittle-hard shale based on NMR[J]. Rock and Soil Mechanics, 2015, 36(3): 687-693. (in Chinese))
    [17] 陈厚群, 丁卫华, 蒲毅彬. 单轴压缩条件下混凝土细观破裂过程的X射线CT实时观测[J]. 水利学报, 2006, 37(9): 1044-1050.
    (CHEN Hou-qun, DING Wei-hua, PU Yi-bin.Real-time X-ray CT observation of mesoscopic fracture process of concrete under uniaxial compression[J]. Journal of Water Conservancy, 2006, 37(9): 1044-1050. (in Chinese))
    [18] 李浩然, 杨春和, 刘玉刚, 等. 单轴荷载作用下盐岩声波与声发射特征试验研究[J]. 岩石力学与工程学报, 2014, 33(10): 2107-2116.
    (LI Hao-ran, YANG Chun-he, LIU Yu-gang, et al.Experimental study on acoustic and acoustic emission characteristics of salt rock under uniaxial loading[J]. Journal of Rock Mechanics and Engineering, 2014, 33(10): 2107-2116. (in Chinese))
    [19] 王海军, 张九丹, 任然, 等. 基于电磁场-介质损伤的三维深埋裂纹3D-ILC实现[J]. 岩土工程学报, 待刊. (WANG Hai-jun, ZHANG Jiu-dan, REN Ran, et al. Embedded crcaks in materials induced by 3D-ILC[J]. Chinese Journal of Geotchnical Engineering, in press.
    [20] 王海军, 郁舒阳, 任然, 等. 基于3D-ILC含三维内裂纹孔口脆性固体断裂特性试验[J]. 岩土力学, 2019, 40(6): 2200-2212.
    (WANG Hai-jun, YU Shu-yang, REN Ran, et al.Based on the test of brittle solid fracture characteristics of 3D-ILC with 3-D internal crack orifice[J]. Rock and Soil Mechanics, 2019, 40(6): 2200-2212. (in Chinese))
    [21] ROESLER F C.Brittle fracture near equilibrium[J]. Proceedings of the Physical Society, 2002, 69(10): 981-992.
    [22] KNAUSS W G.An observation of crack propagation in anti-plane shear[J]. International Journal of Fracture Mechanics, 1970, 6(2): 183-187.
    [23] SOMMER E.Formation of fracture ‘lances' in glass[J]. Engineering Fracture Mechanics, 1969, 1(3): 539.
    [24] 雷振坤. 结构分析数字光测力学[M]. 大连: 大连理工大学出版社, 2012.
    (LEI Zhen-kun.Digital photometric mechanics for structural analysis[M]. Dalian: Dalian University of Technology Press, 2012. (in Chinese))
    [25] DYSKIN A V, JEWELL R J, JOER H, et al.Experiments on 3-D crack growth in uniaxial compression[J]. International Journal of Fracture, 1994, 65(4): R77-R83.
    [26] BANKS-SILLS LESLIE, WAWRZYNEK PAUL A, CARTER BRUCE, et al.Methods for calculating stress intensity factors in anisotropic materials: Part II Arbitrary geometry[J]. Engineering Fracture Mechanics, 2007, 74(8): 1293-1307.
    [27] 孙欣, 朱哲明, 谢凌志, 等. 基于SENDB试样的砂岩复合脆性断裂行为研究[J]. 岩石力学与工程学报, 2017, 36(12): 2884-2894.
    (SUN Xin, ZHU Zhi-ming, XIE Ling-zhi, et al.Study on composite brittle fracture behavior of sandstone based on SENDB specimen[J]. Journal of Rock Mechanics and Engineering, 2017, 36(12): 2884-2894. (in Chinese))
    [28] LI F Z, SHIH C F, NEEDLEMAN A.A comparison of methods for calculating energy release rates[J]. Engfractmech, 1985, 21(2): 405-421.
