反倾岩质边坡次生倾倒机理及稳定性分析

王俊杰; 郭建军

doi:10.11779/CJGE201909005

反倾岩质边坡次生倾倒机理及稳定性分析 English Version

王俊杰^{1, 2},
郭建军^1,3, ,

1. 重庆交通大学水工建筑物健康诊断技术重庆市高校工程研究中心,重庆 400074;
2. 重庆交通大学水利水运工程教育部重点实验室,重庆 400074;
3. 重庆水利电力职业技术学院,重庆 402160

基金项目: 国家自然科学基金项目（U1865103）; 重庆市科技人才专项（cstc2017kjrc-cxcytd30001）; 国家科技支撑计划课题（2015 BAK09B01）; 重庆市基础与前沿研究计划项目（重点）（cstc2015jcyjBX0139）

详细信息

作者简介:
王俊杰(1973— ),男,教授,博士生导师,主要从事库岸边坡稳定性分析方面的研究工作。E-mail: wangjunjiehhu@163.com。

通讯作者:
郭建军，E-mail：guofuzhi@126.com

计量
- 文章访问数: 0221
- HTML全文浏览量: 0
- PDF下载量: 0232
出版历程
- 收稿日期: 2018-10-17
- 发布日期: 2019-09-24

Mechanism and stability of secondary toppling of counter-tilt rock slopes

WANG Jun-jie^{1, 2},
GUO Jian-jun^1,3, ,

1. Diagnostic Technology on Health of Hydraulic Structures Engineering Research Center of Chongqing Education Commission of China, Chongqing Jiaotong University, Chongqing 400074, China;
2. Engineering Research Center of Diagnosis Technology and Instruments of Hydro-Construction, Chongqing Jiaotong University, Chongqing 400074, China;
3. Chongqing Water Resources and Electric Engineering College, Chongqing 402160, China

摘要

摘要: 倾倒破坏是反倾边坡的一种常见破坏模式,其中次生倾倒是反倾岩质边坡倾倒破坏的主要诱因。建立了反倾岩层在坡后土体作用下次生倾倒破坏的地质力学模型,基于室内物理模拟试验,分析了反倾岩层上覆土压力分布规律、岩层的破坏模式和整体破坏面的形状与位置。根据库仑主动土压力理论得到下卧岩层表面各点法向压力的理论值与实测值基本相符,土体中存在土拱效应导致两者存在差异,随着上覆土体厚度及堆载作用的加大,土拱效应越明显。各岩层可能的破坏模式包括弯拉破坏、弯滑破坏和滑动破坏。下卧反倾岩层的整体破坏面是一通过坡脚的近似平面,整体破坏面与岩层层面法线方向呈0°~25°的夹角。基于叠合悬臂梁模型,引入岩层横截面上节理面的黏聚力和岩石抗拉强度随岩层嵌入深度的折减系数,改进了反倾岩层的极限平衡分析方法,推导了坡体任意岩层下推力的理论公式,定义了任意岩层变形破坏的安全系数和边坡整体倾倒破坏的综合安全系数。提出了下卧反倾岩层潜在整体破坏面的理论计算方法,并确定了影响潜在整体破坏面位置的敏感因素。
- 反倾边坡 /
- 次生倾倒 /
- 物理模拟试验 /
- 叠合悬臂梁模型 /
- 稳定性分析 /
- 整体破坏面
Abstract: Among kinds of toppling failures of anti-dipping rock slopes, the secondary toppling is the main inducement. The geo-mechanical model for the secondary toppling of the anti-dipping rock strata under the action of the soil behind the slope is established. Based on the laboratory physical simulation tests, the distribution laws of earth pressure on the surface, failure modes, shapes and positions of the integral failure surface of the counter-tilt rock strata are analyzed. According to the Coulomb's active earth pressure theory, the theoretical values of normal pressure at each point on the underlying stratum surface are basically consistent with the measured values, but the soil arching effect leads to the difference between them. With the increase of overlying soil thickness and surcharge effect, the soil arching effect becomes more obvious. The possible failure modes of various strata include bending failure, bending-slip failure and sliding failure. The integral failure surface of the underlying anti-dipping rock stratum is an approximate plane through the foot of the slope, and the angle between the integral failure surface and the normal direction of the rock strata is 0°~25°. Based on the superimposed cantilever beam model, the limit equilibrium analysis method of anti-dipping rock strata is improved by introducing the reduction coefficient of the cohesion of joints on the cross-section of rock strata and the tensile strength of rock with the embedded depth of rock strata. The theoretical formula of thrust for arbitrary stratum in the slope is derived. The safety factors of deformation and failure of arbitrary rock stratum and the comprehensive safety factor of the whole slope collapse are defined respectively. The theoretical method for calculating the potential integral failure

HTML全文

参考文献(23)

[1]	王思敬. 金川露天矿边坡变形机制及过程[J]. 岩土工程学报, 1982, 4(1): 76-83. (WANG Si-jing.On the mechanism and process of slope deformation in an open pit mine[J]. Chinese Journal of Geotechnical Engineering, 1982, 4(1): 76-83. (in Chinese))
[2]	黄润秋. 20世纪以来中国的大型滑坡及其发生机制[J]. 岩石力学与工程学报, 2007, 26(3): 433-454. (HUANG Run-qiu.Large-scale landslides and their sliding mechanisms in China since the 20th century[J]. Chinese Journal of Rock Mechanics and Engineering, 2007, 26(3): 433-454. (in Chinese))
[3]	CHEN Z Y, GONG W J, MA G W, et al.Comparisons between centrifuge and numerical modeling results for slope toppling failure[J]. Science China Technological Sciences, 2015, 58(9): 1497-1508.
[4]	汪小刚, 张建红, 赵毓芝, 等. 用离心模型研究岩石边坡的倾倒破坏[J]. 岩土工程学报, 1996, 18(5): 14-21. (WANG Xiao-gang, ZHANG Jian-hong ZHAO Yu-zhi, et al. Investigations on mechanism of slope toppling failure by centrifuge model testing[J]. Chinese Journal of Geotechnical Engineering, 1996, 18(5): 14-21. (in Chinese))
[5]	郭建军, 王俊杰, 黎洪光. 反倾层状岩土复合边坡的稳定性分析方法[J]. 重庆交通大学学报(自然科学版), 2017, 36(10): 70-75. (GUO Jian-jun, WANG Jun-jie, LI Hong-guang, et al.Method of stability analysis for anti-inclined and layered slopes with rock and soil composition[J]. Journal of Chongqing Jiaotong University (Natural Science), 2017, 36(10): 70-75. (in Chinese))
[6]	BABIKER A F A, SMITH C C, GILBERT M, et al. Non-associative limit analysis of the toppling-sliding failure of rock slopes[J]. International Journal of Rock Mechanics and Mining Sciences, 2014, 71: 1-11.
[7]	MAJDI A, AMINI M.Analysis of geo-structural defects in flexural toppling failure[J]. International Journal of Rock Mechanics & Mining Sciences, 2011, 48: 175-186.
[8]	GUO J J, WANG J J.Mechanism analysis of the failure for a safe jointed rock high slope: tectonic structures and damage[J]. Geotechnical and Geological Engineering, 2018, 36(1): 455-467.
[9]	EVANS R S.Analysis of secondary toppling rock failures-The stress redistribution method[J]. Quarterly Journal of Engineering Geology, 1981, 14(2): 77-86.
[10]	TEME S C, WEST T R.Some secondary toppling failure mechanisms in discontinuous rock slopes[C]// Proceedings of the 24th US Symposium on Rock Mechanics. Texas, 1983: 193-204.
[11]	ALEJANO L R, GOMEZ-MARQUEZ I, MARTINEZ- ALEGRIA R.Analysis of a complex toppling-circular slope failure[J]. Engineering Geology, 2010, 114: 93-104.
[12]	MOHTARAMI E, JAFARI A, AMINI M.Stability analysis of slopes against combined circular-toppling failure[J]. International Journal of Rock Mechanics & Mining Sciences, 2014, 67: 43-56.
[13]	LIAN J J, LI Q, DENG X F, et al.A numerical study on toppling failure of a jointed rock slope by using the distinct lattice spring model[J]. Rock Mechanics and Rock Engineering, 2018, 51: 513-530.
[14]	ZHANG G C, WANG F, ZHANG H, et al.New stability calculation method for rock slopes subject to flexural toppling[J]. International Journal of Rock Mechanics and Mining Sciences, 2018, 106: 319-328.
[15]	HUANG D, GU D M.Influence of filling-drawdown cycles of the Three Gorges reservoir on deformation and failure behaviors of anaclinal rock slopes in the Wu Gorge[J]. Geomorphology, 2017, 295: 489-506.
[16]	GUO S F, QI S W, YANG G X, et al.An analytical solution for block toppling failure of rock slopes during an earthquake[J]. Applied sciences, 2017, 7: 1-17.
[17]	YAGODA-BIRAN G, HATZOR Y H.A new failure mode chart for toppling and sliding with consideration of earthquake inertia force[J]. International Journal of Rock Mechanics & Mining Sciences, 2013, 64: 122-131.
[18]	WANG J J, ZHAO T L, CHAI H J, et al.Failure of a rock slope 16.5 years after excavation in repeated strata of sandstone and mudstone[J]. Environmental Earth Sciences, 2016, 75: 1458-1471.
[19]	王俊杰, 冯登, 柴贺军, 等. 基于赤平极射投影和K-均值聚类算法的优势结构面分析[J]. 岩土工程学报, 2018, 40(1): 74-81. (WANG Jun-jie, FENG Deng, CHAI He-jun, et al.Dominant discontinuities based on stereographic projection and K-means clustering algorithm[J]. Chinese Journal of Geotechnical Engineering, 2018, 40(1): 74-81. (in Chinese))
[20]	郑允, 陈从新, 刘婷婷, 等. 坡顶荷载作用下岩质边坡倾倒破坏分析[J]. 岩土力学, 2015, 36(9): 2039-2047. (ZHENG Yun, CHEN Cong-xin, LIU Ting-ting, et al.Analysis of toppling failure of rock slopes under the loads applied on the top[J]. Rock and Soil Mechanics, 2015, 36(9): 2039-2047. (in Chinese))
[21]	郭建军, 王俊杰, 黎洪光, 等. 坡后土体推力作用下反倾节理岩质边坡次生倾倒机理分析[J]. 工程地质学报, 2017, 25(5): 1205-1212. (GUO Jian-jun, WANG Jun-jie, LI Hong-guang, et al.Analysis of secondary toppling mechanism of jointed rock slope under soil pressure[J]. Journal of Engineering Geology, 2017, 25(5): 1205-1212. (in Chinese))
[22]	刘海军. 皖南山区反倾板岩边坡倾倒变形机理研究[D]. 成都: 成都理工大学, 2012. (LIU Hai-jun.Research on the toppling deformation mechanism of counter-tilt slate slope in the mountainous area of Southern Anhui[D]. Chengdu: Chengdu University of Technology, 2012. (in Chinese))
[23]	郑允, 陈从新, 刘秀敏, 等. 层状反倾边坡弯曲倾倒破坏计算方法探讨[J]. 岩石力学与工程学报, 2015, 34(增刊2): 4252-4261. (ZHENG Yun, CHEN Cong-xin, LIU Xiu-min, et al.Investigation on calculation method of layered counter-tilt slope for flexural toppling failure[J]. Chinese Journal of Rock Mechanics and Engineering, 2015, 34(S2): 4252-4261. (in Chinese))
