砂砾石垫层料与混凝土面板接触面特性的大型单剪试验研究

王艳丽, 饶锡保, 潘家军, 左永振, 高盼

王艳丽, 饶锡保, 潘家军, 左永振, 高盼. 砂砾石垫层料与混凝土面板接触面特性的大型单剪试验研究[J]. 岩土工程学报, 2019, 41(8): 1538-1544. DOI: 10.11779/CJGE201908019
引用本文: 王艳丽, 饶锡保, 潘家军, 左永振, 高盼. 砂砾石垫层料与混凝土面板接触面特性的大型单剪试验研究[J]. 岩土工程学报, 2019, 41(8): 1538-1544. DOI: 10.11779/CJGE201908019
WANG Yan-li, RAO Xi-bao, PAN Jia-jun, ZUO Yong-Zhen, GAO Pan. Mechanical behaviors of interface between sand-gravel cushion material and concrete face slab by large-scale simple shear tests[J]. Chinese Journal of Geotechnical Engineering, 2019, 41(8): 1538-1544. DOI: 10.11779/CJGE201908019
Citation: WANG Yan-li, RAO Xi-bao, PAN Jia-jun, ZUO Yong-Zhen, GAO Pan. Mechanical behaviors of interface between sand-gravel cushion material and concrete face slab by large-scale simple shear tests[J]. Chinese Journal of Geotechnical Engineering, 2019, 41(8): 1538-1544. DOI: 10.11779/CJGE201908019

砂砾石垫层料与混凝土面板接触面特性的大型单剪试验研究  English Version

基金项目: 国家自然科学基金面上项目(51779017,51579237); 国家自然科学基金-雅砻江联合基金重点项目(U1765203); 长江科学院中央级公益性科研院所基本科研业务费项目(CKSF2017023/YT& CKSF2015051/YT)
详细信息
    作者简介:

    王艳丽(1981— ),女,博士,教授级高级工程师,主要从事粗粒土力学特性与宏细观模拟方法等方面的研究。E-mail: wyldhh@126.com。

  • 中图分类号: TU43

Mechanical behaviors of interface between sand-gravel cushion material and concrete face slab by large-scale simple shear tests

  • 摘要: 采用自主研制的低摩阻叠环式双向静动剪切试验机,考虑面板与垫层间喷涂和不喷涂乳化沥青两种情况,进行混凝土面板与砂砾石垫层料之间的大型剪切试验,研究混凝土面板与垫层料接触面的力学特性,基于Clough和Duncan非线性弹性本构模型整理出接触面模型参数,并探讨了乳化沥青在接触面剪切变形中的作用机制。研究表明:①不喷涂乳化沥青时,接触面应力随着剪切位移的增加逐渐变大,接触面剪应力与位移呈现出很好的双曲线关系。喷涂乳化沥青时,接触面剪应力与剪切位移在峰值强度前呈现出很好的双曲线关系,在峰值强度后,呈现出一定的应变软化特性,法向应力越低,表现越为明显;②两种情况下,随剪切位移的增加,上盒土体变形逐渐发展,并由上到下逐渐增加,最大的相对错动位移均发生在混凝土面板与垫层之间的接触面处,表明接触面的抗剪强度小于砂砾石垫层的抗剪强度;③法向应力对叠环的剪切位移有较大影响,法向应力越大,同一高度处叠环的剪切位移越大;在相同的剪切位移和法向应力作用下,喷涂乳化沥青时叠环水平位移均小于不喷涂时叠环水平位移;④乳化沥青对接触面的力学参数有很大的影响,采用Clough和Duncan非线性弹性本构模型拟合时,与不喷涂乳化沥青时相比,喷涂乳化沥青的接触面其劲度系数、指数及强度指标均有大幅度降低,剪切过程中乳化沥青形成了完整的过渡层来隔离砂砾石垫层料和混凝土面板的直接接触,并起到很好的阻隔-润滑效果。
    Abstract: A series of large-scale shear tests are performed to study the contact characteristics between sand-gravel cushion and concrete structure with two types of interfaces, coated with and without emulsified asphalt by a self-developed large-scale bidirectional low friction laminar-ring simple shear apparatus. The nonlinear elastic constitutive model parameters based on Clough and Duncan of the interfaces are determined, and the effects of emulsified asphalt on shear deformation mechanism of the interface are discussed. The results show that: (1) With the increasing shear displacement, the shear stress of interface coated without emulsified asphalt increases and the curves of shear stress and shear displacement exhibit a good hyperbolic relationship. The curves of shear stress and shear displacement of interface coated with emulsified asphalt exhibit a good hyperbolic relationship before the peak strength. Certain strain softening properties are shown after the peak strength, which is different from that coated without emulsified asphalt. The lower the normal stress, the more obvious it is. (2) For the both cases, with the increasing shear displacement, the deformation of soils in the upper box develops, and gradually increases from top to bottom and the largest relative movement displacement occurs in the contact surface between concrete slabs and cushion layer, which show that the shear strength of the interface is less than that of the sand-gravel cushion. (3)
  • [1] 张嘎, 张建民. 粗粒土与结构接触面单调力学特性的试验研究[J]. 岩土工程学报, 2004, 26(1): 21-25.
    (ZHANG Ga, ZHANG Jian-min.Experimental study on monotonic behavior of interface between soil and structure[J].Chinese Journal of Geotechnical Engineering, 2004, 26(1): 21-25. (in Chinese))
    [2] 朱俊高, SHAKIR R R, 杨有莲, 等. 土-混凝土接触面特性环剪单剪试验比较研究[J]. 岩土力学, 2011, 32(3): 692-696.
    (ZHU Jun-gao, SHAKIR R R, YANG You-lian, et al.Comparison of behaviors of soil-concrete interface from ring-shear and simple shear tests[J]. Rock and Soil Mechanics, 2011, 32(3): 692-696. (in Chinese))
    [3] CLOUGH G W, DUNCAN J M.Finite element analysis of retaining wall behavior[J]. J Soil Mech and Found Engrg Div, ASCE, 1971, 97(12): 1657-1674.
    [4] 胡黎明, 濮家骝. 土与结构物接触面损伤本构模型[J]. 岩土力学, 2002, 23(1): 6-11.
    (HU Li-ming, PU Jia-liu.Damage model of soil-structure interface[J]. Rock and Soil Mechanics, 2002, 23(1): 6-11. (in Chinese))
    [5] 卢廷浩, 鲍伏波. 接触面薄层单元耦合本构模型[J]. 水利学报, 2000(2): 71-75.
    (LU Ting-hao, BAO Fu-bo.A coupled constitutive model for interface thin-layer element[J]. Journal of Hydraulic Engineering, 2000(2): 71-75. (in Chinese))
    [6] 龙尧, 张家生, 陈俊桦. 结构接触面剪切特性及软硬化损伤模型[J]. 华南理工大学学报(自然科学版), 2016, 44(12): 128-134.
    (LONG Yao, ZHANG Jia-sheng, CHEN Jun-hua.Shear characteristics of structure interface and its strain-softening and hardening damage model[J]. Journal of South China University of Technology (Natural Science Edition), 2016, 44(12): 128-134. (in Chinese))
    [7] GOODMAN R E, TAYLOR R L, BREKKE T L.A model for the mechanics of jointed rock[J]. J Soil Mech and Found Engrg Div, ASCE, 1968, 94(3): 637-660.
    [8] DESAI C S, DRUMM E C, ZAMAN M M.Cyclic testing and modeling of interfaces[J]. Journal of Geotechnical Engineering, 1985, 111(6): 793-815.
    [9] 胡启军, 蒋晶, 徐亚辉, 等. 红层泥岩桩-岩接触面本构模型试验及数值模拟[J]. 土木建筑与环境工程, 2017, 39(3): 122-128.
    (HU Qi-jun, JIANG Jing, XU Ya-hui, et al.Interface constitutive model test and numerical simulation of red mudstone pile-rock[J]. Journal of Civil, Architectural & Environmental Engineering, 2017, 39(3): 122-128.
    [10] POTYONDY J G.Skin friction between various soils and construction material[J]. Géotechnique, 1961, 11(4): 339-345.
    [11] 周国庆, 夏红春, 赵思光. 深部土体-结构接触面与界面层力学特性的直接剪切试验[J]. 煤炭学报, 2008, 33(10): 1157-1162.
    (ZHOU Guo-qing, XIA Hong-chun. ZHAO Si-guang.Direct shear experiment of deep soil-structure interface and interface layer mechanical characteristics[J]. Journal of China Coal Society, 2008, 33(10): 1157-1162. (in Chinese))
    [12] 冯大阔, 侯文峻, 张建民. 粗粒土与结构接触面三维力学特性的直剪试验研究[J]. 土木工程学报, 2012, 45(5): 169-175.
    (FENG Da-kuo, HOU Wen-jun, ZHANG Jian-min.Large-scale direct shear test investigation of the 3 D behavior of a gravel-structure interfaces[J]. China Civil Engineering Journal, 2012, 45(5): 169-175. (in Chinese))
    [13] 陈俊桦, 张家生, 李键. 考虑粗糙度的黏性土-结构接触面力学特性试验[J]. 四川大学学报(工程科学版), 2015, 47(4): 22-30.
    (CHEN Jun-hua, ZHANG Jia-sheng, LI Jian.Experimental research on mechanical characteristics of cohesive soil. structure interface by considering its roughness[J]. Journal of Sichuan University(Engineering Science), 2015, 47(4): 22-30. (in Chinese))
    [14] UESUGI M, KISHIDA H, TSUBAKIHARA Y.Friction between sand and steel under repeated loading[J]. Soils and Foundations, 1989, 29(3): 127-137.
    [15] EVGIN E, FAKHARIAN K.Cyclic rotational simple-shear behavior of sand-steel interfaces[J]. Soils and Foundations, 1998, 38(2): 191-199.
    [16] FAKHARIAN K, EVGIN E.Cyclic simple-shear behavior of sand-steel interfaces under constant normal stiffness condition[J]. Journal of Geotechnical and Geoenvironmental Engineering, 1997, 123(12): 1098-1105.
    [17] DESAI C S, PRADHAN S K, COHEN D.Cyclic testing and constitutive modeling of saturated sand-concrete interfaces using the disturbed state concept[J]. International Journal of Geomechanics, 2005, 5(4): 286-294.
    [18] 高俊合, 俞海学, 赵维炳. 土与混凝土接触面特性的大型单剪试验研究及数值模拟[J]. 土木工程学报, 2000, 33(4): 42-46.
    (GAO Jun-he, YU Hai-xue, ZHAO Wei-bing.Characteristics study of interface between soil and concrete by using large size single shear apparatus and numerical analysis[J]. China Civil Engineering Journal, 2000, 33(4): 42-46. (in Chinese))
    [19] 周小文, 龚壁卫, 丁红顺, 等. 砾石垫层—混凝土接触面力学特性单剪试验研究[J]. 岩土工程学报, 2005, 27(8): 876-880.
    (ZHOU Xiao-wen, GONG Bi-wei, DING Hong-shun, et al.Large-scale simple shear test on mechanical properties of interface between concrete face and gravel underlayer[J]. Chinese Journal of Geotechnical Engineering, 2005, 27(8): 876-880. (in Chinese))
    [20] 彭凯, 朱俊高, 张丹, 等. 粗粒土与混凝土接触面特性单剪试验研究[J]. 岩石力学与工程学报, 2010, 29(9): 1893-1900.
    (PENG Kai, ZHU Jun-gao, ZHANG Dan, et al.Study of mechanical behaviors of interface between coarse-grained soil and concrete by simple shear test[J]. Chinese Journal of Rock Mechanics and Engineering, 2010, 29(9): 1893-1900. (in Chinese))
    [21] 冯大阔, 张建民. 粗粒土与结构接触面静动力学特性的大型单剪试验研究[J]. 岩土工程学报, 2012, 34(7): 1201-1208.
    (ENG Da-kuo, ZHANG Jian-min.Monotonic and cyclic behaviors of coarse-grained soil-structure interface using large-scale simple shear device[J]. Chinese Journal of Geotechnical Engineering, 2012, 34(7): 1201-1208. (in Chinese))
    [22] 刘容地, 郑建国, 李致远. 砂砾石与混凝土接触面力学性能的试验研究[J]. 西安建筑科技大学学报(自然科学版), 2013, 45(6): 834-841.
    (LIU Rong-di, ZHENG Jian-guo, LI Zhi-Yuan.Experimental research on mechanical properties of interface between concrete and gravel[J]. Journal Xi'an University of Architecture & Technology (Natural Science Edition), 2013, 45(6): 834-841. (in Chinese))
    [23] 邵生俊, 王强, 吴飞洁. 一种新型动单剪仪的研发与试验验证[J]. 岩土力学, 2017, 38(6): 1841-1848.
    (SHAO Sheng-jun, WANG Qiang, WU Fei-jie.Development and test verification of a new cyclic simple shear apparatus[J]. Rock and Soil Mechanics, 2017, 38(6): 1841-1848. (in Chinese)).
    [24] 饶锡保, 江洎洧, 潘家军, 等. 一种低摩阻叠环式双向动剪切试验机: CN201620559350.6[P].2016-11-16. (RAO Xi-bao, JIANG Ji-wei, PAN Jia-jun, et al. A low riction-resistance ring type bidirectional dynamic shear test machine: CN201620559350.6[P]. 2016-11-16.(in Chinese))
