压实黏土剪切带渗透特性试验研究

王刚, 游克勤, 魏星, 张建民

王刚, 游克勤, 魏星, 张建民. 压实黏土剪切带渗透特性试验研究[J]. 岩土工程学报, 2019, 41(8): 1530-1537. DOI: 10.11779/CJGE201908018
引用本文: 王刚, 游克勤, 魏星, 张建民. 压实黏土剪切带渗透特性试验研究[J]. 岩土工程学报, 2019, 41(8): 1530-1537. DOI: 10.11779/CJGE201908018
WANG Gang, YOU Ke-qin, WEI Xing, ZHANG Jian-min. Experimental study on permeability of shear bands in compacted clay[J]. Chinese Journal of Geotechnical Engineering, 2019, 41(8): 1530-1537. DOI: 10.11779/CJGE201908018
Citation: WANG Gang, YOU Ke-qin, WEI Xing, ZHANG Jian-min. Experimental study on permeability of shear bands in compacted clay[J]. Chinese Journal of Geotechnical Engineering, 2019, 41(8): 1530-1537. DOI: 10.11779/CJGE201908018

压实黏土剪切带渗透特性试验研究  English Version

基金项目: 国家自然科学基金项目(41602286,51679016); 重庆市基础研究与前沿探索项目(cstc2018jcyjAX0752)
详细信息
    作者简介:

    王 刚(1978— ),男,博士,教授,主要从事岩土本构理论、土动力学和岩土工程数值计算方面的研究。E-mail:cewanggang@163.com。

  • 中图分类号: TU411

Experimental study on permeability of shear bands in compacted clay

  • 摘要: 针对中国在建和拟建的300 m级高堆石坝心墙黏土(尤其是接触黏土)在大剪切变形、高水头作用下渗透安全性评价的重大需求,采用新研发的土体环剪渗透试验装置对某高堆石坝心墙黏土进行了系列竖向压缩—环向剪切—径向渗流试验,测定了不同压实密度的黏土剪切带在不同竖向压力下导水系数随剪切位移的变化过程,揭示了压实黏土在大剪切变形过程中渗透特性的演化规律、内在机理及影响因素。在高竖向压力下,剪切带在剪切过程中被压缩得更密实,其导水系数在剪切过程中并不增大,剪切带在经历大剪切变形后仍具有良好的抵抗渗流的能力。在低竖向压力下,剪切带内土体破碎、错动、形成空隙,从而导致其导水系数急剧增大。对于所用的黏土,压实过程导致的前期固结压力可以粗略作为判别产生剪切渗漏带的门槛应力值。超固结的压实黏土易产生剪切渗漏带的试验发现,比目前传统的水力劈裂假设可以更好地解释和判别坝体中集中渗漏发生的条件及部位。
    Abstract: Several 300 m-high rock-fill dams with clay core are being constructed or will be constructed in China, raising an urgent need for evaluating the safety against seepage failure of the clay core after experiencing large shear deformation and subjected to high water heads. A series of vertical-consolidation, circumferential-shear and radial-seepage tests are conducted on a clay using a newly-invented ring shear permeameter. The variations of the hydraulic transmissivities of the shear bands are measured for the specimens with different compaction densities and under different surcharge pressures. When being largely sheared, the original arrangement and bonding among particles in a shear band are damaged. Under high surcharge pressure, the shear band is compressed more tightly and becomes denser, and thus little increase can be observed in its hydraulic transmissivity. Conversely, under low surcharge pressure, the shattered fragments in the shear band glide, rotate, roll and climb across each other, leading to a looser packing, and as a result, the hydraulic transmissivity of the shear band increases sharply. It seems that the preconsolidation pressure originating from compaction may serve as a threshold value to determine whether the permeability will increase for the test clay. The test results highlight an important fact that the heavily over-consolidated clay can generate shear bands of remarkably reduced seepage resistance during shearing, which can be used to explain more rationally the trigger conditions and positions of concentrated leakages happened in earth dams than the conventional hydraulic fracturing hypothesis.
  • [1] DL/T5395—2007 碾压式土石坝设计规范[S]. 2007.
    (DL/T5395—2007 Design specification for rolled earth-rock fill dams[S]. 2007. (in Chinese))
    [2] 刘杰. 土的渗透稳定与渗流控制[M]. 北京: 中国水利水电出版社, 1992.
    (LIU Jie.Seepage stability and seepage control of soil[M]. Beijing: China Water Power Press, 1992. (in Chinese))
    [3] GB/T 50123—1999 土工试验方法标准[S]. 1999.
    (GB/T 50123—1999Standard for Soil test method[S]. 1999. (in Chinese))
    [4] DEWHURST D N.Fabric and hydraulic conductivity of sheared clays[J]. Géotechnique, 1996, 46(4): 761-769.
    [5] ZHANG S, TULLIS T E.The effect of fault slip on permeability and permeability anisotropy in quartz gouge[J]. Tectonophysics, 1998, 295(1/2): 41-52.
    [6] KIMURA S, KANEKO H, ITO T, et al.Investigation of fault permeability in sands with different mineral compositions (evaluation of gas hydrate reservoir)[J]. Energies, 2015, 8(7): 7202-7223.
    [7] 雷红军, 卞锋, 于玉贞, 等. 黏土大剪切变形中的渗透特性试验研究[J]. 岩土力学, 2010, 31(4): 1130-1133.
    (LEI Hong-jun, BIAN Feng, YU Yu-zhen, et al.Experimental study of permeability of clayey soil during process of large shear deformation[J]. Rock and Soil Mechanics, 2010, 31(4): 1130-1133. (in Chinese))
    [8] 雷红军, 刘中阁, 于玉贞, 等. 黏土-结构接触面大剪切变形后渗流特性试验研究[J]. 岩土力学, 2011, 32(4): 1040-1044.
    (LEI Hong-jun, LIU Zhong-ge, YU Yu-zhen, et al.Experimental study of seepage characteristics of clayey soil-structure interface under large shear deformation[J]. Rock and Soil Mechanics, 2011, 32(4): 1040-1044. (in Chinese))
    [9] LUO Y L, JIN X, LI X, et al.A new apparatus for evaluation of contact erosion at the soil-structure interface[J]. Geotechnical Testing Journal, 2013, 36(2): 256-263.
    [10] 王刚, 魏星. 一种土体扭转剪切渗透试验装置及测试方法: CN104142277A[P].2014-11-12. (WANG Gang, WEI Xing. A torsional shear penetration testing device and corresponding testing method for soils: CN104142277A[P]. 2014-11-12.(in Chinese))
    [11] WANG Gang, WEI Xing, ZOU Ting. A hollow cylinder radial-seepage apparatus for evaluating permeability of sheared compacted clay[J/OL]. Geotechnical Testing Journal, https://doi.org/10.1520/GTJ20170215.
    [12] 魏星, 邹婷, 王刚. 压-剪耦合条件下黏土渗透特性的试验研究[J]. 岩石力学与工程学报, 2017, 36(增刊1): 3561-3568.
    (WEI Xing, ZOU Ting, WANG Gang.Experimental study on permeability of clay during coupled compression and shear[J]. Chinese Journal of Rock Mechanics and Geotechnical Engineering, 2017, 36(S1): 3561-3568. (in Chinese))
    [13] 王刚, 魏星, 蒋立. 一种土的剪切面及土与结构界面的环剪渗透实验装置: CN105606508A[P].2015-11-24. (WANG Gang, WEI Xing, JIANG Li. A ring shear seepage testing device for soils and the soil-structure interfaces: CN105606508A[P]. 2015-11-24.(in Chinese))
    [14] FOSTER M, FELL R, SPANNAGLE M.The statistics of embankment dam failures and accidents[J]. Canadian Geotechnical Journal, 2000, 37(5): 1000-1024.
    [15] Teton Dam Failure Review Group. Failure of Teton Dam: a report of findings[R]. Idaho: U. S. Department of the Interior and the Stato of Idaho, 1977.
    [16] JAWORSKI W, DUNCAN J M, SEED H B.Laboratory study of hydraulic fracturing[J]. Journal of the Geotechnical Engineering Division, ASCE, 1981, 107(6): 713-732.
    [17] 黄文熙. 对土石坝科研工作的几点看法[J]. 水利水电技术, 1982(4): 23-27(HUANG Wen-xi. Several views on research of embankment dams[J]. Water Resources and Hydropower Engineering, 1982(4): 23-27. (in Chinese))
    [18] 孙亚平. 水力劈裂机理研究[D]. 北京: 清华大学, 1985.
    (SUN Ya-ping.Study on hydraulic fracturing of clay core material[D]. Beijing: Tsinghua University, 1985. (in Chinese))
    [19] SHERARD J L.Hydraulic fracturing in embankment dams[J]. Journal of Geotechnical Engineering, 1986, 112(10): 905-927.
    [20] LO K Y, KANIARU K.Hydraulic fracture in earth and rock-fill dams[J]. Canadian Geotechnical Journal, 1990, 27(4): 496-506.
    [21] 沈珠江, 易进栋, 左元明. 土坝水力劈裂的离心模型试验及其分析[J]. 水利学报, 1994(9): 67-78.
    (SHEN Zhu-jiang, YI Jin-dong, ZUO Yuan-ming.Centrifuge model test of hydraulic fracture of earth dam and its analysis[J]. Journal of Hydraulic Engineering, 1994(9): 67-78. (in Chinese))
    [22] 张丙印, 李娜, 李全明, 等. 土石坝水力劈裂发生机理及模型试验研究[J]. 岩土工程学报, 2005, 27(11): 42-46.
    (ZHANG Bing-yin, LI Na, LI Quan-ming, et al.Mechanism analysis and model test of hydraulic fracturing in embankment dams[J]. Chinese Journal of Geotechnical Engineering, 2005, 27(11): 42-46. (in Chinese))
    [23] 朱俊高, 王俊杰, 张辉. 土石坝心墙水力劈裂机制研究[J].岩土力学, 2007, 28(3): 487-492.
    (ZHU Jun-gao, WANG Jun-jie, ZHANG Hui.Study on mechanism of hydraulic fracturing in core of earth-rockfill dam[J]. Rock and Soil Mechanics, 2007, 28(3): 487-492. (in Chinese))
    [24] 曹雪山, 殷宗泽. 土石坝心墙水力劈裂的非饱和土固结方法研究[J]. 岩土工程学报, 2009, 31(12): 1851-1857.
    (CAO Xue-shan, YIN Zong-ze.Consolidation method of unsaturated soils for hydraulic fracturing of core walls of rock-fill dams[J]. Chinese Journal of Geotechnical Engineering, 2009, 31(12): 1851-1857. (in Chinese))
