新型预应力路基水平向附加应力扩散规律研究

冷伍明; 艾希; 徐方; 张期树; 杨奇; 聂如松; 刘晓豪

doi:10.11779/CJGE201908008

新型预应力路基水平向附加应力扩散规律研究 English Version

冷伍明^1,2,
艾希¹,
徐方^1,2, ,,
张期树¹,
杨奇^1,2,
聂如松^1,2,
刘晓豪¹

1. 中南大学土木工程学院,湖南长沙410075;
2. 中南大学高速铁路建造技术国家工程实验室,湖南长沙410075

基金项目: 国家自然科学基金项目（51678572,51878666）

详细信息

作者简介:
冷伍明(1964— ),男,教授,博士生导师,主要从事路基工程、地下工程、地基与基础方面的研究。E-mail: wmleng@csu.edu.cn。

通讯作者:
徐方，E-mail：fangxu@csu.edu.cn

中图分类号: TU43
计量
- 文章访问数: 0193
- HTML全文浏览量: 0
- PDF下载量: 0152
出版历程
- 收稿日期: 2018-09-22
- 发布日期: 2019-08-24

Diffusion laws of horizontal additional stress in a new prestressed subgrade

1. School of Civil Engineering, Central South University, Changsha 410075, China;
2. National Engineering Laboratory for High Speed Railway Construction, Changsha 410075, China

摘要

摘要: 基于弹性理论,推导了新型预应力路基内水平向附加应力计算公式,并获得了预应力自坡面向路堤内的扩散规律;同时运用ABAQUS有限元软件建立三维预应力路基模型,分析了不同侧压板布设位置下路堤内的水平向附加应力分布情况。研究表明：①理论公式的适用条件为侧压板上边界距路肩距离不小于2.0 m;②板覆盖区（除板左下角点外）路基内水平向附加应力系数及其衰减速率随距路堤坡面水平距离的增加逐渐减小,且水平向附加应力逐步由“腹鼓形”差异分布过渡呈“腹平状”较均匀分布;③距侧压板距离大于0.1 m时,附加应力系数随水平距离增加先增大后减小,且扩散峰值点距坡面水平距离随外延距离的增加而增大;④通过合理布置板间距,可在路堤受荷核心区外部形成一道连续、稳定、有效的受压加固区,进而改善路堤土体受力状态,提高路堤整体服役性能。研究成果可为预应力路基的设计计算和推广应用提供理论基础和参考。
- 预应力 /
- 路基 /
- 侧压力板 /
- 水平向附加应力 /
- 扩散规律 /
- 板间距
Abstract: Based on the theory of elasticity, the theoretical formulas are derived to calculate the horizontal additional stress (σ_H) in a new type prestressed embankment, and the diffusion laws of the additional stress from the slope surface to the inside of the embankment are revealed. Meanwhile, a 3D finite element model for a prestressed embankment is established to analyze the distribution of the horizontal additional stress in the prestressed embankment with different placement positions of the lateral pressure plate. The results show that: (1) The application condition of the theoretical formulas requires that the net spacing between the lateral pressure plate and the embankment shoulder should be more than 2.0 m. (2) In the region covered by the lateral pressure plate, the horizontal additional stress coefficient as well as its attenuation rate gradually decreases with the increase of the horizontal distance from the slope surface, and the distribution of σ_H gradually transits from a “raised abdomen” pattern to a relatively uniform “flat abdomen” one. (3) When the distance away from the lateral pressure plate is greater than 0.1 m, the additional stress coefficient of σ_H increases first and then decreases with the increasing horizontal distance, and the horizontal distance between the peak point and the slope surface increases as the epitaxial distance increases; (4) A continuous, stable and effective pressure-reinforced zone is likely to be formed when the spacing of the lateral pressure plate is properly designed, therefore, the stress state of the embankment soil and the overall service performance of the embankment can be improved. The research findings can provide theoretical bases and references for the design and promotion application of the prestressed embankments.
- prestress /
- subgrade /
- lateral pressure plate /
- horizontal additional stress /
- diffusion law /
- plate spacing

HTML全文

参考文献(21)

[1]	梅慧浩, 冷伍明, 刘文劼, 等. 持续动荷载作用下基床粗粒土填料累积塑性应变试验研究[J]. 铁道学报, 2017, 39(2): 119-126. (MEI Hui-hao, LENG Wu-ming, LIU Wen-jie, et al.Experimental study on accumulated plastic strain of coarse grained soil filling in subgrade bed under persistent dynamic loading[J]. Journal of the China Railway Society, 2017, 39(2): 119-126. (in Chinese))
[2]	冷伍明, 梅慧浩, 聂如松, 等. 重载铁路基床粗粒土填料的静力特性研究[J]. 铁道工程学报, 2016, 33(11): 23-28. (LENG Wu-ming, MEI Hui-hao, NIE Ru-song, et al.Static characteristic research on coarse grained soil filling in heavy haul railway subgrade bed[J]. Journal of Railway Engineering Society, 2016, 33(11): 23-28. (in Chinese))
[3]	周文权, 冷伍明, 蔡德钩, 等. 循环荷载作用下路基粗粒土填料临界动应力和累积变形特性分析[J]. 铁道学报, 2014, 36(12): 84-89. (ZHOU Wen-quan, LENG Wu-ming, CAI De-gou, et al.Analysis on characteristics of critical dynamic stress and accumulative deformation of coarse-grained soil subgrade filling under cyclic loading[J]. Journal of the China Railway Society, 2014, 36(12): 84-89. (in Chinese))
[4]	冷伍明, 聂如松, 杨奇, 等. 新型预应力路基结构与性能初探[J]. 铁道学报, 2016, 38(11): 111-119. (LENG Wu-ming, NIE Ru-song, YANG Qi, et al.A new type of prestressed embankment structure and its properties[J]. Journal of the China Railway Society, 2016, 38(11): 111-119. (in Chinese))
[5]	于远祥, 谷拴成, 吴璋, 等. 黄土地层下预应力锚索荷载传递规律的试验研究[J]. 岩石力学与工程学报, 2010, 29(12): 2573-2580. (YU Yuan-xaing, GU Shuan-cheng, WU Zhang, et al.Experimental study of load transfer law of prestressed cables under loessstratum[J]. Chinese Journal of Rock Mechanics and Engineering, 2010, 29(12): 2573-2580. (in Chinese))
[6]	管飞, 尹骥, 李象范. 软土深基坑预应力重力式围护结构的设计与分析[J]. 岩土工程学报, 2006, 28(增刊1): 1605-1609. (GUAN Fei, YI Ji, LI Xiang-fan.Design and analysis of gravity wall reinforced by vertical prestressed anchors in deep excavation[J]. Chinese Journal of Geotechnical Engineering, 2006, 28(S1): 1605-1609. (in Chinese))
[7]	范明建, 康红普. 锚杆预应力与巷道支护效果的关系研究[J]. 煤矿开采, 2007, 12(4): 1-3. (FAN Ming-jian, KANG Hong-pu.Relationship research of bolt pre-stress and supporting effect of roadway[J]. Coal Mining Technology, 2007, 12(4): 1-3. (in Chinese))
[8]	蒋楚生, 周德培, 周应华. 预应力地梁锚索改善边坡受力状态的理论分析[J]. 岩土工程学报, 2005, 27(8): 974-976. (JIANG Chu-sheng, ZHOU De-pei, ZHOU Ying-hua.Theoretical analysis for stress state improvement in a slope with the prestressed cable-anchor beam[J]. Chinese Jounal of Geotechnical Engineering, 2005, 27(8): 974-976. (in Chinese))
[9]	赵晓彦, 熊自英. 框架锚固类土质边坡预应力传递规律的研究[J]. 岩土力学, 2011, 32(7): 2146-2152. (ZHAO Xiao-yan, XIONG Zi-ying.Study of transferring mode of prestressed force in frame-anchored soil-like slopes[J]. Rock and Soil Mechanics, 2011, 32(7): 2146-2152. (in Chinese))
[10]	黄雪峰, 马龙, 陈帅强, 等. 预应力锚杆内力传递分布规律与时空效应[J]. 岩土工程学报, 2014, 36(8): 1521-1525. (HUANG Xue-feng, MA Long, CHEN Shuai-qiang, et al.Distribution characteristics and time-space effects of internal force of prestressed anchor rod[J]. Chinese Journal of Geotechnical Engineering, 2014, 36(8): 1521-1525. (in Chinese))
[11]	康红普, 姜铁明, 高富强. 预应力在锚杆支护中的作用[J]. 煤炭学报, 2007, 32(7): 680-685. (KANG Hong-pu, JIANG Tie-ming, GAO Fu-qiang.Effect of pretensioned stress to rock bolting[J]. Journal of China Coal Science, 2007, 32(7): 680-685. (in Chinese))
[12]	林健, 石垚, 孙志勇, 等. 端部锚固锚杆预应力场分布特征的大型模型试验研究[J]. 岩石力学与工程学报, 2016, 35(11): 2237-2247. (LIN Jian, SHI Yao, SUN Zhi-yong, et al.Large scale model test on the distribution characteristics of the prestressed field of end-anchored bolts[J]. Chinese Journal of Rock Mechanics and Engineering, 2016, 35(11): 2237-2247. (in Chinese))
[13]	尤春安, 战玉宝. 预应力锚索锚固段的应力分布规律及分析[J]. 岩石力学与工程学报, 2005, 24(6): 925-925. (YOU Chun-an, ZHAN Yu-bao.Distributing characters and analysis of stresses in prestressed cables[J]. Chinese Journal of Rock Mechanics and Engineering, 2005, 24(6): 925-925. (in Chinese))
[14]	DU Z S,QIN B T,TIAN F C.Numerical analysis of the effects of rock bolts on stress redistribution around a roadway[J]. International Journal of Mining Science and Technology, 2016, 26(6): 975-980.
[15]	WIJK G.A theoretical remark on the stress field around prestressed rock bolts[J]. International Journal of Rock Mechanics & Mining Sciences & Geomechanics Abstracts, 1978, 15(6): 289-294.
[16]	徐芝纶. 弹性力学[M]. 北京: 高等教育出版社, 2016. (XU Zhi-lun.Elasticity[M]. Beijing: Higher Education Press, 2016. (in Chinese))
[17]	贾煜, 杨龙才, 王炳龙. 条形抛物线荷载下桩网结构路基的附加应力计算[J]. 岩石力学与工程学报, 2013, 32(增刊2): 4098-4104. (JIA Yu, YANG Long-cai, WANG Bing-long.Calculation of additional stress caused by strip parabolic load in geosynthetic reinforced pile supported embankment[J]. Chinese Journal of Rock Mechanics and Engineering, 2013, 32(S2): 4098-4104. (in Chinese))
[18]	张克恭, 刘松玉, 等. 土力学[M]. 3版. 北京: 中国建筑工业出版社, 2013. (ZHANG Ke-gong, LIU Song-yu.Soil mechanics[M]. 3rd ed. Beijing: China Architecture and Building Press, 2013. (in Chinese))
[19]	李文坚. 水平预应力加固铁路路堤方法及其初步分析[D]. 长沙: 中南大学, 2015. (LI Wen-jian.Method and preliminary analysis of horizontal prestressed reinforcement of railway embankment[D]. Changsha: Central South University, 2015. (in Chinese))
[20]	TB 10625—2017 重载铁路设计规范[S]. 2017. (TB 10625—2017 Code for design of heavy haul railway[S]. 2017. (in Chinese))
[21]	易思蓉. 铁道工程[M]. 北京: 中国铁道出版社, 2016: 243-244. (YI Si-rong.Railway engineering[M]. Beijing: China Railway Press, 2016. (in Chinese))
