刚柔混合型大型真三轴仪研制与验证

邵生俊; 王永鑫

doi:10.11779/CJGE201908005

刚柔混合型大型真三轴仪研制与验证 English Version

邵生俊^1,2,
王永鑫¹

1.西安理工大学岩土工程研究所,陕西西安 710048;
2. 陕西省黄土力学与工程重点试验室,陕西西安 710048

基金项目: 国家自然科学基金项目（41272320,11572245）

详细信息

作者简介:
邵生俊(1964— ),男,甘肃武威人,教授,博士生导师,从事黄土力学、黄土动力学等的研究工作。E-mail: sjshao@xaut.edu.cn。

中图分类号: TU413
计量
- 文章访问数: 302
- HTML全文浏览量: 12
- PDF下载量: 188
出版历程
- 收稿日期: 2018-06-10
- 发布日期: 2019-08-24

Development and verification of large-scale true triaxial apparatus with rigid-flexible-flexible loading boundary mechanism

SHAO Sheng-Jun^1,2,
WANG Yong-xin¹

1.Institute of Geotechnical Engineering, Xi'an University of Technology, Xi'an 710048, China;
2. Shaanxi Provincial Key Laboratory of Loess Mechanics and Engineering , Xi'an 710048, China

摘要

摘要: 真三轴仪是研究三维主应力作用下土的变形强度变化规律的关键设备,同时也是岩土力学理论研究的试验仪。在西安理工大学已经开发的竖向刚性、水平面内正交两向柔性真三轴加载机构的基础上,将自主研发的试样尺寸分别为70 mm×70 mm×70 mm和70 mm×70 mm×140 mm小型真三轴仪进一步开发为上、下两端伺服控制同步加载的300 mm×300 mm×600 mm大型真三轴仪。该真三轴仪包括压力室主机架,竖向主应力加载伺服控制液压油源,水平面内主应力加载伺服控制液压体变控制器,试样孔隙水压力伺服控制液压控制器,以及伺服控制和信号采集控制系统。压力室加载机构具有沿竖向轴水平面内转动、径向滚动和液压驱动伸缩运动的隔板,有效地隔离了相邻柔性液压囊;具有上下端对称变形的液压缸加载刚性顶板和底座和侧面对称作用分布压力特征。真三轴仪研制中分别采用特殊构造的乳胶膜和装样模以及轴-板滚动结构和PID闭合控制优化算法,解决了试样尺寸增大带来的试样制备和安装、试验操作、边界影响等问题,水平面内正交两向柔性加载腔互相干扰的问题,以及自动控制系统的稳定性问题。最后利用大型真三轴仪对重塑黄土进行了等b试验验证,其应力-应变特性、抗剪强度特性得到了一致的结果。
- 大型真三轴仪 /
- 柔性加载腔 /
- 围压隔离平衡装置 /
- PID闭合控制算法 /
- 重塑黄土
Abstract: The true triaxial apparatus is the key equipment to study the variation laws of the deformation strength of soils under the action of three-dimensional principal stress. It is also a test instrument for theoretical study of geotechnical mechanics. On the basis of vertical rigid and horizontal orthogonal two-direction flexible triaxis loading equipment developed by Xi'an University of Technology, the self-developed small true triaxis instruments with sample sizes of 70 mm×70 mm×70 mm and 70 mm×70 mm×140 mm are further developed into a large one with 300 mm×300 mm×600 mm with both upper and lower servo-controlled synchronous loading. The true triaxis instrument includes the main frame of the pressure chamber, vertical main stress loading servo-control hydraulic oil source, main stress loading servo-control hydraulic variable controller in the horizontal plane, sample pore water pressure servo-control hydraulic controller, and the servo-control and signal acquisition and control system. The loading equipment of the pressure chamber has a baffle with horizontal rotation along the vertical axis, radial rolling and expansion movement under hydraulic driving, which effectively separates the adjacent flexible hydraulic bag. In the development of the true triaxis instrument, special structure latex film and sample mold, axial plate rolling structure and PID-closed control optimization algorithm are used to solve the problem of sample preparation and installation, test operation, boundary influence and so on. The problems of the interference of the orthogonal two-direction flexible loading cavity in horizontal plane as well as the stability of the dynamic control system are solved. Finally, the large-scale true triaxis apparatus is used to verify the tests on remolded loess under the same value of b. The stress-strain characteristics and shear strength of the remolded loess are consistent.
- large-scale true triaxial apparatus /
- flexible loading cavity /
- isolating balance device /
- PID-closed control algorithm /
- remolded loess
