硫酸盐侵蚀水泥改良路基段上拱研究

尧俊凯; 叶阳升; 王鹏程; 陈锋; 蔡德钩

doi:10.11779/CJGE201904024

硫酸盐侵蚀水泥改良路基段上拱研究 English Version

1. 中国铁道科学研究院,北京 100081;
2. 中国铁道科学研究院铁道建筑研究所,北京 100081

详细信息

作者简介:
尧俊凯(1992- ),男,博士研究生,主要从事膨胀性岩土方面研究的工作。E-mail: yao_junkai@163.com。

中图分类号: U213.1
计量
- 文章访问数: 334
- HTML全文浏览量: 8
- PDF下载量: 161
出版历程
- 收稿日期: 2018-05-01
- 发布日期: 2019-04-24

Subgrade heave of sulfate attacking on cement-stabilized filler

1. China Academy of Railway Sciences, Beijing 100081, China;
2. Railway Building Research Institute of China Academy of Railway Sciences, Beijing 100081, China

摘要

摘要: 首先对某高速铁路无砟轨道路基上拱问题进行了资料调研,通过现场变形监测、填料取样试验、矿物成分分析等手段,明确了硫酸盐侵蚀水泥改良填料膨胀是引起路基上拱主要原因,然后结合化学反应机理和室内模拟试验,对发生此类膨胀变形的反应条件、膨胀变形特征进行了分析。研究结果表明,膨胀变形主要发生在路基水泥改良填料层位,该土层具有大量硫酸盐侵蚀水泥产物钙矾石和硅灰石膏发育的特征,路基上拱与硫酸盐侵蚀水泥改良土形成钙矾石和硅灰石膏晶体相关;水泥改良填料中相对潮湿的高PH值碱性环境和石膏等硫酸盐矿物的存在是发生此类膨胀变形的必要条件;硫酸盐侵蚀水泥改良填料将发生持续性膨胀变形,上拱持续时间可达数年,破坏性强。本文研究成果可供类似环境下路基工程的建设及相关研究借鉴。
- 路基上拱 /
- 水泥改良土 /
- 硫酸盐侵蚀膨胀 /
- X射线衍射分析 /
- 钙矾石 /
- 硅灰石膏
Abstract: A high-speed railway subgrade which experiences a continuous and severe heave after construction is investigated through the delamination deformation monitoring, expansive tests and XRD tests. Sulfate attacking on cement-stabilized filler is the main reason of subgrade heave, and the reaction conditions and the development process of sulfate attacking expansion are analyzed based on the mechanism of crystal growth and chemical reaction. The results show that the cement-stabilized filler where the ettringite and thaumasite are identified has obvious swelling deformation, and the subgrade heave relates to the crystal formation of ettringite and thaumasite caused by sulfate attacking on cement-stabilized filler. The relatively humid alkaline environment and existence of sulfate minerals in cement stabilized filler are the necessary condition for such sulfate attacking expansion. The sulfate attacking on cement-stabilized filler exhibits a long-term persistent heave characteristic, and typical expansion of this type may develop for several years to create a critical and dangerous situation.
- subgrade heave /
- cement-stabilized filler /
- sulfate attacking expansion /
- X-ray diffraction analysis /
- ettringite /
- thaumasite

HTML全文

参考文献(21)

[1]	SHERWOOD P T.Effect of sulfates on cement and lime treated soils[J]. Hwy Res Board Bull, 1962, 353.
[2]	ROLLINGS M P, ROLLINGS R S.Geotechnical materials in construction[M]. New York: McGraw-Hill, 1996.
[3]	MICHAEL J M, LASZLO J C, ANISHA S.Fly ash influences on sulfate heave in lime-stabilized soils[J]. Proceedings of the Institution of Civil Engineers, 2012, 165: 147-157.
[4]	ALONSO PÉREZ DE, EDUARDO R T A. Massive sulfate attack to cement-treated railway embankments[J]. Géotechnique, 2013, 63(10): 857-870.
[5]	CHEN D H, HARRIS P, SCULLION T.Forensic investigation of a sulfate-heaved project in texas[J]. Journal of Performance of Constructed Facilities, 2005, 19(4): 324-330.
[6]	DURAN D R.Case study: heave potential associated with ettringite formation in lime treated materials for an aurora, Colorado, roadway[C]// Biennial Geotechnical Seminar. Denver, 2010.
[7]	ADAMS A G, DUKES O M, TABET W, et al.Sulfate induced heave in oklahoma soils due to lime stabilization[J]. Geocongress: Characterization, Monitoring, and, Modeling of Geosystems, 2008, 179: 444-451.
[8]	薛君玕. 钙矾石相的形成、稳定和膨胀记钙矾石学术讨论会[J]. 硅酸盐学报, 1983(6): 247-251. (XUE Jun-gan.Ettringite formation, stability and expansion-ettringite Symposium[J]. Journal of The Chinese Ceramic Society, 1983(6): 247-251. (in Chinese))
[9]	席耀忠. 二次钙矾石形成和膨胀混凝土的耐久性[J]. 混凝土的水泥制品, 2003(2): 5-9. (XI Yao-zhong.The formation of SEF and expansive concrete durability[J]. China Concrete And Cement Products, 2003(2): 5-9. (in Chinese))
[10]	韩宇栋, 张君, 高原. 混凝土抗硫酸盐侵蚀研究评述[J]. 混凝土, 2011(1): 52-61. (HAN Yu-dong, ZHANG Jun, GAO Yuan.Review of sulfate attack on concrete[J]. Concrete, 2011(1): 52-61. (in Chinese))
[11]	孟庆业. 水泥基胶凝材料中碳硫硅钙石的形成研究[D]. 长沙: 中南大学, 2014. (MENG Qing-ye.Investigation on thaumasite formation in cementitious materials[D]. Changsha: Central South University, 2014. (in Chinese))
[12]	BARNETT S J, MACPHEE D E, LACHOWSKI E E.XRD, EDX and IR analysis of solid solutions between thaumasite and ettringite[J]. Cement and Concrete Research, 2002, 32(5): 719-730.
[13]	LITTLE D N, NAIR S, HERBERT B.Addressing sulfate-induced heave in lime treated soils[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2010, 136(1): 110-118.
[14]	HUNTER D.Lime-induced heave in sulphate-bearing clay soils[J]. Geotech Engng, ASCE 1988, 114: 150-167.
[15]	MOHAMED A M O. The role of clay minerals in marly soils on its stability[J]. Engng Geol, 2000, 57: 193-203.
[16]	BENSTED J.Thaumasite: direct, woodfordite and other possible formation routes[J]. Cem Concr Compos, 2003, 25(8): 873-877.
[17]	TALLURI N, PUPPALA A J, CHITTOORI B C S. Calcium- based stabiliser treatment of sulfate-bearing soils[J]. Proceedings of the ICE-Ground Improvement, 2014, 167(3): 162-172.
[18]	MITCHELL J K, DERMATAS D.Clay soil heave caused by lime-sulfate reactions[J]. Innovations & Uses for Lime Astm Stp, 1992(1135): 24.
[19]	邓德华, 刘赞群, GEERT DE S, 等. 关于“混凝土硫酸盐结晶破坏”理论的研究进展[J]. 硅酸盐学报, 2012, 40(2): 175-185. (DENG De-hua, LIU Zan-qun, GEERT DE S, et al.Research progress on theory of “sulfate salt weathering on concrete”[J]. Journal of The Chinese Ceramic Society, 2012, 40(2): 175-185. (in Chinese))
[20]	LITTLE D N, NAIR S.Sensitivity of selected Colorado soils to form ettringite/thaumasite when treated with calcium- based stabilizer sand when soluble sulfates are available[J]. Transportation-Research, 2007, 193(6): 51-59.
[21]	PUPPALA A J, INTHARASOMBAT N, VEMPATI R K.Experimental studies on ettringite-induced heaving in soils[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2005, 131(3): 325-337.
