砂岩拉-剪力学特性试验研究

黄达; 张永发; 朱谭谭; 陈洪凯

doi:10.11779/CJGE201902004

砂岩拉-剪力学特性试验研究 English Version

黄达^{1, 2},
张永发^1, ,,
朱谭谭¹,
陈洪凯³

1. 重庆大学山地城镇建设与新技术教育部重点实验室,重庆 400045;
2. 河北工业大学土木与交通学院,天津 300401;
3. 重庆交通大学岩土工程研究所,重庆 400074

基金项目: 国家自然科学基金项目（41472245,41672300）; 重庆市研究生科研创新项目（CYB17043）; 中央高校基本科研业务费项目（106112017CDJXSYY002）

详细信息

作者简介:
黄达(1976- ),男,博士,教授,博士生导师,主要从事岩体力学及地质灾害方面的研究与教学工作。E-mail: hdcqy@126.com。

通讯作者:
张永发，E-mail：zyfcqu@126.com

计量
- 文章访问数: 0204
- HTML全文浏览量: 0
- PDF下载量: 0252
出版历程
- 收稿日期: 2017-12-20
- 发布日期: 2019-02-24

Experimental study on tension-shear mechanical behavior of sandstone

1. Key Laboratory of New Technology for Construction of Cities in Mountain Area, Ministry of Education, Chongqing University, Chongqing 400045, China;
2. School of Civil and Transportation Engineering, Hebei University of Technology, Tianjin 300401, China;
3. Institute of Geotechnical Engineering, Chongqing Jiaotong University, Chongqing 400074, China

摘要

摘要: 岩体工程开挖和河谷下切均将致使岩体应力沿一个或多个方向卸荷,造成岩体应力场重分布。这种卸荷常造成岩体承受拉剪应力,使得卸荷岩体的破坏呈现明显张性特征。然而由于试验技术的限制,在法向拉应力作用下岩石剪切力学行为的试验研究仍非常困难。笔者研发了拉伸-双面剪切试验装置,可直接在常规微机控制伺服直剪试验机上进行试验（将法向压应力转换成拉应力）。采用此装置,开展了砂岩的拉剪试验,结果表明：拉-剪应力作用下岩石剪应力-剪位移曲线峰前仅出现初始非线性段和线性变形两个阶段（即没有峰前的屈服段）;砂岩抗剪强度和剪切刚度随法向拉应力的增大逐渐减小;Hoek-Brown准则比Mohr-Coulomb准则能更好的描述砂岩在拉剪应力下的强度特征;随着法向拉应力的增大,岩样破裂面张性特征越突出且形状更为平直。
- 拉剪应力 /
- 双面剪切 /
- 抗剪强度 /
- 刚度 /
- 破裂
Abstract: Rock excavation and river incision result in stress unloading in one or more directions, which leads to the redistribution of stress fields of rock masses in the influenced zone. The rock masses in the unloading zone commonly bear tension-shear stress, making the failure of unloading rocks exhibit obvious tensile property. However, due to the limitation of test technology, it is still quite difficult to study the shear mechanical behavior of rock under the action of normal tensile stress. In this study, a tension double-shear test auxiliary device that can be used by conventional direct shear testing machine is designed to convert the normal compressive force to the tensile one. The direct shear tests on sandstone under tensile normal stress are carried out using this device. The results show that under the tension-shear stress, the curves of shear stress versus shear displacement before peak stress only show two deformation stages of initial nonlinear deformation and linear deformation (namely without yield stage before peak). The shear strength and shear stiffness of sandstone gradually decrease with the increase of the normal tensile stress. Compared with the Mohr-Coulomb criterion, the Hoek-Brown criterion is better in describing the strength characteristics of sandstone under tensile shear stress. Besides, as the normal tensile stress increases, the rupture surface of rock specimen has more obvious tension and is straighter in shape.
- tension-shear stress /
- double-face shear /
- shear strength /
- stiffness /
- fracture

HTML全文

参考文献(16)

[1]	张倬元, 王仕天, 王兰生, 等. 工程地质分析原理[M]. 北京: 地质出版社, 2009. (ZHANG Zhuo-yuan, WANG Shi-tian, WANG Lan-sheng, et al.Principles of engineering geology[M]. Beijing: Geological Publishing House, 2009. (in Chinese))
[2]	HUANG R Q, HUANG D.Evolution of rock cracks under unloading condition[J]. Rock mechanics and Rock Engineering, 2014, 47(2): 453-466.
[3]	ETHERIDGE M A.Differential stress magnitudes during regional deformation and metamorphism: upper bound imposed by tensile fracturing[J]. Geology, 1983, 11(4): 231-234.
[4]	黄润秋, 黄达, 段绍辉, 等. 锦屏Ⅰ级水电站地下厂房施工期围岩变形开裂特征及地质力学机制研究[J]. 岩石力学与工程学报, 2011, 30(1): 23-35. (HUANG Run-qiu, HUANG Da, DUAN Shao-hui, et al.Geomechanics mechanism and characteristics of surrounding rock mass deformation failure in construction phase for underground powerhouse of Jinping Ⅰ hydropower station[J]. Chinese Journal of Rock Mechanics and Engineering,(in Chinese))
[5]	赵宝云, 刘东燕, 朱可善, 等. 重庆红砂岩单轴直接拉伸蠕变特性试验研究[J]. 岩石力学与工程学报, 2011, 30(增刊2): 3960-3965. (ZHAO Bao-yun, LIU Dong-yan, ZHU Ke-shan, et al.Experimental research on creep characteristics of Chongqing red sandstone under direct tension[J]. Chinese Journal of Rock Mechanics and Engineering, 2011, 30(S2): 3960-3965. (in Chinese))
[6]	许江, 刘婧, 吴慧, 等.压剪应力条件下砂岩开裂扩展过程的试验研究[J]. 岩石力学与工程学报, 2013, 32(增刊2): 3042-3048. (XU Jiang, LIU Jing, WU Hui, et al.Test study of sandstone cracking and propagation process under compressive-shear stress[J]. Chinese Journal of Rock Mechanics and Engineering, 2013, 32(S2): 3042-3048. (in Chinese))
[7]	李建林. 岩石拉剪流变特性的试验研究[J]. 岩土工程学报, 2000, 22(3): 299-303. (LI Jian-lin.A test study on tension shear creep of rock[J]. Chinses Journal of Geotechnical Engineering, 2000, 22(3): 299-303. (in Chinese))
[8]	RAMSEY J M, CHESTER F M.Hybrid fracture and the transition from extension fracture to shear fracture[J]. Nature, 2004, 428(6978): 63.
[9]	周辉, 卢景景, 徐荣超, 等. 硬脆性大理岩拉剪破坏特征与屈服准则研究[J]. 岩土力学, 2016, 37(2): 305-314. (ZHOU Hui, LU Jing-jing, XU Rong-chao, et al.Research on tension-shear failure characteristics and yield criterion of hard brittle marble[J]. Rock and Soil Mechanics, 2016, 37(2): 305-314. (in Chinese))
[10]	CEN D, HUANG D.Direct shear tests of sandstone under constant normal tensile stress condition using a simple auxiliary device[J]. Rock Mechanics & Rock Engineering, 2017, 50(6): 1425-1438.
[11]	李守定, 李晓, 郭静芸, 等. 岩石拉伸剪切破裂试验研究[J]. 工程地质学报, 2014, 22(4): 655-666. (LI Shou-ding, LI Xiao, GUO Jing-yun, et al.Research of rock failure testing under combined shear and tension[J]. Journal of Engineering Geology, 2014, 22(4): 655-666. (in Chinese))
[12]	许江, 刘婧, 程立朝, 等. 压剪应力条件下砂岩双面剪切细观开裂扩展演化特性试验研究[J]. 岩石力学与工程学报, 2014, 33(4): 649-657. (XU Jiang, LIU Jing, CHEN Li-chao, et al.Mesoscopic cracking and expansion of double sheared sandstone under compressive-shear stress[J]. Chinese Journal of Rock Mechanics and Engineering, 2014, 33(4):649-657. (in Chinese))
[13]	YANG X L, YIN J H.Upper bound solution for ultimate bearing capacity with a modified Hoek-Brown failure criterion[J]. International Journal of Rock Mechanics & Mining Sciences, 2005, 42(4): 550-560.
[14]	GALINDO R A, SERRANO A, OLALLA C.Ultimate bearing capacity of rock masses based on modified Mohr-Coulomb strength criterion[J]. International Journal of Rock Mechanics & Mining Sciences, 2017, 93: 215-225.
[15]	HOEK E, BROWN E T.Empirical strength criterion for rock masses[J]. Journal of the Geotechnical Engineering Division, 1980, 106: 1013-1035.
[16]	周辉, 李震, 杨艳霜, 等. 岩石统一能量屈服准则[J].岩石力学与工程学报, 2013, 32(11): 2170-2184. (ZHOU Hui, LI Zhen, YANG Yan-shuang, et al.Unified energy yield criterion of rock[J]. Chinese Journal of Rock Mechanics and Engineering, 2013, 32(11): 2170-2184. (in Chinese))
