框架预应力锚杆加固多级高边坡地震响应数值分析

叶帅华; 时轶磊; 龚晓南; 陈长流

doi:10.11779/CJGE2018S1025

框架预应力锚杆加固多级高边坡地震响应数值分析 English Version

叶帅华^{1, 2, 3},
时轶磊^{1, 2},
龚晓南³,
陈长流⁴

1. 兰州理工大学甘肃省土木工程防灾减灾重点实验室,甘肃兰州 730050;
2. 兰州理工大学西部土木工程防灾减灾教育部工程研究中心,甘肃兰州 730050;
3. 浙江大学滨海和城市岩土工程研究中心,浙江杭州 310058;
4. 中国移动通信集团甘肃有限公司,甘肃兰州 730030

基金项目: 国家自然科学基金项目（51508256）; 甘肃省建设科技攻关计划项目（JK2015-5）; 兰州市科技发展计划项目（2015-3-131）

详细信息

作者简介:
叶帅华(1983- ),男,河南巩义人,博士后,副教授,主要从事支挡结构、地基处理及岩土工程抗震方面的教学和研究工作。E-mail: yeshuaihua@163.com。

中图分类号: TU476
计量
- 文章访问数: 0157
- HTML全文浏览量: 0
- PDF下载量: 0119
出版历程
- 收稿日期: 2017-06-10
- 发布日期: 2018-08-24

Numerical analysis of earthquake response of multistage high slopes reinforced by frame structure with pre-stressed anchors

1.Key Laboratory of Disaster Mitigation in Civil Engineering of Gansu Province, Lanzhou University of Technology, Lanzhou 730050, China;
2. Western Center of Disaster Mitigation in Civil Engineering, Ministry of Education, Lanzhou University of Technology, Lanzhou 730050, China;
3. Research Center of Coastal and Urban Geotechnical Engineering, Zhejiang University, Hangzhou 310058, China;
4. China Mobile Group Gansu Co., Ltd., Lanzhou 730030, China

摘要

摘要: 依托实际工程,基于Geostudio岩土分析软件,建立了框架预应力锚杆加固多级高边坡的动力分析模型。通过设置边界条件,输入水平地震作用,分析了边坡在地震作用下的位移响应、速度响应、加速度响应和锚杆轴力响应。结果表明：水平地震作用下,边坡内的位移、速度、加速度和锚杆的轴力等均随地震持时呈波动性变化。水平位移随时间变化显著且具有累积效应,边坡水平位移远大于竖直位移。坡体临空面水平加速度幅值明显增大,临空面对地震加速度具有放大效应。边坡总应力从坡底沿坡高递减,在坡底总应力最大。预应力锚杆的自由段与锚固段轴力均随地震持时波动性变化,自由段轴力较大,锚固段轴力沿远离自由段方向递减。分析结果可为框架预应力锚杆加固多级高边坡的地震响应提供一定的依据。
- 多级高边坡 /
- 数值分析 /
- 地震响应 /
- 框架预应力锚杆
Abstract: Based on the actual project and the Geostudio analysis software, the dynamic analysis model for a multistage high slope reinforced by frame structure with pre-stressed anchors is established. By inputting the horizontal seismic action and setting the boundary conditions, the responses of displacement, velocity, acceleration and axial force of anchors are analyzed. The results show that under the effect of horizontal earthquake, the displacement, velocity, acceleration and axial force of anchors of the slope have fluctuating change over the time of earthquake action. The horizontal displacement changes significantly and has an accumulation effect, and the horizontal displacement of slope is greater than the vertical one. The acceleration amplitude of slope surface increases obviously, which indicates that the surface of slope has an amplification effect on the earthquake acceleration. The total stress increases along the slope height, and it reaches the maximum at the bottom of slope. The axial forces of the free segment and anchorage segment fluctuatly change over the time, and the axial force of the free segment is larger, while that of the anchorage body gradually declines along the direction away from the free segment. The results can provide a reference for multistage high slopes reinforced by frame structure with pre-stressed anchors under earthquake action.
- multistage high slope /
- numerical analysis /
- earthquake response /
- frame structure with prestressed anchor

HTML全文

参考文献(11)

[1]	朱彦鹏, 罗晓辉, 周勇. 支挡结构设计 [M]. 北京: 高等教育出版社, 2008. (ZHU Yan-peng, LUO Xiao-hui, ZHOU Yong.Retaining structure design[M]. Beijing: Higher Education Press, 2008. (in Chinese))
[2]	朱彦鹏, 叶帅华. 水平地震下框架锚杆支护边坡简化分析方法[J]. 工程力学, 2011, 28(12) : 27-32. (ZHU Yan-peng, YE Shuai-hua.Simplified analysis of slope supported with frame-anchors under lateral seismic loading[J].Engineering Mechanics, 2011, 28(12): 27-32. (in Chinese))
[3]	董建华, 朱彦鹏, 马巍, 等. 框架预应力锚杆边坡支护结构抗震简化设计方法[J]. 中国公路学报, 2012, 25(5): 38-46. (DONG Jian-hua, ZHU Yan-peng, MA Wei, et al.Simplified seismic design method of frame supporting structure with prestressed anchors for slope stability[J]. China Journal of Highway and Transport, 2012, 25(5): 38-46. (in Chinese))
[4]	董建华, 朱彦鹏, 马巍.框架预应力锚杆边坡支护结构动力计算方法研究[J]. 工程力学, 2013, 30(5): 250-258. (DONG Jian-hua, ZHU Yan-peng, MA Wei.Study on dynamic calculation method for frame supporting structure with pre-stress anchors[J]. Engineering Mechanics. 2013, 30(5): 250-258. (in Chinese))
[5]	董建华, 朱彦鹏, 马巍. 地震作用下框架预应力锚杆边坡锚固结构的动力计算方法[J]. 岩石力学与工程学报, 2014, 33(增刊1): 3135-3143. (DONG Jian-hua, ZHU Yan-peng, MA Wei.Dynamic calculation method of frame prestressed anchors for slope stability under seismic effect[J]. Chinese Journal of Rock Mechanics and Engineering, 2014, 33(S1): 3135-3143. (in Chinese))
[6]	郑颖人, 叶海林, 黄润秋. 地震边坡破坏机制及其破裂面的分析探讨[J]. 岩石力学与工程学报, 2009, 28(8): 1714-1723. (ZHENG Ying-ren, YE Hai-lin, HUANG Run-qiu.Analysis and discussion of failure mechanism and fracture surface of slope under earthquake[J]. Chinese Journal of Rock Mechanics and Engineering, 2009, 28(8): 1714-1723. (in Chinese))
[7]	赵尚毅, 郑颖人, 时卫民, 等. 用有限元强度折减法求边坡稳定安全系数[J]. 岩土工程学报, 2002, 24(3): 343-346. (ZHAO Shang-yi, ZHENG Ying-ren, SHI Wei-min, et al.Analysis on safety coefficient of slope by strength reduction FEM[J]. Chinese Journal of Geotechnical Engineering, 2002, 24(3): 343-346. (in Chinese))
[8]	薄景山, 徐国栋, 景立平. 土边坡地震反应及其动力稳定性分析[J]. 地震工程与工程振动, 2001, 21(2): 116-120. (BO Jing-shan, XU Guo-dong, JING Li-ping.Seismic response and dynamic stability analysis of soil slopes[J]. Earthquake Engineering and Engineering Vibration, 2001, 21(2): 116-120. (in Chinese))
[9]	言志信, 曹小红, 张刘平, 等. 地震作用下黄土边坡动力响应数值分析[J]. 岩土力学, 2011, 32(增刊2): 610-614. (YAN Zhi-xin, CAO Xiao-hong, ZHANG Liu-ping.Numerical analysis of loess slope dynamic response under earthquake[J]. Rock and Soil Mechnaics, 2011, 32(S2): 610-614. (in Chinese)).
[10]	谭儒蛟, 李明生, 徐鹏逍, 等. 地震作用下边坡岩体动力稳定性数值模拟[J]. 岩石力学与工程学报, 2009, 28(增刊2): 3986-3992. (TAN Ru-jiao, LI Ming-sheng, XU Peng-xiao, et al.Numerical simulation of dynamic stability of slope rockmass under seismic loading[J]. Chinese Journal of Rock Mechanics and Engineering, 2009, 28(S2): 3986-3992. (in Chinese))
[11]	陈晓利, 李杨, 洪启宇, 等. 地震作用下边坡动力响应的数值模拟研究[J]. 岩石学报, 2011, 27(6): 1899-1908. (CHEN Xiao-li, LI Yang,HONG Qi-yu, etal. Numerical simulation of earthquake effects on rock slope[J]. Acta Petrologica Sinica, 2011, 27(6): 1899-1908. (in Chinese))
