Manufacture of new transparent clay and its physical and mechanical properties
-
摘要: 基于人工合成透明土材料和PIV技术的可视化模型试验方法是重要的岩土工程测试手段之一,然而,目前已有透明土材料中针对模拟天然黏土的材料仍相对较少。提出以Carbopol® Ultrez10聚合物（简称U10）、NaOH粉末和纯净水为原材料,碳纳米材料掺入作为示踪粒子制成散斑场,制配一种新型透明黏土材料的技术方案与操作方法。基于调制传递函数（MTF）方法,对新型透明黏土材料的光学透明性进行量化分析,并与已有透明土材料的光学透明性进行对比分析,验证其优越性。基于微型十字板剪切试验、压缩固结试验、渗透试验及热传导试验等室内试验方法,对新型透明黏土材料的物理力学特性进行系统研究,探讨其模拟天然黏土的可行性。研究结果表明：新型透明黏土材料的光学透明厚度可达25~40 cm,较目前已有常规透明土材料的光学透明厚度提高约2~3倍;新型材料表现为中低灵敏性黏土、强度随时间明显增加,强度、压缩固结特性与天然淤泥（尤其是海相淤泥）或泥炭土的性质相近,渗透系数为2×10-7~7×10-7 cm/s,热传导系数为0.62~0.71 W·M-1·K-1。Abstract: The visual model test based on synthetic transparent soil materials and PIV technology is one of the most important geotechnical engineering measurement technologies. However, there are still relatively few transparent materials which can be used for simulating the natural clay. A new transparent material which can simulate the natural clay is developed. It is manufactured by using Carbopol® Ultrez 10, NaOH powder and distilled water, and nano materials are served as the tracer particles for spackle pattern. The manufacture processes are introduced. Based on the modulation transfer function (MTF) method, the transparency of this material is analyzed, and also compared with that of the previous transparent materials. Based on the laboratory vane tests, consolidation tests, falling head tests and thermal conductivity tests, the geotechnical properties of this synthetic transparent clay are measured. It is shown that the transparent clay presents a good optical transparency within 30~40 cm, which is 2~3 times that of the previous materials. This material is quite consistent with the low or middle-sensitive natural clay, and its strength increases with time obviously. It has similar shear strength and consolidation properties to the natural mud (especially marine mud). Its permeability ranges from 2×10-7~7×10-7 cm/s, and its thermal conductivity ranges from 0.62~0.71 W·M-1·K-1.
-
Keywords:
- transparent clay /
- Carbopol® /
- Ultrez10 /
- optical transparency /
- laboratory test
-
[1] 孔纲强, 刘璐, 刘汉龙, 等. 玻璃砂透明土与标准砂变形特性对比三轴试验研究[J]. 岩土工程学报, 2013, 35(6): 1140-1146.
(KONG Gang-qiang, LIU Lu, LIU Han-long, et al.Comparative analysis on the deformation characteristics of transparent glass sand and standard sand[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(6): 1140-1146. (in Chinese))[2] 孔纲强, 孙学谨, 肖扬, 等. 透明土与标准砂压缩变形特性对比试验研究[J]. 岩土工程学报, 2016, 38(10): 1895-1903.
(KONG Gang-qiang, SUN Xue-jin, XIAO Yang, et al.Comparative experimental on compression deformation properties of transparent soil and standard sand[J]. Chinese Journal of Geotechnical Engineering, 2016, 38(10): 1895-1903. (in Chinese))[3] ISKANDER M, LAI J, OSWALD C, et al.Development of a transparent material to model the geotechnical properties of soils[J]. Geotechnical Testing Journal, 1994, 17(4): 425-433. [4] WALLACE J F, RUTHERFORD C J.Geotechnical properties of LAPONITE® RD[J]. Geotechnical Testing Journal, 2015, 38(5): 574-587. [5] EZZEIN F M, BATHURST R.J. A transparent sand for geotechnical laboratory modeling[J]. Geotechnical Testing Journal, 2011, 34(6): 590-601. [6] DOWNIE H, HOLDEN N, OTTEN W, et al.Transparent soil for imaging the rhizosphere[J]. Plos One, 2012, 7(9): 1-6. [7] KONG G Q, LI H, HU Y X, et al.New suitable pore fluid to manufacture transparent soil[J]. Geotechnical Testing Journal, 2017, 40(4): 658-672. [8] LO H, TABE K, ISKANDER M, et al.A transparent water-based polymer for simulating multiphase flow[J]. Geotechnical Testing Journal, 2010, 33(1): 1-13. [9] HAKHAMANESHI M, BLACK J A.Shear strength of transparent gelita-effect of mixture ratio, displacement rate and over-consolidation ratio[C]// Geochicago. 2016. [10] 李斗. 滇池泥炭土微观结构特征及工程力学模型研究[D]. 昆明: 昆明理工大学, 2015.
(LI Dou.The study on micro-structure and engineering mechanical model of Dianchi peat soil in Kunming basin[D]. Kunming: Kunming University of science and Technology, 2015. (in Chinese))[11] BLACK J A, TAKE W A.Quantification of optical clarity of transparent soil using the modulation transfer function[J]. Geotechnical Testing Journal, 2015, 38(5): 588-602. [12] TERZAGHI K.Ends and means in soil mechanics[D]. Boston: Harvard University, 1944. [13] SCHLUE B F, MOERZ T, KREITER S.Influence of shear rate on undrained vane shear strength of organic harbor mud[J]. Journal of Geotechnical & Geoenvironmental Engineering, 2010, 136(10): 1437-1447. [14] MORETTO O.Effect of natural hardening on the unconfined compression strength of remolded clays[C]// Proceeding of the 2nd International Conference on Soil Mechanics and Foundation. Rotterdam, 1948. [15] SKEMPTON A W, NORTHEY R D.The sensitivity of clays[J]. Géotechnique, 2015, 3(1): 30-53. [16] 张长生, 高明显, 强小俊. 深圳后海湾海相淤泥固结系数变化规律研究[J]. 岩土工程学报, 2013, 35(增刊1): 247-252.
(ZHANG Chang-sheng, GAO ming-xian, QIANG Xiao-jun. Variation laws of consolidation coefficent of marine clay in Houhai Bay of Shenzhen[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(S1): 247-252. (in Chinese))[17] 房后国. 深圳湾结构性淤泥土固结机理及模型研究[D]. 长春: 吉林大学, 2005.
(FANG Hou-guo.The study on consolidation mechanism and model of structural soft soil in Shenzhen Bay[D]. Changchun: Jilin University, 2005. (in Chinese))[18] 卫国芳. 深圳湾海相淤泥的压缩特性研究[J]. 科学技术与工程, 2013, 13(3): 795-798.
(WEI Guo-fang.Study on compression characteristics of marine silt in Shenzhen bay[J]. Science Technology and Engineering, 2013, 13(3): 795-798. (in Chinese))[19] TERZAGHI K, PECK R, MESRI G.Soil mechanics in engineering practice[M]. 3rd ed. New York: Wiley, 1996. [20] TAVENAS F, JEAN P, LEBLOND P, et al.The permeability of natural soft clays[J]. Canadian Geotechnical Journal, 2011, 20(4): 645-660. [21] CÔTÉ J, KONRAD J M. A generalized thermal conductivity model for soils and construction materials[J]. Canadian Geotechnical Journal, 2005, 42(42): 443-458. -
