土体非共轴各向异性对城市浅埋土质隧道诱发地表沉降的影响

袁冉; 杨文波; 余海岁; 周波

doi:10.11779/CJGE201804011

土体非共轴各向异性对城市浅埋土质隧道诱发地表沉降的影响 English Version

袁冉^1,2,
杨文波^1, ,,
余海岁²,
周波^2,3

1. 交通隧道工程教育部重点实验室（西南交通大学）,四川成都 610013;
2. 英国诺丁汉大学,英国诺丁汉NG7 2RD;
3. 中铁上海工程局,上海 200436;

基金项目: 国家自然科学基金项目（51609204,51408494,51678499）; 中央高校基本科研业务费专项资金项目（2682016CX002,2682015 CX092）

详细信息

作者简介:
袁冉(1987- ),女,讲师,主要从事土体本构建模、数值模拟以及岩土工程应用方面的研究。E-mail: yuanran@home.swjtu.edu.cn。

通讯作者:
杨文波，E-mail：yangwenbo1179@hotmail.com

中图分类号: TU43
计量
- 文章访问数: 0385
- HTML全文浏览量: 0
- PDF下载量: 0252
出版历程
- 收稿日期: 2016-06-05
- 发布日期: 2018-04-24

Effects of non-coaxiality and soil anisotropy on tunneling-induced subsurface settlements

YUAN Ran^1,2,
YANG Wen-bo^1, ,,
YU Hai-Sui²,
ZHOU Bo^2,3

1. Key Laboratory of Transportation Tunnel Engineering, Ministry of Education, Southwest Jiaotong University, Chengdu 610013, China;
2. University of Nottingham, Nottingham, UK, NG7 2RD;
3. Shanghai Civil Engineering Co., Ltd. of China Railway Group Ltd., Shanghai 200436, China;

摘要

摘要: 当前用于隧道工程数值模拟的本构模型,大多局限于土体各向同性框架下的共轴假设,难以充分反映隧道周围土体力学响应的复杂性。针对典型砂土和软黏土,建立考虑初始强度各向异性和非共轴特性的二维平面应变、理想弹塑性的土体本构模型,并编制用户材料子程序（UMAT）,嵌入非线性有限元软件ABAQUS中,对城市浅埋土质隧道开挖施工进行二维数值模拟分析。结果表明：开挖面附近土体应力主轴可能发生明显旋转;同等地层损失率下,考虑土体初始强度各向异性预测的地表归一化沉降槽的形状与离心机试验结果更加吻合;同一程度荷载衰减下,考虑非共轴各向异性影响后沿中轴线的最大地表竖向位移明显偏大。因此可以认为,如忽略土体的非共轴和各向异性特性,可能会导致相关的设计方案偏于不安全。
- 土体强度各向异性 /
- 非共轴性 /
- 数值模拟 /
- 城市浅埋土质隧道 /
- 离心机试验
Abstract: Nowadays, constitutive models for soils used for numerical modelling of tunnelling are normally restricted to the assumption of soil strength isotropy and coaxiality. A plane strain, elastic-perfectly plastic non-coaxial soil model with an anisotropic yield criterion is proposed. The non-coaxial soil model developed is then implemented into the commercial finite element software ABAQUS via the user-defined material subroutine (UMAT). Numerical simulations are performed on two-dimensional city shallow earth tunnel excavations using the newly proposed non-coaxial soil model. A case study is performed to compare the numerical results with the centrifuge test ones. The results show that the representative soil elements around tunnel experience severe principal stress orientations. The prediction of normalized subsurface settlement trough can be improved by considering the initial soil strength anisotropy. A larger value of the non-coaxial coefficient results in a larger magnitude of the maximum vertical displacement. It is concluded that no consideration of soil anisotropy and non-coaxiality may result in unsafe design in tunnelling.
- soil anisotropy /
- non-coaxiality /
- numerical simulation /
- city shallow earth tunnel /
- centrifuge testing

HTML全文

参考文献(24)

[1]	ARTHUR J R F, CHUA K S, DUNSTAN T. Induced anisotropy in a sand[J]. Géotechnique, 1977, 27(1): 13-30.
[2]	ODA M, KONISHI J.Rotation of principal stresses in granular material during simple shear[J]. Soils and Foundations, 1974, 14(4): 39-53.
[3]	童朝霞, 张建民, 于艺林. 中主应力系数对应力主轴循环旋转条件下砂土变形特性的影响[J]. 岩土工程学报, 2009, 31(6): 946-952. (TONG Zhao-xia, ZHANG Jian-min, YU Yi-lin.Effects of intermediate principal stress parameter on deformation behavior of sands under cyclic rotation of principal stress axes[J]. Chinese Journal of Geotechnical Engineering, 2009, 31(6): 946-952. (in Chinese))
[4]	YANG L T.Experimental study of soil anisotropy using hollow cylinder testing[D]. Nottingham: University of Nottingham, 2013.
[5]	黄茂松, 孙海忠, 钱建固. 粗粒土的非共轴性及其离散元数值模拟[J]. 水利学报, 2010, 41(2): 173-181. (HUANG Mao-song, SUN Hai-zhong, QIAN Jian-gu.Non-coaxial behavior of coarse granular aggregates simulated by DEM[J]. Journal of Hydraulic Engineering, 2010, 41(2): 173-181. (in Chinese))
[6]	HASHIGUCHI K, TSUTSUMI S.Shear band formation analysis in soils by the subloading surface model with tangential stress rate effect[J]. International Journal of Plasticity, 2003, 19(10): 1651-1677.
[7]	李学丰, 黄茂松, 钱建固. 宏-细观结合的砂土单剪试验非共轴特性分析[J]. 岩土力学, 2013, 34(12): 3417-3424. (LI Xue-feng, HUANG Mao-song, QIAN Jian-gu.Analysis of non-coaxial characters of sand for simple shear test with the method of macro-meso-incorporation[J]. Rock and Soil Mechanics, 2013, 34(12): 3417-3424. (in Chinese))
[8]	LI X S, DAFALIAS Y F.A constitutive framework for anisotropic sand including non-proportional loading[J]. Géotechnique, 2004, 54(1): 41-45.
[9]	黄茂松. 土体稳定与承载特性的分析方法[J]. 岩土工程学报, 2016, 38(1): 1-34. (HUANG Mao-song.Analysis methods for stability and bearing capacity of soils[J]. Chinese Journal of Geotechnical Engineering, 2016, 38(1): 1-34. (in Chinese))
[10]	YU H S, YUAN X.On a class of non-coaxial plasticity models for granular soils[J]. Proceedings of the Royal Society A: Mathematical, Physical and Engineering Science, 2006, 462(2067): 725-748.
[11]	YANG Y, YU H S.Numerical simulations of simple shear with non-coaxial soil models[J]. International Journal for Numerical and Analytical Methods in Geomechanics, 2006, 30(1): 1-19.
[12]	YANG Y, YU H S.Finite element analysis of anchor plates using non-coaxial models[J]. Journal of Rock Mechanics and Geotechnical Engineering, 2010, 2(2): 178-187.
[13]	陈先国, 高波. 地铁近距离平行隧道有限元数值模拟[J]. 岩石力学与工程学报, 2002, 21(9): 1330-1334. (CHEN Xian-guo, GAO Bo.2D FEM numerical simulation for closely-spaced parallel tunnels in metro[J]. Chinese Journal of Rock Mechanics and Engineering, 2002, 21(9): 1330-1334. (in Chinese))
[14]	崔蓬勃, 陈晶晶. 高速铁路隧道下穿高速公路地表沉降影响分析[J]. 江苏建筑职业技术学院学报, 2015, 15(2): 21-25. (CUI Peng-bo, CHEN Jing-jing.Analysis on influence of ground surface settlement on highway with high-speed railway tunnel passing below[J]. Journal of Jiangsu Jianzhu Institute, 2015, 15(2): 21-25. (in Chinese))
[15]	TSUTSUMI S, HASHIGUCHI K.General non-proportional loading behavior of soils[J]. International Journal of Plasticity, 2005, 21(10): 1941-1969.
[16]	BOOKER J R, DAVIS E H.A general treatment of plastic anisotropy under conditions of plane strain[J]. Journal of the Mechanics and Physics of Solids, 1972, 20(4): 239-250.
[17]	SPENCER A J M. A theory of the kinematics of ideal soils under plane strain conditions[J]. Journal of the Mechanics and Physics of Solids, 1964, 12(5): 337-351.
[18]	HARRIS D.Constitutive equations for planar deformations of rigid-plastic materials[J]. Journal of the Mechanics and Physics of Solids, 1993, 41(9): 1515-1531.
[19]	HARRIS D.A unified formulation for plasticity models of granular and other materials[J]. Proceedings of the Royal Society of London. Series A: Mathematical and Physical Sciences, 1995, 450(1938): 37-49.
[20]	ODA M, KOISHIKAWA I, HIGUCHI T.Experimental study of anisotropic shear strength of sand by plain strain test[J]. Soils and Foundations, 1978, 18(1): 25-38.
[21]	YUAN R.A non-coaxial theory of plasticity for soils with an anisotropic yield criterion[D]. Nottingham: University of Nottingham, 2015.
[22]	ZHAO Y.In situ soil testing for foundation performance prediction[D]. Cambridge: University of Cambridge, 2008.
[23]	ZHOU B.Tunnelling-induced ground displacements in sand[D]. Nottingham: University of Nottingham, 2015.
[24]	YANG D S.Microscopic study of granular material behaviour under general stress paths[D]. Nottingham: University of Nottingham, 2014.
