基于土体的大变形分析钻井船插桩对邻近桩的影响

范怡飞; 王建华; 戴笑如

doi:10.11779/CJGE201801008

基于土体的大变形分析钻井船插桩对邻近桩的影响 English Version

范怡飞^1,2,
王建华^1,2, ,,
戴笑如^1,2

1.天津大学水利工程仿真与安全国家重点实验室,天津 300072
2.天津大学岩土工程研究所,天津 300072

基金项目: 国家自然科学基金项目（51579174）

详细信息

作者简介:
范怡飞(1993-),女,博士研究生,主要从事海洋岩土工程研究。E-mail:1367244424@qq.com。

通讯作者:
王建华，E-mail：tdwjh@eyou.com

中图分类号: TU43
计量
- 文章访问数: 438
- HTML全文浏览量: 7
- PDF下载量: 322
出版历程
- 收稿日期: 2016-10-24
- 发布日期: 2018-01-24

Effects of spudcan penetration on adjacent piles based on large deformation of soils

1.State Key Laboratory of Hydraulic Engineering Simulation and Safety, Tianjin University, Tianjin 300072, China
2.Geotechnical Engineering Institute, Tianjin University, Tianjin 300072, China

摘要

摘要: 自升式钻井船插桩对邻近平台桩基础的影响主要体现为插桩导致的土体大变形会使邻近平台桩基础受到附加水平荷载。当钻井船插桩时的桩靴边缘与邻近平台桩外缘之间间距小于桩靴直径时,就需要定量评价钻井船插桩对邻近平台桩的影响程度。基于分析被动桩响应的两段法原理,通过开发ABAQUS中分析材料大变形的网格重新划分算法与相应的计算结果后处理方法,CEL计算结果的后处理方法,形成了求解钻井船在自由场地插桩时周围土体极大变形的有限元算法;进而,依据计算出的自由场地土体位移,采用增量有限差分方法求解非线性地基梁控制方程,即可获得钻井船插桩时的邻近桩桩身响应。以上形成了一种能够定量分析钻井船插桩对邻近桩影响的两段法。利用此方法预测已有的离心模型试验结果,获得了与实测结果基本吻合的预测结果。这表明建立的用于分析钻井船插桩对邻近桩影响的两段法是可行的。
- mesh-to-mesh /
- CEL /
- 土体位移 /
- 两段法 /
- 钻井船插桩
Abstract: The effects of spudcan penetration on adjacent piles are mainly embodied in the additional lateral loads induced by large deformation of soils. It is a common practice to quantitively evaluate the effects when the edge-to-edge clearance between the spudcan and the pile is less than the spudcan diameter. The conventional two-stage passive pile analysis method is utilized to investigate the process. Analysis continuation after the mesh replacement (mesh-to-mesh) technique is improved and post-processed, and CEL technique is post-processed to calculate the soil displacement during free-field spudcan penetration. Then by considering the nonlinear beam foundation model and p-y data, the bending moments of pile during spudcan penetration can be calculated by means of the incremental finite difference method based on the free-field soil displacement. Thus a two-stage method to analyze the effects of spudcan penetration on adjacent piles can be formed. Good agreement between the calculated and measured results is found compared with the available centrifuge tests by which the efficacy of the proposed method can be proved.
- mesh-to-mesh /
- CEL /
- soil displacement /
- two-stage method /
- spudcan penetration

HTML全文

参考文献(16)

[1]	刘占阁, 王栋, 栾茂田, 等. 钻井船基础压入对邻近平台桩基影响的有限元数值分析[C]// 中国土木工程学会第九届土力学及岩土工程学术会议论文集. 北京, 2003: 25-28. (LIU Zhan-ge, WANG Dong, LUAN Mao-tian.Numerical study of the influence of spudcan penetration on adjacent piles[C]// Chinese Institution of Soil Mechanics and Geotechnical Engineering. Beijing, 2003: 25-28. (in Chinese))
[2]	POULOS H G.Effect of pile driving on adjacent piles in clay[J]. Canadian Geotechnical Journal, 1994, 31(6): 856-867.
[3]	GOH A T C, TEH C I, WONG K S. Analysis of piles subjected to embankment induced lateral soil movements[J]. Journal of Geotechnical and Geoenvironmental Engineering, 1997, 123(9): 792-801.
[4]	XU X T, LIU H L, LEHANE B M.Pipe installation effects in soft clay[C]// Proceedings of Institution of Civil Engineers, Geotechnical Engineering, 2006: 285-296.
[5]	THO K K, CHEN Z G, LEUNG C F, et al.Enhanced analysis of pile flexural behavior due to installation of adjacent piles[J]. Canadian Geotechnical Journal, 2014, 51: 705-711.
[6]	GRABE J, HENKE S.High-performance finite element and coupled Eulerian-Lagrangian simulations of pile installation processes[C]// Proceedings of 4th International Conference on Structural Engineering. Mechanics and Computation, Cape Town, South Africa. 2010: 63-68.
[7]	LI Y, ZHOU Y R, TAO J H, et al.Numerical study of spudcan penetration induced loading on an adjacent jacket pile in soft clays[C]// Proceedings of the Twenty-fifth International Ocean and Polar Engineering Conference, 2015: 692-699.
[8]	吴永韧, 鲁晓兵, 王淑云, 等. Spudcan基础贯入对固定平台基础影响[J]. 中国海洋平台,2008, 23(1): 35-38. (WU Yong-ren, LU Xiao-bing, WANG Shu-chun, et al.Effects of spudcan on pile foundations of fixed platform[J]. China Offshore Platform, 2008, 23(1): 35-38. (in Chinese))
[9]	HOSSAIN M S, ZHENG J B, MENZIES D, et al.Spudcan penetration analysis for case histories in clay[J]. J Geotech Geoenviron Engrg, 2014, 140(7): 04014034.
[10]	XIE Y.Centrifuge model study on spudcan-pile interaction[D]. Singapore: National University of Singapore, 2009.
[11]	ABAQUS 2013. ABAQUS Version 6.13 User's ManualsBAQUS 2013. ABAQUS Version 6.13 User's Manuals[M]. Providence City: SIMULIA, 2013.
[12]	American Petroleum Institute.Geotechnical and foundation design considerations[M]. 1st ed. ANSI/API Recommended Practice 2GEO, 2011.
[13]	KONDNER R L.Hyperbolic stress-strain response: cohesive soils[J]. Journal of Soil Mechanics and Foundation Engineering, 1963, 89(1): 115-144.
[14]	TIAN Y H, CSSIDY M J, RANDOLPH M F, et al.A simple implementation of RITSS and its application in large deformation analysis[J]. Computers and Geotechnics, 2014(56): 160-167.
[15]	PUCKER T, GRABE J.Numerical simulation of the installation process of full displacement piles[J]. Computers and Geotechnics, 2012, 45: 93-106.
[16]	POULOS H G, DAVIS E H.Pile foundation analysis and design[M]. Taipei: Rainbow Bridge Book Co, 1980: 163-225.
