塑料排水板处理软土地基的离心模型试验研究

王存; 侯瑜京; 刘国宝; 彭仁

doi:10.11779/CJGE2017S1034

塑料排水板处理软土地基的离心模型试验研究 English Version

1. 中国水利水电科学研究院岩土工程研究所,北京 100048;
2. 大连中交理工交通技术研究院有限公司,辽宁大连 116023;
3. 北京航空航天大学土木工程系,北京 100191

详细信息

作者简介:
王存(1990-),男,河北唐山人,硕士,主要从事土工离心模型试验研究。E-mail:wangcun@snpdri.com。

计量
- 文章访问数: 0190
- HTML全文浏览量: 0
- PDF下载量: 0202
出版历程
- 收稿日期: 2016-11-27
- 发布日期: 2017-11-19

Centrifugal model tests on vertical strip drains in soft soil foundation

1. Department of Geotechnical Engineering, China Institute of Water Resources and Hydropower Research (IWHR), Beijing 100048, China;
2. Dalian CCCC Water Transportation Consultants Co., Ltd., Dalian 116023, China;
3. Department of Civil Engineering, Beihang University, Beijing 100191, China

摘要

摘要: 采用大型土工离心机对某海上机场工程近海软土地基上堤坝施工期及运行期进行了模拟。原型中采用塑料排水板固结法处理软土地基,模型中则根据固结过程相似的原理,换算成等效圆截面排水体,在模型制作中采用等效透水滤芯来模拟。试验中采用停机加载法模拟分级施工加载过程。根据激光位移传感器试验数据可以计算得出相应原型软土地基的沉降特性。利用试验得到的沉降曲线,采用“经验双曲线法”推算出了地基最终沉降,然后得出按沉降推算的分层地基平均固结度随时间的变化。对比沉降推算的运行5 a时软土地基固结度和理论计算结果,二者基本接近,表明文中塑料排水板的模拟方法用于离心模型试验是可行的。通过与理论计算结果比较,表明试验采用的塑料排水板模拟方法是可行的。
- 塑料排水板 /
- 离心模型试验 /
- 软基 /
- 固结度
Abstract: Centrifugal model tests are carried out to simulate the construction and operation of the dike on a soft soil foundation for the purpose of taxiway construction on the seashore. The vertical strip drains are adopted for the soft foundation treatment and they are simulated by a kind of model cylinder vertical drains in centrifuge models based on the principles of the same consolidation degree in the foundation in average for both types of drains. During the model tests, the construction processes are also simulated by loading dike materials layer by layer. Laser displacement sensors are installed for settlement measurement. Based on the test data, the final settlement of the dike is estimated by using the empirical hyperbolic method. The consolidation degree of the foundation over time is also calculated by getting the average consolidation degrees of the sludge and the sand under the dike. By comparing the simulated consolidation degree of the soft foundation after 5 years operation based on the test results of settlement with that of the theoretical calculation, it is shown that the proposed simulation method for vertical strip drains is feasible and acceptable.
- vertical strip drain /
- centrifugal model test /
- soft soil foundation /
- consolidation

HTML全文

参考文献(14)

[1]	侯瑜京, 韩连兵, 梁建辉. 深水港码头围堤和群桩结构的离心模型试验[J]. 岩土工程学报, 2004, 26(5): 594-600. (HOU Yu-jing, HAN Lian-bing, LIANG Jian-hui. Centrifuge modeling of sea dike and pile groups in a harbor[J]. Chinese Journal of Geotechnical Engineering, 2004, 26(5): 594-600. (in Chinese))
[2]	包承纲, 蔡正银, 陈云敏, 等. 岩土离心模拟技术的原理和工程应用[M]. 武汉: 长江出版社, 2011. (BAO Cheng-gang, CAI Zheng-yin, CHEN Yun-min, et al. The principle and engineering application of geotechnical centrifuge modeling technology[M]. Wuhan: The Changjiang Press, 2011. (in Chinese))
[3]	卢国胜. 塑料排水板处理软基的离心机试验研究[J]. 西南科技大学学报, 2006, 21(4): 43-45. (LU Guo-sheng. Centrifuge experiment to improve soft foundation through plastic wick drain[J]. Journal of Southwest University of Science and Technology, 2006, 21(4): 43-45. (in Chinese))
[4]	饶锡保, 龚壁卫, 程展林, 等. 基于离心模型试验的某公路软基沉降变形规律研究[C]// 物理模拟技术在岩土工程中的应用,中国水利学会2007学术年会论文集. 苏州, 中国水利学会, 2007: 119-125. (RAO Xi-bao, GONG Bi-wei, CHENG Zhan-lin, et al. The research of settlement deformation law of a certain highway soft foundation based on the centrifugal model test[C]// The physical simulation technology application in geotechnical engineering, the monograph of academic annual conference held by Chinese Hydraulic Engineering Society in 2007. Suzhou, Chinese Hydraulic Engineering Society, 2007: 119-125. (in Chinese))
[5]	蒋关鲁, 胡润忠, 李安洪. 离心模型试验预测中等压缩性土地基沉降的可行性[J].交通运输工程学报, 2011, 11(6): 18-23. (JIANG Guan-lu, HU Run-zhong, LI An-hong. Feasibility of predicting settlement of medium compression soil foundation with centrifuge model test[J]. Journal of Traffic and Transportation Engineering, 2011, 11(6): 18-23. (in Chinese))
[6]	陈胜立, 张建民, 张丙印, 等. 软土地基上土工织物加筋堤的离心模型试验研究[J]. 岩土力学, 2006, 27(5): 804-806. (CHEN Sheng-li, ZHANG Jian-min, ZHANG Bing-yin, et al. Numerical simulation of centrifugal model test on reinforced embankment with lime-stabilized soil as backfill on soft clay foundation[J]. Chinese Journal of Rock Mechanics and Engineering, 2006, 27(5): 804-806. (in Chinese))
[7]	侯瑜京. 离心模型试验模拟塑料排水板处理软基的试验研究[J]. 大坝观测与土工测试, 1995, 19(5): 18-20. (HOU Yu-jing. Centrifugal modeling of the plastic plank in soft foundation treatment[J]. Dam Observation and Geotechnical Tests, 1995, 19(5): 18-20. (in Chinese))
[8]	高长胜, 张凌, 汪肇京, 等. 塑料排水板的等效直径[J].水利水运工程学报, 2002, 4: 43-45. (GAO Chang-sheng, ZHANG Ling, WANG Zhao-jing, et al. Equivalent diameter of prefabricated drain[J]. Hydro-science and Engineering, 2002, 4: 43-45. (in Chinese))
[9]	孔德金, 苗中海. 软基加固检测孔隙水压力分析[J]. 港工建设, 2000(3): 29-31. (KONG De-jin, MIAO Zhong-hai. The analysis on variation of pore water pressure during consolidating soft soil foundation[J]. Port Engineering Technology, 2000(3): 29-31. (in Chinese))
[10]	程强, 顾立军, 冯伟骞. 由实测沉降曲线推求最终沉降量计算方法的探讨[J]. 海河水利, 2010(4): 37-39. (CHENG Qiang, GU Li-jun, FENG Wei-jian. The method of calculating the final settlement by the measured settlement curve[J]. Haihe Water Resouces, 2010(4): 37-39. (in Chinese))
[11]	赵辉, 李粮纲. 堆载预压排水固结法加固软土地基的固结度分析[J]. 探矿工程(岩土钻掘工程), 2005, 14(3): 9-11. (ZHAO Hui, Li Liang gang. The consolidation degree analysis of using load pre-pressure drainage consolidation method to consolidate soft-soil foundation[J]. Exploration Engineering (Drilling &Tunneling), 2005, 14(3): 9-11. (in Chinese))
[12]	张超. 堆载预压法处理软土地基时固结度的计算[J].中国水运, 2014, 14(7): 357-358. (ZHANG Chao. Calculation of consolidation degree of soft soil foundation treated by preloading method[J]. China Water Transport, 2014, 14(7): 357-358. (in Chinese))
[13]	钱晓丽, 张建勋, 陈为群. 塑料排水板地基处理固结沉降特性[J]. 贵州大学学报(自然科学版), 2010, 27(3): 92-94. (QIAN Xiao-li, ZHANG Jian-xun, CHEN Wei-qun. Characteristics of consolidation settlement in ground treatment for plastic vertical drain[J]. Journal of Guizhou University(Natural Science), 2010, 27(3): 92-94. (in Chinese))
[14]	JTS.147—1—2010 港口工程地基规范[S]. (JTS.147—1—2010 Code for foundation in port engineering[S]. (in Chinese))
