列车荷载下考虑频率影响的软黏土破坏标准研究

王鑫; 沈扬; 王保光; 杜文汉; 徐海东; 王钦城

doi:10.11779/CJGE2017S1007

列车荷载下考虑频率影响的软黏土破坏标准研究 English Version

王鑫^1,2,
沈扬^1, ,,
王保光¹,
杜文汉¹,
徐海东¹,
王钦城¹

1. 河海大学岩土力学与堤坝工程教育部重点实验室,江苏南京 210098;
2. 济南轨道交通集团有限公司,山东济南 250100

基金项目: 国家自然科学基金面上项目（51479060）; 中央高校基本科研业务费专项资金项目（2015B28214）; 山东省住房与城乡建设厅科技项目（2014QG009）

详细信息

作者简介:
王鑫(1990-),女,山东烟台,硕士,主要从事列车荷载下软土动力特性研究。E-mail:wangxin2014hhu@163.com。

通讯作者:
沈扬，E-mail：shenyang1998@163.com

计量
- 文章访问数: 305
- HTML全文浏览量: 3
- PDF下载量: 205
出版历程
- 收稿日期: 2016-11-27
- 发布日期: 2017-11-19

Failure criteria for soft clay subjected to frequencies under train loads

1. Key Laboratory of Geomechanics and Embankment Engineering of Ministry of Education, Hohai University, Nanjing 210098, China;
2. Jinan Rail Transit Group Co., Ltd., Jinan 250100, China

摘要

摘要: 列车荷载在地基土体中引发一种心形线主应力轴旋转动力路径,考虑频率作用时,会对地基土产生更为复杂的影响。以南京河西典型重塑软黏土为对象开展数组不同频率f和动应力比η的不排水空心扭剪试验。试验发现,不同动应力比下,土体变形随振动频率的变化趋势主要分为两种情况。另外,随着频率f的提高,试样发生破坏的临界动应力比先减小后增大。频率f在1.0~2.0 Hz范围内,孔压发展曲线受频率影响较小,当f=0.5 Hz时,孔压发展显著增大。提出一种适用于列车荷载下考虑频率影响的重塑软黏土破坏评价方法。该标准以孔压-应变耦合曲线为主要辨识曲线,可以判别试样所属的稳定、临界或破坏型状态,为后续开展列车荷载引起的软黏土地基承载力研究提供理论支持。
- 列车荷载 /
- 重塑软黏土 /
- 振动频率 /
- 破坏标准 /
- 动强度
Abstract: The heart-shaped stress path can be caused by train loads in the foundation. The train load path has a more complicated influence on foundation soils when the effects of frequencies are considered. A serious of undrained cyclic hollow torsional shear tests are carried out on typical remold soft clay (in Hexi District of Nanjing) with different values of vibration frequency f and dynamic stress ratio η. It is found that the trend of soil deformation influenced by frequencies can be divided into two types. Otherwise, the critical dynamic stress ratio first decreases and then increases with the increase of the frequency. When the frequency f locates in the range of 1.0~2.0 Hz, the developing curves of pore pressure are consistent and the influences of the frequencies are small. However, when the frequency equals to 0.5 Hz, the development of pore pressure significantly increases. Then a new failure evaluating method for remolded soft clay is presented. It is used to investigate the influences of the frequencies caused by train loads. This criterion can distinguish the stable, critical or destructive states of samples mainly by the pore pressure-strain coupling curve. The range of failure strain and vibration cycles can also be given. The results may provide theoretical support for the researches on the bearing capacity of soft clay foundations subjected to traffic loads.
- train load /
- remolded soft clay /
- vibration frequency /
- failure criterion /
- dynamic strength

HTML全文

参考文献(11)

[1]	ISHIKAWA T, SEKINE E, MIURA S. Cyclic deformation of granular material subjected to moving wheel loads[J]. Canadian Geotechnical Journal, 2011, 48(5): 691-703.
[2]	YASUHARA K, YAMANOUCHI T, HIRAO K. Cyclic strength and deformation of normally consolidation clay[J]. Soils and Foundations, 1982, 22(3): 77-91.
[3]	肖军华, 许世芹, 韦凯,等. 主应力轴旋转对地铁荷载作用下软黏土累积变形的影响[J]. 岩土力学, 2013, 34(10): 2928-2944. (XIAO Jun-hua, XU Shi-qin, WEI Kai, et al. Influences of rotation of principal stress axis on accumulative deformation of soft clay under subway cyclic loading[J]. Rock and Soil Mechanics, 2013, 34(10): 2928-2944. (in Chinese))
[4]	霍海峰. 循环荷载作用下饱和黏土的力学性质研究[D]. 天津: 天津大学, 2012. (HUO Hai-feng. Research on the mechanical property of saturated silty clay under cyclic loading[D]. Tianjin: Tianjin University, 2012. (in Chinese))
[5]	赵慧. 循环荷载作用下粉土的破坏标准及动力特性的试验研究[D]. 南京: 河海大学, 2006. (ZHAO Hui. Study on tests of failure criterion and dynamic properties of silt under the cyclic loading[D]. Nanjing: Hohai University, 2006. (in Chinese))
[6]	SHEN Yang, ZHANG Peng-ju, XU Guo-jian, et al. Dynamic strength characteristics and failure criterion of anisotropically consolidated silt under principal stress rotation[J]. Journal of Central South University of Technology, 2013, 20(7): 2025-2033.
[7]	郑刚, 霍海峰, 雷华阳, 等. 振动频率对饱和黏土动力特性的影响[J]. 天津大学学报 (自然科学与工程技术版), 2013, 46(1): 38-43. (ZHENG Gang, HUO Hai-feng, LEI Huang-yang, et al. Contrastive study on the dynamic characteristics of saturated clay in different vibration frequencies[J]. Journal of Tianjin University (Science and Technology), 2013, 46(1): 38-43. (in Chinese))
[8]	沈扬, 王保光, 陶明安, 等. 重塑黏土空心圆柱试样制备技术改进及应用[J]. 岩土力学, 2015, 36(增刊1): 697-701. (SHEN Yang, WANG Bao-guang, TAO Ming-an, et al. Improvement of preparing technique for hollow cylinder specimen of remolded clay and its application[J]. Rock and Soil Mechanics, 2015, 36(S1): 697-701. (in Chinese))
[9]	陶明安, 沈扬, 王鑫. 空心圆柱仪模拟列车荷载下土中应力路径能力分析[J]. 岩土力学, 2013, 34(11): 3166-3172. (TAO Ming-an, SHEN Yang, WANG Xin, et al. Ability analysis of HCA to imitate stress path of soil caused by train load[J]. Rock and Soil Mechanics, 2013, 34(11): 3166-3172. (in Chinese))
[10]	雷华阳, 姜岩, 陆培毅. 循环荷载作用下软黏土的强度判别标准试验[J]. 长安大学学报（自然科学版）, 2009, 29(6): 54-58. (LEI Hua-yang, JIANG Yan, LU Pei-yi. Test on shear strength criterion of soft soil under cyclic loading[J]. Journal of Chang'an University (Natural Science Edition), 2010, 29(6): 54-58. (in Chinese))
[11]	沈瑞福, 王洪瑾, 周景星. 动主应力轴连续旋转下砂土的动强度[J]. 水利学报, 1996(1): 27-33. (SHEN Rui-fu, WANG Hong-jin, ZHOU Jing-xing. Dynamic strength of sand under cyclic rotation of principal stress directions[J]. Journal of Hydraulic Engineering, 1996(1): 27-33. (in Chinese))
