Two-dimensional simulation of high-frequency scattering of seismic waves by local sites based on fast multi-pole boundary element method
-
摘要: 结合快速多极子展开技术与间接边界元法,发展一种新的高频地震波散射（二维平面内）快速模拟方法。精度和效率检验表明该方法具有很高的计算精度、求解效率及良好的数值稳定性,同时可大幅度降低计算存储量。进而以半空间峡谷与凸起地形对平面SV波的高频散射为例,讨论了峡谷及凸起周围地震波宽频散射基本特征,给出了千米尺度局部场地、0~25 Hz频带宽度的散射模拟结果。分析表明：高频SV波垂直入射下,峡谷角部水平和竖向位移均表现出明显的放大效应,而峡谷底部的散射效应较弱;半圆凸起顶部附近水平位移谱峰值高达5.0,山脚处位移反应则受到明显的抑制作用;斜入射情况,峡谷地形迎波面一侧位移幅值较大,而凸起地形则是背波面一侧放大显著。数值结果可为复杂局部场地中大型工程抗震设计提供部分理论依据。Abstract: A new high-precise fast indirect boundary element method is developed to solve the two-dimensional scattering problems of high-frequency seismic waves (2D in-plane) based on the fast multi-pole expansion technique. It is verified that this method has high accuracy, efficiency and excellent numerical stability, and can greatly reduce the computational storage. Taking the seismic response of a canyon and a hill in a half space under high-frequency incident plane SV waves as an example, the basic characteristics of high-frequency scattering around the canyon and hill are discussed, and the scattering results of 0~25 Hz broadband waves by large-scale local sites of thousands-meters are illustrated. The numerical results show that under the high-frequency incident SV waves, the amplification effect of the canyon on the horizontal and vertical displacement under high-frequency incident SV waves can be seen clearly at the corner of the canyon, but seems not so pronounced at the bottom of the canyon. The spectral peak of displacement amplitudes reaches up to 5.0 near the top of the hill, while the displacement response at the foot of the hill is constrained. As for the obliquely incident SV waves, the displacement at the canyon surface is more pronounced, but the amplification effect is more significant at the back of hill surface. The numerical results may provide a theoretical basis for the seismic design of large-scale projects constructed in complex local sites.
-
[1] GAO Y, ZHANG N, LI D, et al. Effects of topographic amplification induced by a u-shaped canyon on seismic waves[J]. Bulletin of the Seismological Society of America, 2012, 102(4): 1748-1763. [2] LEE V W, AMORN W A. Scattering of anti-plane (SH) waves by a semi-elliptical hill: I shallow hill[J]. Soil Dynamics and Earthquake Engineering, 2013, 52: 116-125. [3] YUAN X. A whole-space transform formula of cylindrical wave functions for scattering problems[J]. Earthquake Engineering and Engineering Vibration, 2014, 13(1): 23-28. [4] 梁建文, 张郁山, 顾晓鲁, 等. 圆弧形层状沉积河谷场地在平面SH波入射下动力响应分析[J]. 岩土工程学报, 2000, 22(4): 396-401. (LIANG Jian-wen, ZHANG Yu-shan, GU Xiao-lu, et al. Surface motion of circular-arc layered alluvial valleys for incident plane SH waves[J]. Chinese Journal of Geotechnical Engineering, 2000, 22(4): 396-401. (in Chinese)) [5] CHEN G, JIN D, ZHU J, et al. Nonlinear analysis on seismic site response of Fuzhou Basin, China[J]. Bulletin of the Seismological Society of America, 2015, 105(2A): 928-949. [6] GRAVES R W. Simulating seismic wave propagation in 3D elastic media using staggered-grid finite differences[J]. Bulletin of the Seismological Society of America, 1996, 86(4): 1091-1106. [7] MANOLIS G D. Elastic wave scattering around cavities in inhomogeneous continua by the BEM[J]. Journal of Sound and Vibration, 2003, 266(2): 281-305. [8] 巴振宁, 梁建文, 梅雄一. 层状饱和半空间中沉积谷地对斜入射平面 P1 波的三维散射[J]. 工程力学, 2013, 30(9): 47-55. (BA Zhen-ning, LIANG Jian-wen, MEI Xiong-yi. 3D scattering by an alluvial valley embedded in a fluid-saturated, layered half-space for obliquely incident plane p1 waves[J]. Engineering Mechanics, 2013, 30(9): 47-55. (in Chinese)) [9] 刘中宪, 梁建文, 赵瑞斌. 流体饱和层状半空间中沉积谷地对地震波的散射—IBIEM 求解[J]. 岩土工程学报, 2013, 35(3): 512-522. LIU Zhong-xian, LIANG Jian-wen, ZHAO Rui-bin. Indirect boundary integral equation method for solving scattering of seismic waves by an alluvial valley in fluid poroelastic layered half-space[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(3): 512-522. [10] FUJIWARA H. The fast multipole method for solving integral equations of three-dimensional topography and basin problems[J]. Geophys J Int, 2000, 140: 198-210. [11] GRASSO E, CHAILLAT S, BONNET M. Application of the multi-level time-harmonic fast multipole BEM to 3-D visco-elastodynamics[J]. Eng Anal Bound Elem, 2012, 36: 744-758. [12] 刘中宪, 唐河仓, 王 冬. 弹性波二维散射快速多极子间接边界元法求解[J]. 工程力学, 2015(5): 6-12. (LIU Zhong-xian, TANG He-cang, WANG Dong. FMM-IBEM solution to two-dimensional scattering of elastic waves[J]. Engineering Mechanics, 2015(5): 6-12. (in Chinese)) [13] SÁNCHEZ-SESMA F J, CAMPILLO M. Diffraction of P, SV, and Rayleigh waves by topographic features: a boundary integral formulation[J]. Bulletin of the Seismological Society of America, 1991, 81(6): 2234-2253. [14] UTSUNOMIYA T, WATANABE E, NISHIMURA N. Fast multipole algorithm for wave diffraction/radiation problems and its application to VLFS in variable water depth and topography[C]// Proc 20th Int OMAE Conf, 2001. [15] SAKUMA T, YASUDA Y. Fast multipole boundary element method for large-scale steady-state sound field analysis: part I setup and validation[J]. Acta Acustica, 2002, 88(4): 513-525. [16] 王海涛. 快速多级边界元法在二维弹性力学中的应用[D].北京: 清华大学, 2002. (WANG Hai-tao. Application of fast multipole boundary element method for two dimensional elasticity[D]. Beijing: Tsinghua University, 2002. (in Chinese)) [17] 钟 慧, 张郁山. 圆弧状凹陷地形对平面 SV 波散射问题的宽频带解析解[J]. 中国地震, 2010(2): 142-155. (ZHONG Hui, ZHANG Yu-shan. Broad-frequency-band analytical solution to scattering of plane SV wave by arc-shaped canyon topography[J]. Earthquake Research in China, 2010(2): 142-155. (in Chinese)) -
