砂性地层孔隙特征对泥水盾构泥浆成膜的影响

刘成, 汤昕怡, 高玉峰

刘成, 汤昕怡, 高玉峰. 砂性地层孔隙特征对泥水盾构泥浆成膜的影响[J]. 岩土工程学报, 2017, 39(11): 2002-2008. DOI: 10.11779/CJGE201711007
引用本文: 刘成, 汤昕怡, 高玉峰. 砂性地层孔隙特征对泥水盾构泥浆成膜的影响[J]. 岩土工程学报, 2017, 39(11): 2002-2008. DOI: 10.11779/CJGE201711007
LIU Cheng, TANG Xin-yi, GAO Yu-feng. Influence of pore characteristics of sand strata on filter-cake formation under slurry shield[J]. Chinese Journal of Geotechnical Engineering, 2017, 39(11): 2002-2008. DOI: 10.11779/CJGE201711007
Citation: LIU Cheng, TANG Xin-yi, GAO Yu-feng. Influence of pore characteristics of sand strata on filter-cake formation under slurry shield[J]. Chinese Journal of Geotechnical Engineering, 2017, 39(11): 2002-2008. DOI: 10.11779/CJGE201711007

砂性地层孔隙特征对泥水盾构泥浆成膜的影响  English Version

基金项目: 国家自然科学基金项目(51508278); 江苏省自然科学基金项目(BK20140979); 教育部博士点基金项目(20133204120014); 江苏省高校自然科学研究项目(14KJB560011); 河海大学岩土力学与堤坝工程教育部重点实验室开放基金项目(GH201402)
详细信息
    作者简介:

    刘成(1982-),男,副教授,主要从事隧道与地下工程方面的教学与科研工作。E-mail:lcheng83@163.com。

    通讯作者:

    高玉峰,E-mail:yfgao66@163.com

  • 中图分类号: TU443

Influence of pore characteristics of sand strata on filter-cake formation under slurry shield

  • 摘要: 透水砂性地层开挖面上成膜特征是影响开挖面稳定性的关键因素,而地层孔隙特征与成膜特征量化关系的建立是进行相关分析的必要条件。通过在不同孔隙特征地层中开展渗透成膜试验,确定了地层孔隙特征和成膜特征的量化指标,基于二者量化关系的构建,研究了地层孔隙特征对泥浆成膜特征的影响规律。研究表明,地层滤失量曲线双参数模型可以描述地层滤失量变化特征,模型参数a,b可量化滤失量曲率特征、成膜时间和成膜阶段等成膜特征,具有明确的物理意义。基于参数a,b和孔隙体积v的幂函数关系,确定了地层孔隙特征和成膜特征的量化关系。研究成果可为泥水盾构穿越透水砂性地层合理确定泥浆配比方案和施工参数,保证开挖面稳定提供试验和理论基础。
    Abstract: The characteristics of filter cake formation on the excavation face of permeable sand strata are the critical factors for the growth and decrease law of the soil and water pressure in the strata as well as the stability of excavation face. Then the requirement of these analyses is to establish the quantitative relationship between the pore characteristics and filter cake forming characteristics. The quantitative indexes of pore characteristics and filter cake forming characteristics are raised by carrying out the slurry filtration tests in the strata with different pore characteristics. Based on the quantitative relationship between the both characteristics, the filter cake formation laws influenced by the pore characteristics are studied. The results show that the two-parameters model for the filtration curve can describe the variation characteristics of seepage discharge. Th model parameters own clear physical significances to quantify filter cake forming characteristics such as curvature characteristics of seepage discharge, formation time and forming stages of filter cake. Based on the relationship of power function between parameters a, b and the pore volume v, the quantitative relationship of pore characteristics and the filter cake forming characteristics is established. The research results can determine the reasonable slurry proportion and construction parameters and may provide experimental and theoretical support for guaranteeing the stability of the excavation face for slurry shield tunneling projects excavated in highly permeable sand soils.
  • [1] 孙 钧. 论跨江越海建设隧道的技术优势与问题[J]. 隧道建设, 2013, 33(5): 337-342. (SUN Jun. study on technological advantages and problems in construction of tunnels crossing rivers and seas[J]. Tunnel Construction, 2013, 33(5): 337-342. (in Chinese))
    [2] 王梦恕. 中国盾构和掘进机隧道技术现状、存在的问题及发展思路[J]. 隧道建设, 2014, 34(3): 179-187. (WANG Meng-shu. Tunneling by TBM/shield in China: state-of art, problems and proposals[J]. Tunnel Construction, 2014, 34(3): 179-187. (in Chinese))
    [3] ANAGNOSTOU G, KOVÁRI K. The face stability of slurry-shield-driven tunnels[J]. Tunnelling and Underground Space Technology, 1994, 9(2): 165-174.
    [4] 邵生俊, 李建军, 杨扶银. 粗粒土孔隙特征及其对泥浆渗透性的影响[J]. 岩土工程学报, 2009, 31(1): 59-65. (SHAO Sheng-jun, LI Jian-jun, YANG Fu-yin. Pore characteristics of coarse grained soil and their effect on study permeability[J]. Chinese Journal of Geotechnical Engineering, 2009, 31(1): 59-65. (in Chinese))
    [5] KRAUSE T. Schildvortreib mit flüssigkeits-und erdgestützter ortsbrust[D]. Braunschweig: Tech-nischen Universität Carolo-Wilhelina, 1987. (KRAUSE T. Shield tunneling with a liquid and earth-supported working face[D]. Braunschweig: Technical University Carolo-Wilhelina, 1987. (in German))
    [6] FILZ G M, ADAMS T, DAVIDSON R R. Stability of long trenches in sand supported by bentonite-water slurry[J]. Journal of Geotechnical and Geoenvironmental Engineering. 2004, 130(9): 915-921.
    [7] 刘 成, 孙 钧, 杨 平, 等. 泥膜形成与状态划分细观分析及模型试验研究[J]. 岩土工程学报, 2014, 36(3): 435-442. (LIU Cheng, SUN Jun, YANG Ping, et al. Mesoscopic analysis and model test research on formation process and state division of slurry membrane[J]. Chinese Journal of Geotechnical Engineering, 2014, 36(3): 435-442. (in Chinese))
    [8] TIEN C, RAMARAO B V. Revisiting the laws of filtration: An assessment of their use in identifying particle retention mechanisms in filtration[J]. Journal of Membrane Science, 2011, 383(1/2): 17-25.
    [9] TALMON A M, MASTBERGEN D R, HUISMAN M. Invasion of pressurized clay suspensions into granular soil[J]. Journal of Porous Media, 2013, 16(4): 351-365.
    [10] 魏代伟, 朱 伟, 闵凡路. 砂土地层泥水盾构泥膜形成时间及泥浆压力转化率的试验研究[J]. 岩土力学, 2014, 35(2): 423-428. (WEI Dai-wei, ZHU Wei, MIN Fan-lu. Experimental study of forming time of filter cake and conversion rate of slurry pressure in slurry shield in sand stratum[J]. Rock and Soil Mechanics, 2014, 35(2): 423-428. (in Chinese))
    [11] 韩晓瑞, 朱 伟, 刘泉维, 等. 泥浆性质对泥水盾构开挖面泥膜形成质量影响[J]. 岩土力学, 2008, 29(增刊): 288-292. (HAN Xiao-rui, ZHU Wei, LIU Quan-wei, et al. Influence of slurry property on filter-cake quality on working face of slurry shield[J]. Rock and Soil Mechanics, 2008, 29(S0): 288-292. (in Chinese))
    [12] 闵凡路, 朱 伟, 魏代伟, 等. 泥水盾构泥膜形成时开挖面地层孔压变化规律研究[J]. 岩土工程学报, 2013, 35(4): 722-727. (MIN Fan-lu, ZHU Wei, WEI Dai-wei, et al. Change of pore water pressure in soil as filter cakes formed on excavation face in slurry shield[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(4): 722-727. (in Chinese))
    [13] 刘尊年, 孙建孟, 迟秀荣, 等. 泥浆侵入研究现状分析[J]. 地球物理学进展, 2012, 27(6): 2594-2601. (LIU Zun-nian, SUN Jian-meng, CHI Xiu-rong, et al. Analysis of research present situation of mud invasion[J]. Progress in Geophysics, 2012, 27(6): 2594-2601 (in Chinese))
    [14] 刘 成, 孙 钧, 赵志峰, 等. 泥水盾构泥膜形成二维理论分析[J]. 岩土力学, 2013, 34(6): 1593-1597. (LIU Cheng, SUN Jun, ZHAO Zhi-feng, et al. Two-dimensional theoretical analysis of slurry membrane formation process in slurry shield[J]. Rock and Soil Mechanics, 2013, 34(6): 1593-1597. (in Chinese))
