堆积碎石土斜坡浅表入渗的空间分布与变异性研究

董辉; 黄润秋; 罗潇; 罗正东; 蒋秀姿

doi:10.11779/CJGE201708018

堆积碎石土斜坡浅表入渗的空间分布与变异性研究 English Version

董辉^{1, 2, 3},
黄润秋¹,
罗潇²,
罗正东^{2, 3},
蒋秀姿²

1. 成都理工大学地质灾害防治与地质环境保护国家重点实验室,四川成都 610059;
2. 湘潭大学土木工程与力学学院,湖南湘潭 411105;
3. 岩土力学与工程安全湖南省重点实验室,湖南湘潭 411105

基金项目: 国家自然科学基金项目（51108397）; 湖南省自然科学基金项目（2015JJ2136）; 湖南省教育厅优秀青年项目（16B255）

详细信息

作者简介:
董辉(1976- ),男,博士,副教授,主要从事环境地质与灾害地质等方面的研究。E-mail：donghui@xtu.edu.cn。

计量
- 文章访问数: 0254
- HTML全文浏览量: 0
- PDF下载量: 0376
出版历程
- 收稿日期: 2016-04-04
- 发布日期: 2017-08-24

Spatial distribution and variability of infiltration characteristics for shallow slope of gravel soil

1. State Key Laboratory of Geohazard Prevention and Geoenvironment Protection, Chengdu University of Technology, Chengdu 610059, China;
2. College of Civil Engineering and Mechanics, Xiangtan University, Xiangtan 411105, China;
3. Hunan Key Laboratory of Geomechanics and Engineering Safety, Xiangtan 411105, China

摘要

摘要: 为探究强降雨下堆积体斜坡入渗参数的空间分布与空间变异性,通过筛分试验及双环入渗试验分别对堆积体斜坡试验点不同粒径区间碎石质量分数、碎石土渗透系数、饱和渗透系数、不同深度碎石土含水率进行测量,对数据进行普通Kriging插值统计分析,运用交叉检验选定合理理论模型与参数,获得其空间分布与变异性特征。研究结果表明：测试区碎石土入渗符合Kostiakov模型;不同粒径区间碎石质量分数采用高斯半变异函数理论模型空间插值精度最高,碎石土渗透系数和不同深度碎石土含水率采用球状半变异函数理论模型空间插值精度最高;粒径大于10 mm碎石主要分布于坡顶与坡腰区域且使该区域碎石土渗透系数的空间变异性相对较大,细小碎石（粒径2~10 mm）则聚积在坡脚位置,碎石土渗透系数速率沿坡面由上至下呈逐渐减少的空间分布趋势;浅土层（0~15 cm）坡腰含水率比坡顶、坡脚要高,而深土层（15~25 cm）坡脚含水率比坡顶、坡腰要高,且随深度增加缓慢上升。研究结果可作为碎石土滑坡降雨致滑的理论参考依据。
- 滑坡 /
- 堆积碎石土 /
- 入渗特性 /
- 空间变异性 /
- Kriging内插法
Abstract: For accurate analysis of the spatial distribution and spatial variability of infiltration characteristics of aggregate gravel soil, the self-made double ring infiltration apparatus and gravel screening instrument have been used for testing gravel mass fraction of different particle size on slope , the permeability coefficient of gravel soil and different depth of gravel soil moisture content. Software is used for spatial interpolation of the discrete test data through the Kriging interpolation method. The cross tests are used to select a reasonable theoretical model, and the precise interpolation results are obtained. The results show that Kostiakov formula is used to simulate the infiltration process of gravel soil. The highest spatial interpolation precision about the gravel in different particle size sections is Gaussian semi-variable function theoretical model, and spherical model for the permeability coefficient of gravel soil and the moisture content of gravel soil at different depths. The gravels with particle size larger than 10 mm are mainly distributed in the top and middle slope regions, and the regional spatial variability of infiltration rate is relatively large. The small gravels (size of 2~10 mm) accumulate in the slope foot. The permeability coefficient of gravel soil along slope from top to bottom has a gradually decreasing spatial distribution trend. The moisture content at the slope waist is higher than that at the slope top and toe in shallow soil (0~15 cm), but that at the slope toe is higher than that at the slope top and toe in deep soil layer (15~25 cm). The water content of slope increases slowly with the increasing depth. The research results lay a theoretical foundation for the establishment of the prediction model for gravel soil.
- landslide /
- aggregate gravel soil /
- infiltration characteristic /
- spatial variability /
- Kriging interpolation method

HTML全文

参考文献(17)

[1]	贺可强, 周敦云, 王思敬. 降雨型堆积层滑坡的加卸载响应比特征及其预测作用与意义[J]. 岩石力学与工程学报, 2004, 23(16): 2665-2670. (HE Ke-qiang, ZHOU Dun-yun, WANG Si-jing. Features of load-unload response ratio and its significance in predication of colluvial landslide[J]. Chinese Journal of Rock Mechanics and Engineering, 2004, 23(16): 2665-2670. (in Chinese))
[2]	许建聪, 尚岳全, 王建林. 松散土质滑坡位移与降雨量的相关性研究[J]. 岩石力学与工程学报, 2006, 25(增刊1): 2854-2860. (XU Jian-cong, SHANG Yue-quan, WANG Jian-lin. Study on relationship between slope-mass slide displacement and precipitation of loose soil landslide[J]. Chinese Journal of Rock Mechanics and Engineering, 2006, 25(S1): 2854-2860. (in Chinese))
[3]	董辉, 陈玺文, 傅鹤林, 等. 堆积碎石土剪切特性的三轴试验[J]. 长安大学学报（自然科学版）, 2015, 35(2): 59-66. (DONG Hui, CHEN Xi-wen, FU He-lin, et al. Triaxlal test of shear properties of eluvial gravel soil[J]. Journal of Chang’an University (Natural Science Edition), 2015, 35(2): 59-66. (in Chinese))
[4]	张春敏, 王根绪, 王军德, 等. 高寒草甸典型小流域雨后土壤水分空间变异特征[J]. 水土保持研究, 2007, 14(6): 10-14. (ZHANG Chun-min, WANG Gen-xu, WANG Jun-de, et al. The spatial heterogeneity of soil moisture after raining in representative gully catchment of the alpine meadow[J]. Research of Soil and Water Conservation, 2007, 14(6): 10-14. (in Chinese))
[5]	武世亮. 土壤入渗特性的空间变异性及与土壤物理特性的相关性研究[D]. 西安: 西北农林科技大学, 2014. (WU Shi-liang. Study on the spatial variability of soil infiltration properties and the spatial correlation with soil physical properties[D]. Xi'an: Northwest A&F University, 2014. (in Chinese))
[6]	王月玲, 蒋齐, 蔡进军, 等. 半干旱黄土丘陵区土壤水分入渗速率的空间变异性[J]. 水土保持通报, 2008, 28(4): 52-55. (WANG Yue-ling, JIANG Qi, CAI Jin-jun, et al. Spatial variability of infiltration rate in the semiarid loess hilly and gully area[J]. Bulletin of Soil and Water Conservation, 2008, 28(4): 52-55. (in Chinese))
[7]	蒋芳市, 黄炎和, 林金石, 等. 崩岗崩积体土壤渗透特性分析[J]. 水土保持学报, 2013, 27(3): 49-54. (JIANG Fang-shi, HUANG Yan-he, LIN Jin-shi, et al. Study on soil permeability of slumping deposits in Benggang[J]. Journal of Soil and Water Conservation, 2013, 27(3): 49-54. (in Chinese))
[8]	冶运涛, 伍靖伟, 王兴奎. 双套环测定土壤渗透系数数值模拟分析[J]. 灌溉排水学报, 2007, 26(3): 14-18. (YE Yun-tao, WU Jing-wei, WANG Xing-kui. Numerical simulation of double-ring measuration on hydraulic conductivity[J]. Journal of Irrigation and Drainage, 2007, 26(3): 14-18. (in Chinese))
[9]	SL345—2007水利水电工程注水试验规程[S]. 2007: 6-9. (SL345—2007 Code of water injection test for water resources and hydropower engineering[S]. 2007: 6-9. (in Chinese))
[10]	SL237—1999土工试验规程[S]. 1999: 114-123. (SL237—1999 Specification of soil test[S]. 1999: 114-123. (in Chinese))
[11]	KHANNA M, MALANO H M. Modelling of basin irrigation systems: a review[J]. Agricultural Water Management, 2006, 83(1): 87-99.
[12]	PHILIP J R. The theory of infiltration: 1 the infiltration equation and its solution[J]. Soil Science, 1957, 83(5): 345-358.
[13]	KOSTIAKOV A N. On the dynamics of the coefficient of water-percolation in soils and on the necessity for studying it from a dynamic point of view for purposes of amelioration [C]// Transcations Communication International Society Soil Science 6th. Moscow, 1932, 6: 17-21.
[14]	邓聚龙. 灰色系统理论教程[M]. 武汉: 华中理工大学出版社, 1990: 33-63. (DENG Ju-long. Grey system theory course[M]. Wuhan: Huazhong University of Science and Technology Press, 1990: 33-63. (in Chinese))
[15]	徐建华. 现代地理学中的数学方法[M]. 北京: 高等教育出版社, 2002: 21-35. (XU Jian-hua. Mathematical methods in modern geography[M]. Beijing: Higher Education Press, 2002: 21-35. (in Chinese))
[16]	胡先莉. 序贯条件模拟方法研究及应用[D]. 成都: 成都理工大学, 2007. (HU Xian-li. Research and application of sequentially conditional simulation methods[D]. Chengdu: Chengdu University of Technology, 2007. (in Chinese))
[17]	凌辉, 武伟, 王润, 等. 小尺度下土壤重金属铬含量的空间插值方法比较研究[J]. 西南大学学报(自然科学版), 2007, 29(11): 93-99. (LING Hui, WU Wei, WANG Run, et al. A comparative analysis of various spatial interpolation methods for soil chrome content on a small scale[J]. Journal of Southwest University (Natural Science Edition), 2007, 29(11): 93-99. (in Chinese))
