衬砌背后空洞影响下隧道结构裂损规律试验研究

张旭; 张成平; 冯岗; 韩凯航

doi:10.11779/CJGE201706021

衬砌背后空洞影响下隧道结构裂损规律试验研究 English Version

张旭^1,2,
张成平^1,2, ,,
冯岗^1,2,
韩凯航^1,2

1. 北京交通大学城市地下工程教育部重点实验室,北京 100044;
2. 北京交通大学土木建筑工程学院,北京 100044

基金项目: 国家自然科学基金面上项目（51378002）; 中央高校基本科研业务费专项资金项目（2016JBM042）

详细信息

作者简介:
张旭(1989- ),男,辽宁大洼人,博士研究生,主要从事隧道及地下工程方面的研究。E-mail：zxbjtu@yeah.net。

通讯作者:
张成平，E-mail：chpzhang@bjtu.edu.cn

中图分类号: TU458
计量
- 文章访问数: 0243
- HTML全文浏览量: 0
- PDF下载量: 0375
出版历程
- 收稿日期: 2016-06-03
- 发布日期: 2017-06-24

Experimental studies on effect of voids behind tunnel linings on progressive failure process of tunnel structures

1. Key Laboratory of Urban Underground Engineering of the Education Ministry, Beijing Jiaotong University, Beijing 100044, China;
2. School of Civil Engineering, Beijing Jiaotong University, Beijing 100044, China

摘要

摘要: 衬砌背后空洞的存在严重影响了围岩与衬砌之间的相互作用,极易引起衬砌结构破损并直接影响到运营安全。通过模型试验,系统研究了拱顶与拱肩背后存在双空洞条件下隧道结构裂损演化过程及衬砌结构轴力和弯矩的变化规律。模型试验结果表明：①衬砌背后双空洞的存在,严重影响隧道结构的受力状态,易导致衬砌结构承载力不足;②拱顶与右拱肩背后存在双空洞条件下衬砌裂缝出现的顺序为：仰拱内表面裂缝→空洞间衬砌内表面裂缝→拱肩空洞右侧衬砌外表面裂缝→拱顶空洞左侧衬砌内表面裂缝→左拱脚衬砌外表面裂缝→右拱腰衬砌外表面裂缝;③空洞尺寸变化显著改变了衬砌内力分布,空洞尺寸的增加,引起两空洞间衬砌结构轴力减小而弯矩增大,使两空洞间的衬砌结构破坏程度更严重;④衬砌背后空洞的位置及数量对隧道结构裂损过程有较大影响,衬砌背后存在双空洞时衬砌裂缝的传播过程更复杂。研究成果可为衬砌背后多空洞影响下衬砌裂缝病害的防治和修复提供参考。
- 衬砌背后空洞 /
- 隧道结构 /
- 破坏过程 /
- 衬砌裂缝 /
- 衬砌内力 /
- 模型试验
Abstract: The voids behind the tunnel linings seriously affect the interaction between the linings and the surrounding soils, generally in the form of cracking, spalling or even failure, directly affecting the safety of tunnel operation. The experimental investigation is conducted to examine the effect of the twin voids between the surrounding soils and the tunnel linings at the crown and spandrel on the progressive failure process of tunnel linings, the thrust forces and the bending moments in the tunnel linings. The results show that: (1) The stress state of tunnel linings is greatly affected by the presence of twin voids, which can induce the shortage of load carrying capacity of tunnel structures. (2) As the loading increases, the cracks are noted to propagate firstly at the inner fiber of the tunnel invert, secondly at the inner fiber of the linings between the twin voids, thirdly at the outer fiber of the lining on the right side of the void located at the spandrel diagonally above the tunnel, fourth at the inner fiber of the linings at the left side of the void at the crown, then at the outer fiber of the lining at the left arch spring, finally at the outer fiber of the linings at the right haunch. (3) The changes in void sizes significantly affect the distribution of internal force of the linings. The increase in void sizes results in a decrease in the magnitude of thrust forces in the linings between the twin voids, while the magnitude of bending moments between the twin voids increases as the void sizes increase, which then causes significant damage to the tunnel linings between the twin voids. (4) The failure process of tunnel linings is greatly affected by the location and quantity of voids. The propagation laws of lining cracks are even more complicated under the influence of twin voids. These studies can provide reference for preventing and repairing lining cracks influenced by the multiple voids behind the tunnel linings.
- void behind tunnel lining /
- tunnel structure /
- failure process /
- lining crack /
- lining internal force /
- model test

HTML全文

参考文献(18)

[1]	WANG Ji-fei, HUANG Hong-wei, XIE Xiong-yao, et al. Risk assessment of voids behind the lining of mountain tunnels[C]// GeoFlorida 2010: Advances in Analysis, Modeling and Design Conference. Florida, 2010: 2319-2328.
[2]	张素磊. 隧道衬砌结构健康诊断及技术状况评定研究[D]. 北京: 北京交通大学, 2012. (ZHANG Su-lei. Study on health diagnosis and technical condition assessment for tunnel lining structure[D]. Beijing: Beijing Jiaotong University, 2012. (in Chinese))
[3]	张顶立, 张素磊, 房倩, 等. 铁路运营隧道衬砌背后接触状态及其分析[J]. 岩石力学与工程学报, 2013, 32(2): 217-224. (ZHANG Ding-li, ZHANG Su-lei, FANG Qian, et al. Study of contact state behind tunnel lining in process of railway operation and its analysis[J]. Chinese Journal of Rock Mechanics and Engineering, 2013, 32(2): 217-224. (in Chinese))
[4]	周强. 高速公路隧道衬砌背后空洞影响及安全性分析[D]. 重庆: 重庆交通大学, 2013. (ZHOU Qiang. Effect and safety analysis of caverns behind highway tunnel lining[D]. Chongqing: Chongqing Jiaotong University, 2013. (in Chinese))
[5]	张成平, 冯岗, 张旭, 等. 衬砌背后双空洞影响下隧道结构的安全状态分析[J]. 岩土工程学报, 2015, 37(3): 487-493. (ZHANG Cheng-ping, FENG Gang, ZHANG Xu, et al. Effect of double voids behind lining on safety state of tunnel structures[J]. Chinese Journal of Geotechnical Engineering, 2015, 37(3): 487-493. (in Chinese))
[6]	应国刚, 张顶立, 陈立平, 等. 荷载结构模型在拱顶空洞存在情况下的修正[J]. 土木工程学报, 2015, 48(增刊1): 181-185. (YING Guo-gang, ZHANG Ding-li, CHEN Li-ping, et al. Amendment of load-structure model with voids behind tunnel lining at vault[J]. China Civil Engineering Journal, 2015, 48(S1): 181-185. (in Chinese))
[7]	MEGUID M A, DANG H K. The effect of erosion voids on existing tunnel linings[J]. Tunneling and Underground Space Technology, 2009, 24(3): 278-286.
[8]	WANG J F, HUANG H W, XIE X Y, et al. Void-induced liner deformation and stress redistribution[J]. Tunneling and Underground Space Technology, 201440: 263-276.
[9]	彭跃, 王桂林, 张永兴, 等. 衬砌背后空洞对在役隧道结构安全性影响研究[J]. 地下空间与工程学报, 2008, 4(6): 1101-1104. (PENG Yue, WANG Gui-lin, ZHANG Yong-xing, et al. Research about effect of cavity behind lining on structural safety of tunnel in active service[J]. Chinese Journal of Underground Space and Engineering, 2008, 4(6): 1101-1104. (in Chinese))
[10]	朱春生, 杨晓华, 来弘鹏, 等. 公路隧道衬砌后空洞对结构安全的影响[J]. 长安大学学报(自然科学版), 2010, 30(5): 63-68. (ZHU Chun-sheng, YANG Xiao-hua, LAI Hong-peng, et al. Impact of empty hole behind expressway tunnel lining on structure safety[J]. Journal of Chang’an University (Natural Science Edition), 2010, 30(5): 63-68. (in Chinese))
[11]	朱正国, 耿亚帅, 武杰, 等. 地震作用下隧道衬砌背后空洞影响机制研究[J]. 铁道工程学报, 2015(9): 79-84. (ZHU Zheng-guo, GENG Ya-shuai, WU Jie, et al. Research on the effect mechanism of cavity behind tunnel lining under the earthquake action[J]. Journal of Railway Engineering Society, 2015(9): 79-84. (in Chinese))
[12]	聂子云, 张春雷, 李凤翔. 衬砌背后空洞对隧道抗震性能影响分析[J]. 地震工程学报, 2015, 37(1): 138-143. (NIE Zi-yun, ZHANG Chun-lei, LI Feng-xiang. Effect of void behind lining on seismic performance of tunnel[J].China Earthquake Engineering Journal, 2015, 37(1): 138-143. (in Chinese))
[13]	黄宏伟, 刘德军, 薛亚东, 等. 基于扩展有限元的隧道衬砌裂缝开裂数值分析[J]. 岩土工程学报, 2013, 35(2): 266-275. (HUANG Hong-wei, LIU De-jun, XUE Ya-dong, et al. Numerical analysis of cracking of tunnel linings based on extended finite element[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(2): 266-275. (in Chinese))
[14]	雷波, 漆泰岳, 陈小雨, 等. 背后空洞引起高速铁路隧道衬砌裂缝形态的FEM对比分析[J]. 铁道标准设计, 2015, 59(9): 104-108. (LEI Bo, QI Tai-yue, CHEN Xiao-yu, et al. FEM-based contrastive analysis of lining cracks caused by cavity behind arch shoulder in high-speed railway tunnels[J]. Railway Standard Design, 2015, 59(9): 104-108. (in Chinese))
[15]	LEUNG C, MEGUID M A. An experimental study of the effect of local contact loss on the earth pressure distribution on existing tunnel linings[J]. Tunneling and Underground Space Technology, 2011, 26(1): 139-145.
[16]	佘健, 何川, 汪波, 等. 衬砌背后空洞对隧道结构承载力影响的模型试验研究[J]. 公路交通科技, 2008, 25(1): 104-110. (SHE Jian, HE Chuan, WANG Bo, et al. Study on effect of cavities behind linings on bearing capacity of tunnel structure by model test[J]. Journal of Highway and Transportation Research and Development, 2008, 25(1): 104-110. (in Chinese))
[17]	方勇, 郭建宁, 康海波, 等. 富水地层公路隧道衬砌背后空洞对结构受力的影响[J]. 岩石力学与工程学报, 2016, 35(8): 1648-1658. (FANG Yong, GUO Jian-ning, KANG Hai-bo, et al. Influence of voids behind lining on the mechanical behavior of lining structure of highway tunnel in watery strata[J]. Chinese Journal of Rock Mechanics and Engineering, 2016, 35(8): 1648-1658. (in Chinese))
[18]	张成平, 张旭, 李贺, 等. 浅埋隧道施工扰动下含空洞地层破坏演化规律试验研究[J]. 岩土工程学报, 2016, 38(2): 263-270. (ZHANG Cheng-ping, ZHANG Xu, LI He, et al. Model tests on failure laws of ground with voids induced by shallow tunnelling[J]. Chinese Journal of Geotechnical Engineering, 2016, 38(2): 263-270. (in Chinese))
