循环荷载下岩体结构面本构关系与积分算法研究

邓建, 肖明, 谢冰冰, 陈俊涛

邓建, 肖明, 谢冰冰, 陈俊涛. 循环荷载下岩体结构面本构关系与积分算法研究[J]. 岩土工程学报, 2017, 39(6): 1048-1057. DOI: 10.11779/CJGE201706010
引用本文: 邓建, 肖明, 谢冰冰, 陈俊涛. 循环荷载下岩体结构面本构关系与积分算法研究[J]. 岩土工程学报, 2017, 39(6): 1048-1057. DOI: 10.11779/CJGE201706010
DENG Jian, XIAO Ming, XIE Bing-bing, CHEN Jun-tao. Constitutive relation and integration algorithm for rock discontinuities under cyclic loading[J]. Chinese Journal of Geotechnical Engineering, 2017, 39(6): 1048-1057. DOI: 10.11779/CJGE201706010
Citation: DENG Jian, XIAO Ming, XIE Bing-bing, CHEN Jun-tao. Constitutive relation and integration algorithm for rock discontinuities under cyclic loading[J]. Chinese Journal of Geotechnical Engineering, 2017, 39(6): 1048-1057. DOI: 10.11779/CJGE201706010

循环荷载下岩体结构面本构关系与积分算法研究  English Version

基金项目: 国家自然科学基金项目(51279136,51579191); 国家重点基础研究发展计划(“973”计划)项目(2015CB057904)
详细信息
    作者简介:

    邓 建(1989- ),男,湖北天门人,博士研究生,主要从事地下洞室开挖与围岩稳定数值分析方面研究工作。E-mail: xianyudj@126.com。

  • 中图分类号: TU452

Constitutive relation and integration algorithm for rock discontinuities under cyclic loading

  • 摘要: 地下结构中广泛存在的各种不连续面是影响岩体工程力学特性的重要因素,研究结构面在循环荷载作用下的力学行为具有重要的工程意义。基于非关联塑性理论,同时定义加载剪胀段和反向剪缩段,建立了岩体结构面剪胀与塑性耦合本构关系;从结构面的基本损伤机制出发,基于拉、剪分离的思路,建立了一类基于能量原理的岩体结构面拉、剪损伤本构模型,该模型基于有效应力空间塑性力学基本原理,定义了岩体结构面拉、剪塑性Helmholtz自由能分量及损伤能释放率,建立了岩体结构面拉、剪损伤破坏准则。针对结构面在循环荷载作用下的强非线性问题,引入算子分解的思想,将弹塑性演化与损伤演化过程分开进行求解,提出了结构面弹塑性损伤本构关系的混合积分算法。分别进行了岩体结构面直剪和循环剪切试验的数值仿真,计算结果与模型试验基本一致,表明该模型在模拟非连续岩体复杂变形方面是合理有效的。
    Abstract: The discontinuities distributed in underground structures are the important factors that affect the mechanical characteristics of rock mass, and to study the mechanical behavior of rock discontinuities under cyclic loading is of great engineering significance. In light of the non-associated plastic theory, defining the dilatancy and reduction zones, a constitutive model for rock discontinuities considering the coupling of dilatancy and plasticity is established. Starting from the basic damage mechanism, with regard to the separation of tension and shear, a new damage constitutive model based on the energy theory is proposed. In which the tension and shear plastic Helmholtz free energy and damage energy release rates are determined by using the basic principle of plastic mechanics in the effective stress space, and the tension and shear damage failure criteria for rock discontinuities are proposed. Aiming at the strong nonlinear performance of rock discontinuities under cyclic loading, the operator decomposition method is introduced. The coupling process of dilatancy and plasticity, as well as the damage evolution process, is solved separately, and a mixed integration algorithm for the elastoplastic damage constitutive relation of rock discontinuities is put forward. Some experiments of direct shear and cyclic shear are simulated respectively, and the agreements between the simulated results and the experimental data indicate that the proposed model is reasonable and effective to simulate the complex deformation of discontinuous rock mass.
  • [1] 夏才初, 孙宗颀. 工程岩体节理力学[M]. 上海: 同济大学出版社, 2002. (XIA Cai-chu, SUN Zong-qi. Engineering rock mass joint mechanics[M]. Shanghai: Tongji University Press, 2002. (in Chinese))
    [2] 蔡美峰, 何满潮, 刘东燕, 等. 岩石力学与工程[M]. 北京: 科学出版社, 2002. (CAI Mei-feng, HE Man-chao, LIU Dong-yan, et al. Rock mechanics and engineering[M]. Beijing: Science Press, 2002. (in Chinese))
    [3] 陆家佑. 岩体力学及其工程应用[M]. 北京: 中国水利水电出版社, 2011. (LU Jia-you. Rock mass mechanics and its applications[M]. Beijing: China Water Power Press, 2011. (in Chinese))
    [4] 张楚汉. 论岩石、混凝土离散-接触-断裂分析[J]. 岩石力学与工程学报, 2008, 27(2): 217-235. (ZHANG Chu-han. Discrete-contact- fracture analysis of rock and concrete[J]. Chinese Journal of Rock Mechanics and Engineering, 2008, 27(2): 217-220. (in Chinese))
    [5] GOODMAN R E. Methods of geological engineering in discontinuous rocks[M]. New York: West Publishing Company, 1976.
    [6] BANDIS S C, LUMSDEN A C, BARTON N R. Fundamentals of rock joint deformation[J]. International Journal of Rock Mechanics & Mining Sciences & Geomechanics Abstracts, 1983, 20(6): 249-268.
    [7] DESAI C S, FISHMAN K L. Plasticity-based constitutive model with associated testing for joints[J]. International Journal of Rock Mechanics & Mining Sciences & Geomechanics Abstracts, 1990, 28(1): 15-26.
    [8] WANG J G, ICHIKAWA Y, LEUNG C F. A constitutive model for rock interfaces and joints[J]. International Journal of Rock Mechanics & Mining Sciences, 2003, 40(1): 41-53.
    [9] 徐 磊, 任青文, 王 威, 等. 岩体结构面非线性弹性-塑性软化本构模型研究[J]. 应用力学学报, 2008, 25(3): 462-465. (XU Lei, REN Qing-wen, WANG Wei, et al. Nonlinear elasto-plastic softening constitutive model for rock interfaces and joints[J]. Chinese Journal of Applied Mechanics, 2008, 25(3): 462-465. (in Chinese))
    [10] 肖卫国, 兑关锁, 陈铁林, 等. 剪胀和破坏耦合的节理岩体本构模型的研究[J]. 岩石力学与工程学报, 2009, 28(12): 2535-2543. (XIAO Wei-guo, DUI Guan-suo, CHEN Tie-lin, et al. A study of constitutive model coupling dilatancy and degradation for jointed rock[J]. Chinese Journal of Rock Mechanics and Engineering, 2009, 28(12): 2535-2543. (in Chinese))
    [11] PLESHA M E. Constitutive models for rock discontinuities with dilatancy and surface degradation[J]. International Journal for Numerical & Analytical Methods in Geomechanics, 1987, 11(4): 345-362.
    [12] 尹显俊, 王光纶, 张楚汉. 岩体结构面切向循环加载本构关系研究[J]. 工程力学, 2005, 22(6): 97-104. (YIN Xian-jun, WANG Guang-lun, ZHANG Chu-han. Study of constitutive model for rock interfaces and joints under cyclic shear loading[J]. Engineering Mechanics, 2005, 22(6): 97-104. (in Chinese))
    [13] SIMON R F, AUBERTIN M F, MITRI H S F. A non-linear constitutive model for rock joints to evaluate unstable slip[C]// Proceedings of the 37th US Rock Mech Symp, Rock Mechanics for Industry. Rotterdam: Balkema A A, 1999: 1091-1098.
    [14] 殷有泉. 考虑损伤的节理本构模型[J]. 工程地质学报, 1994, 2(4): 2-4. (YIN You-quan. Joint constitutive model considering damage [J]. Journal of Engineering Geology, 1994, 2(4): 2-4. (in Chinese))
    [15] HU L M, PU J L. Application of damage model for soil-structure interface[J]. Computers and Geotechnics, 2003, 30(2): 165-183.
    [16] SOULEY M, HOMAND F, AMADEI B. An extension to the Saeb and Amadei constitutive model for rock joints to include cyclic loading paths[J]. International Journal of Rock Mechanics & Mining Sciences & Geomechanics Abstracts, 1995, 32(2): 101-109.
    [17] SAEB S, AMADEI B. Modelling rock joints under shear and normal loading[J]. International Journal of Rock Mechanics & Mining Sciences & Geomechanics Abstracts, 1992, 29(3): 267-278.
    [18] BOULON M, ARMAND G, HOTEIT N, et al. Experimental investigations and modelling of shearing of calcite healed discontinuities of granodiorite under typical stresses[J]. Engineering Geology, 2002, 64(2/3): 117-133.
    [19] LEE H S, PARK Y J, CHO T F, et al. Influence of asperity degradation on the mechanical behavior of rough rock joints under cyclic shear loading[J]. International Journal of Rock Mechanics and Mining Sciences, 2001, 38(7): 967-980.
    [20] 朱福巍, 兑关锁, 任青文. 基于本构积分算法的岩体结构面三维弹塑性有限元模型[J]. 岩土工程学报, 2011, 33(7): 1058-1065. (ZHU Fu-wei, DUI Guan-suo, REN Qing-wen. Three-dimensional elastoplastic model for rock joint elements based on integration algorithm[J]. Chinese Journal of Geotechnical engineering, 2011, 33(7): 1058-1065. (in Chinese))
    [21] ZHANG J, LI J. Elastoplastic damage model for concrete based on consistent free energy potential[J]. Science China (Technological Sciences), 2014, 57(11): 2278-2286.
    [22] SAMADHIYA N K, VILADKAR M N, AL-OBAYDI M A. Three-dimensional joint/interface element for rough undulating major discontinuities in rock masses[J]. International Journal of Geomechanics, ASCE, 2008, 8(6): 328-331.
    [23] BARTON N, BANDIS S, BAKHTAR K. Strength, deformation and conductivity coupling of rock joints[J]. International Journal of Rock Mechanics & Mining Sciences & Geomechanics abstracts, 1985, 22(3): 121-140.
    [24] LEE S W. Stability around underground openings in rock with dilative, non-persistent and multi-scale wavy joints using a discrete element method[D]. Chicago: The University of Illinois, 2003.
    [25] JING L, STEPHANSSON O, NORDLUND E. Study of rock joints under cyclic loading conditions[J]. Rock Mechanics and Rock Engineering, 1993, 26(3): 215-232.
    [26] 任晓丹. 弹塑性损伤本构关系的显式积分算法研究[J]. 固体力学学报, 2014, 35(S1): 134-140. (REN Xiao-dan. Explicit time integration scheme for plastic damage model[J]. Chinese Journal of Solid Mechanics, 2014, 35(S1): 134-140. (in Chinese))
    [27] 李 杰, 吴建营. 混凝土弹塑性损伤本构模型研究I: 基本公式[J]. 土木工程学报, 2005, 38(9): 14-20. (LI Jie, WU Jian-ying. Elastoplastic damage constitutive model for concrete based on damage energy release rates, part I: basic formulations[J]. China Civil Engineering Journal, 2005, 38(9): 14-20. (in Chinese))
    [28] WU J Y, LI J, FARIA R. An energy release rate-based plastic-damage model for concrete [J]. International Journal of Solids and Structures, 2006, 43(3/4): 583-612.
    [29] SIMO J C, HUGHES T J R. Computational inelasticity[M]. New York: Springer-Verlag, 1997.
    [30] JU J W. On energy based coupled elastoplastic damage theories: constitutive modeling and computational aspects[J]. International Journal of Solids and Structures, 1989, 25(7): 803-833.
