冻融循环作用下含盐量对Na<sub>2</sub>SO<sub>4</sub>土体变形特性影响的试验研究

肖泽岸; 赖远明; 尤哲敏

doi:10.11779/CJGE201705021

冻融循环作用下含盐量对Na₂SO₄土体变形特性影响的试验研究 English Version

1. 中国科学院寒区旱区环境与工程研究所冻土工程国家重点实验室,甘肃兰州 730000;
2. 中国科学院大学,北京 100049

基金项目: 国家自然科学基金重点项目（41230630）; 中国科学院前沿科学重点研究项目（QYZDY-SSW-DQC015）; 中科院寒旱所青年人才基金项目（Y451231001）; 中科院寒旱所冻土工程国家重点实验室自主课题（Y452F71001）

详细信息

作者简介:
肖泽岸(1989- ),男,博士研究生,主要从事寒区盐渍土方面的理论和试验研究。E-mail: xzalfx@163.com。

中图分类号: TU445；TU448
计量
- 文章访问数: 0285
- HTML全文浏览量: 0
- PDF下载量: 0349
出版历程
- 收稿日期: 2016-07-17
- 发布日期: 2017-05-24

Experimental study on impact of salt content on deformation characteristics of sodium sulfate soil under freeze-thaw conditions

1. State Key Laboratory of Frozen Soil Engineering, Cold and Arid Regions Environmental and Engineering Research Institute, Chinese Academy of Sciences, Lanzhou 730000, China;
2. University of Chinese Academy of Sciences, Beijing 100049, China

摘要

摘要: 冻融循环作用下,土体孔隙溶液中的盐分不断结晶与溶解,水分不断冻结与融化,使得含盐土体的变形不断变化。以青藏高原粉质黏土为研究对象,对洗盐后的素土分别加入质量分数为0%,1%,2%,3%的Na₂SO₄盐,研究了封闭系统下Na₂SO₄盐渍土在冻融循环作用下的变形规律。结果表明,在冻融循环过程中,不含盐土体和较低含盐量的土体表现出明显的冻胀融沉现象,且土体的融沉大于其的冻胀。而较高含盐量的土体在冻结过程中,土体的冻—盐胀作用显著,融沉现象却不再明显,甚至消失。利用多孔介质力学的方法,探讨了Na₂SO₄盐渍土在冻融循环作用下土体的变形规律,得出土体的变形由冰水/盐分相变、热胀冷缩、相变过程中的密度变化等引起的变形综合而成。结合Na₂SO₄溶液的性质,还分析了Na₂SO₄的结晶机理,从而为进一步研究盐渍化冻土中的变形机理提供一些参考。
- 冻融循环 /
- Na₂SO₄ /
- 盐渍化冻土 /
- 变形 /
- 多孔介质力学
Abstract: Due to the sharp fluctuations of temperature in cold regions, salt may crystallize and water may freeze, resulting in the deformation of soil. In order to investigate the impact of salt content on soil deformation under freeze-thaw cycles, the freeze-thaw tests on soil with different salt contents are conducted. The desalinized Qinghai-Tibet silty clay is used, then different salt contents 0%, 1%, 2%, 3% are added, respectively. By testing the deformation of soil in a close system, the impact of salt content on deformation characteristics of sodium sulfate soil is studied. The results demonstrate that the frost heave and thaw settlement occur when the soil is desalinated or the salt content is 1%, and the thaw settlement is larger than the frost heave. However, when the salt content of soil is higher, though the frost heave still exists, the thaw settlement decreases and even disappears. Based on the porous media mechanics, the mechanism of soil deformation is discussed under freeze-thaw cycles. It is obtained that the deformation of soil is the results of combined effect of many factors, such as the phase change effect, thermal expansion and contraction and so on. In addition, considering the sodium sulfate properties, the crystallization mechanism of sodium sulfate is investigated. The research will help to provide some theoretical basis for the studies on saline frozen soil.
- freeze-thaw cycle /
- sodium sulfate /
- saline frozen soil /
- deformation /
- poromechanics

HTML全文

参考文献(22)

[1]	高江平, 杨荣尚. 含氯化钠硫酸盐渍土在单向降温时水分和盐分迁移规律的研究[J]. 西安公路交通大学学报, 1997(3): 22-25. (GAO Jiang-ping, YANG Rong-shang. Study on the moving pattern of water and salt with directional temperature lowing in suphate salty soil containing NaCl [J]. Journal of Xi'an Highway University, 1997(3): 22-25. (in Chinese))
[2]	徐学祖, 王家澄, 张立新. 土体冻胀和盐胀机理[M]. 北京: 科学出版社, 1995. (XU Xue-zu, WANG Jia-cheng, ZHANG Li-xin. Mechanisms of frost heave and soil expansion of soils[M]. Beijing: Science Press, 1995. (in Chinese))
[3]	徐学祖, 王家澄, 张立新. 冻土物理学[M]. 北京: 科学出版社, 2010. (XU Xue-zu, WANG Jia-cheng, ZHANG Li-xin. Frozen soil physics[M]. Beijing: Science Press, 2010. (in Chinese))
[4]	陈肖柏, 邱国庆, 王雅卿, 等. 温降时之盐分重分布及盐胀试验研究[J]. 冰川冻土, 1989, 11(3): 231-238. (CHEN Xiao-bai, QIU Guo-qing, WANG Ya-Qing. Salt redistribption and heave of saline soil during cooling[J]. Journal of Glaciology and Geocryology, 1989, 11(3): 231-238. (in Chinese))
[5]	张殿发, 郑琦宏. 冻融条件下土壤中水盐运移规律模拟研究[J]. 地理科学进展, 2005(4): 46-55. (ZHANG Dian-fa, ZHEN Qi-hong. Simulation of water-salt movement law under the freeze-thawing condition[J]. Progress in Geography, 2005(4): 46-55. (in Chinese))
[6]	邴慧, 何平. 不同冻结方式下盐渍土水盐重分布规律的试验研究[J]. 岩土力学, 2011, 32(8): 2307-2312. (BING Hui, HE Ping. Experimental study of water and salt redistributions of saline soil with different freezing modes[J]. Rock and Soil Mechanics, 2011, 32(8): 2307-2312. (in Chinese))
[7]	CARY J W. A new method for calculating frost heave including solute effects[J]. Water Resources Research, 1987, 23(8): 1620-1624.
[8]	PADILLA F, VILLENEUVE J P. Modeling and experimental studies of frost heave including solute effects[J]. Cold Regions Science and Technology, 1992, 20(2): 183-194.
[9]	BAKER G C, OSTERKAMP T E. Salt redistribution during freezing of saline sand columns at constant rates[J]. Water Resources Research, 1989, 25(8): 1825-1831.
[10]	ANDERSON D M, TICE A R. Predicting unfrozen water contents in frozen soils from surface area measurements[J]. Highway Research Record, 1972, 393: 12-18.
[11]	BANIN A, ANDERSON D M. Effects of salt concentration changes during freezing on the unfrozen water content of porous materials[J]. Water Resources Research, 1974, 10(1): 124-128.
[12]	陈肖柏, 邱国庆, 王雅卿, 等. 重盐土在温度变化时的物理化学性质和力学性质[J]. 中国科学, 1988(4): 429-438. (CHEN Xiao-bai, QIU Guo-qing, WANG Ya-Qing. The physical chemical properties and mechanical properties of saline soil during temperature change process[J]. Science in China, 1988(4): 429-438. (in Chinese))
[13]	包卫星, 谢永利, 杨晓华. 天然盐渍土冻融循环时水盐迁移规律及强度变化试验研究[J]. 工程地质学报, 2006(3): 380-385. (BAO Wei-xin, XIE Yong-li, YANG Xiao-hua. A laboratory test study on water and salt mitigation in natural saline soils and associated shear strength changes under freezing and thawing cycles[J]. Journal of Engineering Geology, 2006(3): 380-385. (in Chinese))
[14]	王海涛. 冻融循环条件下罗布泊盐渍土工程性质试验研究[D]. 乌鲁木齐: 新疆农业大学, 2013. (WANG Hai-tao. Experimental study on engineering properties of Lop Nor saline soil in condition of freeze-thaw cycle[D]. Urumqi: Xinjiang Agricultural University, 2013. (in Chinese))
[15]	陈锦, 李东庆, 邴慧, 等. 含盐量对冻结粉土单轴抗压强度影响的试验研究[J]. 工程力学, 2013, 13(12): 18-23. (CHEN Jin, LI Dong-qing, BING Hui, et al. The experimental study on the uniaxial compressive strength of frozen silt with different salt content[J]. Engineering Mechanics, 2013, 13(12): 18-23. (in Chinese))
[16]	COUSSY O. Poromechanics of freezing materials[J]. Journal of the Mechanics and Physics of Solids, 2005, 53(8): 1689-1718.
[17]	COUSSY O, MONTEIRO P J M. Poroelastic model for concrete exposed to freezing temperatures[J]. Cement and Concrete Research, 2008, 38(1): 40-48.
[18]	天津化工研究院. 无机盐工业手册[M]. 北京: 化学工业出版社, 1979. (Tianjin Chemical Research Institute. Handbook of inorganic salt industry[M]. Beijing: Chemical Industry Press, 1979. (in Chinese))
[19]	ZENG Q. Poromechanical behavior of cement-based materials subjected to freeze-thaw actions with salts[D]. Paris: Université Paris-Est, 2011.
[20]	LOCH J P G. Tthermodynamic equilibrium between ice and water in porous media[J]. Soil Science, 1978, 126(2): 77-80.
[21]	SCHERER G W. Stress from crystallization of salt[J]. Cement and Concrete Research, 2004, 34(9): 1613-1624.
[22]	张莲海. 土体冻融过程中孔隙水压力测试及冻结缘过程研究[D]. 北京: 中国科学院大学, 2014. (ZHANG Lian-hai. Investigation on the pore water pressures and frozen fringe process during soil freezing and thawing[D]. Beijing: University of Chinese Academy of Science, 2014. (in Chinese))
