透明土中连续球体型锚杆拔出机理研究

夏元友; 陈晨; NI Qing

doi:10.11779/CJGE201705004

透明土中连续球体型锚杆拔出机理研究 English Version

1. 武汉理工大学土木工程与建筑学院,湖北武汉430070;
2. School of Engineering, University of Warwick, Coventry, UK CV4 7ES

基金项目: 国家自然科学基金面上项目（51374163）

详细信息

作者简介:
夏元友(1965- ),男,教授,博士生导师,主要从事岩土工程教学与研究工作。E-mail: xiayy1965@126.com。

中图分类号: TU433
计量
- 文章访问数: 406
- HTML全文浏览量: 5
- PDF下载量: 428
出版历程
- 收稿日期: 2016-08-27
- 发布日期: 2017-05-24

Pull-out mechanism of continuous ball shape anchors in transparent soil

1. School of Civil Engineering and Architecture, Wuhan University of Technology, Wuhan 430070, China;
2. School of Engineering, University of Warwick, Coventry, CV4 7ES, UK

摘要

摘要: 采用透明土材料和粒子图像测速法（PIV）技术,通过物理模型试验研究锚杆拔出机理。在模型试验中采用A、B两种不同尺寸的连续球体锚杆锚固段,试验获得各锚杆锚固段上移对周围土体的扰动规律、锚杆位移与锚固力变化曲线以及拔出破坏时破裂面的位置及形状。通过分析连续球体锚杆锚固段的极限承载力和锚固段破坏机理,推导出连续球体锚杆抗拔力的计算公式。试验结果分析表明：本文试验条件下,锚杆拔出时竖向位移最大影响范围与连续球体的半径和间距有直接关系;A、B型连续球体锚杆的极限承载力,分别比普通圆柱型锚杆提高52%和117%;连续球体锚杆锚固段在上拔破坏过程中抗拔力的贡献可分为3个部分：直杆与土层的黏结、肩部端承力和黏土黏聚力。
- 土层锚杆 /
- 模型试验 /
- 透明土 /
- 土体位移 /
- 锚固机理
Abstract: A physical modelling system is developed to study the pull-out mechanism of embedded soil anchors using transparent soil and particle image velocimetry (PIV). In the system, two different continuous ball shape anchors are set in the experiment to observe displacement impact areas, soil displacement, load-displacement curve and shape and location of pull-out failure interface. After analyzing the ultimate bearing capacity and the failure mechanism of the soil anchors, a suggested method is given. From the results, based on the circumstances of this model, the maximum vertical displacement impact areas have direct relationship with the radius of the ball and the distance between the balls during pull-out of the soil anchors. The continuous ball shape soil anchors (type A and B) can effectively provide 52% and 117% more force than the normal cylinder anchors. The pull-out force of the continuous ball shape soil anchors can be divided into three different parts: adhesion on shaft, end bearing in clay and cohesive through clay.
- soil anchor /
- model test /
- transparent soil /
- soil displacement /
- anchoring mechanism
