正断层错动诱发单桩破坏及避让距离研究

蔡奇鹏, 吴宏伟, 陈星欣, 郭力群

蔡奇鹏, 吴宏伟, 陈星欣, 郭力群. 正断层错动诱发单桩破坏及避让距离研究[J]. 岩土工程学报, 2017, 39(4): 720-726. DOI: 10.11779/CJGE201704018
引用本文: 蔡奇鹏, 吴宏伟, 陈星欣, 郭力群. 正断层错动诱发单桩破坏及避让距离研究[J]. 岩土工程学报, 2017, 39(4): 720-726. DOI: 10.11779/CJGE201704018
shu
CAI Qi-peng, NG C. W. W., CHEN Xing-xin, GUO Li-qun. Failure mechanism and setback distance of single pile subjected to normal faulting[J]. Chinese Journal of Geotechnical Engineering, 2017, 39(4): 720-726. DOI: 10.11779/CJGE201704018
Citation: CAI Qi-peng, NG C. W. W., CHEN Xing-xin, GUO Li-qun. Failure mechanism and setback distance of single pile subjected to normal faulting[J]. Chinese Journal of Geotechnical Engineering, 2017, 39(4): 720-726. DOI: 10.11779/CJGE201704018
shu

正断层错动诱发单桩破坏及避让距离研究  English Version

  • 1. 华侨大学土木工程学院,福建 厦门 361021;
    2. 香港科技大学土木与环境工程系,香港

基金项目: 福建省自然科学基金计划项目（2014J01194,2015J01209）; 华侨大学中青年教师科研提升计划项目（ZQN-PY216）
详细信息
    作者简介:

    蔡奇鹏(1982- ),男,福建泉州人,博士,副教授,主要从事岩土与地下工程方面的研究与教学工作。E-mail: cqp@hqu.edu.cn。

Failure mechanism and setback distance of single pile subjected to normal faulting

  • 1. College of Civil Engineering, Huaqiao University, Xiamen 361021, China;
    2. Department of Civil and Environmental Engineering, Hong Kong University of Science and Technology, Hong Kong, China

摘要

    摘要
  • 摘要: 历次地震实例表明基岩断层错动诱发建筑桩基破坏,针对桩基础的近断层破坏机理认识不足。采用土工离心机试验,研究正断层错动引起上覆砂土中单桩基础的破坏。试验详细量测单桩及土体变形,监测桩身轴力及弯矩随基岩错动量的变化规律。试验数据表明,当错动量为0.4 m时,单桩与桩周土体协同变形,桩顶出现显著位移。随着错动量增加,上覆土体变形集中于破裂带,使得桩顶位移显著减少。该破裂带在基岩和土体的交界面上偏离基岩错动方向,与水平面呈80°方向发展至地表,并在单桩靠近断层上盘一侧地表出露。上覆砂土变形可分为静止区、剪切区和刚体位移区。当单桩位于剪切区附近,桩身受弯变形使得桩顶向上盘一侧倾斜。针对正断层错动,单桩在下盘一侧和上盘一侧离开基岩断层线的安全避让距离分别为15 m和10 m。
    Abstract: Field case studies after earthquake show that pile foundation can be severely damaged by bedrock fault movement. The failure mechanism of this type of foundation damage is not yet fully understood. Centrifuge modeling of a single pile damage induced by normal faulting in sand is conducted. The deformations of pile and soil are measured. The developments of axial forces and bending moments along the pile with bedrock fault movement are monitored. The centrifuge test results show that when the bedrock fault movement equals 0.4 m, the pile displaces consistently with the surrounding soil. With the increase in bedrock fault movement, sand deformation is localized around a fault rupture and pile displacement is significantly reduced. The rupture increases in dip at the soil-bedrock interface and propagates upward with a dip angle of 80 degrees to the horizontal. It outcrops at the ground surface on the hanging wall side of the pile. The sand deformation is classified as a stationary zone, a shearing zone and a rigid body zone. When the single pile is located around the shearing zone, the pile is bent towards the hanging wall. For normal faulting, the setback distances of a single pile from the bedrock fault line on the footwall and the hanging wall are 15 and 10 m, respectively.
    • HTML全文
    • 参考文献(19)
  • [1] FACCIOLI E, ANASTASOPOULOS I, GAZETAS G, et al. Fault rupture-foundation interaction: selected case histories[J]. Bulletin of Earthquake Engineering, 2008, 6(4): 557-583.
    [2] 徐锡伟, 于贵华, 马文涛, 等. 活断层地震地表破裂“避让带”宽度确定的依据与方法[J]. 地震地质, 2002, 24(4): 470-483. (XU Xi-wei, YU Gui-hua, MA Wen-tao, et al. Evidence and methods for determining the safety distance from the potential earthquake surface rupture on active fault[J]. Seismology and Geology, 2002, 24(4): 470-483. (in Chinese))
    [3] 刘守华, 董津城, 徐光明, 等. 地下断裂对不同土质上覆土层的工程影响[J]. 岩石力学与工程学报, 2005, 24(11): 1868-1873. (LIU Shou-hua, DONG Jin-cheng, XU Guang-ming, et al. Influence on different overburden soils due to bedrock fracture[J]. Chinese Journal of Rock Mechanics and Engineering, 2005, 24(11): 1868-1873. (in Chinese))
    [4] LEE J W, HAMADA M. An experimental study on earthquake fault rupture propagation through a sandy soil deposit[J]. Structural Engineering/Earthquake Engineering, 2005, 22(1): 1-13.
    [5] ANASTASOPOULOS I, GAZETAS G, BRANSBY M F, et al. Fault rupture propagation through sand: finite-element analysis and validation through centrifuge experiments[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2007, 133(8): 943-958.
    [6] CAI Q P, NG C W W, LUO G Y, et al. Influences of pre-existing fracture on ground deformation induced by normal faulting in mixed ground conditions[J]. Journal of Central South University, 2013, 20(2): 501-509.
    [7] 蔡奇鹏, 吴宏伟. 胶结黏土中正断层扩展的变形和孔压变化研究[J]. 岩石力学与工程学报, 2014, 33(2): 390-395. (CAI Qi-peng, WU Hong-wei. Deformation mechanism and variation of pore pressure due to normal fault propagation in cemented clay[J]. Chinese Journal of Rock Mechanics and Engineering, 2014, 33(2): 390-395. (in Chinese))
    [8] BRANSBY M F, DAVIES M C R, EL NAHAS A. Centrifuge modeling of normal fault-foundation interaction[J]. Bulletin of Earthquake Engineering, 2008, 6(4): 585-605.
    [9] AHMED W, BRANSBY M F. The interaction of shallow foundations with reverse faults[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2009, 135(7): 914-924.
    [10] LOLI M, ANASTASOPOULOS I, BRANSBY M F, et al. Caisson foundations subjected to reverse fault rupture: centrifuge testing and numerical analysis[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2011, 137(10): 914-925.
    [11] ANASTASOPOULOS I, KOURKOULIS R, GAZETAS G, et al. Interaction of piled foundation with a rupturing normal fault[J]. Géotechnique, 2013, 63(12): 1042-1059.
    [12] NG C W W, VAN LAAK P, TANG W H, et al. The Hong Kong geotechnical centrifuge[C]// Proc 3rd Int Conf soft Soil Engineering. Hong Kong, 2001.
    [13] 胡 平, 丁彦慧, 蔡奇鹏, 等. 第四纪地层中断层同震错动行为的离心机试验研究[J]. 地球物理学报, 2011, 54(9): 2293-2301. (HU Ping, DING Yan-hui, CAI Qi-peng, et al. Centrifuge modeling on the behavior of co-seismic fault dislocation in the Quaterary stratum[J]. Chinese Journal of Geophysics, 2011, 54(9): 2293-2301. (in Chinese))
    [14] NG C W W, CAI Q P, HU P. Centrifuge and numerical modeling of normal fault-rupture propagation in clay with and without a preexisting fracture[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2012, 138(12): 1492-1502.
    [15] CAI Q P, NG C W W. Centrifuge modeling of pile-sand interaction induced by normal faulting[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2016, 142(10): 04016046.
    [16] ISHIHARA K. Liquefaction and flow failure during earthquakes[J]. Géotechnique, 1993, 43(3): 351-415.
    [17] WHITE D J, TAKE W A, BOLTON M D. Soil deformation measurement using particle image velocimetry (PIV) and photogrammetry[J]. Géotechnique, 2003, 53(7): 619-631.
    [18] Cai Q P, NG C W W. Analytical approach for estimating ground deformation profile induced by normal faulting in undrained clay[J]. Canadian Geotechnical Journal, 2013, 50(4): 413-422.
    [19] BRAY J D, SEED R B, CLUFF L S, et al. Earthquake fault rupture propagation through soil[J]. Journal of Geotechnical Engineering, 1994, 120(3): 543-561.
