泥水盾构带压开舱时泥膜的微观孔隙及渗透性研究

张宁; 朱伟; 闵凡路; 徐静波

doi:10.11779/CJGE201703013

泥水盾构带压开舱时泥膜的微观孔隙及渗透性研究 English Version

张宁^{1, 2},
朱伟^{1, 2},
闵凡路^{1, 2},
徐静波^{1, 2}

1. 河海大学岩土力学与堤坝工程教育部重点实验室,江苏南京 210098;
2. 河海大学土木与交通学院,江苏南京 210098

基金项目: 国家重点基础研究发展计划（“973”计划）项目（2015CB057803）; 国家自然科学基金项目（51408191）; 中央高校基本科研业务费专项项目（2015B06014）; 中央高校基本科研业务费专项资金项目（2016B50714）

详细信息

作者简介:
张宁(1992- ),男,河北沧州人,硕士研究生,研究方向为岩土工程、盾构隧道。E-mail: zhanghhu1992@163.com。

计量
- 文章访问数: 348
- HTML全文浏览量: 1
- PDF下载量: 356
出版历程
- 收稿日期: 2015-12-22
- 发布日期: 2017-04-24

Microscopic pores of filter membranes and permeability during chamber opening under high pressure in slurry shield

ZHANG Ning^{1, 2},
ZHU Wei^{1, 2},
MIN Fan-lu^{1, 2},
XU Jing-bo^{1, 2}

1. Key Laboratory of Geomechanics and Embankment Engineering, Hohai University, Ministry of Education, Nanjing 210098, China;
2. Geotechnical Research Institute of Hohai University, Nanjing 210098, China

摘要

摘要: 泥膜的良好闭气性是保证泥水盾构带压开舱安全顺利实施的关键之一,要想提高泥膜的闭气性,首先应了解泥膜在带压开舱过程中的孔隙结构及渗透性变化。以南京纬三路过江通道在江底砂卵石地层中进行带压开舱为背景,在自制的试验装置中进行泥浆成膜和泥膜闭气试验,然后观测泥膜的孔隙结构和孔径变化,最后分析泥膜渗透系数的变化。研究结果表明：试验泥浆在0.2 MPa气压作用下6 h,在试验地层表面形成的泥膜厚度约为5.0 mm、孔隙率约为67%,在闭气过程中泥膜会发生压缩,且第一次单位压力引起的压缩量最大;随着闭气压力的增大,大孔隙组被优先压缩;泥膜基本单元体为骨架状结构,孔隙主要是粒间孔隙与架空孔隙,孔隙分布不连续、连通性差;孔径分布范围较广,其中在0.1~3.0 μm的孔隙组占有绝对优势;本次试验中压缩后泥膜的渗透系数在10^-9 cm/s量级。研究结果有助于明确泥膜在闭气过程中的变化,对后续提高泥膜闭气性的研究有重要的参考意义。
- 带压开舱 /
- 泥膜 /
- 闭气试验 /
- 孔隙结构 /
- 渗透系数
Abstract: Good air tightness of filter membranes is necessary for opening excavation chamber under high pressure. To improve the value of air tightness, one should understand the pore structure and permeability change of filter membranes during chamber opening under high pressure. Taking the sandy cobble stratum of Nanjing Weisan Road river-crossing tunnel as an example, the air tightness tests are carried out for filter membranes formed under different pressures by a self-developed airtightness apparatus. Its pore structures and measured diameters are observed, and the changes of permeability coefficient are analyzed. The results show that the thickness of the filter membranes is 5.0 mm under 0.2 MPa for 6 hours, the porosity is about 67%, the filter membranes are compressed during the air tightness tests and at the first stage it is the largest. With the growth of the air pressure, the large pore group is preferentially compressed. The basic unit of filter membranes is a skeleton-like structure, and the pore structure is mainly inter-particle pore and overhead pore; furthermore, the pore is not continuous and poorly connective. The pore size has a broader distribution, and the group of 0.1~3.0 μm has an absolute advantage. The permeability coefficient in this experiment has a magnitude of 10^-9 cm/s. The results define the change of the filter membranes during air tightness, and it plays a significant role in improving the value of filter membranes during air tightness.
- chamber opening under high pressure /
- filter membrane /
- air tightness test /
- microscopic pore /
- permeability coefficient

HTML全文

参考文献(13)

[1]	朱伟, 闵凡路, 姚占虎, 等. 盾构隧道开舱技术现状及实例[J]. 现代隧道技术, 2015(1): 9-18. (ZHU Wei, MIN Fanlu, YAO Zhan-hu, et al. Technical status and case study on intervention in the shield chamber[J]. Modern Tunnelling Technology, 2015(1): 9-18. (in Chinese))
[2]	邓彬, 顾小芳. 上软下硬地层盾构施工技术研究[J]. 现代隧道技术, 2012(2): 59-64. (DENG Bin, GU Xiao-fang. Study of shield construction technology in soft upper stratumand hard under stratum[J]. Modern Tunnelling Technology, 2012(2): 59-64. (in Chinese))
[3]	贺霄飞. 压气作业在地铁盾构施工中的应用[J]. 山西建筑, 2007, 33(11): 309-310. (HE Xiao-fei. Pressure gas operations in construction of metro shield[J]. Shanxi Architecture, 2007, 33(11): 309-310. (in Chinese))
[4]	ANAGNOSTOU G, KOVÁRI K. The face stability of slurry-shield-driven tunnels[J]. Tunnelling and Underground Space Technology, 1994, 9(2): 165-174.
[5]	WATANABE T, YAMAZAKI H. Giant size slurry shield is a success in Tokyo[J]. Tunnels and Tunnelling, 1981, 13: 13-17.
[6]	MIN Fan-lu, ZHU Wei, LIN Cheng, et al. Opening the excavation chamber of the large-diameter size slurry shield: A case study in Nanjing Yangtze River Tunnel in China[J]. Tunnelling and Underground Space Technology, 2015, 46: 18-27.
[7]	刘成, 孙钧, 杨平, 等. 泥膜形成与状态划分细观分析及模型试验研究[J]. 岩土工程学报, 2014, 36(3): 435-442. (LIU Cheng, SUN Jun,YANG Ping, et al. Mesoscopic analysis and model test on formation process and state division of slurry membrane[J]. Chinese Journal of Geotechnical Engineering, 2014, 36(3): 435-442. (in Chinese))
[8]	张宁, 朱伟, 姚占虎, 等. 泥水盾构带压开舱时泥膜性质对其闭气性的影响研究[J]. 现代隧道技术, 2015(4): 62-67. (ZHANG Ning, YAO Zhan-hu, ZHU Wei, et al. Study on filter membrane to its air tightness during opening chamber under high pressure in slurry shield[J]. Modern Tunnelling Technology, 2015(4): 62-67. (in Chinese))
[9]	姜腾. 盾构开舱时闭气压力与泥膜孔隙结构[D]. 南京: 河海大学, 2015. (JIANG Teng. Experimental study on airproof presure and pore size distribution of the filter cake during compressed air work[D]. Nanjing: Hohai University, 2015. (in Chinese))
[10]	CLEMENT Lapierr, SERGE Lergoue, JACQUES Loca. Mercury intrusion and permeability of Louiseville clay[J]. Canadian Geotechnical Journal, 1990(27): 761-773.
[11]	张先伟, 孔令伟. 利用扫描电镜、压汞法、氮气吸附法评价近海黏土孔隙特征[J]. 岩土力学, 2013(增刊2): 134-142. (ZHANG Xian-wei, KONG Ling-wei. Study of pore characteristics of offshore clay by SEM and MIP and NA methods[J]. Rock and Soil Mechanics, 2013(S2): 134-142. (in Chinese))
[12]	韦良文, 张庆贺, 邓忠义. 大型泥水盾构隧道开挖面稳定机理与应用研究[J]. 地下空间与工程学报, 2007(1): 87-91. (WEI Liang-wen, ZHANG Qing-he, DENG Zhong-yi. Research on mechanism and application of face stability in large slurry shield tunneling[J]. Chinese Journal of Underground Space and Engineering, 2007(1): 87-91. (in Chinese))
[13]	程明亮, 何峰, 吕传田. 大埋深富水砂卵石地层泥水盾构带压换刀及动火焊接技术[J]. 中国工程科学, 2010(12): 46-50. (CHENG Ming-liang, HE Feng, LÜ Chuan-tian. Tools repairing and Welding techniques with high pressure of slurry shield under deep water-rich sandy gravel stratum[J]. Engineering Sciences, 2010(12): 46-50. (in Chinese))
