Experimental study on self-weight consolidation behavior of hydraulically dredged slurries
-
摘要: 大变形自重固结理论可广泛应用于堆场设计和堆场吹填淤泥处理等方面,但对于沉积柱试验中淤泥的自重固结性质,尤其是非线性压缩关系和非线性渗透关系,并没有进行详细深入地研究。利用研制的沉积固结试验方法研究了太湖和白马湖吹填淤泥的自重固结性质。该方法由沉积柱、孔隙水压力测试装置和分层真空取样装置组成,利用该方法可得到淤泥自重固结过程中泥水界面、超静孔隙水压力、密度、有效应力、颗粒分布、压缩关系和渗透关系等参数的变化规律。压缩关系试验结果表明:两种淤泥压缩关系是非线性的。在较低的有效应力时随有效应力的增大孔隙比迅速减小,在较高的有效应力时随有效应力的增大孔隙比减小趋势趋缓。存在一个有效应力的分界点,低于此点不同时间时有效应力与孔隙比的关系较为分散,此时淤泥的压缩性很大,高于此点不同时间时有效应力与孔隙比的关系可认为是唯一的。两种淤泥渗透关系是非线性的。淤泥的非线性压缩关系和渗透关系可采用幂函数关系。Abstract: The large-strain self-weight consolidation theory is widely used for the design of dredged material disposal sites and the treatment of hydraulically dredged slurries in the disposal sites. The self-weight consolidation behavior of hydraulically dredged slurries in settling column experiments, especially nonlinear compressibility relationship and nonlinear permeability relationship, is still unclear. The self-weight consolidation behavior of hydraulically dredged slurries from Taihu Lake and Baimahu Lake is studied by using a new sedimentation and consolidation experimental method which consists of a settling column, a pore pressure measurement apparatus and a multi-layer vacuum extraction sampling apparatus. It can test the changing rules of the interface height, excess pore pressure, density, effective stress, grain size distribution, compressibility relationship and permeability relationship in self-weight consolidation. The experimental results show that the compressibility relationship is nonlinear. Under low effective stresses, the void ratio changes significantly with a small increase in the effective stress, while under higher values of effective stress, change of void ratio with effective stress is more limited. When values of effective stress are greater than one value, a unique relationship is visible, and when the stresses are below this value, the data points cover a triangular shaped area, so the compressibility is large. The permeability relationship is nonlinear. The compressibility relationship and permeability relationship can be represented by a power function equation.
-
[1] BEEN K. Stress-strain behaviour of a cohesive soil deposited under water[D]. Oxford: University of Oxford, 1980. [2] BOWDEN R K. Compression behaviour and shear strength characteristics of a natural silty clay sedimented in the laboratory[D]. Oxford: University of Oxford, 1988. [3] ALEXIS A, LEBRAS G, THOMAS P. Experimental bench for study of settling-consolidation soil formation[J]. Geo- technical Testing Journal, 2004, 27(6): 557-567. [4] TOORMAN E A. Sedimentation and self-weight consolidation: general unifying theory[J]. Géotechnique, 1996, 46(1): 103-113. [5] MERCKELBACH L M. Consolidation and strength evolution of soft mud layers[D]. Delft: Delft University of Technology, 2000. [6] NAM S, GUTIERREZ M, DIPLAS P. Channeling during settling and self-weight consolidation of cohesive sediments[J]. Canadian Geotechnical Journal, 2006, 45(6): 867-576. [7] IMAI G. Experimental studies on sedimentation mechanism and sediment formation of clay materials[J]. Soils and Foundations, 1981, 21(1): 7-20. [8] WANG Liang, ZHU Wei, XIE Jian, et al. Study on shear strength of sediments in main sedimentation stages[J]. Marine Georesources & Geotechnology, 2015, 33: 556-566. [9] GIBSON R E, ENGLAND G L, HUSSEY M J L. The theory of one-dimensional consolidation of saturated clays. I finite non-linear consolidation of thin homogeneous layers[J]. Géotechnique, 1967, 17: 261-273. [10] 詹良通, 童 军, 徐 洁. 吹填土自重沉积固结特性试验研究[J]. 水利学报, 2009, 38(2): 201-205. (ZHAN Liang-tong, TONG Jun, XU Jie. Laboratory study on self weight sedimentation and consolidation behaviors of hydraulic dredged mud[J]. Chinese Journal of Hydraulic Engineering, 2009, 38(2): 201-205. (in Chinese)) [11] 刘 莹, 肖树芳, 王 清. 吹填土室内模拟试验研究[J]. 岩土力学, 2004, 25(4): 518-528. (LIU Ying, XIAO Shu-fang, WANG Qing. Research on indoor scale-down test of dredger fill[J]. Rock and Soil Mechanics, 2004, 25(4): 518-528. (in Chinese)) [12] 曹玉鹏, 吉 锋. 吹填淤泥沉积规律室内试验[J]. 水利水电科技进展, 2011, 31(3): 36-39. (CAO Yu-peng, JI Feng. Model tests on sedimentation behavior of dredged sludge[J]. Advances in Science and Technology of Water Resources, 2011, 31(3): 36-39. (in Chinese)) [13] BUTTERFIELD R. A natural compression law for soils[J]. Géotechnique, 1979, 29(4): 469-480. [14] BARTHOLOMEEUSEN G. Compound shock waves and creep behaviour in sediment beds[D]. Oxford: University of Oxford, 2003. [15] MESRI G, OLSON R E. Mechanisms controlling the permeability of clays[J]. Clay and Clay Mineral, 1971, 19(3): 151-158. [16] TAYLOR D W. Fundamental of soil mechanics[M]. New York: John Wiley & Sons Inc, 1948, 700p. [17] IMAI G, TANG Y X. A constitutive equation of one dimensional consolidation derived from inter-connected tests[J]. Soils and Foundations, 1992, 32(2): 83-96. -
