考虑任意初始条件的均质土质覆盖层降雨入渗解析解

邱清文; 詹良通; 黄依艺

doi:10.11779/CJGE201702021

考虑任意初始条件的均质土质覆盖层降雨入渗解析解 English Version

1. 浙江大学软弱土与环境土工教育部重点实验室,浙江杭州 310058;
2. 同济大学地下建筑与工程系,上海200092

详细信息

作者简介:
邱清文(1986-),男,博士研究生,主要从事非饱和土力学与环境岩土工程研究方面的工作。E-mail：qiuqingwen105@163.com。

计量
- 文章访问数: 0284
- HTML全文浏览量: 0
- PDF下载量: 0300
出版历程
- 发布日期: 2017-03-24

Analytical solutions for rainfall infiltration into monolithic covers considering arbitrary initial conditions

1. MOE Key Laboratory of Soft Soils and Geoenvironmental Engineering, Zhejiang University, Hangzhou 310058, China;
2. Department of Geotechnical Engineering, Tongji University, Shanghai 200092, China

摘要

摘要: 均质土质覆盖层作为填埋场与大气环境的隔离结构其主要功能是控制雨水入渗,近些年该类覆盖层在北美一些干旱和半干旱地区被证明是有效的。基于二维非饱和土渗流控制方程,采用可考虑土体进气值的指数函数描述土体的土水特征曲线和渗透系数曲线,使用单位梯度边界作为土质覆盖层的底部边界条件,推导出可考虑任意初始条件的降雨入渗移解析解。通过与前人试验结果比较与分析,证明了该解析解的有效性。对比分析了均质土质覆盖层底部分别取单位梯度边界、渗流审查边界和固定孔压边界对降雨入渗及渗漏量的影响,分析结果表明：与渗流审查边界和固定孔压边界相比,单位梯度边界更适合土质覆盖层的渗漏量计算。利用该解析解分析不同初始条件对累计渗漏量的影响,结果表明覆盖层累计渗漏量随其底部初始体积含水率的增加而增大。为土质覆盖层防渗漏性能评价提供了一种简单实用的计算方法。
- 均质土质覆盖层 /
- 单位梯度边界 /
- 任意初始条件 /
- 降雨入渗 /
- 解析解
Abstract: As an isolation barrier between landfill and atmospheric environment, monolithic covers are used to control rain water infiltration and deep percolation into landfill. In recent years, the covers are proved to be effective in some arid and semi-arid areas in North America. An analytical solution for rain water infiltration into a monolithic cover is presented on the basis of the two-dimensional governing equation for unsaturated flows. The analytical solution can take arbitrary initial conditions into consideration. To obtain the analytical solution, it is assumed that both the soil-water characteristic curve and the permeability function can be described by using the exponential functions considering entry air value and the bottom boundary of the monolithic cover is set as the unit gradient boundary. The analytical results are compared with those measured results reported in literatures, indicating that the analytical solution is effective. The influence on rain water infiltration into a monolithic cover and its percolation of using three boundaries including unit gradient boundary, seepage face boundary and fixed pore water pressure boundary as its bottom boundary are analyzed. The results indicate that compared with the other two boundaries, the unit gradient boundary is more suitable for the monolithic covers to calculate the percolation. The influence of various initial conditions on accumulated percolation of monolithic covers is analyzed using the analytical solution. The research indicates that the accumulated percolation increases with the increase of the initial volumetric water content near the bottom of the covers. This study provides a simple and practical method for evaluating the performance of monolithic covers to control rain water percolation through a soil cover.
- monolithic cover /
- unit gradient boundary /
- arbitrary initial condition /
- rainwater infiltration /
- analytical solution

HTML全文

参考文献(18)

[1]	ALBRIGHT W H, GEE G W, WILSON G V, et al. Alternative cover assessment project: Phase I report[R]. Publication No. 41183. Reno: Desert Research Institute, 2002.
[2]	HAUSER V L, WEAND B L, GILL M D. Natural covers for landfills and buried waste [J]. Journal of Environmental Engineering, 2001, 127(9): 768-775.
[3]	SCHNABEL W, LEE W, BARNES D L. A numerical simulation of evapotranspiration landfill cover performance at three cold-region locations[C]// World Water and Environmental Resources Congress. Alaska, 2005: 1-8.
[4]	刘川顺, 赵慧, 罗继武. 垃圾填埋腾发覆盖系统渗沥控制试验和数值模拟[J]. 环境科学, 2009, 30(1): 289-296. (LIU Chuan-shun, ZHAO Hui, LUO Ji-wu. Experiment and numerical simulation of percolation control using evapotranspirative landfill cover system[J]. Environmental Science, 2009, 30(1): 289-296. (in Chinese))
[5]	MCGUIRE P E, ANDRASKI B J, ARCHIBALD R E. Case study of a full-scale evapotranspiration cover[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2009, 135(3): 316-332.
[6]	ALBRIGHT W H, BENSON C H, GEE G W, et al. Field water balance of landfill final covers[J]. Journal of Environmental Quality, 2004, 33(6): 2317-2332.
[7]	詹良通, 贾官伟, 邓林恒, 等. 湿润气候区固废堆场封场土质覆盖层性状研究[J]. 岩土工程学报, 2012, 34(10): 1812-1818. (ZHAN Liang-tong, JIA Guan-wei, DENG Lin-heng, et al. Performance of earthen final covers of landfills in humid areas[J]. Chinese Journal of Geotechnical Engineering, 2012, 34(10): 1812-1818. (in Chinese))
[8]	张文杰, 邱战洪, 朱成仁, 等. 长三角地区填埋场ET封顶系统的性能评价[J]. 岩土工程学报, 2009, 31(3): 384-389. (ZHANG Wen-jie, QIU Zhan-hong, ZHU Cheng-ren, et al. Evaluation of evapotranspiration covers of landfills in Yangtze River delta region[J]. Chinese Journal of Geotechnical Engineering, 2009, 31(3): 384-389. (in Chinese))
[9]	BENSON C H, BOHNHOFF G L, OGORZALEK A S, et al. Field data and model predictions for a monolithic alternative cover[C]// Geo-Frontiers Congress. Texas, 2005: 1-16.
[10]	BOHNHOFF G L, OGORZALEK A S, BENSON C H, et al. Field Data and Water-Balance predictions for a monolithic cover in a semiarid climate[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2009, 135(3): 333-348.
[11]	SRIVASTAVA R, YEH T C J. Analytical solutions for one-dimensional, transient infiltration toward the water table in homogeneous and layered soils[J]. Water Resources Research, 1991, 27(5): 753-762.
[12]	ZHAN T L T, JIA G W, CHEN Y M, et al. An analytical solution for rainfall infiltration into an unsaturated infinite slope and its application to slope stability analysis[J]. International Journal for Numerical and Analytical Methods in Geomechanics, 2012, 37(12): 1737-1760.
[13]	李宁, 许建聪. 无限长均质斜坡降雨入渗解析解[J].岩土工程学报, 2012, 34(12): 2325-2330. (LI Ning, XU Jian-cong. Analytical solutions for rainfall infiltration into homogenous infinite slopes[J]. Chinese Journal of Geotechnical Engineering, 2012, 34(12): 2325-2330. (in Chinese))
[14]	HUANG R Q, WU L Z. Analytical solutions to 1-D horizontal and vertical water infiltration in saturated/unsaturated soil considering time-varying rainfall [J]. Computers and Geotechnics, 2012, 39: 66-72.
[15]	WU L Z, ZHANG L M. Analytical solution to 1D coupled water infiltration and deformation in unsaturated soils[J]. International Journal for Numerical and Analytical Methods in Geomechanics, 2009, 33(6): 773-790.
[16]	WU L Z, ZHANG L M, HUANG R Q. Analytical solution to 1D coupled water infiltration and deformation in two-layer unsaturated soils[J]. International Journal for Numerical and Analytical Methods in Geomechanics, 2012, 36(6): 798-816.
[17]	OZISIK M N. Boundary value problems of heat conduction [M]. New York: Dover, 2002.
[18]	OGORZALEK A S, BOHNHOFF G L, SHACKELFORD C D, et al. Comparison of field data and water-balance predictions for a capillary barrier cover[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2008, 134(4): 470-486.
