土工格栅返包土工袋加筋土挡墙的地震响应分析及设计建议

朱宏伟; 姚令侃; 陈晓龙; 项琴

doi:10.11779/CJGE201702016

土工格栅返包土工袋加筋土挡墙的地震响应分析及设计建议 English Version

1. 西南科技大学环境与资源学院,四川绵阳 621010;
2. 西南交通大学土木工程学院,四川成都 610031;
3. 四川省交通运输厅交通勘察设计研究院,四川成都 610017;
4. 四川建筑职业技术学院,四川德阳 610031

基金项目: 国家自然科学基金项目(41172321); 中国铁路总公司科技研究开发计划课题（2014G004-A-6）

详细信息

作者简介:
朱宏伟(1982- ),男,甘肃人,博士,讲师,从事岩土工程抗震方面的教学和科研工作。E-mail: zhw-1-zhw@163.com。

计量
- 文章访问数: 352
- HTML全文浏览量: 6
- PDF下载量: 368
出版历程
- 收稿日期: 2015-12-10
- 发布日期: 2017-03-24

Seismic behaviors and design recommendations of ecological bag-reinforced retaining wall

1. School of Environment and Resources, Southwest Science and Technology University, Mianyang 621010, China;
2. School of Civil Engineering, Southwest Jiaotong University, Chengdu 610031, China;
3. Sichuan Communication Surveying & Design Institute, Chengdu 610017, China;
4. Sichuan College of Architectural Technology, Deyang 618000, China

摘要

摘要: 为了研究土工袋加筋土挡墙在地震作用下的抗震性能,开展了大型的振动台模型试验。结果表明：随着加载的持续进行,挡墙模型的自振频率降低,阻尼比增加;PGA放大系数随输入地震动峰值加速度的增大而减小,墙高对PGA放大系数的影响反倒不大。土工袋加筋土挡墙的峰值动土压力呈现“中间小,两头大”的分布规律,且墙高越高,输入地震动峰值加速度越大,峰值动土压力越大,而不同地震波形的频谱差异对土压力量值和分布的影响较小。通过数值模拟研究了坡度对土工袋加筋土挡墙力学特性的影响,认为土工袋加筋土挡墙墙后侧向土压力和筋材的拉应力随着墙体坡度的增大而增大,当墙体坡度小于1∶0.75时,侧向土压力较小;当墙体坡度大于1∶0.75时,墙后土压力迅速增加,土压力的分布图式类似呈三角形分布。筋材的拉应力沿长度方向呈单峰型分布,各层筋材的拉应力随上覆填土厚度的增加而增大,但增加的幅度逐渐减小。另外,土工袋加筋土挡墙的剪应变增量、活动区范围以及位移均随墙体坡度的增大而增大。
- 土工袋加筋土挡墙 /
- 抗震性能 /
- 墙体坡度 /
- 力学特性 /
- 设计建议
Abstract: In order to study the earthquake seismic behaviors of ecological bags-reinforced wall, the large-scale shaking table model tests are performed. It is shown that the frequency decreases and the damping ratio increases with the increase of external loading. The PGA amplification factor decreases with the increase of earthquake magnitude, and the wall height has little effect. The distribution of horizontal peak dynamic soil pressures along height is of large value at both ends and small value at the middle for the ecological bag-reinforced wall, and the peak dynamic earth pressures increase as the PGA and wall height increase, the effect of frequency content characteristics of ground motions on the amount and distribution of peak dynamic earth pressures is little. The effect of slope rate on mechanical characteristics of ecological bag-reinforced wall is studied through numerical simulation. The results show that the lateral soil pressures and tensile stresses of the tied reinforcement increase with the increasing slope rate. When the slope rate is less than 1∶0.75, the lateral soil pressures increase a little, while it is greater than 1∶0.75, the lateral soil pressure increase quickly and are triangular-distributed approximately. The tensile stress of the tied reinforcement is unimodal distribution along the length, and increases with the increase of backfill depth. Moreover, the shear stress increment, sliding range and displacement increase with the increasing slope rate.
- ecological bag-reinforced wall /
- seismic behavior /
- slope rate /
- mechanical characteristic /
- design recommendation

HTML全文

参考文献(16)

[1]	周德培, 张峻云. 植被护坡工程技术[M]. 北京: 人民交通出版社, 2003. (ZHOU De-pei, ZHANG Jun-yun. Bio-geotechnical technology of vegetation[M]. Beijing: China Communications Press, 2003. (in Chinese))
[2]	王维, 黄向京. 加筋格宾结构分析理论与工程应用新技术[M]. 北京: 人民交通出版社, 2011. (WANG Wei, HUANG Xiang-jing. Analysis theory and engineering application technology of reinforced gabion structures[M]. Beijing: China Communications Press, 2011. (in Chinese))
[3]	MATSUOKA H, LIU Si-hong. A new earth reinforcement method using soilbags[M]. London: Taylor & Francis Group, 2006.
[4]	段晓明, 苗增健, 刘连新, 等. 生态护坡应用及护坡植物群落的选择[J]. 安徽农业科学, 2009, 37(31): 15327-15329. (DUAN Xiao-ming, MIAO Zeng-jian, LIU Lian-xin, et al. Ecological application of ecological slope protection and vegetation community selection for slope production [J]. Journal of Anhui Agriculture Science, 2009, 37(31): 15327-15329. (in Chinese))
[5]	刘斯宏, 王艳巧,金远征. 土工袋基础减震隔振试验[J]. 水利水电科技进展, 2012, 32(1): 87-90. (LIU Si-hong, WANG Yan-qiao, JIN Yuan-zheng. Experimental study on vibration reduction and isolation of bases with soilbags[J]. Advances in Science and Technology of Water Resources, 2012, 32(1): 87-90. (in Chinese))
[6]	刘斯宏, 李玲君, 张雨灼. 土工袋挡土墙小型振动台试验[J]. 河海大学学报(自然科学版), 2015, 43(3): 236-243. (LIU Si-hong, LI Lin-jun, ZHANG Yu-zhuo. Small-scale shaking table tests on retaining wall constructed with soilbags[J]. Journal of Hohai University (Natural Sciences), 2012, 43(3): 236-243. (in Chinese))
[7]	王艳巧, 刘斯宏, 林圣德, 等. 土工袋减震效果振动台试验研究[J]. 水电能源科学, 2011, 29(9): 100-103. (WANG Yan-qiao, LIU Si-hong, LIN Sheng-de, et al. Vibrating platform test study of vibration reduction effect of soil bag [J]. Water Resources and Power, 2011, 29(9): 100-103. (in Chinese))
[8]	朱宏伟, 姚令侃, 刘兆生. 地震作用下柔性挡墙的变形特征分析[J]. 岩石力学与工程学报, 2012, 31(增刊1): 2829-2838. (ZHU Hong-wei, YAO Ling-kan, LIU Zhao-sheng. Research on seismic deformation characteristics of flexible wall[J]. Chinese Journal of Rock Mechanics and Engineering, 2012, 31(S1): 2829-2838. (in Chinese))
[9]	朱宏伟, 姚令侃, 张绪海. 两种加筋土挡墙的动力特性比较及抗震设计建议[J]. 岩土工程学报, 2012, 34(11): 2072-2080. (ZHU Hong-wei, YAO Ling-kan, ZHANG Xu-hai. Comparison of dynamic characteristics between netted and packaged reinforced soil retaining walls and recommendations for seismic design[J]. Chinese Journal of Geotechnical Engineering, 2012, 34(11): 2072-2080. (in Chinese))
[10]	刘泽, 史克友, 雷勇. 重复荷载作用下土工格栅包生态袋加筋土挡墙动力特性试验研究[J]. 振动与冲击, 2015, 34(9): 88-94. (LIU Ze, SHI Ke-you, LEI Yong. Model test on dynamic characteristics of geogrid reinforced earth retaining wall packet ecological bag under repeated loading[J]. Journal of Vibration and Shock, 2015, 34(9): 88-94. (in Chinese))
[11]	GB50011—2006铁路工程抗震设计规范[S]. 2006. (GB50011—2006 Code for seismic design of railway engineering[S]. 2006. (in Chinese))
[12]	JTG/T B02—01—2008 公路桥梁抗震设计细则[S]. 2008. (JTG /T B02—01—2008 Guide lines for seismic design of highway bridges[S]. 2008. (in Chinese))
[13]	蒋良潍, 姚令侃, 王建. 基于振动性态和破坏相似的边坡振动台模型实验相似律[J]. 交通科学与工程, 2009, 25(2): 1-7. (JIANG Liang-wei, YAO Ling-kan, WANG Jian. Similitude for shaking table model test on side slope relating to dynamic characteristics and strength[J]. Journal of Transport Science and Engineering, 2009, 25(2): 1-7. (in Chinese))
[14]	张建经, 冯君, 肖世国. 支挡结构抗震设计中的2个关键技术问题[J]. 西南交通大学学报, 2009, 44(6): 321-325. (ZHANG Jian-jing, FENG Jun, XIAO Shi-guo. Discussions on two key technical problems for seismic design of retaining wall[J]. Journal of Southwest Jiaotong University, 2009, 44(6): 321-325. (in Chinese))
[15]	汪闻韶, 金崇磐, 王克成. 土石坝的抗震计算和模型实验及原型观测[J]. 水利学报, 1987(12): 1-16. (WANG Wen-shao, JIN Chong-pan, WANG Ke-cheng. Earthquake resistance computation and model test of earth-rock dam and its prototype observation[J]. Journal of Hydraulic Engineering, 1987(12): 1-16. (in Chinese))
[16]	朱宏伟, 姚令侃, 蒋良潍. 考虑变形影响的重力式挡墙地震土压力分布[J]. 岩土工程学报, 2013, 35(6): 1035-1044. (ZHU Hong-wei, YAO Ling-kan, JIANG Liang-wei. Distribution of seismic earth pressure on gravity retaining walls considering influence of deformation[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(6): 1035-1044. (in Chinese))
