非饱和导排结构控制降雨入渗的边坡物理模型试验

吴庆华, 张家发, 武金博, 刘习银

吴庆华, 张家发, 武金博, 刘习银. 非饱和导排结构控制降雨入渗的边坡物理模型试验[J]. 岩土工程学报, 2017, 39(1): 154-160. DOI: 10.11779/CJGE201701014
引用本文: 吴庆华, 张家发, 武金博, 刘习银. 非饱和导排结构控制降雨入渗的边坡物理模型试验[J]. 岩土工程学报, 2017, 39(1): 154-160. DOI: 10.11779/CJGE201701014
shu
WU Qing-hua, ZHANG Jia-fa, WU jin-bo, LIU Xi-yin. Physical model tests on slopes with control of infiltration by unsaturated drainage structures[J]. Chinese Journal of Geotechnical Engineering, 2017, 39(1): 154-160. DOI: 10.11779/CJGE201701014
Citation: WU Qing-hua, ZHANG Jia-fa, WU jin-bo, LIU Xi-yin. Physical model tests on slopes with control of infiltration by unsaturated drainage structures[J]. Chinese Journal of Geotechnical Engineering, 2017, 39(1): 154-160. DOI: 10.11779/CJGE201701014
shu

非饱和导排结构控制降雨入渗的边坡物理模型试验  English Version

  • 1.长江科学院水利部岩土力学与工程重点实验室,湖北 武汉 430010；
    2. 中国地质调查局河北省地下水污染机理与修复重点实验室,河北 石家庄050061；
    3. 中国地质大学教育部长江三峡库区地质灾害研究中心,湖北 武汉 430074；
    4. 中交第二公路勘察设计研究院有限公司,湖北 武汉 430056

基金项目: 中国地质科学院水文地质环境地质研究所开放性基金项目（KF201508）; 中国地质大学教育部长江三峡库区地质灾害研究中心开放性基金项目（TGRC201403）; 国家自然科学基金项目（41402213,51279016）; 国家“十二五”科技支撑计划（2011BAB10B04）
详细信息
    作者简介:

    吴庆华(1981- ),男,湖北监利人,博士,高级工程师,主要从事岩土非饱和渗流研究。E-mail: wqh0505@126.com。

Physical model tests on slopes with control of infiltration by unsaturated drainage structures

  • 1. Key Laboratory of Geotechnical Mechanics and Engineering of Ministry of Water Resources, Changjiang River Scientific Research Institute, Wuhan 430010, China;
    2. Key Laboratory of Groundwater Contamination and Remediation, China Geological Survey (CGS) & Hebei Province, Shijiazhuang 050061, China;
    3. Three Gorges Research Center for geo-hazard, Ministry of Education, China University of Geosciences, Wuhan 430074, China.;
    4. CCCC Second Highway Consultant Co. Ltd., Wuhan 430056, China

摘要

    摘要
  • 摘要: 膨胀土渠坡失稳是影响南水北调中线供水工程安全性的重要因素之一,而对其边坡进行防渗处理是解决膨胀土边坡失稳的有效途径。针对传统边坡防渗处理方法（面板与土工布覆盖等）存在生态功能弱以及使用寿命短等不足,开展了非饱和导排结构的边坡防渗效果的物理模型试验研究。利用土壤剖面负压动态监测数据,采用非饱和渗流理论,在不同降雨强度与不同初始含水量条件下,对比分析了两种非饱和导排结构即细/粗粒二元结构和粗粒单一结构,控制降雨入渗边坡的效果。研究结果表明：在降雨强度为4.18×10-4 cm/s的情况下,二元结构能有效阻止降雨入渗;且细粒层初始含水量越低,其储水能力越强,二元结构控制降雨入渗的效果相对越好。在降雨强度为1.72×10-4,4.18×10-4,4.97×10-4 cm/s的情况下,粗粒层单一结构对降雨入渗边坡均具有一定的控制作用,但有5.6%~10.7%的降雨从模型底部排出,存在入渗风险。总体上,从排水-渗流控制效果与生态功能角度考虑,二元结构明显优于单一结构。研究成果可为解决南水北调膨胀土边坡以及其它工程边坡的渗流控制问题提供技术支撑。
    Abstract: The instability of expansive soil slope is vital to the security of water supply in the Middle Route project of South-to-North Water Diversion. Anti-seepage control is considered as an effective method to deal with the instability problem of expansive soil slope. Based on the weak ecological function and short life of the traditional methods to deal with the drainage-seepage phenomenon of slopes, the unsaturated drainage structures are introduced to control rainfall to infiltrate into slope soil. Then two unsaturated drainage structures, i.e., fine/coarse grain soil layers (dual-structure) and coarse layer (single-structure) are chosen. The anti-seepage effects of the both structures on the slope in five rainfall tests are investigated. The results show that: (1) The dual-structure can effectively prevent rainfall from infiltrating into the slope, without leakage at the bottom of the expansive soil in the experiment with rainfall intensity of 4.18×10-4 cm/s. When the initial soil water content of the fine grain layer is lower with a strong storage capacity, the anti-seepage effect is better. (2) The single-structure can protect the expansive soil slope at a certain extent, with the rainfall intensity of 1.72×10-4, 4.18×10-4 and 4.97×10-4 cm/s, however, 5.6%~10.7% of the total rainfall flows out at the bottom of the expansive soil, which indicates the single-structure leakage risk. In a word, the anti-seepage effects of the dual-structure on the slope are better than those of the single-structure. This study is helpful to dealing with the expansive soil slope in the Middle Route project of South-to-North Water Diversion.
    • HTML全文
    • 参考文献(13)
  • [1] 郭熙灵, 李青云, 程展林, 等. 南水北调中线工程若干土力学问题研究[J]. 南水北调与水利科技, 2008, 16(1): 35-37. (GUO Xi-ling, LI Qing-yun, CHENG Zhang-lin, et al. Geotechnical research in the middle route of south-to-north water transfer project[J]. South-to-North Water Transfers and Water Sience & Technology, 2008, 16(1): 35-37. (in Chinese))
    [2] YANG H, RAHARDJO H, LEONG E C, et al. A study of infiltration on three sand capillary barriers[J]. Can Geotech J, 2004, 41(4): 629-643.
    [3] KÄMPF M, HOLFELDER T, MONTENEGRO H. Identification and parameterization of flow processes in artificial capillary barriers[J]. Water Resour Res, 2003, 39(10): 21-29.
    [4] TIDWELL V, GLASS R, CHOCAS C, et al. Visualization experiment to investigate capillary barrier performance in the context of a yucca mountain emplacement drift[J]. Journal of Contaminant Hydrology, 2003, 62/63: 287-301.
    [5] TAMI D, RAHARDJO H, LEONG E-C, et al. A physical model for sloping capillary barriers[J]. Geotechnical Testing Journal, 2004, 27(32): GTJ11431-272.
    [6] ABDOLAHZADEH A M, LACROIX Vachon B, CABRAL A R. Assessment of the design of an experimental cover with capillary barrier effect using 4 years of field data[J]. Geotechnical & Geological Engineering, 2011, 29: 783-802.
    [7] AUBERTIN M, CIFUENTES E, APITHY S A, et al. Analyses of water diversion along inclined covers with capillary barrier effects[J]. Can Geotech J, 2009, 46(10): 1146-1164.
    [8] PARENT S-É, CABRAL A. Design of inclined covers with capillary barrier effect[J]. Geotechnical & Geological Engineering, 2006, 24(3): 689-710.
    [9] 张家发, 刘晓明, 焦赳赳. 膨胀土渠坡兼有排水功能的双层结构防护方案[J]. 长江科学院院报, 2009, 26(11): 37-41. (ZHANG Jia-fa, LIU Xiao-ming, JIAO Jiu-jiu. A protection scheme of double layers with drainage function for expansive soil slopes by canal[J]. Journal of Yangtze River Scientific Research Institute, 2009, 26(11): 37-41. (in Chinese))
    [10] QIAN T W, HUO L J, ZHAO D Y. Laboratory investigation into factors affecting performance of capillary barrier system in unsaturated soil[J]. Water Air Soil Pollut, 2010, 206: 295-306.
    [11] 邓林恒, 詹良通, 陈云敏, 等. 含非饱和导排层的毛细阻滞型覆盖层性能模型试验研究[J]. 岩土工程学报, 2012, 34(1): 75-80. (DENG Ling-hen, ZHANG Liang-tong, CHEN Yun-min, et al. Model tests on capillary-barrier cover with unsaturated drainage layer[J]. Chinese Journal of Geotechnical Engineering, 2012, 34(1): 75-80. (in Chinese))
    [12] WU Qing-hua, ZHANG J F, ZHU G S, et al. Laboratory study on drainage and seepage controlling of fine-coarse structure in unsaturated expansive soil slope[C]// 6th Asia-Pacific Conference on Unsaturated Soils. Guilin, 2015.
    [13] STORMONT J C, ANDERSON C E. Capillary barrier effect from underlying coarse soil layer[J]. Journal of Geotechnical and Geo-environmental Engineering, ASCE, 1999, 125(8): 641-648.
