季冻区典型土类动剪切模量阻尼比计算方法

孙锐; 于啸波; 袁晓铭; 孟上九; 陈卓识; 王淼

doi:10.11779/CJGE201701010

季冻区典型土类动剪切模量阻尼比计算方法 English Version

孙锐¹,
于啸波¹,
袁晓铭^1,,
孟上九^{1, 2},
陈卓识¹,
王淼¹

1. 中国地震局工程力学研究所地震工程与工程振动重点实验室,黑龙江哈尔滨 150080；
2. 哈尔滨理工大学,黑龙江哈尔滨 150080

基金项目: 中央级公益性研究所基本科研业务费专项项目（2016A02）; 国家自然科学基金项目（51378164）; 地震行业专项项目（201408020-03）

详细信息

作者简介:
孙锐（1972- ）,女,研究员,博士生导师,主要从事岩土工程和地震工程研究。E-mail: iemsr@163.com。

计量
- 文章访问数: 467
- HTML全文浏览量: 2
- PDF下载量: 331
出版历程
- 收稿日期: 2015-11-02
- 发布日期: 2017-01-24

Method for dynamic shear moduli and damping ratio of typical soils in seasonal frozen region

1. Key Laboratory of Earthquake Engineering and Engineering Vibration, Institute of Engineering Mechanics, China Earthquake Administration, Harbin 150080, China;
2. Harbin University of Science and Technology, Harbin 150080, China

摘要

摘要: 采用专门设计的低温共振柱仪进行试验研究,研究典型土类动剪切模量阻尼比随负温的变化规律及计算方法。提出温度影响系数的概念,并以较为符合实际的固结压力和冻结过程,完成了黏土、粉土与砂土在常温及不同负温下的动力试验,给出了这3种典型土类不同负温下初始剪切模量、剪切模量比和阻尼比的计算公式。结果表明：无论何种土类,负温对其初始剪切模量、剪切模量比和阻尼比都有重要影响,相应的温度修正系数按Boltzmann与指数函数变化,均在0℃到-6.0℃快速变化之后趋于平缓,但变化程度和修正公式中的参数均与土类有关;随温度降低,3种土类初始剪切模量增长十分显著,完全冻结黏土、粉土和砂土分别为常温土初始模量的50倍、25倍和13倍;随温度降低,3种土类参考剪应变降低十分显著,但完全冻结后3种土的动剪切模量降低程度接近;随温度下降,3种土类最大阻尼比均显著减小,完全冻结后的黏土最大阻尼比降幅最大,砂土降幅最小,粉土居中。3种典型土类负温下动剪切模量阻尼比修正公式,其反映的现象和规律与国际上近期成果定性相符。
- 典型土类 /
- 季冻土 /
- 动剪切模量 /
- 阻尼比 /
- 低温共振柱仪 /
- 温度修正系数
Abstract: Using specially designed low-temperature resonant column apparatus, change rules of dynamic shear moduli and damping ratio with negative temperature and their computational methods for three soils are investigated. Concepts of temperature correction coeffecient are proposed, and dynamic tests on clayey, silty and sandy soils under room and negative temperatures are conducted based on actual consolidation pressure and freezing process. The formulae under different negative temperatures for the initial shear modulus, shear modulus and damping ratio of the soils are also proposed. The results indicate that, for each type of soil, the negative temperature has significant impact on the initial shear modulus, shear modulus and damping ratio, while the corresponding temperature correction coefficient changes according to the combinatorial functions of Boltzmann and exponent. The change becomes gentle after rapid change from 0℃ to -6℃, and the degree of change and parameters fitting the functions are related to soil type. With the decrease in temperature, the initial moduli of three soil types increase very significantly. The completely frozen samples of clayey, silty and sandy soils gain 50, 25 and 13 times the initial shear modulus at room temperature respectively. The reference shear strain remarkably falls with the deceasing temperature, and all these soil dynamic shear moduli have simultaneous attenuation after completely frozen. The maximum damping ratio of the 3 soil types decreases distinctly at the lowering temperature, and to the magnitude of decreasing, the sand is the minimum, the clay is the maximum, and the silt is the intermediate. The proposed correction formulae for dynamic shear moduli and damping ratio of 3 typical soils are qualitatively consistent with recent achievements in the world on the physical laws and phenomena.
- typical soil /
- seasonal frozen ground /
- dynamic shear modulus /
- damping ratio /
- low temperature resonant column apparatus /
- temperature correction coefficient

HTML全文

参考文献(20)

[1]	马巍, 王大雁. 中国冻土力学研究50 a回顾与展望[J]. 岩土工程学报, 2012, 34(4): 625-640. (MA Wei, WANG Da-yan. Studies on frozen soil mechanics in China in past 50 years and their prospect[J]. Chinese Journal of Geotechnical Engineering, 2012, 34(4): 625-640. (in Chinese))
[2]	陈龙伟, 袁晓铭, 孙锐. 2011年新西兰Mw6.3地震液化及岩土震害评述[J]. 世界地震工程, 2013, 29(3): 1-9. (CHEN Long-wei, YUAN Xiao-ming, SUN Rui. Review of liquefaction phenomena and geotechnical damage in the 2011 New Zealand Mw6.3 earthquake[J]. World Earthquake Engineering, 2013, 29(3): 1-9. (in Chinese))
[3]	陈卓识, 孟上九, 袁晓铭. 中等强度地震下季冻区场地响应影响研究[J]. 土木工程学报, 2013, 46(增刊1): 166-171. (CHEN Zhuo-shi, MENG Shang-jiu, YUAN Xiao-ming. The impact of parameters in seasonal frozen area response under moderate intensity earthquake[J]. China Civil Engineering Journal, 2013, 46(S1): 166-171. (in Chinese))
[4]	徐学燕, 仲丛利, 陈亚明, 等. 冻土的动力特性研究及其参数确定[J]. 岩土工程学报, 1998, 20(5): 77-81. (XU Xue-yan, ZHONG Cong-li, CHEN Ya-ming, et al. Research on dynamic characters of frozen soil and determination of its parameters[J]. Chinese Journal of Geotechnical Engineering, 1998, 20(5): 77-81. (in Chinese))
[5]	XIONG Feng, YANG Zhao-hui, XU Gang. Seasonally frozen soil effects on the dynamic behavior of building structures[C]// 14th World Conference on Earthquake Engineering. Beijing, 2008.
[6]	袁晓铭, 孙锐, 孙静, 等. 常规土类动剪切模量比和阻尼比试验研究[J]. 地震工程与工程振动, 2000, 20(4): 133-139. (YUAN Xiao-ming, SUN Rui, SUN Jing, et al. Laboratory experimental study on dynamic shear modulus ratio and damping ratio of soils[J]. Earthquake Engineering and Engineering Vibration, 2000, 20(4): 133-139. (in Chinese))
[7]	陈国兴, 谢君斐, 张克绪. 土的动模量和阻尼比的经验估计[J]. 地震工程与工程振动, 1995, 15(1): 73-83. (CHEN Guo-xing, XIE Jun-fei, ZHANG Ke-xu. The empirical evaluation of soil moduli and damping ratio for dynamic analysis[J]. Earthquake Engineering and Engineering Vibration, 1995, 15(1): 73-83. (in Chinese))
[8]	孙静, 袁晓铭. 土的动模量和阻尼比研究述评[J]. 世界地震工程, 2003, 19(1): 88-95. (SUN Jing, YUAN Xiao-ming. A state of art of research on dynamic modulus and damping ratio of soils[J]. World Earthquake Engineering, 2003, 19(1): 88-95. (in Chinese))
[9]	徐学燕, 仲丛利. 冻土动弹模、动泊桑比的确定[J]. 哈尔滨建筑大学学报, 1997, 30(4): 23-28. (XU Xue-yan, ZHONG Cong-li. The determination of dynamic elastic modulus and dynamic poisson's ratio of frozen soil[J]. Journal of Harbin University of CE & Architecture, 1997, 30(4): 23-28. (in Chinese))
[10]	齐吉琳, 马巍, 孙崇绍, 等. 张掖地区季节冻土场地上的地震动效应[J]. 岩石力学与工程学报, 2005, 24(12): 2082-2088. (QI Ji-ling, MA Wei, SUN Chong-shao, et al. Seismic response analysis of seasonally frozen ground of Zhangye area[J]. Chinese Journal of Rock Mechanics and Engineering, 2005, 24(12): 2082-2088. (in Chinese))
[11]	朱占元. 青藏铁路列车行驶多年冻土场地路基振动反应与振陷预测[D]. 哈尔滨: 哈尔滨工业大学, 2009: 26-40. (ZHU Zhan-yuan. Train-induced vibration response and subsidence prediction of permafrost subgrade along Qinghai-Tibet railway[D]. Harbin: Harbin Institute of Technology, 2009: 26-40. (in Chinese))
[12]	张锋. 深季节冻土区重载汽车荷载下路基动力响应与永久变形[D]. 哈尔滨: 哈尔滨工业大学, 2012: 31-58. (ZHANG Feng. Dynamic response and permanent of subgrade influenced by heavy truck load in deep seasonally frozen region[D]. Harbin: Harbin Institute of Technology, 2012: 31-58. (in Chinese))
[13]	SHAN Wei, JIANG Hua, HU Zhao-guang, et al. Island permafrost degrading process and deformation characteristics of expressway widen subgrade foundation[J]. Disaster Advances, 2012, 5(4): 1291-1296.
[14]	AL-HUNAIDI M O, CHEN P A, RAINER J H, et al. Shear moduli and damping in frozen and unfrozen clay by resonant column test[J]. Canadian Geotechnical Journal, 1996, 33: 510-514.
[15]	GB/T50123—1999土工试验方法标准[S]. 1999. (GB/T50123—1999 Standard of soil test method[S]. 1999. (in Chinese))
[16]	迟世春, 陈崇茂, 贾宇峰. 心墙土料的动力参考剪应变[J]. 水力发电学报, 2013, 32(2): 223-227. (CHI Shi-chun, CHEN Chong-mao, JIA Yu-feng. Dynamic reference shear strain for core wall materials in earth dams[J]. Journal of Hydroelectric Engineering, 2013, 32(2): 223-227. (in Chinese))
[17]	何平, 朱元林, 张家懿, 等. 饱和冻结粉土的动弹模与动强度[J]. 冰川冻土, 1993, 15(1): 170-174. (HE Ping, ZHU Yuan-lin, ZHANG Jia-yi, et al. Dynamic elastic modulus and dynamic strength of saturated frozen silt[J]. Journal of Glaciology and Geocryology, 1993, 15(1): 170-174. (in Chinese))
[18]	罗飞, 赵淑萍, 马巍, 等. 分级加载下冻土动弹性模量的试验研究[J]. 岩土工程学报, 2013, 35(5): 849-855. (LUO Fei, ZHAO Shu-ping, MA Wei, et al. Experimental study on dynamic elastic modulus of frozen soils under stepped axial cyclic loading[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(5): 849-855. (in Chinese))
[19]	吴志坚, 王兰民, 马巍. 地震荷载作用下冻土的动力学参数试验研究[J]. 西北地震学报, 2003, 25(3): 210-214. (WU Zhi-jian, WANG Lan-ming, MA Wei. Laboratory study on dynamics parameters of frozen soil under seismic dynamic loading[J]. Northwestern Seismological Journal, 2003, 25(3): 210-214. (in Chinese))
[20]	SIMONSEN E, JANOO V, ISACSSON U. Resilient Properties of Unbound Road Materials during Seasonal Frost Conditions[J]. Journal of Cold Regions Engineering, 2002, 16(1): 28-50.
