荷载频率对动模量阻尼比影响的试验研究

李瑞山; 陈龙伟; 袁晓铭; 李程程

doi:10.11779/CJGE201701005

荷载频率对动模量阻尼比影响的试验研究 English Version

中国地震局工程力学研究所中国地震局地震工程与工程振动重点实验室,黑龙江哈尔滨 150080

详细信息

作者简介:
李瑞山(1987- ),男,博士,助理研究员,主要从事岩土地震工程研究。E-mail: lrshan22@hotmail.com。

计量
- 文章访问数: 0417
- HTML全文浏览量: 0
- PDF下载量: 0450
出版历程
- 发布日期: 2017-01-24

Experimental study on influences of different loading frequencies on dynamic modulus and damping ratio

Key Laboratory of Earthquake Engineering and Engineering Vibration of China Earthquake Administration; Institute of Engineering Mechanics, China Earthquake Administration, Harbin 150080, China

摘要

摘要: 目前荷载频率对动模量阻尼比影响规律尚无较为统一认识,定量结果尚少。采用新型高精度动三轴仪试验,研究不同荷载频率对典型砂土和黏土动模量阻尼比影响问题,并以此为基础从对地震动影响角度讨论考虑荷载频率相关动模量阻尼比必要性。结果表明：对砂土而言,荷载频率对其动剪切模量影响不大,随着加载频率的增大,阻尼比略有减小,但差别基本可以忽略;对黏土而言,荷载频率对其动剪切模量和阻尼比有重要影响,随着振动频率的增加,动剪切模量增大,阻尼比减小;黏土参考剪应变随荷载频率增大而增大,二者呈递增的指数函数,当f≤1 Hz时,影响十分明显,当1 Hz <f ≤3 Hz时,有一定影响,当f > 3Hz时,影响不明显;黏土最大阻尼比随频率的增大而减小,二者呈递减的指数函数,当f ≤10 Hz时,影响较为明显,当f > 10 Hz时,影响程度显著减弱;采用两组频率下模量阻尼比曲线计算黏土层地震动,地表加速度峰值和反应谱差别很大,且随着震动增强而显著增大,说明考虑黏土层动模量阻尼比的荷载频率相关性是十分必要的。
- 荷载频率 /
- 剪切模量 /
- 阻尼比 /
- 地震反应分析
Abstract: There is not a consistent conclusion on the influences of loading frequency on dynamic modulus and damping ratio, and the quantitative results are few. Through a series of tests using the new cyclic triaxial (CT) divice with high precision, the main objective of which is to evaluate the influences of excitation frequency on the shear modulus and damping ratio of typical sand and clay samples are studied. The necessity of considering the frequency-dependent modulus and damping ratio is discussed from the perspective of ground motion on the basis of the tests. The results show that: (1) For the sand, the shear modulus is almost independent of the loading frequency. The damping ratio slightly decreases due to the increase of vibration frequency, but the deviations can be ignored. (2) For the clay soil, the loading frequency has significant influences on its shear modulus and damping ratio. The shear modulus increases, but the damping ratio decreases with the increase of the loading frequency. (3) The CT tests indicate measurable growth in the reference shear strain γ_r with the loading frequency in the form of an increasing exponential function. The dynamic properties are very sensitive to the excitation frequency when f ≤ 1 Hz. In the range of 1 Hz <f ≤ 3 Hz, the influences are clear. When the frequency exceeds the upper band of 3 Hz, the shape is nearly on the same level. (4) The maximum damping ratio D_max decreases with the vibration frequency in a form of exponential function. When the frequency is lower than 10 Hz, the influences are obvious. If f>10 Hz, the influences gradually vanish. (5) The ground motion of a simplified ideal clay site is calculated using two sets of shear modulus and damping ratio curves under two different test loading frequencies, 0.1 Hz and 3 Hz. The peak ground accelerations and the response spectra show serious dissimilarities, which are increasingly severe as the intensity of ground shaking is enhanced. This study therefore demonstrates that considering the frequency correlation of shear modulus and damping ratio is of extreme necessity.
- loading frequency /
- shear modulus /
- damping ratio /
- seismic response analysis

HTML全文

参考文献(24)

[1]	袁晓铭, 孙锐, 孙静, 等.常规土类动剪切模量比和阻尼比试验研究[J]. 地震工程与工程振动, 2000, 20(4): 133-140. (YUAN Xiao-ming, SUN Rui, SUN Jing, et al. Laboratory experimental study on dynamic shear modulus ratio and damping ratio of soils[J]. Earthquake Engineering and Engineering Vibration, 2000, 20(4): 133-140. (in Chinese))
[2]	孙静, 袁晓铭. 土的动模量和阻尼比研究述评[J]. 世界地震工程, 2003, 19(1): 88-95. (SUN Jing, YUAN Xiao-ming. A state-of-art of research on dynamic modulus and damping ratio of soils[J]. World Earthquake Engineering, 2003, 19(1): 88-95. (in Chinese))
[3]	SHNABEL P B, LYSMER J, SEED H B. SHAKE: a computer program for earthquake response analysis of horizontal layer sites[R]. Berkeley: University of California, 1972.
[4]	SEED H B, IDRISS I M. Soil moduli and damping factors for dynamic response analysis[R]. Report No. EERC-70-10, Berkeley: University of California, 1970.
[5]	YOSHIDA N, KOBAYASHI S, SUETOMI I, et al. Equivalent linear method considering frequency dependent characteristics of stiffness and damping[J]. Soil Dynamics and Earthquake Engineering, 2002, 22(3): 205-222.
[6]	ASSIMAKI D, KAUSEL E. An equivalent linear algorithm with frequency and pressure-dependent moduli and damping for the seismic analysis of deep sites[J]. Soil Dynamics and Earthquake Engineering, 2002, 22(9-12): 959-965.
[7]	蒋通, 邢海灵. 水平土层地震反应分析考虑频率相关性的等效线性化方法[J]. 岩土工程学报, 2007, 29(2): 218-224. (JIANG Tong, XING Hai-ling. An equivalent linear method considering frequency-dependent soil properties for seismic response analysis[J]. Chinese Journal of Geo- technical Engineering, 2007, 29(2): 218-224. (in Chinese))
[8]	BOLTON M D, WILSON J M R. An experimental and theoretical comparison between static and dynamic torsional soil tests[J]. Géotechnique, 1989, 39(4): 585-599.
[9]	IWASAKI T, TATSUOKA F, TAKAGI Y. Shear modulus of sands under cyclic torsional shear loading[J]. Soils and Foundations, 1978, 18(1): 39-56.
[10]	张建民, 王稳祥. 振动频率对饱和砂土动力特性的影响[J]. 岩土工程学报, 1990, 12(1): 89-97. (ZHANG Jian-min, WANG Wen-xiang. Effect of vibration frequency on dynamic properties of saturated sandy soil[J]. Chinese Journal of Geotechnical Engineering, 1990, 12(1): 89-97. (in Chinese))
[11]	WICHTMANN T, NIEMUNIS A, TRIANTAFYLLIDIS T. Strain accumulation in sand due to cyclic loading: drained triaxial tests[J]. Soil Dynamics and Earthquake Engineering, 2005, 25(12): 967-979.
[12]	YASUHARA K, YAMANOUCHI T, HIRAO K. Cyclic strength and deformation of normally consolidated clay[J]. Soils and Foundations, 1982, 22(3): 77-91.
[13]	TEACHAVORASINSKUN S, THONGCHIM P, et al. Shear modulus and damping of soft Bangkok clays[J]. Canadian Geotechnical Journal, 2002, 39(5): 1201-1208.
[14]	何昌荣. 动模量和阻尼的动三轴试验研究[J]. 岩土工程学报, 1997, 19(2): 39-48. (HE Chang-rong. Dynamic triaxial test on modulus and damping[J]. Chinese Journal of Geotechnical Engineering, 1997, 19(2): 39-48. (in Chinese))
[15]	MATEŠIĆ L, VUCETIC M. Strain-rate effect on soil secant shear modulus at small cyclic strains[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2003, 129(6): 536-549.
[16]	陈存礼, 胡再强. 强夯地基黄土的动力特性参数及其与振动频率的关系[J]. 西安理工大学学报,1998, 14(2): 216-220. (CHEN Cun-li, HU Zai-qiang. Dynamic characteristics parameters and their relation to vibrofrequency of dynamically-compacted foundation loess[J]. Journal of Xi'an University of Technology, 1998, 14(2): 216-220. (in Chinese))
[17]	王建荣, 张振中, 王峻, 等. 振动频率对原状黄土动本构关系的影响[J]. 西北地震学报, 1999, 21(3): 310-314. (WANG Jian-rong, ZHANG Zhen-zhong, WANG Jun, et al. Effect of vibration frequency on dynamic constitutive relationship of loess[J]. Northwestern Seismological Journal, 1999, 21(3): 310-314. (in Chinese))
[18]	徐学燕, 仲丛利, 陈亚明, 等. 冻土的动力特性研究及其参数确定[J]. 岩土工程学报, 1998, 20(5): 77-81. (XU Xue-yan, ZHONG Cun-li, CHEN Ya-ming, et al. Research on dynamic characters of frozen soil and determination of its parameters[J]. Chinese Journal of Geotechnical Engineering, 1998, 20(5): 77-81. (in Chinese))
[19]	张茹, 涂扬举, 费文平, 等. 振动频率对饱和黏性土动力特性的影响[J]. 岩土力学, 2006, 27(5): 699-704. (ZHANG Ru, TU Yang-ju, FEI Wen-ping, et al. Effect of vibration frequency on dynamic properties of saturated cohesive soil[J]. Rock and Soil Mechanics, 2006, 27(5): 699-704. (in Chinese))
[20]	郑刚, 霍海峰, 雷华阳, 等. 振动频率对饱和黏土动力特性的影响[J]. 天津大学学报(科学技术版), 2013, 46(1): 38-43. (ZHENG Gang, HUO Hai-feng, LEI Hua-yang, et al. Contrastive study on the dynamic characteristics of saturated clay in different vibration frequencies[J]. Journal of Tianjin University (Science and Technology), 2013, 46(1): 38-43. (in Chinese))
[21]	黎冰, 高玉峰, 丰土根. 振动频率对LCES动力特性的影响分析及其机理初探[J]. 岩土力学, 2008, 29(10): 2731-2734, 2740. (LI Bing, GAO Yu-feng, FENG Tu-gen. Cyclic loading frequency effect and mechanism of lightweight clay-EPS beads soil[J]. Rock and Soil Mechanics, 2008, 29(10): 2731-2734, 2740. (in Chinese))
[22]	D’ONOFRIO A, SILVESTRI F, VINALE F. Strain rate dependent behaviour of a natural stiff clay[J]. Soils and Foundations, 1999, 39(2): 69-82.
[23]	SHIBUYA S, MITACHI T, FUKUDA F, et al. Strain-rate effects on shear modulus and damping of normally consolidated clay[J]. Geotechnical Testing Journal, 1995, 18(3): 365-375.
[24]	KHAN Z, NAGGAR M H E, CASCANTE G. Frequency dependent dynamic properties from resonant column and cyclic triaxial tests[J]. Journal of the Franklin Institute, 2011, 348(7): 1363-1376.
