Quantitative analysis of influencing factors of subgrade service depth of civil airport runway
-
摘要: 借助有限元数值分析方法求解了飞机荷载作用附加应力在民用机场场道土基分布的边值问题,在此基础上定量地研究了飞机荷载类型、刚性道面厚度、土基回弹模量以及工作区不同定义标准对工作区深度的影响：飞机荷载越重、起落架形式越复杂,土基中附加应力的影响范围越大,相应工作区深度越大;刚性道面的厚度越大,工作区深度越小;土基回弹模量越大,工作区深度越大;刚性道面的工作区深度与刚性道面厚度、土基回弹模量之间存在良好的线性关系,并且这种线性关系与工作区深度的定义标准有关。在上述分析的基础上,提出了一种确定刚性道面工作区深度的简易方法,可以规避繁琐的数值模拟。在场道的设计和建设工程中,可以借鉴本文研究成果确定机场场道路基的工作区深度进而选取合适的路基处理深度和处理方法。Abstract: The finite element numerical analysis method is adopted to solve the boundary value problem of additional stress distribution in subsoil of civil airport runway under aircraft load, and the effects of the aircraft load types, slab thickness of rigid pavement and subsoil resilient modulus on service depth are quantitatively analyzed. Heavier aircraft load and more complicated landing gear configuration lead to greater distributional zone and corresponding service depth. The service depth decreases with the increasing slab thickness of rigid pavement, but increases with the increasing subsoil resilient modulus. The relations between the service depth and the slab thickness of rigid pavement and the subsoil resilient modulus are both linear and depend upon the definition standard of the service depth. Based on the analysis, a simple method for determining the service depth of rigid pavement is proposed to avoid the complicated numerical analysis. The findings can be referenced for determining the service depth of airport runway, subsoil treatment depth and treatment method in the design and construction practice.
-
Keywords:
- service depth /
- aircraft load /
- additional stress /
- slab thickness /
- subsoil resilient modulus /
- simple method
-
[1] 冷培义, 翁兴中, 蔡良才. 机场道面设计[M]. 北京: 人民交通出版社, 2007. (LENG Pei-yi, WENG Xing-zhong, CAI Liang-cai. Design of airport runway[M]. Beijing: China Communication Press, 2007. (in Chinese)) [2] 呙润华, 凌建明. 飞机荷载作用下场道地基附加应力特征[J]. 同济大学学报, 2001, 29（3）: 288-293. (GUO Run-hua, LING Jian-ming. Additional stresses of pavement subgrade resulted from aircraft loads[J]. Journal of Tongji University, 2001,29(3): 288-293. (in Chinese)) [3] 程国勇, 杨召焕. 机场刚性道面地基的工作区深度研究[J]. 中国民航大学学报, 2013, 31(2): 51-56.(CHENG Guo-yong, YANG Zhao-huan. Study of service depth of airport rigid pavement subgrade[J]. Journal of Civil Aviation University of China, 2013, 31(2): 51-56. (in Chinese)) [4] 杨召焕, 程国勇. 机场柔性道面地基工作区深度研究[J]. 公路交通科技, 2013, 30(10): 11-17. (YANG Zhao-huan, CHENG Guo-yong. Study on service of airport flexible pavement subgrade[J]. Journal of Highway and Transportation Research and Development, 2013, 30(10): 11-17. (in Chinese)) [5] 张 磊, 高玉峰, 王 军. 飞机荷载作用下温州机场超固结软黏土地基变形研究[J]. 三峡大学学报（自然科学版）, 2013, 35(3): 59-68. (ZHANG Lei, GAO Yu-feng, WANG Jun. Study of deformations of Wenzhou airport over-consolidated soft clay foundation under cyclic aircarft loading[J]. Journal of China Three Gorges University (Natural science), 2013, 35(3): 59-68. (in Chinese)) [6] 郭 通, 邓荣贵. 大型飞机荷载作用下站坪结构对地基土附加应力的影响分析[J]. 路基工程, 2014(1): 95-99. (GUO Tong, DENG Rong-gui. Analysis on influence of apron structure on additional stress in foundation soil under action of large aircraft loads[J]. Subgrade Engineering, 2014(1): 95-99. (in Chinese)) [7] 张献民, 薛华鑫, 董 倩, 等. 飞机跑道荷载响应深度变化规律[J]. 北京航空航天大学学报, 2014, 40(4): 427-432. (ZHANG Xian-min, XUE Hua-xin, DONG Qian, et al. Influencing depth under aircraft loads of runway[J]. Journal of Beijing University of Aeronautics and Astronautics, 2014, 40(4): 427-432. (in Chinese)) [8] MH /T5004 2010民用机场水泥混凝土道面设计规范[S]. (MH /T5004 2010 Specifications for airport cement concrete pavement design[S]. (in Chinese)) [9] 吕耀志, 董 倩, 胡春飞．跑道动荷载与国际平整度指数关系研究[J]. 中外公路, 2013, 33(3): 74-77. (LÜ Yao-zhi, DONG Qian, HU Chun-fei. A study on the change law between dynamic load of pavement and IRI[J]. Journal of China and Foreign Highway, 2013, 33(3): 74-77. (in Chinese)) [10] 庞小滢, 王 睿. 云南某机场联络道扩建工程道面地基工后沉降计算[J]. 地质灾害与环境保护, 2013, 24(3): 99-103. (PANG Xiao-ying, WANG Rui. Calculating the settlement of pavement foundation at an airport in Yunnan[J]. Journal of Geological Hazards and Environmental Preservation, 2013, 24(3): 99-103. (in Chinese)) -
