循环荷载作用下吸力锚基础变形的数值分析方法研究

李书兆, 王建华

李书兆, 王建华. 循环荷载作用下吸力锚基础变形的数值分析方法研究[J]. 岩土工程学报, 2016, 38(12): 2203-2211. DOI: 10.11779/CJGE201612008
引用本文: 李书兆, 王建华. 循环荷载作用下吸力锚基础变形的数值分析方法研究[J]. 岩土工程学报, 2016, 38(12): 2203-2211. DOI: 10.11779/CJGE201612008
shu
LI Shu-zhao, WANG Jian-hua. Numerical method for the deformation of suction anchor under cyclic loading[J]. Chinese Journal of Geotechnical Engineering, 2016, 38(12): 2203-2211. DOI: 10.11779/CJGE201612008
Citation: LI Shu-zhao, WANG Jian-hua. Numerical method for the deformation of suction anchor under cyclic loading[J]. Chinese Journal of Geotechnical Engineering, 2016, 38(12): 2203-2211. DOI: 10.11779/CJGE201612008
shu

循环荷载作用下吸力锚基础变形的数值分析方法研究  English Version

  • 1. 中海油研究总院,北京 100028; 2.中国科学院力学研究所,北京 100190;
    3. 天津大学岩土工程研究所,天津 300072

基金项目: 国家自然科学基金项目（51179120）
详细信息
    作者简介:

    李书兆(1985- ),女,博士,主要从事土动力特性及海洋岩土工程等方面的研究。E-mail: lishzh25@126.com。

Numerical method for the deformation of suction anchor under cyclic loading

  • 1. CNOOC Research Institute, Beijing 100028, China;
    2. Institute of Mechanics, Chinese Academy of Sciences, Beijing, 100190 China;
    3. Geotechnical Engineering Institute of Tianjin University, Tianjin 300072, China

摘要

    摘要
  • 摘要: 张紧式吸力锚是一种重要的深水海洋浮式平台锚固基础。静荷载与循环荷载共同作用下地基土体产生较大变形,严重影响吸力锚基础的稳定性。介绍了一种能够描述饱和软黏土不排水循环应力应变响应的拟动力黏弹塑性本构模型。该模型将等效黏弹性理论和蠕变理论相结合,利用等效黏弹性模型描述土单元循环应力应变关系中的非线性和滞回性,依据蠕变关系描述土单元的循环累积性。基于拟动力黏弹塑性本构模型,提出了一种分析静荷载与循环荷载共同作用下软土中张紧式吸力锚基础变形过程的拟动力黏弹塑性有限元方法。该方法并不详细追踪土单元的循环应力应变响应,而是将循环次数视为时间,通过等效黏弹性分析确定吸力锚基础的循环变形;根据土单元静应力和循环累积应变势,采用初应变法确定吸力锚基础的累积变形。结合循环变形和累积变形,确定吸力锚基础变形随时间的变化关系,即位移时程曲线。最后,将有限元计算结果与1g条件下吸力锚模型试验结果进行比较,结果显示两者基本一致。
    Abstract: The suction anchor with taut mooring system is an important floating platform foundation in deep water. Large deformation of soil occurs under the combination of static and cyclic loadings, which impacts the stability of the suction anchor foundation severely. A pseudo-dynamic visco-elastic plastic constitutive model which describes the undrained cyclic stress-strain response of saturated soft clay is introduced. The model combines the equivalent visco-elastic theory with the creep theory, describing the nonlinearity and hysteresis of the cyclic stress-strain relationship through the equivalent visco-elastic model and the cyclic accumulative characteristic through the creep theory. Based on the pseudo-dynamic visco-elastic plastic constitutive model, a pseudo-dynamic visco-elastic plastic finite element method is developed for the assessment of the deformation process of the suction anchor foundation subjected to the combination of the static and cyclic loadings. The method does not track the cyclic stress-strain response, but treats the number of cycles as the time. The cyclic deformation of anchor foundation is determined by the equivalent visco-elastic calculation. The accumulative deformation is determined using the initial strain method on the basis of the static stress and cyclic accumulative strain potential. The relationship between the deformation and the time of anchor foundation that is the displacement-time history curve can be obtained according to the cyclic and accumulative deformations. The comparison between the calculated results by the finite element method and the anchor model test results under 1g conditions shows that the both are basically in agreement.
    • HTML全文
    • 参考文献(19)
  • [1] AUDIBERT J M E, CLUKEY E C, HUANG J. Suction caisson installation at Horn Mountain: A case history[C]// Proceedings of the 13th International Offshore and Polar Engineering Conference. Honolulu, 2003.
    [2] El-SHERBINY R M. Performance of suction caisson anchors in normally consolidated clay[D]. Austin: University of Texas at Austin, 2005.
    [3] 谢定义. 土动力学[M]. 北京: 高等教育出版社, 2011. (XIE Ding-yi. Soil dynamics[M]. Beijing: Highter Education Press, 2011. (in Chinese))
    [4] KUWANO J, ISHIHARA K. Analysis of permanent deformation of earth dams due to earthquakes[J]. Soils and Foundations, 1988, 28(1): 44-55.
    [5] KUWANO J, ISHIHARA K, HAYA H. Analysis on permanent deformation of embankments caused by earthquakes[J]. Soils and Foundations, 1991, 31(3): 97-110.
    [6] 刘汉龙, 陆兆溱. 土石坝地震永久变形分析[J]. 河海大学学报, 1996, 24(1): 91-96. (LIU Han-long, LU Zhao-zhen. Earthquake-induced permanet deformation of earth-rock dams[J]. Journal of Hohai University, 1996, 24(1): 91-96. (in Chinese))
    [7] SERFF N, SEED H B, MAKDISI F I. Earthquake induced deformations of earth dams[R]. Berkeley: Earthquake Engineering Research Center, University of California, 1976.
    [8] 张克旭, 李明宰. 地震引起的土坝永久变形的分析[C]// 建筑物及地震抗震学术讨论会. 北京, 1986: 392-401. (ZHANG Ke-xu, LI Ming-zai. Analysis of permanent deformation of dam induced earthquake[C]// Architecture and Aseismic Symposium. Beijing, 1986: 392-401. (in Chinese))
    [9] TANIGUCHI F, WHITMAN R V, MARR W A. Prediction of earthquake induced deformation of earth dams[J]. Soils and Foundations, 1983, 23(4): 126-132.
    [10] BOUCKOVALAS G, WHITMAN R V, MARR W A. Permanent displacement of sand with cyclic loading[J]. ASCE, Journal of Geotechnical Engineering, 1984, 110(11): 1606-1623.
    [11] BOUCKOVALAS G, MARR W A, CHRISTIAN J T. Analyzing permanent drift due to cyclic loads[J]. ASCE, Journal of Geotechnical Engineering, 1986, 112(6): 579-593.
    [12] 贺林林, 王元战. 饱和软黏土循环累积变形简化计算方法研究[J]. 水利学报, 2015, 46(1): 183-187. (HE Lin-lin, WANG Yuan-zhan. Research on simplified calculation method of cyclic cumulative deformation of saturated soft clay[J]. Journal of Hydraulic Engineering, 2015, 46(1): 183-187. (in Chinese))
    [13] 胡 存, 刘海笑. 考虑循环荷载下饱和黏土软化的损伤边界面模型研究[J]. 岩土力学, 2012, 33(2): 460-466. (HU Cun, LIU Hai-xiao. Damage-dependent bounding surface model for cyclic degradation of saturated clay[J]. Rock and Soil Mechanics, 2012, 33(2): 460-466. (in Chinese))
    [14] 胡 存. 适用于饱和黏土循环动力分析的边界面塑性模型及应用[D]. 天津: 天津大学, 2012. (HU Cun. Anisotropic bounding-surface plasticity model for cyclic behaviors of saturated clay and its application[D]. Tianjin: Tianjin University, 2012. (in Chinese))
    [15] 李 涛. 循环荷载作用下饱和黏性土的弹塑性双面模型[J]. 土木工程学报, 2006, 39(1): 92-97. (LI Tao. Elasto-plastic two surface model for clays under undrained cyclic loading[J]. China Civil Engineering Journal, 2006, 39(1): 92-97. (in Chinese))
    [16] 刘晶磊. 循环荷载作用下软黏土中张紧式吸力锚承载力研究[D]. 天津: 天津大学, 2011. (LIU Jing-lei. Study on bearing capacity of suction anchors with taut mooring systems in soft clay under cyclic loading[D]. Tianjin: Tianjin University, 2011. (in Chinese))
    [17] 穆霞英. 蠕变力学[M]. 西安: 西安交通大学出版社, 1990. (MU Xia-ying. Creep mechanics[M]. Xi'an: Xi'an Jiaotong University Press, 1990. (in Chinese))
    [18] 谢贻权, 何福保. 弹性和塑性力学中的有限单元法[M]. 北京: 机械工业出版社, 1983. (XIE Yi-quan, HE Fu-bao. Finite element method in elastic and plastic mechanics[M]. Beijing: Mechnice Industry Press, 1983. (in Chinese))
    [19] 王建华, 李书兆. 描述软土不排水循环应力应变响应的拟动力关系[J]. 地震工程学报, 2014, 36(3): 421-428. (WANG Jian-hua, LI Shu-zhao. A pseudo-dynamic relationship for describing the cyclic stress-strain response of soft clays in undrained conditions[J]. China Earthquake Engineering Journal, 2014, 36(3): 421-428. (in Chinese))
