饱和南京细砂初始液化后特大流动变形特性试验研究

庄海洋; 胡中华; 王瑞; 陈国兴

doi:10.11779/CJGE201612004

饱和南京细砂初始液化后特大流动变形特性试验研究 English Version

南京工业大学岩土工程研究所,江苏南京 210009

基金项目: 国家自然科学基金面上项目（51278246）; 江苏省自然科学基金面上项目（BK20141458）

详细信息

作者简介:
庄海洋(1978- ),男,博士后,教授,主要从事岩土地震工程等方面的教学和科研。E-mail: zhuang7802@163.com。

计量
- 文章访问数: 375
- HTML全文浏览量: 2
- PDF下载量: 323
出版历程
- 收稿日期: 2015-10-18
- 发布日期: 2016-12-24

Cyclic torsional shear loading tests on the extremely large post-liquefaction flow deformation of saturated Nanjing sand

Institute of Geotechnical Engineering, Nanjing Tech University, Nanjing 210009, China

摘要

摘要: 针对地震中倾斜场地砂土液化流动大变形特征与机理,以具有明显片状颗粒结构特征的南京细砂为研究对象,采用了英国GDS公司的动态空心圆柱扭剪仪,开展了饱和南京细砂液化后特大流动变形特性的循环扭剪试验研究,主要分析了橡皮膜效应、有效围压、循环加载幅值和初始静剪应力等因素对南京细砂液化流动大变形特性的影响规律及其机理。试验结果表明：在其它条件不变时,随着有效围压增加,饱和南京细砂抗液化强度和抗单向液化流动累积变形强度都有所增加。当保持围压不变时,饱和南京细砂抗单向液化流动累积变形的强度有增加的趋势。随着初始静剪应力比的变大,南京细砂的抗液化和抗单向累积变形强度特征可以分为三个不同阶段。在无初始静剪应力条件下饱和南京细砂液化后仍以循环液化流动变形为主和单向流动累积变形为辅。但是,随着初始静剪应力比的增大,饱和南京细砂抗液化强度和抗单向液化流动累积变形强度明显降低,即主要发生单向液化流动累积变形破坏。当初始静剪应力比接近或超过循环动剪应力比时,饱和南京细砂的抗液化和抗单向流动累积变形的强度又明显增大,但仍以液化单向流动累积破坏为主。当初始静剪应力比继续增大到一定程度时,饱和南京细砂已经很难液化,其抵抗单向累积变形的强度也明显降低,主要原因应为此时试样发生的是塑性累积大变形破坏。同时,试验结果表明饱和南京细砂的液化后流动大变形特性也明显区别于含圆形颗粒为主的日本丰浦砂。
- 饱和南京细砂 /
- 液化流动大变形 /
- 初始静剪应力比 /
- 循环扭剪试验
Abstract: To investigate the post-liquefaction flow deformation of saturated Nanjing sand mostly composed of flaky grains, the hollow column torsional shear apparatus is used to simulate the loading states of the soils in the site with large liquefaction-induced lateral deformation. The results show that the resistance of Nanjing sand against the liquefaction and the post-liquefaction accumulation deformation increase with the effective confining pressure, and they also have increasing tendency under the same effective confining pressure. Without the initial shear forces, the post-liquefaction deformation of saturated Nanjing sand is mainly the cyclic liquefaction-induced deformation, and single direction accumulated flow deformation is also found, which also increases with the cyclic loading. The effect of the initial shear forces should be divided into three stages. In the first stage, the resistance of Nanjing sand against the liquefaction and the post-liquefaction accumulation deformation decrease severely with the increasing initial shear forces, and the soil samples are mainly damaged by the large liquefaction-induced flow deformation. However, when the initial shear forces are close to the cyclic shear forces, the resistance of Nanjing sand against the liquefaction and the post-liquefaction accumulation deformation increase quickly with the increasing initial shear forces, and the soil samples are mainly damaged by the large liquefaction-induced flow deformation in this stage. When the initial shear force is large enough, the saturated Nanjing sand is not liquefied until the single direction accumulated deformation reaches 30%, which proves that the large deformation of the saturated Nanjing sand is mainly caused by the large plastic deformation. Meanwhile, the large post-liquefaction deformation of saturated Nanjing sand is also different from that of the Toyoura sand mainly composed of round grains.
- saturated Nanjing sand /
- liquefaction-induced flow deformation /
- initial shear stress ratio /
- cyclic torsional shear test

HTML全文

参考文献(20)

[1]	HAMADA M. Large ground deformations and their effects on lifelines: 1964 Niigata Earthquake. Case studies of liquefaction and lifelines performance during past earthquake[R]. New York: National Centre for Earthquake Engineering Research, 1992.
[2]	SEED H B, LEE K L. Liquefaction of saturated sands during cyclic loading[J]. J Soil Mech Found Eng Div ASCE 92, 1966(SM6): 105-134.
[3]	VAID Y P, THOMAS J. Liquefaction and post liquefaction behavior of sand[J]. J Geotech Eng ASCE, 1995, 121(2): 163-173.
[4]	HYODO M, TANIMIZU H, YASUFUKU N, et al. Undrained cyclic and monotonic triaxial behaviour of saturated loose sand[J]. Soils and Foundations, 1994, 34(1): 19-32.
[5]	周燕国, 梁田, 李永刚, 等. 含黏粒砂土场地液化离心机振动台试验研究[J]. 岩土工程学报, 2013, 35(9): 1650-1658. (ZHOU Yan-guo, LIANG Tian, LI Yong-gang, et al. Site liquefaction of sand containing clay by centrifuge shaking table tests[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(9): 1650-1658. (in Chinese))
[6]	周健, 陈小亮, 杨永香, 等. 饱和层状砂土液化特性的动三轴试验研究[J]. 岩土力学, 2011, 32(4): 967-973. (ZHOU Jian, CHEN Xiao-liang, YANG Yong-xiang, et al. The characteristics of liquefaction of Saturated layered soil by dynamic triaxial tests[J]. Rock and Soil Mechanics, 2011, 32(4): 967-973. (in Chinese))
[7]	RAHMAN M M, LO S C R. Effect of sand gradation and fines type on liquefaction behavior of sand-fines mixture[J]. Geotechnical Special Publication, 2011(318): 1-11.
[8]	SZE H Y, YANG J. Failure modes of dand in undrained cyclic loading: impact of sample peparation[J]. J Geotech Geoenviron, Eng, 2014, 140: 152-169.
[9]	张建民, 王刚. 砂土液化后大变形的机理[J]. 岩土工程学报, 2006, 28(7): 835-840. (ZHANG Jian-min, WANG Gang. The mechanism of large deformation after sand liquefaction[J]. Chinese Journal of Geotechnical Engineering, 2006, 28(7): 835-840. (in Chinese))
[10]	张建民. 砂土动力学若干基本理论探究[J]. 岩土工程学报, 2012, 34(1): 1-50. (ZHANG Jian-min. Several research of basic theory of sandy soil dynamics[J]. Chinese Journal of Geotechnical Engineering, 2012, 34(1): 1-50. (in Chinese))
[11]	陈育民, 刘汉龙, 邵国建, 等. 液化及液化后砂土的流动特性分析[J]. 岩土工程学报, 2009, 31(9): 1408-1413. (CHEN Yu-min, LIU Han-long, SHAO Guo-jian, et al. Liquefaction and post-liquefaction flow behavior of sand [J]. Chinese Journal of Geotechnical Engineering, 2009, 31(9): 1408-1413. (in Chinese))
[12]	刘汉龙, 周云东, 高玉峰. 砂土地震液化后大变形特性试验研究[J]. 岩土工程学报, 2009, 24(2): 142-146. (LIU Han-long, ZHOU Yun-dong, GAO Yu-feng. The study of extremely large post-liquefaction flow deformations of saturated sand[J]. Chinese Journal of Geotechnical Engineering, 2009, 24(2): 142-146. (in Chinese))
[13]	徐小敏. 砂土液化及其判别的微观机理研究[D]. 杭州: 浙江大学, 2012. (XU Xiao-min. The study of microscopic mechanism of saturated sand liquefaction evaluation[D]. Hangzhou: Zhejiang University, 2012. (in Chinese))
[14]	SHAMY UE, DENISSEN C. Microscale characterization of energy dissipation mechanisms in liquefiable granular soils[J]. Computers and Geotechnics, 2010, 37(7): 846-857.
[15]	CHIARO G, KIYOTA T, DE SILVA L, et al. Extremely large post-liquefaction deformations of saturated sand under cyclic torsional shear loading[C]// Earthquake Geotechnical Engineering Satellite Conference VXⅡth International Conference on Soil Mechanics and Geotechnical Engineering. Alexandria, 2009.
[16]	CHIARO G, KIYOTA T, KOSEKI J. Strain localization characteristics of loose saturated Toyoura sand in undrained cyclic torsional shear tests with initial static shear[J]. Soils and Foundations, 2012, 52(3): 498-510.
[17]	KIYOTA T, JUNICHI K, TAKESHI S. Relationship between limiting shear strain and reduction of shear moduli due to liquefaction in large strain torsional shear tests[J]. Soil Dynamics and Earthquake Engineering, 2013, 49: 122-134.
[18]	陈文化, 孙谋, 刘明丽, 等. 南京细砂的结构特性与地铁地基液化判别[D]. 岩土力学, 2003, 24(5): 755-758. (CHEN Wen-hua, SUN Mou, LIU Ming-li, et al. Study of Nanjing sand structural characteristics and the subway foundation liquefaction estimation[D]. Rock and Soil Mechanics, 2003, 24(5): 755-758. (in Chinese))
[19]	吴焕然. 南京细砂颗粒形状及静态液化特性研究[D]. 南京: 南京大学, 2014. (WU Hun-ran. Study of Nanjing sand particle shape and static liquefaction characteristics[D]. Nanjing: Nanjing University, 2014. (in Chinese))
[20]	朱建群, 孔令伟, 钟方杰. 南京细砂强度特征与静态液化现象分析[J]. 岩土力学, 2008, 29(6): 1461-1466. (ZHU Jian-qun, KONG Ling-wei, ZHONG Fang-jie. Analysis of Nanjing sand strength characteristics and the static liquefaction phenomenon[J]. Rock and Soil Mechanics, 2008, 29(6): 1461-1466. (in Chinese))
