管片径向拼装偏差对盾构隧道管片环防水性能的影响分析

曾格华; 夏才初

doi:10.11779/CJGE201611011

管片径向拼装偏差对盾构隧道管片环防水性能的影响分析 English Version

曾格华¹,
夏才初^1,2, ,

1. 同济大学土木工程学院地下建筑与工程系,上海 200092;
2. 同济大学岩土及地下工程教育部重点实验室,上海 200092

基金项目: 国家重点基础研究发展计划（“973”计划）项目

详细信息

作者简介:
曾格华(1986-),男,博士研究生,主要从事隧道及地下建筑工程方面的研究工作。E-mail: zenggehua@126.com。

通讯作者:
夏才初，E-mail：tjxiaccb@126.com

计量
- 文章访问数: 364
- HTML全文浏览量: 5
- PDF下载量: 459
出版历程
- 收稿日期: 2016-02-20
- 发布日期: 2016-11-19

Effect of radial erection error of segments on waterproofness of segment rings of shield tunnels

ZENG Ge-hua¹,
XIA Cai-chu^1,2, ,

1. Department of Geotechnical Engineering,School of Civil Engineering, Tongji University, Shanghai 200092, China;
2. Key Laboratory of Geotechnical and Underground Engineering of Ministry of Education, Tongji University, Shanghai 200092, China

摘要

摘要: 以上海地铁13号线区间盾构隧道管片环为工程实例,比选确定了管片径向拼装偏差各情况的防水最不利管片环初始结构,对外荷载作用下以上各防水最不利管片环防水失效时的收敛变形值计算后,以该值变化量对管片环防水性能下降程度进行了量化。认为：管片径向拼装偏差导致接头错台及腰部接头外侧张开的同时发生,后者对管片环防水性能影响更甚;1个接头发生错动情况的防水最不利管片环结构收敛变形特征值为1.53‰D,小于无拼装偏差情况特征值的1/2,环内错动接头数量越多,该特征量越小;当拼装偏差接头个数大于3时,其防水最不利管片环出盾尾前已防水失效。根据以上研究结论,提出了一些对管片环拼装质量控制及其运营期防水可靠性监测具有参考意义的建议。
- 盾构隧道 /
- 径向拼装偏差 /
- 弹性橡胶密封垫 /
- 管片环 /
- 防水性能 /
- 收敛变形
Abstract: Taking the segment rings of shield tunnel of Shanghai Metro Line 13 as a study case, the initial structure of segment rings with the worst waterproofness under various error cases is determined. The decrease of waterproofness is quantified through change of convergence of segment ring as its waterproofness fails. The results indicate that the radial erection error of segments causes the joint dislocation and external opening of waist joints simultaneously, and the latter is worse to the initial waterproofness than the former. As the waterproofness fails, the convergence of segment rings with the worst waterproofness in one joint error case is 1.53‰D, it is less than a half of that in the no error case, and the convergence further decreases as the number of erroneous joints increases. If there are more than three erroneous joints, the waterproofness of segment rings with the worst waterproofness will fail before they come out of shield rear. According to the above conclusions, some recommend actions are proposed for the quality control of segment erection during construction phase and the waterproof monitoring of segment rings during service phase.
- shield tunnel /
- radial erection error /
- elastic rubber gasket /
- segment ring /
- waterproofness /
- convergence

HTML全文

参考文献(17)

[1]	GB50446—2008 盾构法隧道施工与验收规范[S]. 2008. (GB50446—2008 Code for construction and acceptance of shield tunneling method[S]. 2008. (in Chinese))
[2]	顾丽江. 考虑拼装误差影响下的软土盾构隧道变形控制标准研究[D]. 上海: 同济大学, 2011. (GU Li-jiang. Influence of installation errors on performance-based evaluation index of shield tunnel in soft clays[D]. Shanghai: Tongji University, 2011. (in Chinese))
[3]	彭益成. 盾构隧道管片结构非线性性态及流固耦合模型研究[D]. 上海: 同济大学, 2007. (PENG Yi-cheng. Study on non-linear properties and fluid-structure interaction model for segment structure of shield tunnel[D]. Shanghai: Tongji University, 2011. (in Chinese))
[4]	赵运臣, 肖龙鸽, 刘招伟, 等. 武汉长江隧道管片接缝防水密封垫设计与试验研究[J]. 现代隧道技术, 2008(增刊1): 144-149. (ZHAO Yun-chen, XIAO Long-ge, LIU Zhao-wei, et al. Experiment study and design on the watertight seal for reinforced concrete segment joint of Wuhan Yangtze River Tunnel[J]. Modern Tunnelling Technology, 2008(S1): 144-149. (in Chinese))
[5]	樊庆功. 隧道接缝弹性橡胶密封垫防水性能试验及有限元分析[D]. 上海: 同济大学, 2002. (FAN Qing-gong. Tunnel joints rubber gasket waterproof performance tests and finite element analysis[D]. Shanghai: Tongji University, 2002. (in Chinese))
[6]	ABAQUS Inc. Abaqus example problems manual, version 6.10[M]. Paris: Dassault Systemes Corp, 2010.
[7]	GENT A N. Engineering with rubber: how to design rubber components[M]. Munich: Hanser Publisher, 2012.
[8]	左亮, 肖绯雄. 橡胶Mooney-Rivlin模型材料系数的一种确定方法[J]. 机械制造, 2008, 46(7): 38-40. (ZUO Liang, XIAO Fei-xiong. A method for determining the Mooney-Rivlin constitutive model parameters of rubber[J]. Machinery, 2008, 46(7): 38-40. (in Chinese))
[9]	BATTERMANN W, KÖHLER R. Elastomere federung, elastische Lagerungen: Grundlagen ingenieurmäßiger Berechnung und Konstruktion[M]. Berlin: W Ernst, 1982. (BATTERMANN W, KÖHLER R. Elastomeric suspension, elastic bearing: Basics engineering calculation and construction[M]. Berlin: W Ernst, 1982. (in German))
[10]	夏才初, 曾格华, 卞跃威. 盾构隧道管片环纵向接头抗弯刚度值的不动点迭代确定方法[J]. 岩石力学与工程学报, 2014, 33(5): 901-912. (XIA Cai-chu, ZENG Ge-hua, BIAN Yue-wei. Method for determining bending stiffness of shield tunnel segment rings longitudinal joint based on Fiex-point iteration[J]. Chinese Journal of Rock Mechanics, 2014, 33(5): 901-912. (in Chinese))
[11]	赵玉花, 沈日庚, 李青. 软黏土侧压力系数 K 0 阶段性特征研究[J]. 岩土力学, 2008, 29(5): 1264-1268. (ZHAO Yu-hua, SHEN Ri-geng, LI Qing. Research on staged characteristics of lateral pressure coefficient K 0 of soft clay[J]. Rock and Soil Mechanics, 2008, 29(5): 1264-126. (in Chinese))
[12]	LI X J, YAN Z G, WANG Z, et al. Experimental and analytical study on longitudinal joint opening of concrete segmental lining[J]. Tunnelling and Underground Space Technology, 2015: 46:52-63.
[13]	DING W Q, PENG Y C, YAN Z G, et al. Full-scale testing and modeling of the mechanical behavior of shield TBM tunnel joints[J]. Structural Engineering and Mechanics, 2013, 45(3): 333-350.
[14]	张厚美, 过迟, 付德明. 圆形隧道装配式衬砌接头刚度模型研究[J]. 岩土工程学报, 2000, 22(3): 309-313. (ZHANG Hou-mei, Guo Chi, FU De-ming. A study on the stiffness model of circular tunnel prefabricated lining[J]. Chinese Journal of Geotechnical Engineering, 2000, 22(3): 309-313. (in Chinese))
[15]	ITA. Guidelines for the design of shield tunnel lining (ITAWG 2 report)[J]. Tunnelling and Underground Space Technology, 2000, 15(3): 303-331.
[16]	GB50010—2010混凝土结构设计规范[S]. 2010. (GB50010—2010 Code for design of concrete structures[S]. 2010. (in Chinese))
[17]	朱祖熹. 上海地铁1号线盾构隧道衬砌防水技术述评[J].地下工程与隧道, 1993, 4: 54-60. (ZHU Zu-xi. Ling waterproof technology review of the of Shanghai Metro Line1 shield tunnel[J]. Underground Engineering and Tunnels, 1993, 4: 54-60. (in Chinese))
