基于WLSM的多参数裂隙岩体统计均质区划分

阮云凯; 陈剑平; 李严严; 朱雷; 曹琛; 占洁伟

doi:10.11779/CJGE201607015

基于WLSM的多参数裂隙岩体统计均质区划分 English Version

1. 吉林大学建设工程学院,吉林长春 130026；
2. 中国科学院地质与地球物理研究所 ,北京 100029；
3. 地质灾害防治与地质环境保护国家重点实验室（成都理工大学）,四川成都,610059

基金项目: 国家自然科学基金重点项目（41330636）

详细信息

作者简介:
阮云凯(1989- ),男,福建建阳人,博士研究生,主要从事岩体结构及其工程地质稳定性方面的研究。E-mail: ruanyunkai@163.com。

计量
- 文章访问数: 294
- HTML全文浏览量: 4
- PDF下载量: 233
出版历程
- 收稿日期: 2015-07-27
- 发布日期: 2016-07-24

Evaluation of statistical homogeneity of jointed rock masses based on weighted least-square method

1. College of Construction Engineering, Jilin University, Changchun 130026, China;
2. Institute of Geology and Geophysics, Chinese Academy of Sciences, Beijing 100029, China;
3. State Key Laboratory of Geological Hazards Prevention and Geological Environment Protection, Chengdu University of Technology, Chengdu 610059, China

摘要

摘要: 岩体统计均质区的划分一直是岩土工程领域研究的重要课题。大多学者采用产状或者其它单一参数划分岩体统计均质区,却很少有人考虑多参数进行划分研究。考虑了产状、间距、张开、迹长和粗糙度共5个参数,提出了一种划分裂隙岩体统计均质区的新方法,即采用权的最小平方法确定参数的权重并用相关系数法计算研究区裂隙各个参数之间的相关性,从而确定均质系数以此实现对裂隙岩体统计均质区的划分。通过工程实例即云南省马吉水电站左岸坝肩某一高程相邻4个平硐的岩体结构统计均质区划分,分析了多参数对裂隙岩体统计均质区划分的影响。研究结果表明：裂隙岩体统计均质区划分与裂隙产状、间距、张开、迹长和粗糙度等因素有关并成功划分了研究区的统计均质区,证明了该方法的可行性。
- 统计均质区 /
- 多参数 /
- 权的最小平方法 /
- 相关系数法 /
- 均质系数（HI）
Abstract: The identification of structural homogeneity has been an important topic in the field of geotechnical engineering. Most of scholars use joint orientations or the other joint parameters to identify statistically homogeneous regions or structural domains in a jointed rock mass. However, few studies have been conducted by integrating both of them. Five parameters are considered for this identification, namely: joint orientation, spacing, aperture, trace length and roughness. Based on the weighted least-square method, the weights of the parameters are obtained. A statistical parameter, known as the correlation coefficient, is used to quantify the degree of the similarity between the joint parameters collected from the studied regions. The overall homogeneity of the rock mass is determined based on the homogeneity index. A practical engineering case is analyzed, illustrating the effect of the multiple parameters collected from four adjacent adits at Maji dam site on the left bank of the Nujiang River in Yunnan Province on identification of statistical homogeneity in fractured rock mass. The results indicate that the identification of statistical homogeneity is influenced by many factors such as the joint orientations, spacing, aperture, trace length and roughness. The statistical homogeneous domains in the studied regions are successfully divided, indicating the feasibility of the proposed method.
- statistical homogeneity /
- multiple joint parameters /
- weighted least-square method /
- correlation coefficient /
- homogeneity index

HTML全文

参考文献(15)

[1]	陈剑平, 肖树芳, 王清. 随机不连续面三维网络计算机模拟原理[M]. 长春: 东北师范大学出版社, 1995. (CHEN Jian-ping, XIAO Shu-fang, WANG Qing. Computer simulation principle of 3D network numerical modeling tenique[M]. Changchun: Northeast Normal University, 1995. (in Chinese))
[2]	MILLER R S M. A Statistical method to evaluate homogeneity of structural populations[J]. Journal of Mathematical Geology, 1983, 15(2): 317-328.
[3]	KULATILAKE P H S W, FIEDLER R, PANDA B B. Box fractal dimension as a measure of statistical homogeneity of jointed rock masses[J]. Engineering Geology, 1997, 48(3): 217-229.
[4]	陈剑平, 王清, 肖树芳, 等. 岩体结构统计均质区的划分 [J]. 地质灾害与环境保护, 1996, 7(1): 19-24. (CHEN Jian-ping, WANG Qing, XIAO Shu-fang, et al. Evaluation of statistical homogeneity of rock mass structural[J]. Journal of Geological Hazards and Environment Preservation, 1996, 7(1): 19-24. (in Chinese))
[5]	范留明, 黄润秋, 丁秀美. 一种基于结构面密度的岩体结构均质区划分方法[J]. 岩石力学与工程学报, 2003, 22(7): 1132-136. (FAN Liu-ming, HUANG Run-qiu, DING Xiu-mei. Analysis on structural homogeneity of rock mass based on discontinuity density[J]. Chinese Journal of Rock Mechanics and Engineering, 2003, 22(7): 1132-1136. (in Chinese))
[6]	MARTIN M W, TANNANT D D. A technique for identifying structural domain boundaries at the EKATI Diamond Mine[J]. Engineering Geology, 2004, 74(3/4): 247-264.
[7]	张文, 陈剑平, 刘存合. 卡方检验在裂隙岩体统计均质区划分中的应用研究[J]. 岩土工程学报, 2011, 33(9): 1440-1446. (ZHANG Wen, CHEN Jian-ping, LIU Cun-he. Application of chi-square test in structural homogeneity dividing of fractured rock mass[J]. Chinese Journal of Geotechnical Engineering, 2011, 33(9): 1440-1446. (in Chinese))
[8]	LI Y Y, WANG Q, CHEN J P, et al. Identification of structural domain boundaries at the Songta dam site based on nonparametric tests[J]. Rock Mechanics and Mining Sciences, 2014, 70: 177-184.
[9]	HUDSON J A, PRIEST S D. Discontinuity and rock mass geometry[J]. Rock Mechanics and Mining Sciences, 1979, 16: 339-362.
[10]	HUDSON J A, HARRISON J P. Engineering rock mechanics: an introduction to the principles[J]. Journal of Applied Mechanics Reviews, 2002, 55(2): B30.
[11]	ZHANG L, EINSTEIN H H. Estimating the mean trace length of rock discontinuities[J]. Rock Mechanics and Rock Engineering, 1998, 31(4): 217-235.
[12]	COHEN J. Statistical power analysis for the behavioral sciences[M]. 2nd ed. New Jersey: Lawrence Erlbaum, 1988.
[13]	CHU A T W, KALAB R E, SPINGARN K. A comparison of two methods for determining the weights of belonging to fuzzy sets[J]. Journal of Optimization Theory and Applications, 1979, 27(4): 531-538.
[14]	王志仁. 层次分析法中权的最小平方法[J]. 东北电力学院学报, 1995, 15(2): 53-57. (WANG Zhi-ren. Least-square priority method of analytic hierarchy process[J]. Chinese Journal of Northeast China Institute of Electric Power Engineering, 1995, 15(2): 53-57. (in Chinese))
[15]	BIENIAWSKI Z T. Engineering rock mass classifications[M]. New York: Wiley, 1989.
