粉质黏土深基坑土钉墙支护作用机理模型试验研究

单仁亮; 郑赟; 魏龙飞

doi:10.11779/CJGE201607002

粉质黏土深基坑土钉墙支护作用机理模型试验研究 English Version

中国矿业大学（北京）力学与建筑工程学院,北京 100083

基金项目: 教育部高等学校博士学科点专项科研基金项目（20120023110009）

详细信息

作者简介:
单仁亮(1964- ),男,博士,教授,博士生导师,主要从事岩土工程方面的教学与研究工作。E-mail: srl@cumtb.edu.cn。

计量
- 文章访问数: 504
- HTML全文浏览量: 3
- PDF下载量: 503
出版历程
- 收稿日期: 2015-07-11
- 发布日期: 2016-07-24

Model tests on supporting mechanism of soil nailing wall in silty clay deep foundation

School of Mechanics and Civil Engineering, China University of Mining & Technology, Beijing 100083, China

摘要

摘要: 以相似理论为基础,确定模型试验的相似比,然后按照相似比的要求选定相似材料,建立试验所需的土钉墙物理模型。设计合理的测试系统、加载系统模拟基坑开挖、土钉墙支护及降雨过程。测试整个试验过程中的土钉墙的墙顶水平位移、土钉内力、土压力等。试验结果表明,基坑开挖引起土体应力重新分布是影响土钉墙墙顶水平位移变化的主要因素,且每步开挖均都会引起墙顶水平位移呈台阶式增大,在土钉墙的施工阶段墙顶最终水平位移达基坑开挖深度的2.3‰;在墙顶的均布荷载不是很大的情况下,墙顶水平位移会随荷载的增大近似呈线性增大,且降雨是引起粉质黏土基坑位移的重要因素;基坑开挖过程中,墙侧土压力呈现先增大后减小再逐渐增加的变化规律;随基坑开挖深度增加,土钉受力逐渐由尾部向内部发展。
- 深基坑 /
- 土钉墙 /
- 模型试验
Abstract: Based on the similarity theory, the similitude ratio of model tests is confirmed, the similar materials are selected according to the similitude ratio, and the physical model for soil nailing wall is established. The reasonable test system, loading system and precipitation testing procedure are designed. The horizontal displacement of soil nailing wall top, axial force of soil nails and earth pressure are tested and analyzed. The results show that the primary factor that affects the displacement of soil nailing wall is the soil stress redistribution caused by pit excavation, and every excavation makes the horizontal displacement of the wall top present stepped increases. The horizontal displacement reaches 2.3‰ of excavation depth at the excavation and supporting stage. The rainfall is an important factor of the horizontal displacement. If the loading on the top of the wall is not very large, the horizontal displacement of the wall top increases with the growth of excavation depth. With the pit excavation the lateral earth pressure of soil nailing wall first increases and then decreases but its overall trend is to increase. During the pit excavation, the forces on soil nails develop from the end to the inside.
- deep foundation /
- soil nailing wall /
- model test

HTML全文

参考文献(13)

[1]	陈肇元, 崔京浩. 土钉支护在基坑工程中的应用[M]. 2版. 北京: 中国建筑工业出版社, 2000: 19. (CHEN Zhao-yuan, CUI Jing-hao. The application of soil nailing supporting in the foundation pit[M]. 2nd ed. Beijing: China Architecture and Building Press, 2000: 19. (in Chinese))
[2]	龚晓南. 土钉和复合土钉支护的若干问题[J]. 土木工程学报, 2003, 36(10): 80-83. (GONG Xiao-nan. Some problems on soil nailing and composite soil nailing[J]. China Civil Engineering Journal, 2003, 36(10): 80-83. (in Chinese))
[3]	叶书麟, 陈仲颐. 基础工程[M]. 北京: 中国建筑工业出版社, 1991: 16. (YE Shu-lin, CHEN Zhong-yi. The foundation engineering[M]. Beijing: China Architecture and Building Press, 1991: 16. (in Chinese))
[4]	张明聚. 土钉支护工作性能的研究[D]. 北京: 清华大学, 2000. (ZHANG Ming-ju. Research on behavior of soil Nailing[D]. Beijing: Tsinghua University, 2000. (in Chinese))
[5]	程良奎, 杨志银. 喷射混凝土与土钉墙[M]. 北京: 中国建筑工业出版社, 1998: 13. (CHENG Liang-kui, YANG Zhi-yin. The shotcrete and soil nailing wall[M]. Beijing: China Architecture and Building Press, 1998: 13. (in Chinese))
[6]	FARID E, MASOOD V, MOHAMMAD S, et al. Displacement measurement of soil nail walls using close range photogrammetry[J]. Procedia Engineering, 2013, 54(1): 516-524.
[7]	SANG C B, YOUN I C. The effect of the nail skew angle of soil nailing wall[J]. KSCE Journal of Civil Engineering, 1999, 3(1): 73-39.
[8]	VIKAS P S, BABU G L S. 2D numerical simulations of soil nail walls[J]. Geotechnical and Geological Engineering, 2010, 28(4): 299-309.
[9]	汪班桥, 门玉明, 陈文玲. 土钉墙模型试验研究[J]. 西安工程学院学报, 2004, 24(3): 15-17. (WANG Ban-qiao, MEN Yu-ming, CHEN Wen-ling. Studies of model test on soil-nailing wall[J]. Journal of Xi'an Engineering University,2002, 24(3): 15-17. (in Chinese))
[10]	孙铁成, 张明聚, 杨茜. 深基坑复合土钉支护模型试验研究[J]. 岩石力学与工程学报, 2004, 23(15): 2585-2592. (SUN Tie-cheng, ZHANG Ming-ju, YANG Qian. Modeling study on composite soil nailing for deep excavation[J]. Chinese Journal of Rock Mechanics and Engineering, 2004, 23(15): 2585-2592. ( in Chinese))
[11]	张建红, 张雁, 濮家骝, 等. 土钉支护的离心模型试验研究[J]. 土木工程学报, 2009, 42(1): 76-80. (ZHANG Jian-hong, ZHANG Yan, PU Jia-liu. et al. Centrifuge modeling of soil nail reinforcements[J]. China Civil Engineering Journal, 2009, 42(1): 76-80. ( in Chinese))
[12]	袁文忠. 相似理论与静力学模型试验[M]. 成都:西南交通大学出版社, 1998. (YUAN Wen-zhong. The similarity theory and the statics model test[M]. Chengdu: Southwest Jiaotong University Press, 1998. (in Chinese))
[13]	徐挺. 相似理论与模型试验[M]. 北京：中国农业机械出版社, 1982. (XU Ting. The similarity theory and the model test[M]. Beijing: China Agricultural Mechanical Press, 1982. (in Chinese))
